ARHCSP90921451USB stick Transceiver for near field communication (NFC)

Declaration of Conformity (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer- ence that may cause undesired operation. (http://downloads.cardolution.com/cardabrapro/declaration_FCC) FCC ID: ARHCSP90921451 Trade Name: Cardolution Handels GmbH Model: Cardabra Stick Pro Declaration of Conformity (CE) CARDOLUTION HANDELS GMBH hereby declares that this Cardabra Stick Pro product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. (http://www.cardolution.com/conformity) Cardabra Stick Pro Dear Customer, thank you very much for purchasing this NFC product. Please read this manual carefully before installation and follow the instructions to get the optimal performance. Starting up Unpack the Cardabra Stick Pro and remove the USB-protecting cap to reveal the USB plug. Now insert the stick into a free USB port of your computer. For a correct identifi cation of the Cardabra Stick Pro please install the driver for the USB to UART converter CP2104. (http://www.silabs.com/products/mcu/Pages/USBtoUARTBridgeVCPDrivers.aspx) Usage Cardabra Stick Pro is a NFC device which is equipped with a chip of the type NXP PN532 and can only be used with appropriate software. For developers If you would like to use this product for developing your own software it is strongly recommended to use a NFC Stack (e.g. NFCStack+ from Stollmann / www.stollmann.de) Safety instructions and warranty Please keep this manual for future use. Make yourself familiar with the functionality and features of this product. With the purchase of this product you receive a warranty of 2 years in the case the product fails under appropriate use. Please note that you are bound by the General Terms and Conditions, too. Use this product in an appropriate way only. Otherwise damage may occur. Reconstruction or modifi cation of this product is prohibited. Damage or injuries caused by such modifi cations lead to the expiration of any warranty claims. Do not open or repair the product yourself. Pay attention to careful usage of the product. Damage may occur in the case of mechanical stress. Do not expose the product to moisture or extreme heat. Caution Modifi cations not authorized by the manufacturer may void user’s authority to operate this device. No warranty is given for damage resulting from improper and inappropriate use. This warranty does not cover incidental and consequential damages caused by the product. Technical data are subject to change without notice. Errors and omissions excepted. Cardolution Handels GmbH Lainzerstraße 162/6 1130 Wien AUSTRIA

Coverletter: Cardolution Handels GmbH wants to get FCC-Certification for the following product: RF NFC Reader (two-way communication) Cardabra Stick Pro. The unit will get the following FCC-ID: ARHCSP90921451 List of documents: Exhibit Thema File Exhibit 01 Label and placement stick-label-final.jpg Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_12-116.pdf * Exhibit 04 Block Diagrams CardabraStickPro_Blockschaltbild.pdf * Exhibit 05 Schematic Diagrams Schematics_CardabraStickPro_V1.0.pdf Exhibit 06 Testreport 12-116.pdf Exhibit 07 Test Set-up Photos setup_12-116.pdf Exhibit 08 User Manual manual_ENG.pdf Exhibit 09 Internal Photos Cardabra-Stick-Pro_V1_Top_W2600.jpg Cardabra-Stick-Pro_V1_Bot_W2600.jpg Exhibit 10 Informations -------------------- Exhibit 11 RF exposure -------------------- * Exhibit 12 Operational Description TechnicalDescription_CardabraStickPro_20120229.pdf Exhibit 13 Cover letter Request for confidentiality This file CardabraStickPro-FCC-ConfidentialityRequest.pdf For the Exhibits marked with ‘*’ Cardolution Handels GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may be not the actual status. The correct labelling you can see on the label and placement photo in Exhibit 1.
