APIJBLL75MS2WIRELESS SPEAKER

ENEN Pg 1 of 3 L75MS QSG | Part No: 950-0594-001 | Rev 1.0 © 2021 HARMAN International Industries, Incorporated. All rights reserved. L75ms Integrated Music System Quick Start Guide 1. Verify Box Contents 1x L75ms Integrated Music System 1x Speaker Grille 1x RF Remote 1x Region Specific Power Cord 2. Determine Speaker Location Set the bass contour switch based on the speakers proximity to side boundaries such as walls and inside a bookcase or cabinet. When close to a boundary the switch should be in the -3dB position in order to maintai n level bass response. Away from side boundaries such as walls. BASS CONTOUR 0dB -3dB Close to side boundaries suc h as walls or when the speaker is inside of a cabinet or bookcase. BASS CONTOUR 0dB -3dB 3. Connect Physical Sources Sub Out: Single RCA to Powered Sub (Optional) Aux In: 3.5mm (1/8in) Stereo Ethernet: Connect to port on wireless router for streaming Phono: Stereo RCA plus Ground HDMI ARC: ARC from TV 4. Pair the Remote - 12 Press & Hold >2 sec Press & Hold >3 sec www.jbl.com/specialtyaudio EN Pg 2 of 3 L75MS QSG | Part No: 950-0594-001 | Rev 1.0 © 2021 HARMAN International Industries, Incorporated. All rights reserved. 5. Connect to a Network For a Wired Connection Connect the Ethernet port on the rear to the port on a wireless router using a CAT-5e or higher cable. For a Wi-Fi Direct Connection 1. On your mobile device, download and open the Google Home App. 2. Follow Google Home instructions to add devices. 3. Follow the prompts for adding devices. Note: We recommend giving the speaker a common name so that it can be easily found for streaming later. NOTE: If a name other than L75ms is selected during this step, write it down as it will be what is used to connect to the unit when streaming or using Bluetooth. 'ŽŽŐůĞ,ŽŵĞ Turning Off Network Network functionality can be turned Off should it be required. The same buttons are used to turn the network On and Off. Note: When network is Off the following conditions exist. • Speaker cannot be used for Network streaming when in or out of standby • Speaker can be used for Bluetooth streaming when out of standby • Button on top panel must be pressed to wake the unit from standby Allow <1min to allow unit to wake up from standby before using the remote or connecting via Bluetooth. Apple Airplay To listen to audio via AirPlay on the speaker, ensure your Apple device is connected to the same network as the Receiver and simply select the Speaker as the AirPlay audio playback device. Note: The speaker will appear as L75MS within the AirPlay speaker menu. 6. Connect a Source via Bluetooth Select the Bluetooth Source Select L75ms in your devices Bluetooth menu Press & Hold >3 sec 231 7. Listening to Streaming Media Sources Apple Airplay To listen to audio via AirPlay on the speaker, ensure your Apple device is connected to the same network as the Receiver and simply select the Speaker as the AirPlay audio playback device. Note: The speaker will appear as L75MS within the AirPlay speaker menu. Spotify Your phone or tablet may be used as a remote control. Visit spotify.com/connect t o for details. Press Simultaneously + Press Simultaneously ENEN Pg 3 of 3 L75MS QSG | Part No: 950-0594-001 | Rev 1.0 © 2021 HARMAN International Industries, Incorporated. All rights reserved. 8. Trademarks and Licenses Apple ® , AirPlay ® and the AirPlay Logo™, iPod ® , iPhone ® and iPad ® are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. AirPlay 2 works with iPhone ® , iPad ® , and iPod touch ® with iOS 11.4 or later, Mac with OS X ® Mountain Lion or later, and PC with iTunes ® 10.2.2 or later. The Spotify software is subject to third party licenses that can be found here: https://developer.spotify.com/legal/third-party-licenses/ The Wi-Fi CERTIFIED™ logo is a registered trademark of Wi-Fi Alliance ® . Google, Google Play, Chromecast, and other related marks are trademarks of Google LLC. The Google Assistant requires an internet connection and is not available in certain countries and languages. Availability and react of certain features and services are device, service, and network-dependent and may not be available in all areas. Controlling certain devices in your home requires compatible smar t devices. Subscriptions for services and applications may be required and additional terms, conditions and/or charges may apply. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. MP3MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson multimedia. Flac FLAC Decoder Copyright © 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008 Josh Coalson • Redistribution and use in source and binary forms, with or without modification, are perm itted provided that the following conditions are met: • Redistribution of source code must retain the above copyright notice, this list of conditions and the following disclaimer. • Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. • Neither the name of the Xiph.org Foundation nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS 'AS IS' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A P ARTICULAR PURPOSE AR E DISCLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT…

Text truncated - open the document above for the full version.

