APIJBLGO3HPORTABLE BLUETOOTH SPEAKER

and FCC limits may The equipment et États-Unis

Play ×2 ×1 Bluetooth pairing WHAT’S IN THE BOX ON SettingsBluetooth Bluetooth DEVICES Now Discoverable Connected JBL Go 3 GO 3 chargING WATERPROOF DUSTPROOF IP67 1m 30 mins IP67 12 TECH SPEC Transducer: 43 x 47 mm / 1.5” Output power: 4.2 W RMS Frequency response: 110 Hz - 20 kHz Signal-to-noise ratio: > 85 dB Battery type: Li-ion polymer 2.7 Wh Battery charge time: 2.5 hours (5 V 1 A) Music play time: up to 5 hours (dependent on volume level and audio content) Bluetooth® version: 5.1 Bluetooth® profile: A2DP 1.3, AVRCP 1.6 Bluetooth® transmitter frequency range: 2402 MHz − 2480 MHz Bluetooth® transmitter power: ≤ 8 dBm (EIRP) Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK Dimensions (W x H x D): 87.5 x 75 x 41.3 mm / 3.4 x 2.7 x 1.6 ” Weight: 0.209 kg / 0.46 lbs DA Hvad er der i kassen Bluetooth-parring Afspil Oplader Oplader Lavt batteriniveau Vandtæt støvtæt IP67 Teknisk specifikation Transducer: 43 x 47 mm/ 1,5” Udgangseffekt: 4,2 W RMS Frekvensområde: 110 Hz - 20 kHz Signal til støj-forhold: > 85 dB Batteritype: Li-ion polymer 2,7 Wh Batteriopladningstid: 2,5 Timer (5 V / 1 A) Musik spilletid: op til 5 timer (afhængig af lydstyrkeniveau og lydindhold) Bluetooth® version: 5.1 Bluetooth® profil: A2DP 1.3, AVRCP 1.6 Bluetooth® senderfrekvensområde: 2402 MHz − 2480 MHz Bluetooth® sendereffekt: ≤ 8 dBm (EIRP) Bluetooth® sendemodulation: GFSK, π/4 DQPSK, 8DPSK Mål (B x H x D): 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Vægt:0,209 kg / 0,46 lbs DE Verpackungsinhalt Bluetooth-Kopplung Wiedergabe Wird geladen Wird geladen Akku schwach Wasser- und staubdicht IP67 Techn. Daten Schallgeber: 43 x 47 mm (1,5") Ausgangsleistung: 4,2 W RMS Frequenzbereich: 110 Hz – 20 kHz Rauschabstand: > 85 dB Akku-Typ: Lithium-Ionen-Polymer 2,7 Wh Akkuladedauer: 2,5 Stunden (5 V / 1 A) Musikwiedergabezeit: Bis zu 5 Stunden (abhängig von Lautstärke und Audioinhalt) Bluetooth®-Version: 5.1 Bluetooth®-Profil: A2DP 1.3, AVRCP 1.6 Frequenzbereich für die Bluetooth®-Übertragung: 2402–2480 MHz Bluetooth®- Übertragungsleistung: ≤ 8 dBm (EIRP) Bluetooth®- Übertragungsmodulation: GFSK, π/4 DQPSK, 8DPSK Abmessungen (B x H x T): 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Gewicht:0,209 kg (0,46 lbs) EL Τι είναι στο κουτί Ζεύξη Bluetooth Αναπαραγωγή Φόρτιση Φόρτιση Χαμηλή στάθμη μπαταρίας Αδιάβροχο, Ανθεκτικό στη σκόνη IP67 Τεχνικά χαρακτηριστικά Μετατροπέας: 43 x 47 mm/ 1,5” Ισχύς εξόδου: 4,2 W RMS Συχνότητα απόκρισης: 110 Hz - 20 kHz Αναλογία ωφέλιμου σήματος προς τον θόρυβο:> 85 dB Τύπος μπαταρίας: Πολυμερών ιόντων λιθίου 2,7 Wh Χρόνος φόρτισης μπαταρίας: 2,5 ώρες (5 V / 1 A) Διάρκεια αναπαραγωγής μουσικής: έως 5 ώρες (διαφέρει ανάλογα με την ένταση ήχου και το περιεχόμενο μουσικής) Έκδοση Bluetooth®: 5.1 Προφίλ Bluetooth®: A2DP 1.3, AVRCP 1.6 Εύρος ζώνης συχνοτήτων του πομπού Bluetooth®: 2402 MHz − 2480 MHz Ισχύς πομπού Bluetooth®: ≤ 8 dBm (EIRP) Διαμόρφωση πομπού Bluetooth®:GFSK, π/4 DQPSK, 8DPSK Διαστάσεις (Β x Υ x Β): 