APIHKADAPTStreaming wireless adaptor

Quick Start Guide Guide de demarrage rapide Buttons Connections What’s in the box x1 x1 Bluetooth® AUX input source FC2 WPS 1 2 1s Multi-room music streaming (without using HK app) 1s Single button Play / Stop functionality 3s Party Mode AUX FC2 Out of the box (Restore Factory Setting) LED StatusLED Behaviors Slash - White blinking Ring - Off Bluetooth® paring mode Bluetooth® reconnecting Bluetooth® connected, no streaming Bluetooth® connected, streaming LED StatusLED Behaviors Slash - Blue blinking Ring - Blue blinking Slash - Blue blinking Ring - Off Slash - Solid Blue Ring - Off Slash - Solid Blue Ring - Solid Blue Aux active Inactive LED StatusLED Behaviors Slash - Solid White Ring - Solid Green Slash - Solid White Ring - Off Network streaming Source switching LED StatusLED Behaviors 1x Slash - Solid White Ring - Solid White Ring - Multicolor blinking Party Mode LED StatusLED Behaviors 3s Ring - Multicolor blinking Mute LED StatusLED Behaviors FPO APP harmankardon.com/HK Omni 20 H/K Connect H/K Connect Setup and Control your Harman Kardon wireless system with the required HK Connect app. Setup and Control your Harman Kardon wireless system with the required HK Connect app. Setup and Control your Harman Kardon wireless system with the required HK Connect app. Setup and Control your Harman Kardon wireless system with the required HK Connect app. Setup and Control your Harman Kardon wireless system with the required HK Connect app. Full owners manual Propriétaires complètes manuelles Proprietari manuale completo Propietarios completos manuales Ausführliche Anleitung Полный Инструкции HK OMNI 20 FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Harman International Industries, Incorporated. Date (2014-06-24) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, Harman International Industries, Incorporated., 8500 Balboa Blvd, Northridge, CA 91329, United States , hereby authorize Brown Lu Shenzhen NTEK Testing Technology Co., Ltd. , 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China 0755-61156547 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 6 months duration. Type of equipment: Streaming wireless speaker Model name: HK OMNI 20 FCC ID: APIHKOMNI20 This authorization expires on 6 months duration. Sincerely, Company Officer: Fernando reyes/ Director Telephone Number: 818-895-8173 Email: [email protected]

Test Setup Photos

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FC2_Compliance_2014-04-11_V1 Complaince Silk Printing_ Black CMF : Black Glossy White CMF: White Glossy WPSAudio In Power Reset XXXXXX-XX Harman International Industries, Incorporated Connector indicator Silk Printing_ Black CMF : Cool gray 5C White CMF: Cool gray 5C XXXXXXXXXXX MSIP-CMM-HOE-HKOMNI20 XXX-JNXXXX This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS-Gen. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this must accept any interference received, including interference that may cause undesired operation. Can ICES-003 (B) / NMB-003 (B). Guoguang Electric Co., Ltd. In Mold_debossed 0.2mm

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 BT ANT WIFI ANT Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15

FCC ID: APIHKOMNI20 FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: APIHKOMNI20 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density FCC ID: APIHKOMNI20 MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS WIFI: Ant A Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (Numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11b 12.32 17.06 3.12(2.05dBi)0.0070 1 Pass 802.11g 11.42 13.87 3.12(2.05dBi)0.0057 1 Pass 802.11n-HT20 10.51 11.25 3.12(2.05dBi)0.0046 1 Pass WIFI: Ant B Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (Numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11b 12.53 17.91 3.34(2.16dBi)0.0077 1 Pass 802.11g 11.42 13.87 3.34(2.16dBi)0.0060 1 Pass 802.11n-HT20 10.62 11.53 3.34(2.16dBi)0.0050 1 Pass BT: Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (Numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 1Mbps 5.324 3.41 2.19(1.66dBi)0.0011 1 Pass 2Mbps 5.180 3.30 2.19(1.66dBi)0.0011 1 Pass 3Mbps 4.714 2.96 2.19(1.66dBi)0.0010 1 Pass Note: Note: The assess distance is 20cm.

