APIJBLJR310BTBluetooth Headset

BUTTON COMMAND WHAT’S IN THE BOX Choose "JBL JR310BT" to connect ON SettingsBluetooth Bluetooth DEVICES JBL JR310BT Now Discoverable Connected ON SettingsBluetooth Bluetooth DEVICES JBL JR310BT Now Discoverable Connected Choose "JBL JR310BT" to connect POWER ON AND AUTOMATICALLY ENTER PAIRING MODE ×1×1 > 2S > 2 S led behaviors Manual Pairing power on & connect Charging 2S Manual pairing mode > 2S quick start guide JR 310 BT ×1 BT CONNECTING BT connected POWER ON/OFF Low battery CHARGING FULLY CHARGED ×2 TECH SPEC Model: Driver size: Power supply: Weight: Battery type: Charging time: Music playtime with BT on: Frequency Response: Impedance: Sensitivity: Maximum SPL: Microphone sensitivity: Bluetooth version: Bluetooth profile version: Bluetooth transmitter frequency range: Bluetooth transmitter power: Bluetooth transmitter modulation: Maximum operation temperature: JR310BT 32 mm / 1.25 " Dynamic driver 5.0 V 1.0 A 115 g / 0.254 lbs Lithium-ion Polymer (410 mAh, 3.7 V) <2 hrs from empty 30 hrs 20 Hz – 20 kHz 32 ohm 90 dB SPL @ 1kHz / 1mW 80 dB -40 ± 3 dBV @ 1kHz / Pa 5.0 A2DP V1.3, AVRCP V1.5,HFP V1.6 2.402 GHz -2.480 GHz <4 dbm GFSK, π/4 DQPSK, 8DPSK 45 °C DADEEL Tekniske specifikationer Model:JR310BT Enhedsstørrelse:1,25" (32 mm) dynamisk enhed Strømforsyning:5,0 V 1,0 A Vægt:115 g Batteritype:Lithium-ion Polymer (410 mAH, 3,7 V) Opladningstid:< 2 timer fra tom Musik-spilletid med Bluetooth tændt:30 timer Frekvensområde:20 Hz – 20 kHz Impedans:32 ohm Følsomhed:90 dB SPL @ 1kHz / 1mW Maksimal SPL:80 dB Mikrofonfølsomhed:-40 ± 3 dBV @ 1kHz / Pa Bluetooth-version:5.0 Bluetooth-profil version:A2DP V1.3, AVRCP V1.5,HFP V1.6 Bluetooth-sendere Frekvensområde :2,4 GHz - 2,4835 GHz Bluetooth-sendeeffekt:<4 dbm Bluetooth-sendemodulation:GFSK, π/4 DQPSK, 8DPSK Maksimal driftstemperatur:45 °C Techn. Daten Modell:JR310BT Treibergröße:Dynamischer 32 mm (1,25")-Treiber Energieversorgung:5,0 V 1,0 A Gewicht:115 g (0,254 lbs) Akku-Typ:Lithium-Ionen-Akku (410 mAh, 3,7 V) Ladezeit:< 2 Std. ab leerem Akku Musikwiedergabezeit mit aktiviertem BT:30 Std. Frequenzbereich:20 Hz – 20 kHz Impedanz:32 ohm Empfindlichkeit:90 dB SPL bei 1 kHz / 1 mW Maximaler Schalldruckpegel:80 dB Mikrofonempfindlichkeit:-40 ± 3 dBV bei 1 kHz / Pa Bluetooth-Version:5.0 Bluetooth-Profilversion:A2DP V1.3, AVRCP V1.5, HFP V1.6 Frequenzbereich für die Bluetooth- Übertragung:2,4 GHz - 2,4835 GHz Bluetooth-Übertragungsleistung:<4 dbm Bluetooth-Übertragungsmodulation:GFSK, π/4 DQPSK, 8DPSK Maximale Betriebstemperatur:45 °C Τεχνικά χαρακτηριστικά Μοντέλο:JR310BT Μέγεθος οδηγού:32 mm / 1,25" Δυναμικός οδηγός Τροφοδοσία:5,0 V 1,0 A Βάρος:115 g / 0,254 lbs Τύπος μπαταρίας:Μπαταρία πολυμερών ιόντων λιθίου (410 mAH, 3,7 V) Χρόνος φόρτισης:< 2 ώρες όταν είναι άδεια Διάρκεια αναπαραγωγής μουσικής με το BT ενεργοποιημένο:30 ώρες Συχνότητα απόκρισης:20 Hz – 20 kHz Αντίσταση:32 