Harman International Industries, Inc Authority letter FCC Date: 3/14/2022 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: APIJBLL75MS2 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch and Kobe Jian in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Harman International Industries, Inc. This authorization is valid until further written notice from the applicant. Name (Printed): Terry Shi Title: Prin.Engineer,Regulatory Compliance, Quality Signature: On behalf of Company: Harman International Industries, Inc

Harman International Industries, Inc Confidential letter FCC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Harman International Industries, Inc 8500 Balboa Boulevard Northridge, California, 91329, United States Regarding: Confidentiality Request regarding application for FCC ID: APIJBLL75MS2 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Name (Printed): Terry Shi Title: Prin.Engineer,Regulatory Compliance, Quality Signature: On behalf of Company: Harman International Industries, Inc

SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Declaration Applicant Declaration Letter Applicant Legal Business Name Harman International Industries, Inc Address 8500 Balboa BoulevardNorthridge, 91329, California, United States Grantee Code API FCC ID APIJBLL75MS2 Authorized Contact Name Terry Shi Contact Email [email protected] Contact Phone 86-75523189391 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 3/14/2022 Print Name: Terry Shi Title: Prin.Engineer,Regulatory Compliance, Quality *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Rev:0.0

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 1 of 4 Appendix - External Photos for GZCR2201000012AT Test Model No.: L75ms SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 4 of 4

100-240V ~ 50/60Hz 350W Max. POWER PHONO (MM) SUB AUX USB 5V 350 mA BASSRESET ETHERNET HDMI ARC L75ms 350 Max 100-240 ~ SERVICE CONTOUR 0dB R L --- INOUT -3dB approved by the party responsible for compliance could void the user’s authority to operate the equipment This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. FCC ID: APIJBLL75MS2 / IC: 6132A-JBLL75MS2. CAN ICES-003(B)/NMB-003(B) HVIN: V Harman International Industries, Incorporated 8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES European Representative: Harman International Industries, Inc. EMEA Liaison Oce, Danzigerkade 16, 1013 AP Amsterdam, The Netherlands. UK business address: Ground Floor, Westside 2, London Road, Apsley, Hemel Hempstead, Hertfordshire, HP3 9TD, United Kingdom. Designed and Engineered in USA Made In China / Сделано в Китай / R-R-SEC-L75ms XXX-XXXXXX Wireless Speaker 2000 R63234 JBL L75ms_Rear Panel Silk_Rev4_FINAL220316 CMIIT ID: 2021DJ17189 XXXXXXXXXXXXXX 5.2/5.3 GHz

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.0 Page: 1 of 15 Appendix - Internal Photos for GZCR2201000012AT Test Model No.: L75ms EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 2 of 15 EUT Constructional Details (EUT Photos) EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 3 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 4 of 15 Wi-Fi ANT connector Wi-Fi & BT ANT connector EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 5 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 6 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 7 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 8 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 9 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 10 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 11 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 12 of 15 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 13 of 15 Wi-Fi ANT Wi-Fi & BT ANT EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 14 of 15 Ant1 for BT and 2.4G/5G Wi-Fi EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 15 of 15 Ant2 for 2.4G/5G Wi-Fi only