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Βάρος:0,209 kg / 0,46 lbs ES Contenido de la caja Emparejamiento Bluetooth Reproducción Carga Carga Batería baja A prueba de agua y polvo IP67 Especificaciones técnicas Transductor: 43 x 47 mm/1,5” Potencia de salida: 4,2 W RMS Intervalo de frecuencias: 110 Hz - 20 kHz Relación señal-ruido: >85 dB Tipo de batería: Polimérica de ion-litio 2,7 Wh Tiempo de carga de la batería: 2,5 horas (5 V / 1 A) Tiempo de reproducción de música: hasta 5 horas (depende del nivel de volumen y el contenido del audio) Versión de Bluetooth®: 5.1 Perfil de Bluetooth®: A2DP 1.3, AVRCP 1.6 Intervalo de frecuencias del transmisor Bluetooth®: 2402 MHz − 2480 MHz Potencia del transmisor Bluetooth®: ≤8 dBm (EIRP) Modulación del transmisor Bluetooth®: GFSK, π/4 DQPSK, 8DPSK Dimensiones (Ancho x Alto x Profundidad): 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Peso:0,209 kg FI Laatikon sisältö Bluetooth-parimuodostus Toista Lataus Lataus Akku vähissä Vedenpitävä Pölynkestävä IP67 Tekniset tiedot Muunnin: 43 x 47 mm / 1,5 tuumaa Lähtöteho: 4,2 W RMS Taajuusvaste: 110 Hz - 20 kHz Kohinanvaimennussuhde: > 85 dB Akkutyyppi: Li-ion polymeeri 2,7 Wh Akun latausaika: 2,5 h @ 5 V / 1 A Musiikin toistoaika: jopa 5 tuntia (riippuu äänenvoimakkuudesta ja äänisisällöstä) Bluetooth®-versio: 5.1 Bluetooth® -profiili: A2DP 1.3, AVRCP 1.6 Bluetooth®-lähettimen taajuusalue: 2402 MHz − 2480 MHz Bluetooth® -lähettimen teho: ≤ 8 dBm (EIRP) Bluetooth®-lähettimen modulaatio:GFSK, π/4 DQPSK, 8DPSK Mitat (L x K x S): 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Paino:0,209 kg / 0,46 paunaa FR Contenu de l’emballage Jumelage Bluetooth Lire Charge Charge Batterie faible Étanchéité à l’eau et à la poussière IP67 Spéc. techniques Haut-parleur : 43 x 47 mm / 1,5” Puissance de sortie : 4,2 W RMS Réponse en fréquence : 110 Hz - 20 kHz Rapport signal sur bruit : > 85 dB Type de batterie : Li-ion polymère 2,7 Wh Temps de charge de la batterie : 2,5 heures (5 V / 1 A) Durée de lecture de la musique : jusqu’à 5 heures (selon le niveau du volume et le contenu audio) Version Bluetooth® : 5.1 Profils Bluetooth® : A2DP 1.3, AVRCP 1.6 Plage de fréquences de l'émetteur Bluetooth® : 2402 MHz - 2480 MHz Puissance de l'émetteur Bluetooth®: ≤ 8 dBm (PAR) Modulation de l'émetteur Bluetooth®:GFSK, π/4 DQPSK, 8DPSK Dimensions (L x H x P) : 87,5 x 75 x 41,3 mm / 3.4 x 2.7 x 1.6 ” Poids : 0,209 kg / 0,46 lbs HU A csomag tartalma Bluetooth-párosítás Lejátszás Töltés Töltés Akkumulátor töltöttsége alacsony Vízálló, porálló IP67 Műszaki spec. Transzduktor: 43 x 47 mm / 1,5” Kimeneti tápellátás: 4,2 W RMS Frekvenciaválasz: 110 Hz – 20 kHz Jel-zaj arány: > 85 dB Akkumulátor típus: Li-ion polimer 2,7 Wh Akkumulátor töltési idő: 2,5 óra (5 V / 1 A) Zenelejátszási idő akár 5 óra (a hangerőszinttől és a hangfájl tartalmától függően) Bluetooth®-változat: 5.1 Bluetooth®-profil: A2DP 1.3, AVRCP 1.6 Bluetooth®-adó frekvenciatartománya: 2402 MHz − 2480 MHz Bluetooth®-adó teljesítménye: ≤ 8 dBm (EIRP) Bluetooth®-adó modulációja: GFSK, π/4 DQPSK, 8DPSK Méretek (Sz x…

