UHF Synthesized Transmitter 2-693-883-02(1) DRAFT version Operating Instructions U3032/U4244 WRT-8P ©2006 Sony Corporation 2 Owner’s Record The model number plate is located on the side and the serial number is located inside the battery compartment. Record the model and serial numbers in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. M o d e l N o . S e r i a l N o . Notice for customers in the U.S.A. Use of Sony wireless devices is regulated by the Federal Communications Commission as described in Part 74 subpart H of the FCC regulations and users authorized thereby are required to obtain an appropriate license. You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user's authority to operate this device. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC Radiation Exposure Statement: The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. Notice for customers in Canada: Use of Sony wireless devices is regulated by the Industry Canada as described in their Radio Standard Specification RSS-123. A license is normally required. The local district office of Industry Canada should therefore be contacted. When the operation of the device is within the broadcast band, the license is issued on no-interference, no- protection basis with respect to broadcast signals. Operation of this device is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. IC Exposure of Humans to RF Fields The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada's website: www.hc-sc.gc.ca/rpb. English 3 Table of Contents GB Table of Contents Overview ..................................................................................4 Precautions ..............................................................................4 Parts Identification ................................................................. 5 Power Supply ..........................................................................7 Inserting the battery ..........................................................8 Settings .....................................................................................9 Entering setting mode .......................................................9 Setting the transmission channel ......................................9 Resetting the accumulated battery use time indication ...10 Setting the RF output power level .................................. 10 Setting the audio input level ...........................................11 Setting the +48 V power supply .....................................11 Attachment and Insertion Procedures ................................ 12 Attaching a microphone or a cable ................................. 12 Inserting into the supplied soft case ................................ 13 Notes on Microphone System Operations ..........................13 System Configuration ........................................................... 14 Error Messages ..................................................................... 15 Specifications ......................................................................... 16 4 Overview / Precautions Overview The WRT-8P is a plug-on transmitter for a UHF synthesized wireless microphone system to be used for broadcast or movie production purpose. This transmitter is suitable for ENG 1) and EFP 2) . The microphone/transmitter and tuner of the wireless microphone system are classified by frequency band. A 24-MHz frequency band is assigned to each microphone/transmitter and tuner model. In building a UHF wireless microphone system, be sure to combine a microphone/transmitter and a tuner having the same wireless channel (frequency). 1) ENG: Electronic News Gathering 2) EFP: Electronic Field Production Features The features of the WRT-8P are as follows: • Converts a wired microphone to a wireless microphone via an XLR-type connector. • Compact and lightweight metal body provides high durability and good balanced handling. • 250 mW high RF output power for stable long-distance transmission. • Selectable RF output power: 250 mW/50 mW. • +48 V power supply for microphone. • Switchable input level (MIC or LINE). • Attenuator function allows adjustment of the audio input level. • An LCD with a backlighting provides extensive information. • Optimized balance when combined with the F-112 Dynamic Microphone. Precautions • The unit is designed for use in ambient temperature range of 0°C to 50°C (32°F to 122°F). • Do not place the …

Text truncated - open the document above for the full version.

PCTEST Engineering Laboratory, Inc. 6660 Dobbin Road Suite A-E Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 January 26, 2007 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Stan Lyles SUBJECT: Sony Corporation FCC ID: AK8WRT8P1 731 Confirmation No.: EA634279 Correspondence Reference No.: 32334 Request for Tech. Info.: January 8, 2007 Dear Stan: Transmitted herewith, on behalf of Sony Corporation is an amendment provided in response to the request for technical information dated January 8, 2007. 1. The antenna of the product is the microphone body. Please find attached the photo of the antenna of the microphone showing the antenna portion. 2. This microphone is intended to be used less than 20 cm from the person’s face/ head and hand. Therefore, SAR was performed in a typical face-held configuration in a worst-case touch mode position (0 cm spacing). 3. We followed the procedures specified in Alternative System Verification “Method B” per FCC Lab SAR Probe Calibration and System Verification, November 2006. The 615 MHz Dipole target was validated with five measurements to verify that the standard deviation was less than 2%. Please find attached revised pg. 16 of the SAR Report. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Sony Corporation

SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30) SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30) SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30) SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30)

SONY FCC ID: AK8WRT8P1 EUT Photographs © 2007 PCTEST Lab. UHF Synthesized Transmitter Model: WRT -8P (30)

Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 Internal Photo AF Side A AF Side B Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 CPU Side A CPU Side B Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 RF Side A RF Side B Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 RF with soldered shield case RF with shield case Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 FL Side A FL Side B Model: WRT-8P (42) FCC ID: AK8WRT8P2 IC: 409B-WRT8P2 VR Side A VR Side B

Reviewed by: FCC ID: AK8WRT8P1 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0611030975 November 30, 2006 UHF Synthesized Transmitter Page 1 of 22 © 2006 PCTEST Engineering Laboratory, Inc. REV 3.6C 11/27/06 Applicant Name: Date of Testing: Sony Corporation November 16, 2006 6-7-35 Kitashinagawa Test Site/Location: Shinagawa-ku, Tokyo PCTEST Lab, Columbia, MD, USA 141-0001 JAPAN Test Report Serial No.: 0611030975 FCC ID: AK8WRT8P1 APPLICANT: SONY CORPORATION EUT Type: UHF Synthesized Transmitter Application Type: Certification FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Broadcast Transmitter Held to Face (TBF) Model(s): WRT-8P (30) Tx Frequency: 566.125 - 589.875 MHz Conducted Power: 0.250 W (23.973 dBm) Max. SAR Measurement: 0.754 W/kg Face SAR Test Device Serial No.: Pre-Production [S/N: 8003] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-2005 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: AK8WRT8P1 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0611030975 November 30, 2006 UHF Synthesized Transmitter Page 2 of 22 © 2006 PCTEST Engineering Laboratory, Inc. REV 3.6C 11/27/06 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 ANSI/IEEE C95.1-2005 RF EXPOSURE LIMITS......................................................................... 14 11 MEASUREMENT UNCERTAINTIES ............................................................................................ 15 12 SYSTEM VERIFICATION.............................................................................................................. 16 13 SAR TEST DATA SUMMARY ....................................................................................................... 17 14 SAR DATA SUMMARY ................................................................................................................. 18 15 EQUIPMENT LIST......................................................................................................................... 19 16 CONCLUSION............................................................................................................................... 20 17 REFERENCES .............................................................................................................................. 21 Reviewed by: FCC ID: AK8WRT8P1 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0611030975 November 30, 2006 UHF Synthesized Transmitter Page 3 of 22 © 2006 PCTEST Engineering Laboratory, Inc. REV 3.6C 11/27/06 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring the Specific Absorption Rate (SAR) due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the Internation…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: AK8WRT8P1 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0611030975-R1 November 16, 2006 UHF Synthesized Transmitter Page 16 of 22 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.6C 11/27/06 12 SYSTEM VERIFICATION – per NEW FCC Lab Probe Cal. Procedure 12.1 Tissue Verification – per FCC Lab SAR Probe Calibration and Systems Verification (Nov. 2006) Table 12-1 Measured Tissue Properties Calibrated Date: Deviation (%) Deviation (%) TargetMeasuredDeviationTargetMeasuredDeviation Dielectric Constant42.6443.141.17%41.5040.442.55% Conductivity0.8800.8701.14%0.9000.9000.00% 11/16/0611/16/06 615MHz Brain615MHz Muscle 12.2 Test System Verification (Method B) - per FCC Lab SAR Probe Calibration and Systems Verification (Nov. 2006) Prior to assessment, the system is verified to ±10% of the specifications at 615MHz by using the system validation kit(s). (Graphic Plots Attached) Table 12-2 System Verification Results 11/16/0623.621.20.250 615MHz Brain 2.3752.310-2.73% System Verification TARGET & MEASURED Date: Amb. Temp (?C) Liquid Temp(?C ) Input Power (W) Tissue Frequency (Mhz) Targeted SAR 1g (mW) Measured SAR 1g (mW) Deviation (%) Table 12-3 Standard Deviation Measurements Number of Measurement Measured SAR (mW/g) Deviation (%) Spec #10.5040.00< 2.0 % #20.5060.40< 2.0 % #30.503-0.20< 2.0 % #40.5040.00< 2.0 % #50.503-0.20< 2.0 % Figure 12-1 System Verification Setup Diagram Figure 12-2 System Verification Setup Photo Average SAR (mW/g) A Standard Deviation B B/ASpec 0.5040.0010.002< 2.0 % Table 12-4 Standard Deviation Summary

