Everest 100 Quick Start Guide Guide de démarrage rapide Everest 100 S, M, L mushroom ear tips S, M, L Freebit ™ ergonomic ear tips Overview – Buttons & LEDs 1 Turn on headphone to pair 3 Cable clip 2 >3s LED Status LED behaviors Pairing mode Quick Start Guide Guide de démarrage rapide Everest 100 To turn on Bluetooth to pair 3a To control music with MFB 4 JBL Everest 100 JBL Everest 100 LED Status LED behaviors Connected Disconnected Low battery Slow Twice Slow Quick Start Guide Guide de démarrage rapide Everest 100 More controls for music with MFB 5 To control call with MFB 6 Next track Previous track Short Press x2 Short Press x3 long press x1 Answer call Reject call x1 Hang up Quick Start Guide Guide de démarrage rapide Everest 100 Multi-point connect 7 Charge battery 8 JBL Everest 100 JBL Everest 100 LED Status LED behaviors Charging battery Battery is fully charged Quick Start Guide Guide de démarrage rapide Everest 100 • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Musicplaytime:8hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 ES • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Musicplaytime:8hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 EN FPO • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Music play time: 8 hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 PT • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Music play time: 8 hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 FR FPO FPO Quick Start Guide Guide de démarrage rapide Everest 100 • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Musicplaytime:8hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 NL • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Music play time: 8 hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 NO • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Musicplaytime:8hours • Earbud dimension W x H x L (mm): 14.7 x 14.8 x 30.4 • Mic housing diemnsion W x H x L (mm): 9.1 x 7.2 x 42.3 • Weight (kg): 0.016 • Model: V100BT • Driver size: 5.8mm • Dynamic frequency response range: 10-22k Hz • Driver sensitivity: 96dB / 1kHz, 1mW • Maximum SPL: 103dB • Rated power input: 5mW • Microphone sensitivity: -42dBV/Pa • Bluetooth ® transmitted power: <4dBm • Bluetooth ® transmitted modulation: GFSK pi/4, DQPSK, 8-DPSK • Bluetooth ® spec: 4.1 • Bluetooth ® profiles: A2DP V1.3, AVRCP V1.5, HFP V1.6, HSP V1.2 • Battery type: Polymer Li-ion Battery (3.7V, 60mAh x 2) • Charging time: 2 hours • Music play time: 8 hours • Earbud dimension W x H x …

Text truncated - open the document above for the full version.

R L 01 label location Bluetooth headsetПользовательские наушники/蓝牙耳机 Made In China / 中国制造 / Сделано в Китае MODEL: V100BT FCC ID: APIJBLV100BT IC: 6132A-JBLV100BT CMIIT ID:XXXXXXXXXX CC AEXXXXXXXX 80mm 13mm 13mm XXXX XXX-XXX-XXX-XXXXXXX XXXXX/SDPPI/2015 4534 XXX-XXXXXX

ANTENNA LOCATION BT LOCATION

RF Exposure Compliance Requirement 1. LIMITS According 447498 D01 General RF Exposure Guidance v05r01 Appendix A SAR Test Exclusion Thresholds for 100 MHz– 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The equation and threshold in section 4.3.1 must be applied to determine SAR test exclusion. Frequency Distance(mm) SAR Test Exclusion Threshold 2450MHz 5 10mW(10dBm) 2. EUT RF Exposure The Max Conducted Peak Output Power is 6.26dBm (4.23mW) in 2402MHz of BT3.0 8DPSK; The max antenna gain of this antenna is -2.6dBi. -2.6dB logarithmic terms convert to numeric result is nearly 0.55. EIRP= P x G = 4.23mW x 0.55 = 2.33 mW. SAR requirement :S=10mw EIRP < S So the SAR report is not required.

TEST REPORT Report No.: E201508117208-3 Application No.: E201508117208 Client: Harman International Industries, Incorporated Address: 8500 Balboa Blvd, Northridge, CA 91329, United States Sample Description: Bluetooth headset Model: V100BT Adding Model: / FCC ID APIJBLV100BT Test Specification: FCC Part 15,Subpart C:2014 Test Date: 2015-08-11 to 2015-08-27 Issue Date: 2015-08-27 Test Result: Pass. Prepared By: Reviewed By: Approved By: Bruce Li / Test Engineer Lynn Xiao /Technical Manager Yong Dai /Technical Manager Date:2015-08-27 Date:2015-08-27 Date:2015-08-27 Other Aspects: / Abbreviations: ok / P = passed; fail / F = failed; n.a. / N = not applicable The test result in this test report refers exclusively to the presented test sample. This report shall not be reproduced except in full, without the written approval of GRGT. GRG Metrology and Test Co., Ltd. Address: 163, Pingyun Road, West of Huangpu Avenue, Guangzhou, Guangdong, P.R. China Tel:+86-20-38699960 Fax:+86-20-38695185 Email: [email protected] http://www.grgtest.com Ver.:2.0 / 01.Jan.2012 Report No.: E201508117208-3 Application No.: E201508117208 Page 2 of 49 FCC ID: APIJBLV100BT DIRECTIONS OF TEST 1. This station carries out test task according to the national regulation of verifications which can be traced to National Primary Standards and BIPM. 2. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. 3. If there is any objection concerning the test, the client should inform the laboratory within 15 days from the date of receiving the test report. Report No.: E201508117208-3 Application No.: E201508117208 Page 3 of 49 FCC ID: APIJBLV100BT Table of Contents 1. TEST RESULT SUMMARY .................................................................................................................................. 4 2. GENERAL DESCRIPTION OF EUT .................................................................................................................... 5 2.1 APPLICANT ....................................................................................................................................................... 5 2.2 MANUFACTURER ............................................................................................................................................ 5 2.3 BASIC DESCRIPTION OF EQUIPMENT UNDER TEST ................................................................................ 5 3. LABORATORY AND ACCREDITATIONS ........................................................................................................ 6 3.1 LABORATORY .................................................................................................................................................. 6 3.2 ACCREDITATIONS ........................................................................................................................................... 6 3.3 MEASUREMENT UNCERTAINTY .................................................................................................................. 6 3.4 LIST OF USED TEST EQUIPMENT AT GRGT ................................................................................................ 7 4. TEST RESULTS ...................................................................................................................................................... 8 4.1 E.U.T. TEST CONDITIONS ............................................................................................................................... 8 4.2 ANTENNA REQUIREMENT ........................................................................................................................... 12 4.3 OCCUPIED BANDWIDTH .............................................................................................................................. 13 4.3.1 LIMITS ....................................................................................................................................................... 13 4.3.2 TEST PROCEDURES ................................................................................................................................ 13 4.3.3 TEST SETUP ............................................................................................................................................. 13 4.3.4 TEST RESULTS ......................................................................................................................................... 13 4.4 CARRIER FREQUENCIES SEPARATED ...................................................................................................... 17 4.4.1 LIMITS ....................................................................................................................................................... 17 4.4.2 TEST PROCEDURES ................................................................................................................................ 17 4.4.3 TEST SETUP ............................................................................................................................................. 17 4.4.4 TEST RESULTS ......................................................................................................................................... 17 4.5 HOPPING CHANNEL NUMBER .................................................................................................................... 21 4.5.1 LIMITS ....................................................................................................................................................... 21 4.5.2 TEST PROCEDURES ................................................................................................................................ 21 4.5.3 TEST SETUP ............................................................................................................................................. 21 4.5.4 TEST RESULTS .............…
