AK8ZTXB01Digital Wireless Transmitter

E:\#works_2\120800937_DWZ- M50_B30GB\120800937_4445504122_GB\4445504122 \4445504122DWZM50UC\01GB01COV.fm masterpage:Right DWZ-M50/B30GB 4-445-504-12 (2) 4-445-504-12 (2) © 2012 Sony Corporation Digital Wireless Package Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. DWZ-M50 DWZ-B30GB The supplied CD-ROM includes the Operating Instructions (English, French, German, Italian, and Spanish versions) in PDF format. For more details, see “Using the CD-ROM manual” on page 19. 00DWZ.book Page 1 Friday, August 31, 2012 11:50 AM E:\#works_2\120700180_DWZ- M50_B30GB\120700180_4445504111_GB\4445504111 \4445504111DWZM50UC\01GB02REG.fm masterpage:Left DWZ-M50/B30GB 4-445-504-11 (1) 2 For the ZTX-M01/B01 Transmitters Owner’s Record The model and serial numbers are located at the rear or on the bottom of the unit. Record the model and serial numbers in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. _____________________ Serial No. ______________________ WARNING Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. If the transmitter develops an abnormally high temperature, a burning odor or smoke during use, remove the battery holder and stop using the transmitter immediately. Take care not to burn your fingers when removing the battery holder as the batteries may be very hot at this time. AVERTISSEMENT N’exposez pas les batteries à une chaleur excessive, au soleil ou près d’un feu par exemple. Si l’émetteur dégage une température anormalement élevée, une odeur de brûlé ou de la fumée pendant son utilisation, enlevez le support de piles et arrêtez toute utilisation immédiatement. Attention à ne pas vous brûler les doigts lorsque vous retirez le support de piles car celles–ci peuvent être brûlantes. WARNUNG Akkus dürfen keinesfalls übermäßiger Wärmeeinwirkung ausgesetzt werden, wie z.B. Sonneneinstrahlung, Feuer o. ä. Wenn der Sender eine abnorm hohe Temperatur, einen Geruch nach Verbranntem oder Rauch entwickelt, entnehmen Sie den Batterie-Halter und stoppen Sie sofort den Betrieb des Senders. Achten Sie bei der Entnahme des Batterie- Halters darauf, sich nicht die Finger zu verbrennen, denn die Batterien könnten sehr heiß zu diesem Zeitpunkt sein. For the customers in the U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. All interface cables used to connect peripherals must be shielded in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules. If you have any questions about this product, you may call ; 00DWZ.book Page 2 Wednesday, August 15, 2012 3:38 PM E:\#works_2\120800937_DWZ- M50_B30GB\120800937_4445504122_GB\4445504122 \4445504122DWZM50UC\01GB02REG.fm masterpage:Right DWZ-M50/B30GB 4-445-504-12 (2) 3 Sony Customer Information Service Center 1-800-222-7669 or http://www.sony.com/ IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate this device. This device complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This device has very low levels of RF energy that it is deemed to comply without testing of specific absorption ratio (SAR). This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. For the customers in Canada This Class B digital apparatus complies with Canadian ICES-003. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR). Pour les clients au Canada Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout br…

Text truncated - open the document above for the full version.

ZTX ‐ B01 Outline Front Rear ZTX ‐ B01 Outline Right Side Left Side ZTX ‐ B01 Outline Bottom Top

NamePlate

ZTX ‐ B01 Internal Structure [1] Opposite side. Detached the Battery Cases and the Rear Case. ZTX ‐ B01 Internal Structure [2] Detached the Antenna Case and Board DTX ‐ 11. Detached the Battery Terminal and Board PS ‐ 863 ZTX ‐ M01 Internal Structure [3] Side B of Board DTX ‐ 11. ZTX ‐ M01 Internal Structure [4] Side A of Board DTX ‐ 11. ZTX ‐ M01 Internal Structure [5] Side B of Board PS ‐ 863. ZTX ‐ M01 Internal Structure [6] Side A of Board PS ‐ 863.