Reviewed by: PCTEST  Part 74(H) Certification FCC MEASUREMENT REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: (TBF) FCC ID: AK8WRT8P1 0611030974 November 10, 2006 UHF Synthesized TX –- Wireless Microphone System Page 1 of 29 © 2006 PCTEST Engineering Laboratory, Inc. Applicant Name: Date of Testing: SONY Corporation November 10, 2006 6-7-35 Kitashinagawa, Shinagawa-ku Test Site/Location: Tokyo, 141-0001 PCTEST Lab, Columbia, MD, USA JAPAN Test Report Serial No.: 0611030974 FCC ID: AK8WRT8P1 APPLICANT: SONY CORPORATION Application Type: Certification FCC Classification: Licensed Broadcast Transmitter Held to Face (TBF) FCC Rule Part(s): § 2 & § 74 Subpart H – Low Power Auxiliary Stations EUT Type: UHF Synthesized Transmitter – Wireless Microphone System Model(s): SONY WRT-8P (30) TX Frequency Range: 566.125 – 589.875 MHz Frequency Tolerance ±0.005 % RF Power Output: 250 mW / 50 mW (selectable) Frequency Response 50 to 18,000 Hz Emission Designator(s): 116KF3E Test Device Serial No.: S/N: 8003 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in Part 74 and Part 2 of the FCC Rules. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: (M4) Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 74 Certification Reviewed by: PCTEST  Part 74(H) Certification FCC MEASUREMENT REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: (TBF) FCC ID: AK8WRT8P1 0611030974 November 10, 2006 UHF Synthesized TX –- Wireless Microphone System Page 2 of 29 © 2006 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1.0 SCOPE............................................................................................................................................................4 1.1 GENERAL INFORMATION.............................................................................................................................................4 2.0 INTRODUCTION.............................................................................................................................................5 2.1 TESTING FACILITY........................................................................................................................................................5 2.2 ACCREDITATIONS.........................................................................................................................................................5 3.0 PRODUCT (EUT) SPECIFICATIONS..............................................................................................................6 4.0 SUMMARY OF TEST RESULTS.....................................................................................................................7 5.0 TEST CONFIGURATION.................................................................................................................................8 5.1 TEST CONFIGURATION................................................................................................................................................8 5.2 OPERATING CONDITION OF EUT...............................................................................................................................8 5.3 GENERATING AND OPERATING FREQUENCY.........................................................................................................8 5.4 EMI SUPPRESSION DEVICE(S)...................................................................................................................................8 6.0 RF OUTPUT POWER MEASUREMENT.........................................................................................................9 6.1 APPLICABLE STANDARDS – §74.861(E)(1)(II) & §2.1046.............................................................................................9 6.2 TEST PROCEDURE...........................................................................................................................................................9 6.3 TEST DATA.........................................................................................................................................................................9 6.4 RF OUTPUT POWER MEASUREMENT PLOTS............................................................................................................10 SEE ATTACHED......................................................................................................................................................................10 7.0 MODULATION CHARACTERISTICS............................................................................................................11 7.1 APPLICABLE STANDARDS – §74.861(E)(3) & §2.1047(A)...........................................................................................11 7.2 TEST PROCEDURE.........................................................................................................................................................11 7.3 TEST DATA.......................................................................................................................................................................11 7.4 MODULATION CHARACTERISTICS PLOTS........................................................................…

Text truncated - open the document above for the full version.

