APIBAR51CNTRMSOUNDBAR

满足无卤要求； 满足不含有邻苯二甲酸盐要求。 此文件及附页属公司机密文件，版权属通力电子控股有限公司所有， 任何人未经允许不得复制、抄袭。任何部门如有需求，须向通力电子研发申请。 These files are confidential documents in company, The copyright totally belongs to Tonly electronic holdings Limited, Anybody who are unauthorized is forbidden to copy and plagiarize the files. Any Department must get permission from the Tonly R&D if they need to use them. FOR HUAWEI: 必须满足RoHS2.0、REACH要求； 必须符合TCL《公司环境管理物质标准》要求； 美国走向必须满足CP65要求 72-HMSB51-QSGD4 JBL BAR5.1 QSG 2021-5-28 V1.0 是 41 Harman N/A N/A N/A N/A N/A N/A N/A N/A XXXX N/A XXXX N/A N/A XXXX 76-XXXXXX-XXXXX JAN Harman EN等 40P NA NA 订装,双钉 4色+Pantone 172c,过水油 148mm105mm 80g铜板纸 80g铜板纸 XXXX XXXXXXXX XXXXXXXX XXXXXXXX XXXX XXXX XXXX N/A N/A N/A 71-XXXXXX-XXXXX 2019-09-06 v 69 工艺说明（尺寸单位：毫米（mm））： 蒋如意 QUICK START GUIDE BAR 5.1 SURROUND SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 1SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 15/25/2021 5:11:53 PM5/25/2021 5:11:53 PM SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 2SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 25/25/2021 5:11:53 PM5/25/2021 5:11:53 PM EN Before using this product, read the safety sheet carefully. DA Læs sikkerhedsarket omhyggeligt, før du bruger dette produkt. DE Lies vor der Verwendung dieses Produkts das Sicherheitsdatenblatt sorgfältig durch. ES Antes de usar este producto, lee la hoja de seguridad atentamente. FI Lue käyttöturvallisuustiedote huolellisesti ennen tuotteen käyttöä. FR Avant d’utiliser ce produit, lisez attentivement la fiche de sécurité. IT Prima di utilizzare questo prodotto, leggere attentamente la scheda di sicurezza. NL Lees het veilighsblad voordat u dit product gebruikt. NO Før du bruker dette produktet, må du lese sikkerhetsbladet nøye. PL Przed użyciem produktu, przeczytaj uważnie arkusz dot. bezpieczeństwa. PT Antes de usar este produto, leia cuidadosamente as instruções de segurança. RU Перед использованием изделия внимательно прочитайте инструкцию по безопасности. SV Läs säkerhetsbladet noggrant innan du använder produkten. SK Pred použitím tohto výrobku si pozorne prečítajte bezpečnostný hárok. PT-BR Antes de usar o produto, leia cuidadosamente esta ficha de segurança. ES-MX Antes de usar este producto, lea la hoja de seguridad con atención. KO 제품을 사용하기 전에 안전 관련 주의사항을 자세히 읽으십시오. ZH-TW 在使用本產品前，請仔細閱讀安全說明書。 ID Sebelum menggunakan produk ini, bacalah lembar panduan keselamatan dengan cermat. قبل استخدام هذا المنتج، اقرأ صحيفة بيانات السلامة بعناية. AR לפני השימוש במוצר זה, קרא בעיון את גיליון הבטיחות. HE SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 3SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 35/25/2021 5:11:53 PM5/25/2021 5:11:53 PM x 2 * x 2 x 2 x 2 x 2 x 2 (AAA) EN * Power cord quantity and plug type vary by regions. DA * Strømledningens længde og stiktype varierer efter region. DE * Anzahl und Steckertyp des Netzkabels weichen je nach Region ab. ES * El número y el tipo de cables de alimentación puede variar según la región. FI * Virtajohtojen määrä ja