AVXMTGHR9HD 9” LCD Monitor With Built-In DVD Player and HDMI/MHL Port For Rear Seat Entertainment Installation And Operation Manual TM TM Important Notices Installation of headrest products requires careful planning and preparation. Be extremely careful with seats that have airbags built into them. Keep wiring away from any air bag wiring (usually identified by yellow connectors and yellow wire jackets). Damage to air bag wiring can result in personal injury to vehicle occupants. If you have any questions regarding wire routing or installation in a vehicle, please contact VOXX Electronics Technical Support at 1-800-225-6074. When connecting power and ground in a mobile video installation, insure that the ACC wire is fused at the point where it is connected to the vehicle ACC wiring. Failure to do so can result in damage to the vehicle if a short circuit develops between the vehicle connection point and the mobile video product. An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park” or when the vehicle’s parking brake is applied. An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the parking is not applied must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle. Patented: Refer to www.voxxintl.com/patents 3 Table of Contents Features ..............................................................................................................4 Quick Start Guide ............................................................................................5 Materials Supplied ..........................................................................................6 Headrest Cover Replacement .....................................................................7 Installation - Vehicle Preparation ..............................................................8 Installation - Wiring Diagram ......................................................................9 Controls and Indicators Diagram ............................................................10 Remote Control Battery Replacement .................................................11 Remote Control Operation ................................................................12-15 System Settings and Adjustments .........................................................16 DVD Settings and Adjustments ........................................................17-22 Playing DVDs and Audio Discs ................................................................23 Playing USB Devices .............................................................................23-24 Playing MP3 Discs ........................................................................................24 DVD Basics ......................................................................................................25 HDMI/MHL Usage ..................................................................................26-27 USB Devices (Media and Charging) .......................................................28 Troubleshooting ...........................................................................................29 Specifications .................................................................................................30 Warranty ..........................................................................................................31 4 • 9” Digital Thin Film Transistor (TFT) Active Matrix Liquid Crystal Display (LCD) Monitor • Built-in DVD Player • Last position memory for DVD Player • Five Audio / Video Source inputs • DVD • USB • AV • AUX • HDMI/MHL • USB 2.0 port • HDMI®/MHL® Input • On Screen Display (OSD) for control of picture quality and functions • Full function remote control • Plays DVD, CD and MP3 discs • 8 Channel Wireless FM Modulator • Dual Channel IR Transmitter (for use with optional IR headphones) • Adjustable posts and tilting headrest (for adjusting screen viewing angle). FeaturesFeatures 5 Quick Start Guide 1. Press the POWER () button on the front panel or the POWER button on the remote control. 2. Press the screen release (PUSH) button. The screen will pop open a short distance. Raise the screen up 90 degrees to access the DVD mechanism. 3. Snap a DVD, CD or MP3 disc onto the hub (label facing outward). Spin the disc to ensure that it is properly attached to the hub. 4. Lower the screen back to its stored position and press on the bottom of the screen to latch it to the DVD housing. (Note: For safety reasons, the DVD will not play if the screen is not latched closed. The headrest can be tilted forward or backward to adjust the viewing angle.) 5. When the DVD menu appears, select the menu item using the +/- buttons on the front panel and press the Play (4/; ) button to start the DVD playing. If using the remote control press the or buttons to select the menu item and then press the Play (4;) button to start the movie playing. 6. If using IR wireless head phones, first turn the volume control to its lowest setting, press the power button and increase the volume to a comfortable listening level. 7. If audio playback through the vehicle radio is preferred, use the following steps: • Tune your vehicle's radio to 87.7, 88.1, 88.5, 88.9, 106.7, 107.1, 107.5 or 107.9 MHz. Pick one of these frequencies that is either unused or is a very weak station • Press the MENU () button on the front panel or the CONSOLE ( CONSOLE ) button on the remote control until FMM ON appears on the screen. • Press the +/- buttons on the front panel or the o…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 ACTION ELECTRONICS CO.,LTD. 2015-08-12 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ACTION ELECTRONICS CO.,LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): 9" Headrest Monitor with DVD Player MODEL No.: HRDA0902, AVXMTG9HD FCC ID:ATI9R3HRDA0902 Sincerely, L.L TAN /Asst. Manager E-mail: [email protected] Phone: 604-3997600 Fax: 604-3997604 Address: 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA