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR220100001206 Page: 1 of 12 FCC ID: APIJBLL75MS2 Kobe Jian EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2201000012AT Applicant:Harman International Industries, Incorporated Address of Applicant:8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES Manufacturer:Harman International Industries, Incorporated Address of Manufacturer:8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES Factory:Guoguang Electric Co., Ltd. Address of Factory:No.8 Jinghu Road, Xinya Street, Huadu Reg, Guangzhou, China Equipment Under Test (EUT): EUT Name:WIRELESS SPEAKER Model No.: L75ms Trade Mark:JBL Standard(s) : 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2022-01-06 Date of Evaluation: 2022-03-02 to 2022-05-07 Date of Issue: 2022-05-09 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001206 EMC-TRF-03 Rev 1.0 Page: 2 of 12 Revision Record VersionReport No.DateRemark 01GZCR2201000012062022-05-09Original Authorized for issue by: Curry Wu/Project Engineer Ricky Liu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001206 EMC-TRF-03 Rev 1.0 Page: 3 of 12 2Evaluation Summary Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001206 EMC-TRF-03 Rev 1.0 Page: 4 of 12 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................7 4.3Facility...............................................................................................................................................7 4.4Deviation from Standards..................................................................................................................8 4.5Abnormalities from Standard Conditions...........................................................................................8 5Technical Requirements Specification..................................................................................................9 5.1General Description of Applied Standards........................................................................................9 5.2RF Exposure Evaluation....................................................................................................................9 5.2.1Limit & Test Method......................................................................................................................9 5.2.2Conclusion..................................................................................................................................10 6EUT Constructional Details (EUT Photos)...........................................................................................12 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001206 EMC-TRF-03 Rev 1.0 Page: 5 of 12 4General Information 4.1Details of E.U.T. Power supply:AC 100-240V 50/60Hz DC 3V for remote controller Cable(s):About 1.2m x 2 wires unscreened AC mains cable For Bluetooth BLE Operation Frequency:2402MHz to 2480MHz Modulation Type:GFSK Number of Channels:40 Channel Spacing:2MHz Antenna Type:Integral antenna Antenna Gain:5dBi For Bluetooth Classic Operation Frequency:2402MHz to 2480MHz Modulation Type:GFSK, pi/4DQPSK, 8DPSK Number of Channels:79 Channel Spacing:1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type:Integral antenna Antenna Gain:5dBi For 2.4 GHz Wi-Fi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels:802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing:5MHz Antenna Type:Integral antenna Antenna Gain: ANT1:5dBi ANT2:5dBi Two antennas can simultaneous transmission. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001206 EMC-TRF-03 Rev 1.0 Page: 6 of 12 For 5 GHz Wi-Fi Operation Frequency (20MHz): U-NII-1: 5180-5240MHz; U-NII-2A: 5260-5320MHz; U-NII-2C: 5500- 5700MHz; U-NII-3: 5745-5825MHz Operation Frequency (40MHz): U-NII-1: 5190-5230MHz; U-NII-2A: 5270-5310MHz; U-NII-2C: 5510- 5670MHz; U-NII-3: 5755-5795MHz Operation Frequency (80MHz): U-NII-1: 5210MHz; U-NII-2A: 5290MHz; U-NII-2C: 5530-5610MHz; U-NII-3: 5775MHz Modulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK); 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM); 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) Channel Spacing: 802.11a/n(HT20)/ac(HT20): 20MHz; 802.11n(HT40)/ac(HT40): 40MHz; 802.11ac(HT80): 80MHz DFS Function:Slave without Radar detection TPC Function:Without TPC function Antenna Type:Integral Antenna Antenna Gain: ANT1:7dBi ANT2:7dBi Two antennas can simultaneous transmission. SGS-CSTC Standards Techni…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.0 Report No.: GZCR220100001203 Page: 1 of 90 FCC ID: APIJBLL75MS2 Kobe Jian EMC Laboratory Manager TEST REPORT Application No.: GZCR2201000012AT Applicant: Harman International Industries, Incorporated Address of Applicant: 8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES Manufacturer: Harman International Industries, Incorporated Address of Manufacturer: 8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES Factory: Guoguang Electric Co., Ltd. Address of Factory: No.8 Jinghu Road, Xinya Street, Huadu Reg, Guangzhou, China Equipment Under Test (EUT): EUT Name: WIRELESS SPEAKER Model No.: L75ms Trade Mark: JBL Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2022-01-06 Date of Test: 2022-03-02 to 2022-05-07 Date of Issue: 2022-05-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001203 Page: 2 of 90 Revision Record Version Report No. Date Remark 01 GZCR220100001203 2022-05-09 Original Authorized for issue by: Curry Wu/Project Engineer Ricky Liu/Reviewer EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001203 Page: 3 of 90 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence N/A 47 CFR Part 15, Subpart C 15.247(a)(1), (g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Emission Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR220100001203 Page: 4 of 90 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 6 4.4 Test Location ...................................................................................................................................... 7 4.5 Test Facility ........................................................................................................................................ 7 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ........................................................................................... 8 5 Equipment List .......................................................................................................................................... 9 6 Radio Spectrum Technical Requirement ............................................................................................. 12 6.1 Antenna Requirement ...................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................... 12 6.2 Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence ............... 13 6.2.1 Test Requirement: ........................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.0 Page: 1 of 3 Appendix - Test Setup Photos for GZCR220100001202 to GZCR220100001205 Test Model No.: L75ms SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.0 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.0 Page: 3 of 3 Radiated Emissions which fall in the restricted bands & Radiated Spurious Emissions