Test report No. : 32KE0148-HO-01-A-R1 Page : 2 of 29 Issued date : September 7, 2012 Revised date : September 12, 2012 FCC ID : AK8ZTXB01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ......................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ........................................................................................... 3 SECTION 3: Test specification, procedures & results ............................................................................ 4 SECTION 4: Operation of E.U.T. during testing .................................................................................... 7 SECTION 5: Radiated Spurious Emission .............................................................................................. 8 SECTION 6: Antenna Terminal Conducted Tests .................................................................................. 9 APPENDIX 1: Data of EMI test .............................................................................................................. 10 6dB Bandwidth ................................................................................................................................. 10 Maximum Peak Output Power .......................................................................................................... 12 Radiated Spurious Emission ............................................................................................................. 13 Conducted Spurious Emission .......................................................................................................... 17 Conducted Emission Band Edge compliance ................................................................................... 23 Power Density ................................................................................................................................... 24 99%Occupied Bandwidth ................................................................................................................. 26 APPENDIX 2: Test instruments ............................................................................................................. 27 APPENDIX 3: Photographs of test setup ............................................................................................... 28 Radiated Spurious Emission ............................................................................................................. 28 Worst Case Position .......................................................................................................................... 29 Test report No. : 32KE0148-HO-01-A-R1 Page : 3 of 29 Issued date : September 7, 2012 Revised date : September 12, 2012 FCC ID : AK8ZTXB01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : Sony Corporation Address : 1-7-1 Konan, Minato-ku, Tokyo 108-0075, Japan Telephone Number : +81-53-577-1012 Facsimile Number : +81-53-577-3489 Contact Person : Youhei Hisano SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : DIGITAL WIRELESS TRANSMITTER Model No. : ZTX-B01 Serial No. : Refer to Section 4, Clause 4.2 Rating : DC 3V Receipt Date of Sample : June 14, 2012 Country of Mass-production : Korea Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product Description To be used in the wireless microphone system, mainly aimed at amateur musicians. General Specification Clock frequency(ies) in the system : 26MHz Radio Specification Radio Type : Transmitter Frequency of Operation : 2402 - 2478.5 MHz Modulation : GFSK Power Supply (radio part input) : DC1.2V, DC 2.7V, DC5.0V Antenna type : Lambda/4, Mono-pole (internal) Antenna Gain : 0dBi Test report No. : 32KE0148-HO-01-A-R1 Page : 4 of 29 Issued date : September 7, 2012 Revised date : September 12, 2012 FCC ID : AK8ZTXB01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C: 2012, final revised on August 13, 2012 and effective September 12, 2012 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.207 Conducted limits Section 15.247 Operation within the bands 902-928MHz, 2400-2483.5MHz, and 5725-5850MHz * The revision on August 13, 2012 does not affect the test specification applied to the EUT. * The EUT complies with FCC Part 15 Subpart B: 2012, final revised on August 13, 2012 and effective September 12, 2012. 3.2 Procedures and results Item Test Procedure Specification Worst margin Results Remarks Conducted Emission FCC: ANSI C63.4:2003 7. AC powerline Conducted Emission measurements FCC: Section 15.207 N/A N/A *1) - IC: RSS-Gen 7.2.4 IC: RSS-Gen 7.2.4 6dB Bandwidth FCC: "Guidance on Measurement of Digital Transmission Systems Operating under Section15.247" FCC: Section 15.247(a)(2) See data. Complied Conducted IC: RSS-Gen 4.6.2 IC: RSS-210 A8.2(a) Maximum Peak Output Power FCC: "Guidance on Measurement of Digital Transmission Systems Operating under Section15.247" FCC: Section 15.247(b)(3) Complied Conducted IC: RSS-Gen 4.8 IC: RSS-210 A8.4(4) Power Density FCC: "Guidance on Measurement of Digital Transmission Systems Operating under Section15.247" FCC: Section 15.247 (e) Complied Conducted IC: - IC: RSS-210 A8.2(b) Spurious Emission Restricted Band Edges FCC: "Guidance on Measurement of Digital Transmission Systems Operating under Section15.247" FCC: Section15.247(d) 4.2dB 4804.000MHz…

Text truncated - open the document above for the full version.

Test report No. : 32KE0148-HO-01-A-R1 Page : 28 of 29 Issued date : September 7, 2012 Revised date : September 12, 2012 FCC ID : AK8ZTXB01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Radiated Spurious Emission Photo 1 Photo 2 Test report No. : 32KE0148-HO-01-A-R1 Page : 29 of 29 Issued date : September 7, 2012 Revised date : September 12, 2012 FCC ID : AK8ZTXB01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Worst Case Position Below 1GHz Horizontal: X-axis Vertical: Y-axis Above 1GHz Horizontal: Z-axis Vertical: Y-axis X-axis Y-axis Z-axis End of Report
