AK8TA-15ATablet

FCC ID: AK8TA-15A USER’SMANUALDraft Since Tablet TA-15A is to be assembled in monitors for personal computers, the following statement or equivalent will be printed in User’s Manual of the personal computers. This device complies with Part 15 of the FCC Rules and RSS-210 of the IC standards. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: As for CANADA, the above statement will be mentioned in French, too. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Sony Electronics Inc. One Sony Drive, Park Ridge, New Jersey 07656-8003 Telephone (201) 930-1000 Ms. Diane Poole Equipment Authorization Branch Laboratory Division Office of Engineering & Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Application No. EA99330 AK8TA-15A Dear Ms. Poole, Pursuant to the procedures set forth in FCC Public Notice DA-1407 (the “Public Notice”), Sony Electronics Inc. on behalf of Sony Corporation, hereby requests Limited Modular Approval (“LMA”) for the modular transmitter contained in the device for which the above-referenced application was filed. Sony Corporation wishes to import and market approximately 6000 of these devices, which it has manufactured and labeled. In addition, Sony Corporation wishes to obtain LMA for the modular transmitter contained in the device so it can incorporate it into future devices. Sony Corporation will not sell this transmitter to any other entity and will retain final control over the final installation of the device in order to ensure compliance of the end product with all applicable rules and regulations of the Commission. This letter addresses seriatim the eight requirements set forth in the Public Notice 1. The modular transmitter does not have its own RF shielding. It will rely on the shielding of the device into which it is installed, and Sony Electronics hereby commits to ensure that all devices into which this module is installed comply with all applicable transmission emissions limits. 2. The modular transmitter does not have buffered modulation/data inputs. It has a data input, but the data rate is constant and not modulated and the device complies with applicable FCC requirements under conditions of excessive data rates.3. The modular transmitter operates on DC12V. It contains a DC-DC converter that supplies regulated voltage to the transmitter unit. 4. The antenna and transmitter unit do not contain specialized couplers not obtainable by ordinary consumers. It also should be noted that the antenna coupler is not accessible to the end user. Sony Electronics will ensure that only this antenna is supplied with this module. This should ensure that the purpose of requirement 4 of the Public Notice is met. 5. The Part 15 test was conducted with the modular transmitter in a stand-alone configuration and without any ferrite cores on DC cable. A 1.5 meter DC cable was used for EMC measurement, and we believe that such length represents typical usage. 6. The modular transmitter will be labeled with its FCC ID number. The LCD Monitor will display a label stating: " Contains FCC ID: AK8TA-15A" on the cabinet. Sony Electronics makes the FCC ID label for both the module and monitor. 7. The transmitter module complies with the requirement of Subpart B of Part 15 of the Commission’s rules. The test report for model TA-15A prepared by JQA and filed with the application will confirm the device’s compliance with Part 15. 8. As the JQA test report shows, the level of radiated emission from the device which is the subject of the instant application is 61.4 dB uV/m at 3 M (3 meter measurement). The transmitter is not designed to transmit beyond a very short distance. It is designed to transmit from a pen tablet to an LCD monitor with the distance the pen tablet and the monitor being generally no more than 1 cm. Sony Corporation will ensure that the devices into which the modular transmitter is installed will comply with the applicable RF exposure limits contained in Parts 2 and 15 of the Commission’s rules. Sony Corporation very much appreciates the help you have provided it with respect to this application and requests your expedited consideration of this request. If you have any questions, please contact the undersigned or Steve Kaminer of the Alliance Law Group, our attorneys. He can be reached at (703) 848-8351. Respectfully yours; Julio Posse Manager Product Safety & Compliance Sony Electronics Inc.