FCC RADIO TEST REPORT FCC ID: APIHKOMNI20 Product： Streaming wireless speaker Trade Name： harman/kardon Model Name： HK OMNI 20 Serial Model： N/A Report No.： NTEK-2014DC0523061F1 Prepared for Harman International Industries, Incorporated. 8500 Balboa Blvd, Northridge, CA 91329, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 87 Report No.: NTEK-2014DC0523061F1 TEST RESULT CERTIFICATION Applicant’s name........ Harman International Industries, Incorporated. Address ........................ 8500 Balboa Blvd, Northridge, CA 91329, United States Manufacture's Name... Harman International Industries, Incorporated. Address ........................ 8500 Balboa Blvd, Northridge, CA 91329, United States Product description Product name .................Streaming wireless speaker Model and/or type reference ..................... HK OMNI 20 Serial Model .................... N/A Standards.................... FCC Part15.247: Oct. 1, 2013 Test procedure ................ ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 23 May 2014 ~20 Jun. 2014 Date of Issue..................................... 20 Jun. 2014 Test Result......................................... Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 87 Report No.: NTEK-2014DC0523061F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 19 3.2.1 RADIATED EMISSION LIMITS 19 3.2.2 TEST PROCEDURE 20 3.2.3 DEVIATION FROM TEST STANDARD 20 3.2.4 TEST SETUP 21 3.2.5 EUT OPERATING CONDITIONS 22 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 23 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 24 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 27 4 . POWER SPECTRAL DENSITY TEST 47 4.1 APPLIED PROCEDURES / LIMIT 47 4.1.1 TEST PROCEDURE 47 4.1.2 DEVIATION FROM STANDARD 47 4.1.3 TEST SETUP 47 4.1.4 EUT OPERATION CONDITIONS 47 4.1.5 TEST RESULTS 48 5 . BANDWIDTH TEST 60 5.1 APPLIED PROCEDURES / LIMIT 60 5.1.1 TEST PROCEDURE 60 Page 4 of 87 Report No.: NTEK-2014DC0523061F1 Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 60 5.1.3 TEST RESULTS 61 6 . PEAK OUTPUT POWER TEST 73 6.1 APPLIED PROCEDURES / LIMIT 73 6.1.1 TEST PROCEDURE 73 6.1.2 DEVIATION FROM STANDARD 73 6.1.3 TEST SETUP 73 6.1.4 EUT OPERATION CONDITIONS 73 6.1.5 TEST RESULTS 74 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 76 7.1 DEVIATION FROM STANDARD 76 7.2 TEST SETUP 76 7.3 EUT OPERATION CONDITIONS 76 7.4 TEST RESULTS 77 8 . ANTENNA REQUIREMENT 87 8.1 STANDARD REQUIREMENT 87 8.2 EUT ANTENNA 87 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 87 Report No.: NTEK-2014DC0523061F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 87 Report No.: NTEK-2014DC0523061F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 87 Report No.: NTEK-2014DC0523061F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Streaming wireless speaker Trade Name harman/kardon Model Name HK OMNI 20 Serial Model N/A Model Difference N/A Product Description The EUT is a Streaming wireless speaker Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz Modulation Type: CCK/OFDM/DBPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):150/144.44/130/117/ 115.56/104/86.67/78/52/6.5Mbps Number Of Channel 802.11b/g/n20MHz:11CH Antenna Designation: Please see Note 3. Output Power(Conducted): Ant A: 802.11b: 12.32 dBm (Max.) 802.11g: 11.42 dBm (Max.) 802.11n(20M): 10.51 dBm (Max.) Ant B: 802.11b: 12.53 dBm (Max.) 802.11g: 11.42 dBm (Max.) 802.11n(20M): 10.62 dBm (Max.) Antenna Gain (dBi) Ant A:3.12 dbi Ant B:3.34 dbi Based on the application, features, or specification exhibited in Us…
