ATI9R3ODM9100310.2" DIGITAL AUDIO VIDEO PLAYER

ODM90903 ODM91003 9”, 10.2” Overhead TFT LCD Monitor with Built-in DVD Player Owner’s Manual / Installation Guide CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. RISK OF ELECTRONIC SHOCK DO NOT OPEN CAUTION Important Notice An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park” or when the vehicle’s parking brake is applied. An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the parking brake is not applied must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle. Licensed under one or more of the following patents, Patent NOS. 5,775,762 , 5,927,784 and 6,678,892 FCC ID : ATI9R3ODM91003 FCC ID : ATI9R3ODM90903 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 3 FEATURES ODM90903 / ODM91003 • 9”, 10.2” TFT (Thin Film Transistor) Active Matrix LCD (Liquid Crystal Display) Monitor •Built-in DVD Player •OSD (On Screen Display) for control of picture quality and functions •Three Audio / Video Source inputs (DVD/USB/CARD, AV and AUX). •Dome lights with 3-position switch •Built-in 16 channels frequency wireless FM modulator •Last position memory for DVD • • • • •cable •Playing DVD, CD and MP3 disc •USB 2.0 port / SD Card Reader Screen mode selection (4:3, 16:9) Wireless game controller Full function remote control Backlit controls AV output via RCA SPECIFICATIONS Specifications subject to change without notice. LCD Backlighting Edge Light Tube Resolution 1440 x 234 ODM90903(9”) Pixels 336, 960 Operation Temperature 32 ~131º F (0 ~ 55º C) Storage Temperature -4 ~ 158º F (-20 ~ 70º C) Backlit life 10,000 Hours Video Display System NTSC / PAL Headphone Audio Output 0.03W @ 32 ohms Video Output 1.0Vp-p @ 75 ohms Power Source 12V DC Dimension (L x W x H) 297mm x 272mm x 62mm Edge Light Tube 2400 x 480 ODM91003(10.2”) 1,152,000 32 ~131º F (0 ~ 55º C) -4 ~ 158º F (-20 ~ 70º C) 30,000 Hours NTSC / PAL 0.03W @ 32 ohms 1.0Vp-p @ 75 ohms 12V DC 297mm x 272mm x 62mm CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW) 1.POWER ( ) Control Used to turn the system on/off (standby). 2.PLAY (u) Control This control is used to start playback of a disc. 3.Source Select (S) Use to select one of the two sources: DVD/USB/CARD, AV and AUX. 4.STOP (n) Control - Press STOP once : Stops playback, Pressing the PLAY button again will resume normal playback from where movie was stopped. - Press STOP twice and then press PLAY to start playback from the beginning of the DVD. 5.EJECT (Å) Control This control is used for ejecting disc from the disc compartment. (Note: Disc can be ejected with the unit turned Off. Vehicle ignition must be in Run or ACC position). After the disc is removed the unit will turn Off after 15-20 seconds. 4 1 6 3 4 5 2 6 7 8 8 9 10 5 6.Dome Lights Provide additional interior illumination. 7.Screen Release Press to release the screen. 8.Ventilation holes 9.LCD Cut Off Switch Used to turn off the LCD backlight when the LCD is in the closed position. 10.LCD Panel CONTROL FUNCTION DESCRIPTIONSIDE VIEW 1.Disc insertion Slot For loading and removing discs. Unit must be in power on state to load a disc. Insert disc with label side facing upwards. 2.Headphone Jack The jack is applicable for wired headphone with a 1/8” (3.5mm) plug to listen audio output. 3.AUX IN The Jack is applicable for audio and video input. 4.USB PORT USB input for USB thumb drive. 5.SD Card Reader Allow to read the contents (Audio, Photo, Video) data on the Secure Digital Card (SD Card), Multimedia Card (MMC), Memory Stick (MS). 6.Three Position Dome Light Switch ON - Turns on the dome lights. OFF - The dome lights will not turn on in this position. AUTO - Automatically switches on the dome lights in conjunction with the vehicle's interior illumination. () 1 23456 M1M2 POWEREJECT TVDVD SOURCE MUTE DVD SOURCEVOLUME PIX SYSTEM MENUDISC MENUZOOM REPEAT ENTER SUBTITLE SETUPDISPLAY AUDIO 1234 5678 90 IRT ON/OFF FMM ON/OFF 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1617 18 19 20 21 22 23 24 25 26 27 28 29 30 6 CONTROL FUNCTION DESCRIPTIONBACK 1. REAR IR SENSOR REMOTE CONTROL OPERATION Initial Use When purchased the remote control has a battery installed with a Pull Tab to prevent battery discharge. Remove the Pull Tab before attempting to use the remote. Battery Replacement 1.Remove the battery holder. 2.Insert the battery into the battery holder And insert the battery holder into the remote. Be sure to observe the correct polarity. 3.Align the battery holder with the remote control and push it in until the holder clicks. MAIN FUNCTION OPERATION ( VIEW) CR2025 1 7 * Function control is available on the unit and the Remote Control. ** Function not available in this model. 1. POWER* Press this button to turn the unit ON and OFF. 2.MONITOR SELECT M1 Button – Set the remote control code to allow control of the unit in M1 mode. M2 Button** – Set the remote control code to allow control of the unit in M2 mode. 3.SOURCE* Each time the button is pressed, the unit will cycle through modes DVD/USB/CARD, AV and AUX. 4.TV Mode Select Switches certain function keys on the remote control for monitor functions. 5.DVD Source This button is select key only can be active when remote control is in DVD mode function. Each time the button is pressed one of the source DVD, Card Reader and USB will be selected. If the Card Reader and USB not apply on …