Sony Electronics Inc. One Sony Drive, Park Ridge, New Jersey 07656-8003 Telephone (201) 930-1000 Ms. Diane Poole Equipment Authorization Branch Laboratory Division Office of Engineering & Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Application No. EA99330 AK8TA-15A Dear Ms. Poole, According to your request, I hereby certify that every unit of Sony Model PCVA-15TXSA1 will have a label stating: “Contains FCC ID AK8TA-15A” as illustrated of page 2, photo 4 of exhibit G2. Respectfully yours; Julio Posse Manager Product Safety & Compliance Sony Electronics Inc.

Photo-1. External View (FCC ID : AK8TA-15A) Photo-2 Control Unit PC Board, Component Side (FCC ID: AK8TA-15A) Photo-3 Control Unit Board, Foil Side (FCC ID: AK8TA-15A) Photo-4 Antenna PC Board, Front Side (FCC ID: AK8TA-15A) Photo-5 Antenna PC Board, Rear Side (FCC ID : AK8TA-15A)

Photo-1 Front View of Photo-2 Rear View Photo-3 Bottom View Photo-4 FCC ID Label

FCC ID: AK8TA-15A FCC ID Label Location (on the control unit board, foil side)

BRIEF EQUIPMENT DESCRIPTION Tablet is an input/output integrated device for a computer, using Tablet Sensor with VAIO Pen and TFT color LCD monitor. The Tablet continuously transmits data to and from VAIO Pen. When transmitting, the tablet sends a signal to the VAIO Pen. The VAIO Pen stores energy from the signal. When receiving, the VAIO Pen sends a signal that carries coordinate, switch, and pressure data back to the tablet. The tablet sends this data to the computer. Tablet provides a Pen computing. The intentionally radiated frequencies The intentionally radiated frequencies are 531.25kHz, 562.50kHz and 593.75kHz. All the other frequencies are unintentionally radiated. A. Antenna (Tablet sensor) The sensor board has two groups of multiple loop coil in X (horizontal) and Y (vertical) directions. Radio frequency energy is radiated from these coils. Each coil is approximately 28.8mm wide and as long as the height, for the X-axis, and width, for the Y-axis, of the effective area of the table. Each coil consists of 2 turns (loops) of copper conductor. B. Original oscillation frequency and intentionally radiated frequency. We make three (531.25kHz, 562.50kHz, 593.75kHz) intentionally radiated frequencies from the original oscillation frequency of 16MHz by ASIC(Gate Array W7003F). C. Operation The tablet looks for a pointing device, such as a stylus, by feeding electrical current of above-mentioned frequencies through the coils in both X axis and Y axis. The current fed through each coil is 250mA(Type). The tablet is able to detect the position of a pointing device because of the induction caused between the coil of the pointing device and two coils, one from X-axis and the other from X-axis, of the sensor board. D. Comment on pointing device The pointing device operates completely passively and has no battery or active oscillator.

