AMWUA2301RADAR DETECTOR

LONG RANGE Radar/Laser Detector User’s Manual R9 © 2020 Uniden America Corporation Irving, Texas Issue 1, February 2020 Printed in Korea CUSTOMER CARE At Uniden®, we care about you! If you need assistance, please do NOT return this product to your place of purchase Save your receipt/proof of purchase for warranty. Quickly find answers to your questions by: • Reading this User’s Manual. • Visiting our customer support website at www.uniden.com. Images in this manual may differ slightly from your actual product. DISCLAIMER: Radar detectors are illegal in some states. Some states prohibit mounting any object on your windshield. Check applicable law in your state and any state in which you use the product to verify that using and mounting a radar detector is legal. Uniden radar detectors are not manufactured and/or sold with the intent to be used for illegal purposes. Drive safely and exercise caution while using this product. Do not change settings of the product while driving. Uniden expects consumer’s use of these products to be in compliance with all local, state, and federal law. Uniden expressly disclaims any liability arising out of or related to your use of this product. CONTENTS CUSTOMER CARE ..........................................................................................................2 R9 EXTREME OVERVIEW ............................................................................5 FEATURES ........................................................................................................................5 WHAT’S IN THE BOXES? .............................................................................6 PARTS OF THE R9 EXTREME ......................................................................7 KEY PAD ............................................................................................................................7 DISPLAY UNIT .................................................................................................................9 MENU SYSTEM .........................................................................................11 BASIC OPERATIONS ................................................................................21 FEATURE DETAILS ...................................................................................22 LASER TRANSPONDER SETTING FOR DRAGON EYE ....................................22 AUTO DIM ......................................................................................................................23 Configure Auto Dim from MENU ..................................................................23 ALLOCATING MEMORY ............................................................................................23 USER MARKS (LASER AND RADAR SITES) .........................................................24 RED LIGHT CAMERA POINT DELETE ...................................................................25 HIGHWAY VS CITY MODE ........................................................................................25 POP MODE ....................................................................................................................26 MODE DISPLAY ............................................................................................................26 SCAN DISPLAY .............................................................................................................26 TIME DISPLAY ...............................................................................................................27 ALARM PRIORITIES.....................................................................................................27 THREATS .........................................................................................................................28 AUTO MUTE/AUTO MUTE VOLUME.....................................................................29 USER SPEED LIMIT ......................................................................................................29 QUIET RIDE ....................................................................................................................30 RED LIGHT CAMERA QUIET RIDE .........................................................................30 MAINTENANCE ........................................................................................30 MAINTAINING THE EQUIPMENT ...........................................................................30 UPDATING THE FIRMWARE/DATABASE .............................................................30 TROUBLESHOOTING ...............................................................................30 FCC/IC COMPLIANCE ..............................................................................31 FCC COMPLIANCE ......................................................................................................31 IC COMPLIANCE ..........................................................................................................32 ONE-YEAR LIMITED WARRANTY ...........................................................32 - 5 - UNIDEN LONG RANGE RADAR/LASER DETECTOR USER’S MANUAL R9 EXTREME R9 EXTREME OVERVIEW Uniden’s R9 Extreme is an advanced installed laser rdar detector with actual laser interruption capability. It provides outstanding detection range and usability. FEATURES • GPS on/off • User Mark Alert • Mute on/off and Mute Memory • Store and Update Database (up to 20,000 points should it be 2,000 points? • POI Alert on.off (Speed Camerra Alarm and Red-Light Camera Alarm) • Red-Light Camera Delete • Red-Light Camera Quiet Ride on/off • Front/Read X, K, MRCD, KA, POP, and Laser Detectuion on/off • OLED display (16 x 32 Full Color) • Keyboard (Mute, Dim, Volume +, Volume -, Mark, Menu, Power) • Volume Control (0 - 8) • Dim Mode (Auto, Bright, Dim, Dimmer, Dark, Off) • Operating Modes (Highway, City, Advanced) • Scan, Mode, and Time Displays • Background Color Options • Speed, Speed+Compass, Compass, Voltage, Alti…

Text truncated - open the document above for the full version.

Uniden America Corporation Feb 15, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for AMWUA2301 [Uniden America Corporation] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely,

Uniden America Corporation 6225 N. State highway 161, Suite 300, Irving Texas 75038 Date: January 03, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (RADAR DETECTOR / R9 / AMWUA2301) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be permanently withheld from public review. Permanent Confidential Request -. Schematics -. Block Diagram -. Operational Description SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Paul Roby / Manager

Uniden America Corporation 6225 N. State highway 161, Suite 300, Irving Texas 75038 Date: January 03, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (RADAR DETECTOR / R9 / AMWUA2301) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be short-term Confidentiality f or a period of 180 days after grant is issued. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual SPECIFY REASON FOR REQUEST (i.e. These documents contain detailed system and equipment descriptions and related information about the product, which we considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, we feel that this information would be of benefit to our competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Paul Roby / Manager

Uniden America Corporation 6225 N. State highway 161, Suite 300, Irving Texas 75038 Date: January 03, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 R E: LETTER OF AGENT AUTHORIZATION T o Whom It May Concern: We, the undersigned, hereby authorize Hyejin Lee/Deputy General Manager of Eurofins KCTL Co.,Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We a lso hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). T his agreement expires one year from the current date.

External photos of EUT

<Label format> Bottom of the device

Internal photos of EUT

verify No.376716449883 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008-A Page (2) of (17) KCTL-TIT004-006/6 KP22-07347 REPORT REVISION HISTORY Date Revision Page No 2023-01-10 Originally issued - 2023-02-02 Change the FCC ID - This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR23-SEF0008 is superseded by the report No. KR23-SEF0008-A. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008 Page (3) of (17) KCTL-TIT004-006/6 KP22-07347 Contents 1. Applicant information ..................................................................................................................... 4 2. Laboratory information ................................................................................................................... 5 3. Test system configuration .............................................................................................................. 6 3.1 Operation environment ....................................................................................................... 6 3.2 Measurement Uncertainty .................................................................................................. 7 4. Description of EUT .......................................................................................................................... 9 4.1 General information ............................................................................................................ 9 4.2 Product description ........................................................................................................... 10 4.3 Auxiliary equipments ........................................................................................................ 10 4.4 Test configuration .............................................................................................................. 11 4.5 Operating conditions ......................................................................................................... 11 5. Summary of test results ............................................................................................................... 12 5.1 Summary of EMI emission test results ............................................................................. 12 6. Test results .................................................................................................................................... 13 6.1 Radiated Emission ........................................................................................................... 13 7. EUT photographs .......................................................................................................................... 17 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008 Page (4) of (17) KCTL-TIT004-006/6 KP22-07347 1. Applicant information Applicant: Uniden America Corporation Address: 6225 N. State highway 161, Suite 300, Irving Texas 75038 Manufacturer: ATTOWAVE Co., Ltd. Address: 1005, 10F Leader's Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008 Page (5) of (17) KCTL-TIT004-006/6 KP22-07347 2. Laboratory information Address Eurofins KCTL Co.,Ltd. (Suwon Lab.) 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Telephone Number: 82 31 285 0894 Facsimile Number: 82 505 299 8311 FCC Site Designation No: KR0040 VCCI Registration No.: R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS NO.: KT231 SITE MAP Eurofins KCTL Co.,Ltd. Suwon city Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008 Page (6) of (17) KCTL-TIT004-006/6 KP22-07347 3. Test system configuration 3.1 Operation environment Temperature Humidity Pressure Chamber 10 m (RE) 22.1 °C 20.3 % R.H. - Test site These testing items were performed following locations; Test item Test site Conducted Emission Shielded Room Radiated Emission 10 m Chamber Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0008 Page (7) of (17) KCTL-TIT004-006/6 KP22-07347 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to uncertainties are test receiver, cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna frequency in…

Text truncated - open the document above for the full version.

Test setup photos - Radiated Emission 11.7 GHz ~ 12.2 GHz