Text truncated - open the document above for the full version.

AGENCY AUTHORIZATION LETTER FCC ID: ATI9R3ODM91003 Product Name: 10.2”DIGITAL AUDIO VIDEO Model Name: ODM91003 ,ODM91003CR,ODM91003ACR,ODM91003BCR Trade Name: AXION Date: 25/03/2010 To whom it may concern: We, the undersigned, hereby authorize Audix Technology (Shenzhen) Co., Ltd Audix of Shenzhen to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Audix within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, LL TAN RD ASSISTANT MANAGER ACTION INDUSTRIES (M) SDN BHD (Tel.):604-3997600 (Fax): 604-3997604

Date:25/04/2008 Federal Communications Commission Authorization and Evaluation Division FCC ID: ATI9R3ODM91003 Product Name: 10.2”DIGITAL AUDIO VIDEO Model Name: ODM91003 ,ODM91003CR,ODM91003ACR,ODM91003BCR Trade Name: AXION Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, LL TAN RD ASSISTANT MANAGER ACTION INDUSTRIES (M) SDN BHD (Tel.):604-3997600 (Fax): 604-3997604

FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-1 8. PHOTOGRAPH OF EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-2 Figure 3 General Appearance of the EUT Figure 4 Inside of the EUT

MODEL.: ODM91003CR POWER SOURCE : DC 12V 10.2” OVERHEAD TFT LCD MONITOR WITH DVD PLAYER 1. MODEL PLATE (53 X 34MM)2. SERIAL NUMBER UNIT BACK VIEWUNIT FRONT VIEW 1 2 4. LOGO PLATE (32 X 6.5MM) (P/N: 50-KC-00010G) S/No.: ODM91003CR00090400001 4 MADE IN MALAYSIA Licensed under one or more of the following patents, Patent NOS. 5,775,762 , 5,927,784 and 6,678,892 FCC ID : ATI9R3ODM91003 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions : (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation. This product is Class 1 Laser Product and complies with FDA Rules 21 CFR Chapter 1, Subchapter J. 3. FCC / FDA / Class 1 Laser Label 3 ODM91003CR MODEL.: ODM91003ACR POWER SOURCE : DC 12V 10.2” OVERHEAD TFT LCD MONITOR WITH DVD PLAYER 1. MODEL PLATE (53 X 34MM)2. SERIAL NUMBER UNIT BACK VIEWUNIT FRONT VIEW 1 2 4. LOGO PLATE (32 X 6.5MM) (P/N: 50-KC-00010G) S/No.: ODM91003ACR00090400001 4 MADE IN MALAYSIA Licensed under one or more of the following patents, Patent NOS. 5,775,762 , 5,927,784 and 6,678,892 FCC ID : ATI9R3ODM91003 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions : (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation. This product is Class 1 Laser Product and complies with FDA Rules 21 CFR Chapter 1, Subchapter J. 3. FCC / FDA / Class 1 Laser Label 3 ODM91003ACR MODEL.: ODM91003BCR POWER SOURCE : DC 12V 10.2” OVERHEAD TFT LCD MONITOR WITH DVD PLAYER 1. MODEL PLATE (53 X 34MM)2. SERIAL NUMBER UNIT BACK VIEWUNIT FRONT VIEW 1 2 4. LOGO PLATE (32 X 6.5MM) (P/N: 50-KC-00010G) S/No.: ODM91003BCR00090400001 4 MADE IN MALAYSIA Licensed under one or more of the following patents, Patent NOS. 5,775,762 , 5,927,784 and 6,678,892 FCC ID : ATI9R3ODM91003 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions : (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation. This product is Class 1 Laser Product and complies with FDA Rules 21 CFR Chapter 1, Subchapter J. 3. FCC / FDA / Class 1 Laser Label 3 ODM91003BCR

FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-2 Figure 3 General Appearance of the EUT Figure 4 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-3 Figure 5 Inside of the EUT Figure 6 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-4 Figure 7 Inside of the EUT Figure 8 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-5 Figure 9 Inside of the EUT Figure 10 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-6 Figure 11 Inside of the EUT Figure 12 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-7 Figure 13 Inside of the EUT Figure 14 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-8 Figure 15 Inside of the EUT Figure 16 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-9 Figure 17 Inside of the EUT Figure 18 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-10 Figure 19 Inside of the EUT Figure 20 Inside of the EUT FCC ID:ATI9R3ODM91003 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 8-11 Figure 21 Remote Control Figure 22 Remote Control

FCC ID:ATI9R3ODM91003 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 APPLICATION FOR CERTIFICATION On Behalf of Action Industries (M) SDN BHD 10.2" DIGITAL AUDIO VIDEO PLAYER Model Number: ODM91003CR; ODM91003ACR; ODM91003BCR FCC ID: ATI9R3ODM91003 Prepared for : Action Industries (M) SDN BHD 2480, Tingkat Perusahaan Enam, Prai Free Trade Zone, 13600, Perai, Penang, Malaysia. Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F10065 Date of Test ： Mar.27, 2010 Date of Report ： Mar.30, 2010 FCC ID:ATI9R3ODM91003 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 TABLE OF CONTENTS Description Page Test Report Declaration 1. SUMMARY OF STANDARDS AND RESULTS .................................................................. 1-1 1.1. Description of Standards and Results.............................................................................................1-1 2. GENERAL INFORMATION .................................................................................................. 2-1 2.1. Description of Device (EUT) .........................................................................................................2-1 2.2. Test Facility....................................................................................................................................2-2 2.3. Measurement Uncertainty (95% confidence levels, k=2) ..............................................................2-2 3. POWER LINE CONDUCTED EMISSION TEST................................................................ 3-1 4. RADIATED EMISSION TEST ............................................................................................... 4-1 4.1. Test Equipment ..............................................................................................................................4-1 4.2. Block Diagram of Test Setup .........................................................................................................4-1 4.3. Radiated Emission Limit 30~1000MHz.........................................................................................4-2 4.4. EUT Configuration on Test............................................................................................................4-2 4.5. Operating Condition of EUT..........................................................................................................4-2 4.6. Test Procedure................................................................................................................................4-2 4.7. Radiated Emission Test Results .....................................................................................................4-3 5. BANDWIDTH TEST................................................................................................................ 5-1 5.1. Test Equipment ..............................................................................................................................5-1 5.2. Block Diagram of Test Setup .........................................................................................................5-1 5.3. Limit ...............................................................................................................................................5-1 5.4. Test Signal......................................................................................................................................5-1 5.5. Test Results ....................................................................................................................................5-1 6. DEVIATION TO TEST SPECIFICATIONS ........................................................................ 6-1 7. PHOTOGRAPH........................................................................................................................ 7-1 7.1. Photos of Radiated Emission Test (In Anechoic Chamber) ...........................................................7-1 8. PHOTOGRAPH OF EUT........................................................................................................ 8-1 FCC ID:ATI9R3ODM91003 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 1-1 1. SUMMARY OF STANDARDS AND RESULTS 1.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below. EMISSION Description of Test Item Standard Results Conducted Emission Test FCC Part 15: 15.207 ANSI C63.10: 2009 N/A Radiated Emission Test FCC Part 15: 15.239 ANSI C63.10: 2009 PASS Bandwidth Test FCC Part 15: 15.239 PASS N/A is an abbreviation for Not Applicable. FCC ID:ATI9R3ODM91003 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 2-1 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Description : 10.2" DIGITAL AUDIO VIDEO PLAYER Model Number : ODM91003CR; ODM91003ACR; ODM91003BCR Note: This device have three model numbers, and the actual device is same. FCC ID : ATI9R3ODM91003 Operating Frequency : 88.1MHz to 91.1MHz Applicant : Action Industries (M) SDN BHD 2480, Tingkat Perusahaan Enam, Prai Free Trade Zone, 13600, Perai, Penang, Malaysia. Manufacturer : Action Industries (M) SDN BHD 2480, Tingkat Perusahaan Enam, Prai Free Trade Zone, 13600, Perai, Penang, Malaysia. Date of Test : Mar.27, 2010 Date of Receipt : Mar.27, 2010 Sample Type : Prototype production FCC ID:ATI9R3ODM91003 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 2-2 2.2. Test Facility Site Description Name of Firm : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park,Nantou, Shenzhen, Guangdong, China 3m Anechoic Chamber : Mar.31, 2009 File on Federal Communication Commission Registration Number: 90454 3m & 10m Anechoic Chamber : Dec. 30, 2009 File on Federal Communication Commission Registration Number: 794232 EMC Lab. : Accredited by DATech, German R…

Text truncated - open the document above for the full version.

FCC ID:ATI9R3ODM91003 Page 7-1 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F10065 7. PHOTOGRAPH 7.1. Photos of Radiated Emission Test (In Anechoic Chamber)