JAPAN QUALITY ASSURANCE ORGANIZATION 2096, OHHATA, TSURU-SHI, YAMANASHI 402-0045, JAPAN PHONE (0554) 43-5517, FAX (0554) 43-6316 JQA APPLICATION NO.: 441-00504 Issue Date : November 2, 2000 Page 1 of 25 EMI TEST REPORT JQA APPLICATION NO. : 441-00504 Model No. : TA-15A Type of Equipment : TABLET Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : AK8TA-15A Applicant : Sony Corporation Address : 7-35, Kitashinagawa 6-chome, Shinagawa-ku Tokyo 141-0001, Japan Manufacture : Sony Corporation Address : 7-35, Kitashinagawa 6-chome, Shinagawa-ku Tokyo 141-0001, Japan Received date of EUT : October 20, 2000 Final Judgment : Passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to Electrotechnical Lab. of MITI Japan and Communications Research Lab. of MPT Japan. The test results only respond to the tested sample. It is not allowed to copy this report even partly without the allowance of the JQA EMC Engineering Dept. Testing Div. JQA Application No. :441-00504 FCC ID : AK8TA-15A Model No. :TA-15A Issue Date : November 2, 2000 Standard :CFR 47 FCC Rules Part 15 Page 2 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 8 1.4 EUT Modifications / Deviation from Standard 9 1.5 Test results 10 1.6 Summary 11 1.7 Test Configuration / Operation of EUT 12 1.8 EUT Arrangement(Drawing) 13 1.9 Preliminary Test and Test-setup (Drawings) 14 – 19 1.10 EUT Arrangement (Photographs) 20 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N / A 2.2 Radiated Emission (Electric Field)9 kHz – 30 MHz 21 – 22 2.3 Radiated Emission (Electric Field)30 MHz – 1000 MHz 23 – 24 2.4 Radiated Emission (Electric Field) Above 1 GHz N / A 2.5 Frequency Stability N / A 2.6 Occupied Bandwidth N / A JQA Application No. :441-00504 FCC ID : AK8TA-15A Model No. :TA-15A Issue Date : November 2, 2000 Standard :CFR 47 FCC Rules Part 15 Page 3 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and C (June 23, 1989) Intentional Radiators. Test procedure : AC power line conducted emission, radiated emission, frequency stability and occupied bandwidth tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1)Test Facility located at JQA SAFTY TESTING CENTER EMC ENGINEERING DEPT. TSURU EMC BRANCH: Open Site No.1, No.2, An Anechoic Chamber (3 m and 10 m, on common plane)and a Shielded Room Date of Listing : March 30,1999 2)JQA SAFTY TESTING CENTER EMC ENGINEERING DEPT. TSURU EMC BRANCH is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200192-0 (Effective through : June 30, 2001) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : TABLET 2) Product Type : Prototype 3) Category : Low Power Communication Device Transmitter 4) EUT Authorization : Certification 5) FCC ID : AK8TA-15A 6) Trade Name : SONY 7) Model No. : TA-15A 8) Operating Frequency Range : 531.2 kHz, 562.1 kHz, 593.0 kHz 9) Other Frequency Used in the EUT : 16 MHz, 2 MHz 10) Serial No. : - 11) Date of Manufacture : - 12) Power Rating : 12.0 VDC 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. JQA Application No. :441-00504 FCC ID : AK8TA-15A Model No. :TA-15A Issue Date : November 2, 2000 Standard :CFR 47 FCC Rules Part 15 Page 4 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Tsuru EMC Branch 2096 Ohhata, Tanbozawa, Tsuru-shi Yamanashi-ken 402-0045, JAPAN - Shielded Room No.1 - Shielded Room No.2 - Anechoic Chamber - Open Site No.1 - Open Site No.2 Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESHS30 Rohde & Schwarz 842053/001 Oct. 2000 1 Year - Test Receiver ESH-3 Rohde & Schwarz 872994/047 May. 2000 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/016 May. 2000 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-5 May. 2000 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-680-14 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-1 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-2 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-3 May. 2000 1 Year - LISN KNW-243C Kyoritsu Electrical 8-831-4 May. 2000 1 Year - LISN ESH 2-Z5 Rohde & Schwarz 879341/007 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.1 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.2 May. 2000 1 Year - RF Cable 3D-2W Fujikura No.3 May. 2000 1 Year - 50ohm Termination - TDC 15406501E1 Feb. 2000 1 Year - 50ohm Termination - - 15406502E1 Feb. 2000 1 Year JQA Application No. :441-00504 FCC ID : AK8TA-15A Model No. :TA-15A Issue Date : November 2, 2000 Standard :CFR 47 FCC Rules Part 15 Page 5 of 25 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(9 kHz – 30 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Tsuru EMC Branch 2096 Ohhata, Tsuru-shi, Yamanashi-ken 402-0045, JAPAN X - Open Site No. 1 (3, 10 or 30 meters) - Open Site No. 2 (3 or 10 meters) - Anechoic Chamber(3 or 10 meters) Validation of Site Attenuation : 1) Last Confirmed Date : N/A 2) Interval : N/A Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESHS30 Rohde & Schwarz 842053/001 Oct. 2000 1 Year x - Test Receiver ESH-3 Rohde & Schw…