ohm Ευαισθησία:90 dB SPL @ 1kHz / 1mW Μέγιστο SPL:80 dB Ευαισθησία μικροφώνου:-40 ± 3 dBV @ 1kHz / Pa Έκδοση Bluetooth:5.0 Έκδοση προφίλ Bluetooth:A2DP V1.3, AVRCP V1.5,HFP V1.6 Εύρος συχνοτήτων πομπού Bluetooth:2,4 GHz - 2,4835 GHz Ισχύς πομπού Bluetooth:<4 dbm Διαμόρφωση πομπού Bluetooth:GFSK, π/4 DQPSK, 8DPSK Μέγιστη θερμοκρασία λειτουργίας:45 °C HVAD ER DER I ÆSKEN TÆND OG FORBIND Tænd, og gå automatisk til parringstilstand Vælg "JBL JR310BT" for at oprette forbindelse MANUEL PARRING Manuel parringstilstand Vælg "JBL JR310BT" for at oprette forbindelse STYRING MED KNAP VERPACKUNGSINHALT EINSCHALTEN UND VERBINDEN Einschalten und automatisch in den Kopplungsmodus wechseln Wähle „JBL JR310BT“ zum Verbinden MANUELLE KOPPLUNG Manueller Kopplungsmodus Wähle „JBL JR310BT“ zum Verbinden TASTENBEFEHL ΠΕΡΙΕΧΟΜΕΝΟ ΤΗΣ ΣΥΣΚΕΥΑΣΙΑΣ ΑΝΑΜΜΑ & ΣΥΝΔΕΣΗ Άναμμα και αυτόματη μετάβαση στη λειτουργία ζεύξης Επιλέξτε “JBL JR310BT” για να συνδεθείτε ΧΕΙΡΟΚΙΝΗΤΗ ΖΕΥΞΗ Λειτουργία χειροκίνητης ζεύξης Επιλέξτε “JBL JR310BT” για να συνδεθείτε OPLADNING LED-SIGNALER Tænd/sluk Bluetooth forbinder Bluetooth forbundet Lavt batteri Opladning Helt opladt WIRD GELADEN LED-VERHALTEN Ein/Aus BT wird verbunden BT verbunden Schwacher Akku WIRD GELADEN Voll geladen ΕΝΤΟΛΗ ΠΛΗΚΤΡΟΥ ΦΟΡΤΙΣΗ ΛΕΙΤΟΥΡΓΙΑ LED Άναμμα/Σβήσιμο Σύνδεση BT BT συνδέθηκε Χαμηλή στάθμη μπαταρίας ΦΟΡΤΙΣΗ Έχει φορτίσει πλήρως Пользовательские наушники Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500 Сделано в Китае Импортер: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к. 1 Гарантийный период: 1 год Срок службы: 2 года Информация о сервисных центрах: www.harman.com/ru Техническая поддержка: 8 (800) 700 0467 Организация, уполномоченная на принятие претензий потребителей: OOO “ХАРМАН РУС СиАйЭс“ Товар сертифицирован Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного номера изделия, следующих после разделительного знака «-». Кодировка соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.). HP_JBL_JR310BT_QSG_SOP_V7 TO PROLONG BATTERY LIFESPAN, FULLY CHARGE AT LEAST ONCE EVERY 3 MONTHS. BATTERY LIFE VARIES BY USE AND SETTINGS. DA FOR AT FORLÆNGE BATTERIETS LEVETID SKAL DU OPLADE DET HELT MINDST ÉN GANG HVER 3. MÅNED. BATTERIETS LEVETID VARIERER AFHÆNGIG AF BRUG OG INDSTILLINGER. DE ZUM VERLÄNGERN DER AKKULEBENSDAUER MINDESTENS EINMAL ALLE 3 MONATE VOLLSTÄNDIG AUFLADEN. DIE AKKULEBENSDAU- ER VARIIERT JE NACH ANWENDUNG UND EINSTELLUNGEN. EL ΓΙΑ ΝΑ ΠΑΡΑΤΕΙΝΕΤΕ ΤΗ ΔΙΑΡΚΕΙΑ ΖΩΗΣ ΤΗΣ ΜΠΑΤΑΡΙΑΣ, ΦΟΡΤΙΣΤΕ ΤΗΝ ΠΛΗΡΩΣ ΤΟΥΛΑΧΙΣΤΟΝ ΜΙΑ ΦΟΡΑ ΚΑΘΕ 3 ΜΗΝΕΣ. Η ΔΙΑΡΚΕΙΑ ΖΩΗΣ ΤΗΣ ΜΠΑΤΑΡΙΑΣ ΠΟΙΚΙΛΛΕΙ ΑΝΑΛΟΓΑ ΜΕ ΤΗ ΧΡΗΣΗ ΚΑΙ ΤΙΣ ΡΥΘΜΙΣΕΙΣ. ES PARA PROLONGAR LA DURACIÓN DE LA BATERÍA, CÁRGALA COMPLETAMENTE POR LO MENOS UNA VEZ CADA 3 MESES. LA DURACIÓN DE LA BATERÍA DEPENDE DEL USO Y DE LOS AJUSTES. FI PIDENNÄ AKUN KÄYTTÖIKÄÄ LATAAMALLA SE TÄYTE…

Text truncated - open the document above for the full version.