Family models declaration letter. 2015-08-12 We ACTION ELECTRONICS CO., LTD. Of 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA (address) Declare under our sole responsibility that the product Product: 9" Headrest Monitor with DVD Player FCC ID: ATI9R3HRDA0902 MODEL No.: HRDA0902, AVXMTG9HD All models have the same constructions, circuit diagram and PCB layout. Only model name is different. Unless otherwise stated Sincerely, L.L TAN/Asst Manager E-mail: [email protected] Phone: 604-3997600 Fax: 604-3997604 Address: 2480,TINGKAT PERUSAHAAN ENAM,PRAI FREE TRADE ZONE,13600, PERAI,PENANG, Malaysia

ACTION ELECTRONICS CO., LTD. 2015-8-12 9" Headrest Monitor with DVD Player Model No.: HRDA0902, AVXMTG9HD FCC ID: ATI9R3HRDA0902 1. How does this device operate Plug into MP3 & similar device and powered from Car Cigarette lighter. 2. Provide information on the device and its antenna The device is a low power communication device (FM Transmitter) The EUT use Monopole Antenna (Without any antenna connector). 3. How is it installed This is usually installed in car and antenna is fixed with EUT. 4. What test procedure was used According to ANSI C63, 10-2013 and FCC Part 15.239 5. If test in a car, How was it configured/tested? N/A 6. Was the tuning range properly verified? The test lab should indicate in the report that the tuning controls were manually adjusted to verify maximum tuning range. EUT was adjusted to work at the selected channels: 88.1 MHz to 107.9MHz. The EUT will not allow operation below 88.1 MHz and will not allow operation above 107.9 MHz. 7. Was the bandwidth properly tested with maximum audio input? Emissions from the intentional radiator shall be confined within a band 100 kHz wide centered on the operation frequency. The 100 kHz band shall lie wholly within the frequency range of 88.1– 107.9MHz. Setup the EUT and simulators as shown in the report. Enable RF signal and confirm EUT active. Modulate output capacity of EUT up to specifications. Sincerely, L.L TAN E-mail: [email protected] Phone: 604-3997600 Fax: 604-3997604 Address: 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA

150 6 00000113655300 WARRANTY VOID IF LABEL REMOVED 4. BC S/N LBL 136-5530-POD CUSTOMER: REVISION: MODEL: DESCRIPTION: DATE: PAGE: OF: AVXMTGHR9HD MOVIE 2 GO 0 30/06/15 38 LABEL LOCATION ON UNIT LABEL LOCATION ON UNIT UNIT (BACK VIEW) 3. CHASSIS LABEL AVXMTGHR9HD (45 x 63MM) UNIT (FRONT VIEW) 1. LOGO PLATE (32 x 6.5MM) 2. WARNING LABEL (90 x 70MM) WARNING 1 2 3 4 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions : (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation. MODEL NO.: AVXMTGHR9HD MASTER 132-7930 MADE IN CHINA 150 Marcus Blvd., Hauppauge, NY 11788 Technical Assistance: 1-800-225-6074 POWER SOURCE : 12V DC 9” LCD MONITOR WITH FOR REAR SEAT ENTERTAINMENT BUILT-IN DVD PLAYER VOXX ELECTRONICS CORP. This product is Class 1 Laser Product and complies with FDA Rules 21 CFR Chapter 1, Subchapter J. FCC ID : ATI9R3HRDA0902 Patented, refer to www.voxxintl.com/company/patents