Text truncated - open the document above for the full version.

Harman International Industries, Inc. Agent Authorization Company: Harman International Industries, Inc. Address: 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Product Name: PORTABLE BLUETOOTH SPEAKER Model Number(s): GO3H Product Description: Portable Speaker with Bluetooth function We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/05/21 Name: Tim Song Title: Manager Company: Harman International Industries, Inc.

Harman International Industries, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/05/21 Subject; Request for Confidentiality FCC ID: APIJBLGO3H To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Tim Song Title: Manager

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 75 of 85 16. Photos of The EUT Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 76 of 85 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 77 of 85 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 78 of 85

R210-141575

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 51 of 57 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 52 of 57 BT Antenna Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 53 of 57 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 54 of 57 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 55 of 57 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 56 of 57 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E5 Page 57 of 57 END OF REPORT

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20022613-1E8 Page 1 of 5 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Equipment under Test : PORTABLE BLUETOOTH SPEAKER Model No. : GO3H Trade Mark : JBL FCC ID : APIJBLGO3H Manufacturer : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES ■Report No.: DDT-R20022613-1E8 ■Issued Date: May 18, 2020 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20022613-1E8 Page 2 of 5 Table of Contents Test report declares.......................................................................................................3 1. General Information .................................................................................................................. 5 1.1. Description of equipment ......................................................................................................... 5 1.2. Assess laboratory ..................................................................................................................... 5 2. RF Exposure evaluation for FCC ........................................................................................... 5 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20022613-1E8 Page 3 of 5 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R20022613-1E8 Date of Receipt: Apr. 08, 2020 Date of Test: Apr. 08, 2020 ~ May 18, 2020 Prepared By: Approved By: ___________________ _____________________ Talent Zhang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Equipment under Test : PORTABLE BLUETOOTH SPEAKER Model No. : GO3H Trade mark : JBL Manufacturer : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20022613-1E8 Page 4 of 5 Revision History Rev. Revisions Issue Date Revised By --- Initial issue May 18, 2019 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20022613-1E8 Page 5 of 5 1. General Information 1.1. Description of equipment 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected] CNAS Registration No. CNAS L6451; A2LA Certificate Number: 3870.01; FCC Designation Number: CN1182; FCC Test Firm Registration Number: 540522 Industry Canada Site Registration Number: 10288A-1 2. RF Exposure evaluation for FCC According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2402MHz,5.21dBm 3.32mW) output power] (3.32/5) ·[√2.402(GHz)] =1.030<3.0 for 1-g SAR Then SAR evaluation is not required END OF REPORT Eut* Name : PORTABLE BLUETOOTH SPEAKER Model Number : GO3H EUT Function Description : Please reference user manual of this device Power Supply : DC 5 V from external AC Adapter DC 3.7V Polymer Li-ion built-in battery Radio Specification : Bluetooth V5.1 Operation Frequency : 2402MHz-2480MHz Modulation : GFSK, /4-DQPSK, 8DPSK Data Rate : 1 Mbps, 2 Mbps, 3 Mbps Antenna Type : PCB antenna, maximum PK gain: 2.28 dBi Sample Type : Series production