SSA2011_JBL_Non-waterproof_Safety Sheet_Global_CR_V11.indd 1 12/2/2019 5:26:59 PM 18. Do not expose batteries to excessive heat such as sunshine, fire or the like. 19. This apparatus is intended to be used only with the power supply and/or charging cable provided by the manufacturer. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. THE LIGHTNING FLASH WITH AN ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE" WITHIN THE PRODUCT'S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE PRODUCT. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION FCC AND IC STATEMENT FOR USERS (USA AND CANADA ONLY)This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.CAN ICES-3(B)/NMB-3(B)FCC SDOC SUPPLIER'S DECLARATION OF CONFORMITYHARMAN International hereby declares that this equipment is in compliance with the FCC Part 15 Subpart B.The declaration of conformity may be consulted in the support section of our Web site, accessible from www.jbl.comFederal Communication Commission Interference StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help.Caution: Changes or modifications not expressly approved by HARMAN could void the user's authority to operate the equipment. For Products That Transmit RF Energy:FCC AND IC INFORMATION FOR USERSThis device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation.FCC/IC Radiation Exposure StatementThis equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. ENGLISH IMPORTANT SAFETY INSTRUCTIONSFor all products:1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install this apparatus in accordance with the manufacturer's instructions. 8. Do not install this apparatus near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point where they exit from the apparatus. 11. Use only attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, or the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped. 15. Do not expose this apparatus to dripping or splashing, and ensure that no objects filled with liquids, such as vases, are placed on the apparatus. 16. To disconnect this apparatus from the AC mains completely, disconnect the power- supply cord plug from the AC receptacle. 17. The mains plug of the power-supply cord shall remain readily operable. SSA2011_JBL_Non-waterproof_Safety Sheet_Global_CR_V11.indd 2 12/2/2019 5:26:59 PM FOR ALL EU COUNTRIES:For products that include audio out Prevention of hearing loss Caution: Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of time.For France, the products have been tested to comply with the Sound Pressure Level requirement laid down in the applicable NF EN 50332-1:2013 and/or EN 50332-2:2013 standards as required by French Article L.5232-1. Note: To prevent possible hearin…

Text truncated - open the document above for the full version.

