Charge 2 1 What’s in the box Quick Start Guide Guide de démarrage rapide Charge 2 x1 x1 x1 Quick Start Guide Guide de démarrage rapide Charge 2 2 Buttons 3 Connections Quick Start Guide Guide de démarrage rapide Charge 2 4 Bluetooth JBL Charge 2 JBL Charge 2 Quick Start Guide Guide de démarrage rapide Charge 2 5 Hands-free Quick Start Guide Guide de démarrage rapide Charge 2 6 Social mode 7 Warning Quick Start Guide Guide de démarrage rapide Charge 2 EN • Bluetooth version: 3.0 • Support: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Transducer: 2 x 45 mm • Rated Power input: 2 x 7.5W • Frequency response: 75Hz – 20kHz • Signal-to-noise ratio: >80 dB • Power supply: 5VDC, 2.0A USB Output: 5V, 2.1A (maximum) • Battery Type: Lithium-ion Polymer (3.7V, 6000mAh) • Battery charge time: 4 hrs @ 1.8A • Music playing time: up to 12 hours (varies by volume level and audio content) • Bluetooth transmitter power: 0-4 dBm • Bluetooth transmitter frequency range: 2.402 – 2.480 GHz • Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK • Dimensions (H x W x D): 79 mm x 184 mm x 75 mm • Weight: 540 g FR • Bluetooth version: 3.0 • Support: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Transducer: 2 x 45 mm • Rated Power input: 2 x 7.5W • Frequency response: 75Hz – 20kHz • Signal-to-noise ratio: >80 dB • Battery Type: Li-ion • Battery charge time: 4 hrs @ 1.8A • Music playing time: up to 12 hours (varies by volume level and audio content) • Bluetooth transmitter power: 0-4 dBm • Bluetooth transmitter frequency range: 2.402 – 2.480 GHz • Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK • Dimensions (H x W x D): 79 mm x 184 mm x 75 mm • Weight: 540 g FPO

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 ANT

2cm 8cm

Photo 7 Photo 8 Photo 9 BT module Photo 10 BT Antenna Photo 11 Photo 12 Photo 13 Photo 14

FCC ID: APICHARGE2 RF EXPOSURE EVALUATION METHOD FCC ID: APICHARGE2 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. BT 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 3.530 2.238 CH39 2441 2.963 1.978 CH78 2480 1.920 1.555 2Mbps CH00 2402 2.604 1.821 CH39 2441 1.874 1.539 CH78 2480 0.507 1.123 3Mbps CH00 2402 2.614 1.825 CH39 2441 1.876 1.540 CH78 2480 0.544 1.133 Remark: The best case gain of the antenna is 2.48dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.77 FCC ID: APICHARGE2 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] BT Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance, mm)] [√f(GHz)] Result Limit 1Mbps CH00 2.254 5 2.402 0.698 3 CH39 1.978 5 2.441 0.621 3 CH78 1.555 5 2.480 0.489 3 2Mbps CH00 1.821 5 2.402 0.564 3 CH39 1.539 5 2.441 0.481 3 CH78 1.123 5 2.480 0.354 3 3Mbps CH00 1.825 5 2.402 0.566 3 CH39 1.540 5 2.441 0.481 3 CH78 1.133 5 2.480 0.357 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: APICHARGE2 Product： Portable wireless stereo speaker Trade Name： JBL Model Name： JBL CHARGE2 Serial Model： N/A Report No.： NTEK-2014DC0321060F Prepared for Harman International Industries, Incorporated 8500 Balboa blvd, Northridge, CA91329, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 74 Report No.: NTEK-2014DC0321060F TEST RESULT CERTIFICATION Applicant’s name .................. : Harman International Industries, Incorporated Address .................................. : 8500 Balboa blvd, Northridge, CA91329, United States Manufacture's Name ............ : Harman International Industries, Incorporated Address .................................. : 8500 Balboa blvd, Northridge, CA91329, United States Manufactory 1 ....................... : TCL TECHNOLY ELECTRONICS (HUIZHOU) CO., LTD Address .................................. : Section 37, Zhongkai High-tech Development Zone, Huizhou Cit y Guang Dong Province, China, 516006 Manufactory 2 ....................... : Guoguang Electric Co., Ltd Address .................................. : No. 8 Jinghu Road, Xinhua Street, Huadu Reg, Guangzhou, 510800, P.R.China Product description Product name ........................... : Portable wireless stereo speaker Model and/or type reference : JBL CHARGE2 Standards ............................. : FCC Part15.247 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 21 Mar. 2014 ~10 Apr. 2014 Date of Issue ........................................... : 10 Apr. 2014 Test Result ............................................... : Pass Testing Engineer : (Jason Chen) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 74 Report No.: NTEK-2014DC0321060F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . AVERAGE TIME OF OCCUPANCY 35 5.1 APPLIED PROCEDURES / LIMIT 35 Page 4 of 74 Report No.: NTEK-2014DC0321060F Table of Contents Page 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 42 6.1 APPLIED PROCEDURES / LIMIT 42 6.1.1 TEST PROCEDURE 42 6.1.2 DEVIATION FROM STANDARD 42 6.1.3 TEST SETUP 42 6.1.4 EUT OPERATION CONDITIONS 42 6.1.5 TEST RESULTS 43 7 . BANDWIDTH TEST 49 7.1 APPLIED PROCEDURES / LIMIT 49 7.1.1 TEST PROCEDURE 49 7.1.2 DEVIATION FROM STANDARD 49 7.1.3 TEST SETUP 49 7.1.4 EUT OPERATION CONDITIONS 49 7.1.5 TEST RESULTS 50 8 . PEAK OUTPUT POWER TEST 56 8.1 APPLIED PROCEDURES / LIMIT 56 8.1.1 TEST PROCEDURE 56 8.1.2 DEVIATION FROM STANDARD 56 8.1.3 TEST SETUP 56 8.1.4 EUT OPERATION CONDITIONS 56 8.1.5 TEST RESULTS 57 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 63 9.1 DEVIATION FROM STANDARD 63 9.2 TEST SETUP 63 9.3 EUT OPERATION CONDITIONS 63 9.4 TEST RESULTS 64 10 . ANTENNA REQUIREMENT 72 10.1 STANDARD REQUIREMENT 72 10.2 EUT ANTENNA 72 11 . EUT TEST PHOTO 73 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 74 Report No.: NTEK-2014DC0321060F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 74 Report No.: NTEK-2014DC0321060F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted …
