ALT4308Bluetooth Speaker and Light Show

INSTRUCTIONS INCLUDES: Bluetooth® Speaker and Light Show and AC adapter WARNING SEIZURES - People with photosensitive epilepsy can have seizures triggered by flickering or flashing lights such as strobe or disco lights. Do not operate the product in water while the unit is plugged in. Serious and/or fatal injury may result. KEEP OUT OF REACH OF CHILDREN. THIS IS NOT INTENDED AS A TOY. NOTE • The product projects light show approximately 10-15 feet in diameter. • Light show intensity will vary according to color, size and depth of your pool. GETTING STARTED IMPORTANT: Before first use, fully charge battery (6 hours). When fully charged, the red indicator light on top of the speaker will turn blue. 1. Plug the USB adapter into your computer’s USB port or any standard 5V USB wall adapter. WARNING: Use the supplied battery charge adapter; DO NOT substitute with any other charger. Never turn on the product while is charging. 2. Remove the charging port plug located on top of the speaker and plug the AC adapter connector into charging port. 3. After indicator light turns blue, unplug the charger from the charging port. 4. Replace the charging port plug, pressing it firmly into place so water doesn’t seep into the port. NOTE: Speaker indicator light will flash repeatedly and beep twice when the battery is low. PAIRING YOUR DEVICE 1. Press the ON/OFF button. A “beep” tone sounds and light show turns on. 2. LED indicators flash blue while looking for Bluetooth® devices. 3. Select the searching mode on your device (refer to your device’s owner’s manual for details). 4. Pair your Bluetooth device (mobile phone or music player). When your device finds “GAMEBT,” select it and connect. 5. The top flashing LEDs turn solid blue when Bluetooth device is connected. POWERING OFF Press the ON/OFF button. A tone will sound, and light show and speaker will turn off. IMPORTANT: • Remove from pool when not in use or while cleaning so unit is not damaged by skimmers or other devices. • Do not submerse unit in water as this could damage the electronic components. CLEANING & MAINTENANCE STORAGE Wipe dry with a soft cloth after use. When the product is out of water, it should be stored in a cool, dry place. Do not leave the product in direct sunlight as this could damage the batteries. IMPORTANT: The batteries are permanently sealed in the product and cannot be removed or replaced. Attempting to remove and/or replace the batteries will void the warranty. The battery in the remote control is replaceable. ~ continued ~ NOTE • Do not mix old and new batteries. • Do not dispose batteries into fire. Batteries may explode or leak. • Do not mix alkaline standard (carbon-zinc), or rechargeable (nickel-cadium) batteries. • Replace batteries ensuring the correct battery type, and as a simultaneous act. • Remove batteries if product is to be left unused for a long time. • Clean the battery contacts and also those of the devices prior to battery installation. • The supply terminal is not to be short circuited (+) (-). • Non-rechargeable batteries are not to be recharged. • Batteries are to be inserted with the correct polarity. • Remove exhausted batteries promptly and dispose of properly. Check your local regulations for proper disposal instructions of batteries. SpeakerHanger Charging PortPower On/Off Volume Down Light Show On/Off Volume Up TROUBLESHOOTING ProblemPossibilities/Solutions Unit doesn’t respond (no power) Make sure unit is completely charged Make sure your device is properly paired with the GAME BT Interference or static during playback Avoid using the device between concrete or other building structures that may interfere with the signal. Please check if the battery level of the unit and the Bluetooth device and charge if necessary Unable to connect your speaker and your Smartphone Ensure the speaker is paired with your Smartphone. Ensure your Smartphone’s Bluetooth feature is activated. Please refer to your Smartphone user guide for specific instruction. Ensure the speaker is within a maximum of 30 feet of your mobile headset(s) and there are no obstructions, such as thick solid wall or other electronic devices in between as it may cause shorter or interference transmission. If all the above steps do not resolve your problem, please turn off and restart the speaker The light show isn’t bright on my pool floor Check to see if the product is fully charged If your pool floor is colored vinyl, “pebble tech”, or other dark or colored material, some colors may not show up as well No light showCheck to see if the product is fully charged Press the light button on the speaker No sound/sound is low Make sure both your audio devise and GAME Bluetooth speaker are charged Make sure to turn up the volume on your audio devise and GAME Bluetooth speaker 4308_R0B_IM_1L_GAM_101915 Great American Merchandise & Events™ 16444 N. 91st Street Scottsdale, AZ 85260-1567 USA tel: 888.382.5988 fax: 602.957.7665 © 2015 GAME™: Great American Merchandise & Events™ All rights reserved. Designed in the USA. Made in China. U.S. Patents 7,413,319 & 7,717,582 email: [email protected] www.game-group.com CAUTION: Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the u…

Text truncated - open the document above for the full version.

Great American Merchandise & Events Agent Authorization Letter 2015/10/28 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : Tom Sollars /Director of Engineering Contact information / address: 16043 N.82nd street , Scottsdale, AZ 85260-1567, USA

Great American Merchandise & Events Long Term Confidentiality Request Letter 2015/10/28 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Bluetooth Speaker and Light Show MODEL : 4308, 4312 FCC ID: ALT4308 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Client’s name / title : Tom Sollars /Director of Engineering Contact information / address: 16043 N.82nd street , Scottsdale, AZ 85260-1567, USA

Great American Merchandise & Events Model Difference FCC ID: ALT4308 Model : 4308, 4312 All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Tom Sollars /Director of Engineering Contact information / address: 16043 N.82nd street , Scottsdale, AZ 85260-1567, USA

M/N: 4308 FCC ID: ALT4308 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 33 FCC Part 15C Test Report FCC ID: ALT4308 Product Name: Bluetooth Speaker and Light Show Trademark: N/A Model Name : 4308, 4312 Prepared For : Great American Merchandise & Events Address : 16043 N.82nd street , Scottsdale, AZ 85260-1567, USA Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Oct. 22 – Oct. 27, 2015 Date of Report : Oct. 28, 2015 Report No.: BCTC-151013046 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 33 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Great American Merchandise & Events Address ................................. : 16043 N.82nd street , Scottsdale, AZ 85260-1567, USA Manufacture's Name ............ : Shenzhen Yinlida Electronics Co.,Ltd Address ................................. : Building A ,Hengbang Industrial Park ,Lou village ,guangming New Dist,Shenzhen, China Product description Product name ........................... : Bluetooth Speaker and Light Show Trademark: Model Name: 4308, 4312 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 33 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 RADIATED EMISSION MEASUREMENT 13 3.1.1 RADIATED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 16 3.1.6 TEST RESULTS 17 4 . BANDWIDTH TEST 23 4.1 APPLIED PROCEDURES / LIMIT 23 4.1.1 TEST PROCEDURE 23 4.1.2 DEVIATION FROM STANDARD 23 4.1.3 TEST SETUP 23 4.1.4 EUT OPERATION CONDITIONS 23 4.1.5 TEST RESULTS 24 5 . BANDWIDTH OF FREQUENCY BAND EDGE 28 5.1 DEVIATION FROM STANDARD 28 5.2 TEST SETUP 28 5.3 EUT OPERATION CONDITIONS 28 5.4 TEST RESULTS 29 6 . ANTENNA REQUIREMENT 30 6.1 STANDARD REQUIREMENT 30 6.2 EUT ANTENNA 30 7 . EUT TEST PHOTO 31 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 33 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Speaker and Light Show Trade Name N/A Model Name 4308, 4312 Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter DC 5V from adapter input AC 120V/60Hz Battery DC 3.7V Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013046 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 33 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 247…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