WARRANTY CARD / BON DE GARANTIE / TARJETA DE GARANTÍA / CERTIFICATO DI GARANZIA / GARANTIEKARTE / ГАРАНТИЙНЫЙ ТАЛОН / CARTÃO DE GARANTIA / GARANTIKORT / TAKUUKORTTI / KARTA GWARANCYJNA / ΚΑΡΤΑ ΕΓΓΥΗΣΗΣ / GARANTI / JÓTÁLLÁSI KÁRTYA / GARANTIEKAART / GARANTIKORT / GARANTİ BELGESİ / بطاقة ضمان / תעודת אחריות SET UP INFORMATION & PRODUCT REGISTRATION Congratulations with the purchase of your new Product. We have done our utmost to make your experience the best one possible. If you have any questions when setting up your Product and would like some helpful hints, we recommend that you visit the relevant country specific support website for your Product: www.jbl.com. There you will also find relevant contact information. If you cannot find the information you are looking for, please contact the vendor that sold the Product to you or contact the relevant JBL customer support center by electronic mail or phone. We recommend that you register your Product via the relevant country specific website for your Product. Your registration will allow us to inform you about updates for certain products, possible new offers and new Products and/or applications. Registering is easy; just follow the instructions on the relevant country specific website for your Product. NOTE: THIS LIMITED WARRANTY DOES NOT APPLY TO CONSUMERS IN THE EUROPEAN ECONOMIC AREA (EEA) MEMBER STATES AND THE RUSSIAN FEDERATION AS THEY ARE PROTECTED BY LOCAL CONSUMER LAW AND BENEFIT FROM LOCAL STATUTORY WARRANTIES LIMITED WARRANTY WHO IS PROTECTED BY THE WARRANTY This limited warranty (the “Limited Warranty”) protects only the original end-user (“you” or “your”), and is not transferable and is applicable only in the country (excluding EEA member states and the Russian Federation) in which you originally purchased your JBL Product (the “Product”). Any attempt to transfer this warranty shall immediately make this warranty void. LIMITED WARRANTY HARMAN International Industries, Incorporated (“HARMAN”) is the manufacturer and through its local subsidiary, warrants to you that the Product (including components provided in/with the Product) will be free from defects in workmanship and materials for a period of ONE year from the date of retail purchase by you (the “Warranty Period”). During the Warranty Period, the Product (including components), will be repaired or replaced at HARMAN’s option, without charge for either parts or labor OR at HARMAN’s sole option, the price of the Product may be refunded, subject to depreciation based on your purchase price for the Product pro-rated over the remaining balance of the Warranty Period. Any warranty service or replacement of parts will not extend the Warranty Period. This Limited Warranty does not cover defects which are a result of: (1) damage caused by accident, unreasonable use or neglect (including the lack of reasonable and necessary maintenance); (2) damage during shipment (claims must be presented to the carrier); (3) damage to, or deterioration of, any accessory or decorative surface; (4) damage resulting from failure to follow instructions contained in your owner’s manual; (5) damage resulting from the performance of repairs by someone other than an authorized JBL service center; (6) deterioration of component parts, the nature of which is to become worn or depleted with use, such as batteries and headphone ear pads. Furthermore, this Limited Warranty covers only actual defects within the Product itself, and does not cover the cost of installation or removal from a fixed installation, setup or adjustments, claims based on misrepresentation by the seller, performance variations resulting from installation-related circumstances such as source quality or AC power or Product modifications, any unit on which the serial number has been effaced, modified or removed, or units used for other than home use. This Limited Warranty is valid only for JBL products purchased from an authorized dealer. Except to the extent expressly prohibited in your jurisdiction by applicable law, all implied warranties, including fitness for a particular purpose and merchantability are hereby excluded and in no event shall HARMAN or any HARMAN subsidiary be liable for any indirect, direct, incidental, special or consequential loss or damages whatsoever (including, without limitation, other pecuniary loss) arising out of the use of or inability to use the Product, even if HARMAN and/or a HARMAN subsidiary have been advised of the possibility of such damages. To any extent that HARMAN cannot lawfully disclaim implied warranties under this Limited Warranty, all such implied warranties are limited in duration to the duration of this warranty. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitations on the duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary by jurisdiction. HOW TO OBTAIN WARRANTY SERVICE Contact the dealer who sold you this Product, or contact JBL customer support using the contact information on the relevant country specific support website for your Product to request warranty service. To validate your right to this Limited Warranty, you must provide the original sales invoice or other proof of ownership and date of purchase. Do not return your Product without prior authorization from the corresponding dealer or HARMAN. Warranty repair of the HARMAN Product must be carried out by an authorized dealer or service center. Unauthorized warranty repair will void the warranty and is performed at your sole risk. You are also welcome to consult the relevant country specific HARMAN support website for your Product for helpful hints. WHO PAYS FOR WHAT This Limited Warranty covers all expenses for labor and materials required for the repair OR replacement of the Product that is found to be defective, and…

Text truncated - open the document above for the full version.

Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Product name: Bluetooth Headset Model number: JR310BT Responsible Party – U.S. Contact Information Company name: HARMAN INTERNATIONAL INDUSTRIES INC Address: 8500 Balboa Blvd Nothridge CA 91329,UNITED STATES Internet contact information: www.jbl.com FCC Compliance Statement (e.g., products subject to Part 15) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Harman International Industries, Inc Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant.

Harman International Industries, Incorporated 8500 Balboa Blvd. Northridge, CA 91329 USA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: APIJBLJR310BT To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Company Name: Harman International Industries, Inc Contact Name: Tim Song Title of Person：Sr Compliance Manager Address: 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Date: 07/28/2020

Harman International Industries, Incorporated 8500 Balboa Blvd. Northridge, CA 91329 USA DATE : 7/28/2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request f or Short-Term Confidentiality Company name: Harman International Industries, Inc FCC ID: APIJBLJR310BT FCC Part 15 Certification Pursuant to Sections 0.457 and 0.459 of t he commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality f or the following items prior t o marketing the device.: (1)Test Setup Photos (2)External Photos (3)Internal Photos (4)User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Sincerely, Signature Company Name: Harman International Industries, Inc Contact Name: Tim Song Title of Person：Sr Compliance Manager Address: 8500 Balboa Boulevard, Northridge, CA 91329, UNITED STATES Date: 07/28/2020