TRF NO. FCC15/A Page 1 of 3 Report No.: ES150618265E Ver.1.0 TRF NO. FCC15/A Page 2 of 3 Report No.: ES150618265E Ver.1.0 TRF NO. FCC15/A Page 3 of 3 Report No.: ES150618265E Ver.1.0 -----------The end----------

TRF No：FCC 15.239/A Page 1 of 25 Report No. ES150804031E Access to the World ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF 9" Headrest Monitor with DVD Player MODEL No.: HRDA0902, AVXMTG9HD FCC ID: ATI9R3HRDA0902 Trademark: N/A REPORT NO: ES150804031E ISSUE DATE: August 12, 2015 Prepared for ACTION ELECTRONICS CO., LTD. 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No：FCC 15.239/A Page 2 of 25 Report No. ES150804031E Access to the World VERIFICATION OF COMPLIANCE Applicant: ACTION ELECTRONICS CO., LTD. 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA Manufacturer1: ACTION INDUSTRIES (M) SDN. BHD. 2480, TINGKAT PERUSAHAAN ENAM, PRAI FREE TRADE ZONE, 13600, PERAI, PENANG, MALAYSIA Manufacturer2: ACTION ASIA(SHENZHEN) CO., LTD DeDe industrial Park, Jian'an Road, High-Tech industrial Park, Fuyong Town, Bao'an District, Shenzhen, China. Product Description: 9" Headrest Monitor with DVD Player Brand Name: N/A Model Number: HRDA0902, AVXMTG9HD Serial Number: N/A File Number: ES150804031E Date of Test: August 05, 2015 to August 11, 2014 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10:2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.239. The test results of this report relate only to the tested sample identified in this report. Date of Test : August 05, 2015 to August 11, 2014 Prepared by : Doris Su/Editor Reviewer : Joe Xia /Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No：FCC 15.239/A Page 3 of 25 Report No. ES150804031E Access to the World Table of Contents 1. GENERAL INFORMATION ........................................................................................................... 4 1.1 PRODUCT DESCRIPTION ................................................................................................................... 4 1.2 RELATED SUBMITTAL(S) / GRANT (S) ............................................................................................ 4 1.3 TEST METHODOLOGY ....................................................................................................................... 4 1.4 SPECIAL ACCESSORIES ..................................................................................................................... 4 1.5 EQUIPMENT MODIFICATIONS ......................................................................................................... 4 1.6 TEST FACILITY .................................................................................................................................... 5 2. SYSTEM TEST CONFIGURATION .................................................................................... 6 2.1 EUT CONFIGURATION ....................................................................................................................... 6 2.2 EUT EXERCISE ..................................................................................................................................... 6 2.3 TEST PROCEDURE ............................................................................................................................... 6 2.4 LIMITATION ......................................................................................................................................... 7 2.5 CONFIGURATION OF TESTED SYSTEM .......................................................................................... 8 3. SUMMARY OF TEST RESULTS ......................................................................................... 9 4. DESCRIPTION OF TEST MODES ...................................................................................... 9 5. RADIATED EMISSION AND BAND EDGE TEST .......................................................... 10 5.1 MEASUREMENT PROCEDURE ........................................................................................................ 10 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ........................................................... 11 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 11 5.4 MEASUREMENT RESULT ................................................................................................................. 12 6. OCCUPIED BANDWIDTH .................................................................................................. 22 6.1 MEASUREMENT PROCEDURE ........................................................................................................ 22 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ........................................................... 22 6.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 22 6.4 MEASUREMENT RESULTS: ............................................................................................................. 22 7. ANTENNA APPLICATION ........................................................................................................... 25 7.1 ANTENNA REQUIREMENT ................................................................................................................... 25 7.2 RESULT ..................................................................................................................................................... 25 TRF No：FCC 15.239/A Page 4 of 25 Report No. ES150804031E Access to the World 1. GENERAL INFORMATION 1.1 Product Description A maj…