liitäntätyyppi vaihtelevat alueittain. FR * Le nombre de cordons secteur et les types des prises varient selon les régions. IT * Il numero dei cavi di alimentazione e il tipo di spina variano da regione a regione. NL * Aantal netsnoeren en type stekker is afhankelijk van de regio. NO * Antall strømkabler og kontakter varierer mellom områder. PL * Ilość przewodów zasilających i rodzaj wtyczki różnią się w zależności od regionu. PT * Os cabos de alimentação e o tipo de tomada variam de região para região. RU * Длина шнура питания и тип вилки зависит от региона. SV * Antalet strömkablar och kontakttyp varierar i olika regioner SK * Špecifikácia napájacieho kábla a typ zástrčky sa líšia podľa regiónov. PT-BR * O cabo de alimentação e o tipo de tomada variam de região para região. ES-MX * La cantidad de cables de alimentación y el tipo de enchufe varía según la región. KO * 전원 코드 수량 및 플러그 유형은 지역별로 다릅니다. ZH-TW * 電源線數量和插頭類型因區域而異。 ID * Jumlah kabel daya dan jenis steker berbeda-beda tergantung wilayah. تختلف كمية كبل الطاقة ونوع القابس حسب المناطق. * AR * כמות כבלי החשמל וסוג התקע משתנים בהתאם לאזור. HE SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 4SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 45/25/2021 5:11:53 PM5/25/2021 5:11:53 PM > 10cm/4” 1m/3ft 1 4 3 2 ≤8 mm/ 0.31" 4mm/ 0.16" ≥30 mm/1.18" SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 5SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 55/25/2021 5:11:54 PM5/25/2021 5:11:54 PM HDMI (ARC) HDMI OUT (TV ARC) OPTICAL * OPTICAL OPTICAL * * x 2 1 HDMI IN HDMI OUT (TV ARC) HDMI OUT 2 . . . HDMI (ARC) * HDMI OUT (TV ARC)HDMI IN SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 6SB_JBL_Bar5.1 & SUB_QSG_Global_Non MRM_CR_V36.indd 65/25/2021 5:11:54 PM5/25/2021 5:11:54 PM 1 2 4 3 5 POWER POWER HELLO EN The subwoofer and the soundbar will be paired automatically when both are powered on. DA Subwoofer og soundbar parres automatisk, når de tændes. DE Der Subwoofer und die Soundbar werden automatisch gekoppelt, wenn beide eingeschaltet sind. ES El subwoofer y la barra de sonido se emparejan automáticamente al encender ambos dispositivos. FI Subwoofer ja soundbar-kaiutin yhdistetään automaattisesti laitepariksi, kun molemmat on kytketty päälle. FR Le caisson de graves et la barre de son sont jumelés automatiquement lorsque les deux sont allumés. IT Il subwoofer e la soundbar si abbineranno automaticamente una volta accesi entrambi. NL De subwoofer en de soundbar worden automatisch gekoppeld wanneer beide worden ingeschakeld. NO Subwooferen og lydplanken vil bli paret automatisk når begge er slått på. PL Subwoofer oraz soundbar zostaną sparowane automatycznie po włączeniu zasilania. PT O subwoofer e a barra de som serão emparelhados automaticamente quando ambos estiverem ligados. RU Сабвуфер и звуковая панель будут сопряжены автоматически при включении обоих устройств. SV Subwoofern och soundbaren parkopplas automatiskt när de slås på. SK Subwoofer a soundbar sa automaticky spárujú po ich zapnutí. PT-BR O subwoofer …