Appendix I External Photographs Page 2 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-1 View of EUT-2 Page 3 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-3 View of EUT-4 Page 4 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-5

CMIIT ID:XXXXXXXXXX FCC ID: APIJBLJR310BT Model: JR310BT Bluetooth headset IC: 6132A-JBLJR310BT XXXXX/SDPPI/2020/4117 XXXXX-XX-XXXXX H a r m a n I n t e r n a t i o n a l I n d u s t r i e s , I n c . , 8 5 0 0 B a l b o a B o u l e v a r d , N o r t h r i d g e , C A 9 1 3 2 9 U S A . M a d e i n C h i n a / 中 国 制 造 右耳壳 A / S 연 락 처 : 0 2 - 5 5 3 - 3 4 9 4 С Д Е Л А Н О В К И Т А Е Left extension arm of earphone right extension arm of earphone

Appendix II Internal Photographs Page 2 of 5 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Open View of EUT Internal View of EUT-1 Page 3 of 5 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-2 Internal View of EUT-3 Page 4 of 5 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-4 Internal View of EUT-5 Antenna Page 5 of 5 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-6

FCC ID: APIJBLJR310BT According to KDB 447498 D01 General RF Exposure Guidance v06, section 4.3.1 At 100 MHz to 6 GHz and for test separation distances ≤ 50mm, the SAR test exclusion threshold is determined according to the following [(max. power of channel, including tune-up tolerance, ㎽) / (min. test separation distance, ㎜)] x [√f(㎓)] ≤ 3.0 1. SAR test exclusion threshold Frequency: 2 480 MHz (min. separation distances = 5 mm) SAR test exclusion thresholds (5 ㎜) = 3 x 5 / (√ 2.480 ) = 9.525 ㎽ Test mode Max. Tune-up Tolerance (mW) SAR Test Exclusion Thresholds (5mm) (mW) Classic BT 1.12 9.525 Calculation value : 2.00 (㎽) / 5 (㎜) x √ 2.480 = 0.630 So, Calculation value ≤ 3.0 Remark: -For Classic BT Max. conducted power is 1.12 (㎽), so 2.00 (㎽) was calculated. -When the minimum test separation distance is < 5 ㎜, a distance of 5 ㎜ is applied to determine SAR test exclusion. 2. Conclusion: No SAR is required.

CFR 47 FCC PART 15 SUBPART C ISED RSS-247 ISSUE 2 CERTIFICATION TEST REPORT For Bluetooth Headset MODEL NUMBER: JR310BT FCC ID: APIJBLJR310BT IC: 6132A-JBLJR310BT REPORT NUMBER: 4789485754-5 ISSUE DATE: June 01, 2020 Prepared for HARMAN INTERNATIONAL INDUSTRIES INC 8500 Balboa Blvd Nothridge CA 91329,UNITED STATES Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi-Tech Development Zone Dongguan, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to th e test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. REPORT No.: 4789485754-5 Page 2 of 114 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0086 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 06/01/2020 Initial Issue REPORT No.: 4789485754-5 Page 3 of 114 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0086 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Clause Test Items FCC/ISED Rules Test Results 1 20dB Bandwidth and 99% Occupied Bandwidth FCC 15.247 (a) (1) RSS-247 Clause 5.1 (a) RSS-Gen Clause 6.7 Pass 2 Conducted Output Power FCC 15.247 (b) (1) RSS-247 Clause 5.1 (b) Pass 3 Carrier Hopping Channel Separation FCC 15.247 (a) (1) RSS-247 Clause 5.1 (b) Pass 4 Number of Hopping Frequency 15.247 (a) (1) III RSS-247 Clause 5.1 (d) Pass 5 Time of Occupancy (Dwell Time) 15.247 (a) (1) III RSS-247 Clause 5.1 (d) Pass 6 Conducted Bandedge FCC 15.247 (d) RSS-247 Clause 5.5 Pass 7 Radiated Bandedge and Spurious FCC 15.247 (d) FCC 15.209 FCC 15.205 RSS-247 Clause 5.5 RSS-GEN Clause 8.9 RSS-GEN Clause 8.10 Pass 8 Conducted Emission Test For AC Power Port FCC 15.207 RSS-GEN Clause 8.8 Pass 9 Antenna Requirement FCC 15.203 RSS-GEN Clause 6.8 Pass Note: 1.This test report is only published to and used by the applicant, and it is not for evidence purpose in China. 2.The measurement result for the sample received is <Pass> according to < CFR 47 FCC PART 15 SUBPART C >< ISED RSS-247 > when <Accuracy Method> decision rule is applied…

Text truncated - open the document above for the full version.