Reviewed by: PCTEST Part 74(H) Certification FCC MEASUREMENT REPORT Quality Manager Test Report S/N: Test Dates: Nov. 10, 2006 EUT Type: (TBF) FCC ID: AK8WRT8P1 0611030974-R1 Add. Test Dates: Jan. 5-12, 2007 UHF Synthesized TX –- Wireless Microphone System Page 1 of 30 © 2007 PCTEST Engineering Laboratory, Inc. REV 0.1F 01/01/2007 Applicant Name: Date of Testing: SONY Corporation November 10, 2006 6-7-35 Kitashinagawa, Shinagawa-ku Additional Test Date(s): Tokyo, 141-0001 January 5-12, 2007 JAPAN Test Site/Location: PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0611030974-R1 FCC ID: AK8WRT8P1 APPLICANT: SONY CORPORATION Application Type: Certification FCC Classification: Licensed Broadcast Transmitter Held to Face (TBF) FCC Rule Part(s): § 2 & § 74 Subpart H – Low Power Auxiliary Stations EUT Type: UHF Synthesized Transmitter – Wireless Microphone System Model(s): SONY WRT-8P (30) TX Frequency Range: 566.125 – 589.875 MHz Operating Freq. Band 23.75 MHz Frequency Tolerance ±0.005 % (ERP) RF Power Output: 250 mW / 50 mW (selectable) Frequency Response 50 to 18,000 Hz Emission Designator(s): 120KF3E Test Device Serial No.: S/N: 8003 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in Part 74 and Part 2 of the FCC Rules. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. * This revised Test Report (S/N: 0611030974-R1) supersedes and replaces the previously issued test report on the same subject EUT for the same type of testing as indicated. Please discard or destroy the previously issued report (S/N: 0611030974) and dispose of it accordingly. Grant Conditions: (M4) Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 74 Certification Reviewed by: PCTEST Part 74(H) Certification FCC MEASUREMENT REPORT Quality Manager Test Report S/N: Test Dates: Nov. 10, 2006 EUT Type: (TBF) FCC ID: AK8WRT8P1 0611030974-R1 Add. Test Dates: Jan. 5-12, 2007 UHF Synthesized TX –- Wireless Microphone System Page 2 of 30 © 2007 PCTEST Engineering Laboratory, Inc. REV 0.1F 01/01/2007 TABLE OF CONTENTS 1.0 SCOPE............................................................................................................................................................4 1.1 GENERAL INFORMATION.....................................................................................................................................4 2.0 INTRODUCTION.............................................................................................................................................5 2.1 TESTING FACILITY................................................................................................................................................5 2.2 ACCREDITATIONS.................................................................................................................................................5 3.0 PRODUCT (EUT) SPECIFICATIONS..............................................................................................................6 4.0 SUMMARY OF TEST RESULTS.....................................................................................................................7 5.0 TEST CONFIGURATION.................................................................................................................................8 5.1 TEST CONFIGURATION........................................................................................................................................8 5.2 OPERATING CONDITION OF EUT........................................................................................................................8 5.3 GENERATING AND TESTED OPERATING FREQUENCY.....................................................................................8 5.4 EMI SUPPRESSION DEVICE(S)............................................................................................................................8 6.0 RF OUTPUT POWER MEASUREMENT.........................................................................................................9 6.1 APPLICABLE STANDARDS – §74.861(E)(1)(II) & §2.1046........................................................................................9 6.2 TEST PROCEDURE...................................................................................................................................................9 6.3 TEST DATA................................................................................................................................................................9 6.4 RF OUTPUT POWER MEASUREMENT PLOTS......................................................................................................10 7.0 MODULATION CHARACTERISTICS............................................................................................................11 7.1 APPLICABLE STANDARDS – §74.861(E)(3) & §2.1047(A)......................................................................................11 7.2 TEST PROCEDURE.................................................................................................................................................11 7.3 TEST DATA................................................................................................…

Text truncated - open the document above for the full version.

SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30) SONY FCC ID: AK8WRT8P1 EUT Photographs © 2006 PCTEST Lab. UHF Synthesized Transmitter Model: WRT-8P (30)
