APILIVEPROTWSPBLUETOOTH HEADSET

Harman International Industries, Inc

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Oct 08, 2020
Application Purpose: Original Equipment
Date of Application: Oct 08, 2020
Equipment Note: BLUETOOTH HEADSET
Frequency Range: 2402.00000000 - 2480.00000000
Company: Harman International Industries, Inc
Country: United States