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 1 of 72 FCC ID AND ISED CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Equipment under Test : PORTABLE BLUETOOTH SPEAKER Model No. : GO3H Trade Mark : JBL FCC ID : APIJBLGO3H IC : 6132A-JBLGO3H Manufacturer : Harman International Industries, Inc. Address : 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES ■Report No.: DDT-R20022613-1E4 ■Issued Date: May 18, 2020 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 2 of 72 Table of Contents Test report declares.......................................................................................................4 1. Summary of Test Results ............................................................................................... 6 2. General Test Information ............................................................................................... 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 8 2.3. Assistant equipment used for test .................................................................................. 8 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Deviations of test standard............................................................................................. 8 2.6. Test environment conditions .......................................................................................... 9 2.7. Test laboratory ............................................................................................................... 9 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment Used During Test ....................................................................................... 10 4. Maximum Peak Output Power ..................................................................................... 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 12 4.5. Original test data .......................................................................................................... 13 5. 20dB Bandwidth and 99% Bandwidth .......................................................................... 16 5.1. Block diagram of test setup .......................................................................................... 16 5.2. Limits ............................................................................................................................ 16 5.3. Test procedure ............................................................................................................. 16 5.4. Test result ..................................................................................................................... 16 5.5. Original test data .......................................................................................................... 17 6. Carrier Frequency Separation ...................................................................................... 20 6.1. Block diagram of test setup .......................................................................................... 20 6.2. Limits ............................................................................................................................ 20 6.3. Test procedure ............................................................................................................. 20 6.4. Test result ..................................................................................................................... 20 6.5. Original test data .......................................................................................................... 21 7. Number of Hopping Channels ...................................................................................... 22 7.1. Block diagram of test setup .......................................................................................... 22 7.2. Limits ............................................................................................................................ 22 7.3. Test procedure ............................................................................................................. 22 7.4. Test result ..................................................................................................................... 22 7.5. Original test data .......................................................................................................... 23 8. Dwell Time .................................................................................................................... 24 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 3 of 72 8.1. Block diagram of test setup .......................................................................................... 24 8.2. Limits ...........................................................…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 37 of 72 In 3m Anechoic Chamber, test setup diagram for frequency above 1GHz: Note: For harmonic emissions test an appropriate high pass filter was inserted in the input port of AMP. 10.2. Limit (1) FCC 15.205 Restricted frequency band MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 1 0.