Text truncated - open the document above for the full version.

RSS standard(s). For Wi-Fi 5G deviceFCC Caution:The device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. the frequency of operations outside the FCC grant of authorization for US operation according to Part 15.407 of the FCC rules.IC Caution:User should also be advised that:(i) The device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) the maximum antenna gain permitted for devices in the bands 5250 - 5350 MHz and 5470 - 5725 MHz shall comply with the e.i.r.p. limit: and (iii) The maximum antenna gain permitted for devices in the band 5725 - 5825 MHz shall operation as appropriate. (iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. 19. This apparatus is intended to be used only with the power supply and/or charging cable provided by the manufacturer. Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site at http://www.hc-sc.gc.ca/The radiated energy from the antennas connected to the wireless adapters conforms to the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 5 clause 4. SAR tests are conducted using recommended operating positions accepted by the FCC/ RSS band without distance attaching away from the body. Non-compliance with the above restrictions may result in violation of FCC RF exposure guidelines. Use Restriction Attention in France, operation is limited to indoor use within the band 5150-5350 MHz. EN 50332-1:2013 EN 50332-2:2013 14/02/2014 2013/56/EU 2013/56/EU 01/07/2015 2014/30/EU 2014/35/EU 2014/53/EU. TR02631_080_2425_J

Harman International Industries, Inc. 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES DATE : Jun. 10, 2021 Harman International Industries, Inc. 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Na me Damon Hu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-38826678-850 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by CETECOM GmbH, still resides with: Applicant name Harman International Industries, Inc. Address 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Yours sincerely, Signatory Na me Terry Shi Position Prin.Engineer,Regulatory Compliance, Quality Company Name Harman International Industries, Inc. Address 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Tel / Fax 86-75523189391 / 818-892-0325 E-Mail [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <06/10/2021> TO WHOM IT M AY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we request confidentiality for the following products: FCC ID: APIBAR51CNTRM Model name: BAR 5.1 CNTR For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos 180 days Internal Photos 180 days Block Diagram Schematics Test Setup Photos 180 days User’s Manual 180 days Tune Up 180 days Operational Descriptions Software security requirement The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Name: Terry Shi Company: Harman International Industries, Inc Address: 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Phone: 86-75523189391 F a x: 818-892-0325 E-Mail: [email protected]

Harman International Industries, Inc. 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Date: June 10, 2021 FCC ID: APIBAR51CNTRM Model Number: BAR 5.1 CNTR To Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 We, Harman International Industries, Inc. declare that this EUT (FCC ID: APIBAR51CNTRM) doesn’t have Ad Hoc mode function on “on-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name / Title: Terry Shi / Prin.Engineer, Regulatory Compliance, Quality Company: Harman International Industries, Inc. Address: 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Tel: 86-75523189391 Fax: 818-892-0325 E-Mail: [email protected]

DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page47of70 14.PhotosoftheEUT DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page48of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page49of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page50of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page51of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page52of70

5.1 Surround _ Sound bar: Back View - Scale: 1-1 Harman International. Confidential. Copyright © 2020 Color: Pantone Black C Material: Metal Finish: Matte Rear and Bottom Housing Color: Pantone 10393C (refer to the color sample) Finish: Metallic Paint - Semi-Glossy Material: Plastic No need Screws covers Color sample Wall Mounted Bracket Connector Names Color: Pantone Cool Grey 3C Material: Silk Print Finish: Matte 2.12 11.43 1.59 7.23 2.12 14.89 2.11 15.62 1.25 6.61 2.12 12.81 2.12 5.92 1.23 5.50 2.12 10.85 Compliances Color: Black Material: Silk Print Finish: Semi Matte (refer to the color sample) Color sample 5V500mA JBL Bar 5.1 Surround with wireless subwoofer /5.1 家庭影院条形音箱系统/ SOUNDBAR/MODEL/型号/: BAR 5.1 CNTR INPUT/输入/ 100-240V~, 50/60Hz, 175W FCC ID: APIBAR51CNTRM IC: 6132A-BAR51CNTRM CMIIT ID: 2019AJ5784 HVIN: JBL BAR5.1 CNTR This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Opera�on is subject to the following two condi�ons: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. CAN ICES-3(B)/NMB-3(B). This device is restricted to indoor use when opera�ng in the 5150 to 5350 MHz. 制造商Manufacturer: Harman Interna�onal Industries, Incorporated. 8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES. Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, Dolby Vision and the double-D symbol are trademarks of Dolby Laboratories. European Representa�ve: Harman Interna�onal Industries, Incorporated EMEA Liaison Office, Danzigerkade 16, 1013 AP Amsterdam, The Netherlands. UK business address: Ground Floor, Westside 2, London Road, Apsley, Hemel Hempstead, Her�ordshire, HP3 9TD, United Kingdom. Made in China/Сделано в Китае/중국산/ 中国制造 A/S 연락처: 02-553-3494 The terms HDMI, HDMI High-Defini�on Mul�media Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. 注意：请勿打 开机盖，以防触电。本机内部没有用户可以维修的零件，需要时，请交给有资格的维修人员进行维修。仅供海拔2000米及以下安全使用 R-C-SEC-BAR51CNTRM XXXXX-XX-XXXXX

DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page53of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page54of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page55of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page56of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page57of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page58of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page59of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page60of70 BT/2.4G/5GWiFiAntennaport2 2.4G/5GWiFiAntennaport1 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page61of70 BT/2.4G/5GWiFiAntenna2 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page62of70 2.4G/5GWiFiAntenna1

DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page63of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page64of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page65of70 SRDAntenna0 SRDAntenna1 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page66of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page67of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page68of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page69of70 DongguanDongdianTestingServiceCo.,Ltd.ReportNo.:DDT-R21050705-2E02 Page70of70 ENDOFREPORT

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 1 of 7 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Equipment under Test : SOUNDBAR Model No. : BAR 5.1 CNTR HVIN : JBL BAR5.1 CNTR Trade Mark : JBL FCC ID : APIBAR51CNTRM IC : 6132A-BAR51CNTRM Manufacturer : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES ■Report No.: DDT-R21050705-2E11 ■Issued Date: Jun. 17, 2021 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 2 of 7 TABLE OF CONTENTS Test report declares.......................................................................................................3 1. General information ........................................................................................................ 5 1.1. Description of Equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 6 2. RF Exposure evaluation ................................................................................................. 6 2.1. Requirement ................................................................................................................... 6 2.2. Calculation Method ........................................................................................................ 7 2.3. Estimation Result ........................................................................................................... 7 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 3 of 7 TEST REPORT DECLARE Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R21050705-2E11 Date of Receipt: May 15, 2021 Date of Test: May 15, 2021 ~ Jun. 17, 2021 Prepared By: Approved By: _________________ _____________________ Sam Li/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Equipment under Test : SOUNDBAR Model No. : BAR 5.1 CNTR HVIN : JBL BAR5.1 CNTR Trade mark : JBL Manufacturer : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 4 of 7 Revision history Rev. Revisions Issue Date Revised By --- Initial issue Jun. 17, 2021 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 5 of 7 1. General information 1.1. Description of Equipment EUT* Name : SOUNDBAR Model Number : BAR 5.1 CNTR EUT function description : Please reference user manual of this device Power supply : 100-240V~, 50/60Hz, 175W Radio Specification : Bluetooth V4.2, IEEE802.11b/g/n, IEEE802.11a/n/ac, SRD Operation frequency : Bluetooth: 2402MHz-2480MHz IEEE 802.11a: 5180MHz-5240MHz, 5260MHz-5320MHz, 5500MHz-5700MHz, 5745MHz-5825MHz IEEE 802.11n HT20: 5180MHz-5240MHz, 5260MHz-5320MHz, 5500MHz-5700MHz, 5745MHz-5825MHz IEEE 802.11n HT40: 5190MHz-5230MHz, 5270MHz-5310MHz, 5510MHz-5670MHz, 5755MHz-5755MHz IEEE 802.11ac HT20: 5180MHz-5240MHz, 5260MHz-5320MHz,5500MHz-5700MHz, 5745MHz-5825MHz IEEE 802.11ac HT40: 5190MHz-5230MHz, 5270MHz-5310MHz, 5510MHz-5670MHz, 5755MHz-5755MHz IEEE 802.11ac HT80: 5210MHz, 5290MHz, 5530MHz, 5610MHz, 5775MHz SRD: 5732-5848 MHz Modulation : Bluetooth: GFSK, /4-DQPSK, 8DPSK IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) SRD: FSK Data rate : Bluetooth: 1Mbps, 2Mbps, 3Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: 6.5, 13, 19.5, 26, 39, 52, 58.5, 65 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: 14.4, 28.9, 43.3, 57.8, 86.7, 115.6, 130.0, 144.4 Mbps IEEE 802.11n HT40: 30, 60, 90, 120, 180, 240, 270, 300 Mbps IEEE 802.11acHT20: 14.4, 28.8, 43.4, 57.8, 86.6, 115.6, 130, 144.4, 173.4 Mbps IEEE 802.11ac HT40: 30, 60, 90, 120, 180, 240, 270, 300, 360, 400 Mbps IEEE 802.11ac HT80: 65, 130, 195, 260, 390, 520, 585, 650, 780, 866.6 Mbps Antenna Type : Antenna 1: Dedicated FPC antenna, 2.4G band maximum PK gain: 2.97 dBi, 5G band maximum PK gain: 3.32 dBi Antenna 2: Dedicated FPC antenna, 2.4G band maximum PK gain: 2.36 dBi, 5G band maximum PK gain: 3.68 dBi SRD: Antenna 0: Integral PCB antenna, maximum PK gain: 1.57 dBi Antenna 1: Integral PCB antenna, maximum PK gain: 1.57 dBi Sample Type : Series production Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21050705-2E11 Page 6 of 7 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Acc…
