AK8WCS999T2wireless microphone

WCS-999. 3-867-779-12 (1). EF WCS-999. 3-867-779-12 (1). EF Wireless Microphone System Sony Corporation  1999 Printed in Japan WCS-999 Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. Mode d’emploi Avant la mise en service de cet appareil, prière de lire attentivement ce mode d’emploi que l’on conservera pour toute référence ultérieure. Owner's Record The model and serial numbers are located at the rear of both the receiver and the transmitter. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No.WCS-999T Serial No. Model No.WCS-999R Serial No. 3-867-779-12 (1) Information You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. Note Please note that accordingly only Sound and TV- Radio Receivers meant for the entire population are allowed to be received via this set. It is prohibited to receive all other transmission such as police radio or mobile radio. For the Customers in Canada This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. For the Customers in the U.S.A Declaration of Conformity Trade Name: SONY Model No.: WCS-999R (Receiver Unit) Responsible Party: Sony Electronics Inc. Address: 1 Sony Drive, Park Ridge, NJ.07656 USA Telephone No.: 201-930-6970 This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Features This wireless microphone system is designed to be used with a video camera recorder, etc. By attaching the receiver unit onto a video camera recorder, etc. you can receive the sound picked up by the transmitter unit. You can enjoy vivid sound which matches the zoomed up images recorded by your video camera recorder. You can also use this system with a tape recorder as a conventional wireless microphone system to record the sound. • The operational distance between the transmitter unit and the receiver unit can be up to approximately 150 feet (45 m). However, this distance may become shorter if there are some obstacles in between the transmitter unit and the receiver unit. • The radio frequency can be selected so that a less busy channel can be used while the air is busy. • Compact design featuring built-in antennas. • The transmitter unit is equipped with a plug in power∗ type MIC jack (monaural/ 3.5 mm dia.) An optional microphone other than the supplied one can be connected to this jack. • The transmitter and receiver units are equipped with clip type holders with the adjustable clips which can be rotated 360 degrees so that the transmitter and receiver units can be attached onto your clothes, etc. with optimum angles. • The receiver unit is equipped with the MIX MIC jack to which an optional microphone such as the ECM-T145 (lavalier microphone) can be connected, so that the sound transmitted from the transmitter unit can be mixed with the sound picked up by the optional microphone. • The receiver unit is equipped with the v (earphone) jack to which the supplied earphone can be connected, so that you can monitor the sound being recorded. You can use the earphone connected to the receiver unit to monitor the subject using the transmitter unit. • The supplied lavalier microphone has a built-in wind screen effect so that you can use the microphone in the open air without a wind screen. ∗Plug in power system The system that power is supplied directly to the microphone from the microphone jack of the connected equipment. Precautions This wireless microphone system uses FM radio waves for transmission. Therefore, there may be cases where the transmission of the sound may be hindered when the system is used near certain obstacles. FM radio waves may also be deflected by walls, etc. Under such circumstances, the sound may be intermittent or distorted at times. However, these are the characteristics of FM radio waves and this does not indicate a malfunction. • The system should never be dropped or subjected to extreme shock. • Keep the system away from extremely high temperatures (above 140° F or 60° C) and humidity. • Do not use this system in the following locations as doing so can cause microphonics (electrical disturbance noise) which will impair the performance of this system. — A very noisy (more than 70 phone) location. — A location with a lot of vibration. — A location near a rotating machine or a transformer. — Near a speaker of a PA system. — Near recording studio equipment. • You do not need to have a license to operate this microphone system. However, observe the following points. — Avoid using the system near a broadcasting station, airport or inside an airplane. — If radio interference from other radio equipment occurs, alter the radio channel or change the location. (You are not protected by law against any radio interference caused by other radio equipment .) • When this system is connected to a radio cassette player, etc. and the system's lavalier microphone is placed too close to the speaker of the radio cassette player, acoustic feedback (a howling effect) may occur. If this happens, change the direction of the microphone until the howling stops, or decrease the volume of the radio cassette player. • When using the system outdoors, avoid getting the system wet. • Should any liquid fall onto the system, wipe it thoroughly with a dry soft cloth. • The system is a monaural type. Therefore, if you use this system with equipment capable of stereo recording, the recorded sound will become …

Text truncated - open the document above for the full version.

External Photos 1 Model: WCS-999T FCC ID: AK8WCS999T2 External Photos 2 Model: WCS-999T FCC ID: AK8WCS999T2

ID Label / Location Info. Model: WCS-999T FCC ID: AK8WCS999T2

Internal Photos 1 Model: WCS-999T FCC ID: AK8WCS999T2 Internal Photos 2 Model: WCS-999T FCC ID: AK8WCS999T2 Internal Photos 3 Model: WCS-999T FCC ID: AK8WCS999T2