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.1772&4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.2072&4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 108-121.94 1718.8-1722.2 13.25-13.4 6.31175-6.31225 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 ( 2 ) 13.36-13.41 1 Until February 1, 1999, this restricted band shall be 0.490-0.510 MHz. 2 Above 38.6 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 38 of 72 (2) FCC 15.209 Limit. FREQUENCY MHz DISTANCE Meters FIELD STRENGTHS LIMIT V/m dB(V)/m 0.009 ~ 0.490 300 2400/F(kHz) 67.6-20log(F) 0.490 ~ 1.705 30 24000/F(kHz) 87.6-20log(F) 1.705 ~ 30.0 30 30 29.54 30 ~ 88 3 100 40.0 88 ~ 216 3 150 43.5 216 ~ 960 3 200 46.0 960 ~ 1000 3 500 54.0 Above 1000 3 74.0 dB(V)/m (Peak) 54.0 dB(V)/m (Average) Note: (1) The emission limits shown in the above table are based on measurements employing a CISPR QP detector except for the frequency bands 9-90kHz, 110-490kHz and above 1000MHz, radiated emissions limits in these three bands are based on measurements employing an average detector. (2) At frequencies below 30MHz, measurement may be performed at a distance closer than that specified, and the limit at closer measurement distance can be extrapolated by below formula: Limit 3m (dBuV/m)= Limit 30m (dBuV/m) + 40Log(30m/3m) (3) Limit for this EUT All the emissions appearing within 15.205 restricted frequency bands shall not exceed the limits shown in 15.209, all the other emissions shall be at least 20dB below the fundamental emissions or comply with 15.209 limits. 10.3. Test procedure (1) EUT was placed on a non-metallic table, 80 cm above the ground plane inside a semi-anechoic chamber for below 1G and 150 cm above the ground plane inside a fully-anechoic chamber for above 1G. (2) Test antenna was located 3m from the EUT on an adjustable mast, and the antenna used as below table. Test frequency range Test antenna used Test antenna distance 9kHz-30MHz Active Loop antenna 3m 30MHz-1GHz Trilog Broadband Antenna 3m 1GHz-18GHz Double Ridged Horn Antenna(1GHz-18GHz) 3m 18GHz-40GHz Horn Antenna(18GHz-40GHz) 1m According ANSI C63.10:2013 clause 6.4.4.2 and 6,5.3, for measurements below 30 MHz, the loop antenna was positioned with its plane vertical from the EUT and rotated about its vertical axis for maximum response at each azimuth position around the EUT. And the loop antenna also be positioned with its plane horizontal at the specified distance from the EUT. The center of the Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 39 of 72 loop is 1 m above the ground. for measurement above 30MHz, the trilog Broadband Antenna or Horn Antenna was located 3m from EUT, Measurements were made with the antenna positioned in both the horizontal and vertical planes of Polarization, and the measurement antenna was varied from 1 m to 4 m. in height above the reference ground plane to obtain the maximum signal strength. (3) Below pre-scan procedure was first performed in order to find prominent frequency spectrum radiated emissions from 9 kHz to 25 GHz: (a) Scanning the peak frequency spectrum with the antenna specified in step (3), and the EUT was rotated 360 degree, the antenna height was varied from 1m to 4m (Except loop antenna, it’s fixed 1m above ground.) (b) Change work frequency or channel of device if practicable. (c) Change modulation type of device if practicable. (d) Change power supply range from 85% to 115% of the rated supply voltage (e) Rotated EUT though three orthogonal axes to determine the attitude of EUT arrangement produces highest emissions. Spectrum frequency from 9 kHz to 25 GHz (tenth harmonic of fundamental frequency) was investigated, and the emission levels are 20 dB below the limit were detected from 18 GHz to 25 GHz, so below final test was performed with frequency range from 9 kHz to 18 GHz. (4) For final emissions measurements at each frequency of interest, the EUT was rotated and the antenna height was varied between 1m and 4m in order to maximize the emission. Measurements in both horizontal and vertical polarities were made and the data was recorded. In order to find the maximum emission, the relative positions of equipment and all of the interface cables were changed according to ANSI C63.10:2013 on Radiated Emission test. (5) The emissions from 9 kHz to 1GHz were measured based on CISPR QP detector except for the frequency bands 9-90 kHz, 110-490 kHz, for emissions from 9 kHz-90 kHz,110 kHz-490 kHz and above 1 GHz were measured based on average detector, for emissions above 1 GHz, peak emissions also be measured and need comply with Peak limit. (6) The emissions from 9 kHz to 1 GHz, QP or average values were measured with EMI receiver with below RBW. Frequency band RBW 9 kHz-150 kHz 200 Hz 150 kHz-30 MHz 9 kHz 30 MHz-1 GHz 120 kHz (7) For emissions above 1GHz, both Peak and Average level were measured with Spectrum Analyzer, and the RBW is set at 1 MHz, VBW is set at 3 MHz for Peak measure; According ANSI C63.10:2013 clause 4.1.4.2.2 procedure for average measure. (8) X axis, Y axis, Z axis are tested, and worse setup X axis is reported. Dongguan Dongdian Test…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 73 of 85 15. Test Setup Photograph Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20022613-1E4 Page 74 of 85
