AUSS300AS300 SPEAKER

EnglishEnglishEnglishEnglishEnglishEnglishEnglishEnglishEnglishEnglishEnglish Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. 3. Do not defeat the safety purpose of the polarized plug.A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician. 4. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. 5. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 6. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. 7Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 8Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 9Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 11. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. Do not block or cover these openings. 12.Unplug the product during lightning storm or when unused for long periods of time. . . . . Safety InstructionsItems in this packageSpecificationsProduct Description 2 2 3 345 45 6 6 7 7 8 8 9 9 10 10 11 11 12 12 Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package: Please contact Crosley Customer Service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes. Power Source Power consumption Output Power Speaker Charging Time Playing Time Bluetooth version Type –C, DC 5V/2.1A 30W 15WX2 4Ω 15 W 3 Hours Up to 8 hours 5.0 Note: • Design and specifications are subject to change without notice. To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, you will need to turn off the power and turn it on again. • Charging/Power Source 1. This unit has a built in rechargeable battery. 2. Connect to a PC,Laptop or 5V USB adaptor with the provided Type C cable. 1. Esta unidad tiene una batería recargable incorporada. 2. Conecte a una PC, computadora portátil o adaptador USB de 5V con el cable USB provisto. Aux Input Connection Conexión de entrada auxiliar You can connect an audio device to this unit and play your music through its speakers. To do this, turn on the unit, connect a 3.5 mm auxiliary cable between your audio device to the Aux In Jack of this unit and start playing the music. Puede conectar un dispositivo de audio a esta unidad y reproducir su música através de los parlantes. Para hacerlo, encienda la unidad, conecte un cable auxiliar de 3.5 mm entre su dispositivo de audio y el conector de entrada auxiliar de esta unidad y comience a reproducir la música. Bluetooth Operation Funcionamiento de Bluetooth 1. Short press the Power button to turn it ON, and the indicator LED will flash blue. 2. Turn on the Bluetooth feature of your audio device, search for “CROSLEY S300A” and pair. 3. Once your device is successfully paired with the unit, you will hear a short confirmation sound from the unit. 4. Play and stream music from your device to the unit. 5. To disconnect from the unit, long press the Play/Pause button. 1. Presione brevemente el botón de encendido para encenderlo y el indicador LED parpadeará en azul. 2. Active la conexión de Bluetooth en el dispositivo de audio, busque “CROSLEY S300A” y conéctelo. 3. Una vez que su dispositivo se haya emparejado con éxito con la unidad,escuchará un breve sonido de confirmación de la unidad. 4. Reproduzca y transmita música desde su dispositivo a la unidad. 5. Para desconectarse de la unidad, mantenga presionado el botón Reproducir /Pausa. TWS mode Modo TWS 1. Turn on both sets of speakers by short pressing the Power button. 2. Quickly double-click the Power on each speaker separately. 3. You will hear a confirmation notification showing they are paired. 4. Connect your Bluetooth. 5. There will be a confirmation notification from one speaker showing they are paired with your Bluetooth device. Note: This speaker will be the Primary and the other will be secondary. The primary speaker indicator LED will flash blue. To Disconnect To disconnect the speakers from the TWS Mode, long press Play/Pause button on one of twins- connected speakers. You will hear a confirmation notification showing they are disconnected. 1. Encienda ambos conjuntos de altavoces presionando brevemente el botón de encendido. 2. Haga doble clic rápidamente en Power (Encendido) en cada altavoz por eparado. 3. Escuchará una notificación de confirmación que muestra que están emparejados. 4. Conecte su Bluetooth. 5. Habrá una notificación de confirmación de un altavoz que muestra que están emparejados con su dispositivo Bluetooth. Nota: Este altavoz será el primario y el otro será secundario. El LED in…

Text truncated - open the document above for the full version.

DATE: .July .5 2021 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint BLUEASIA OF TECHNICAL SERVICES (SHENZHEN) CO., LTD. Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District, Shenzhen, GuangDong, 518000 P.R.C(Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Modern Marketing Concepts,Inc. 1220 E Oak, St.Louisville, KY 40204United States.(Applicant Name and address) <Signature> Name Mr Scott McWhorter Title Director of Engineering Applicant Company Modern Marketing Concepts, Inc.

DATE 2021.07.5 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: ______AUSS300A_ Product Name: _S300 SPEAKER Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name Mr Scott McWhorter Title Director of Engineering Company Modern Marketing Concepts, Inc.

Model No.: S300A-BK

Productname:S300SPEAKER FCCID:AUSS300A

Model No.: S300A-BK

RF Exposure Evaluation Statement Product Name: S300 SPEAKER Model No.：S300A-BK, S300XX-XXXX. FCC ID：AUSS300A 1.1 RF Exposure Compliance Requirement 1.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 1.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion 1.1.3 EUT RF Exposure Operational Mode: EDR （8-DPSK worst case） Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dB) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) 2402MHZ 2.39 ±1 3.39 2.18 0.68 3.0 2441MHz 1.77 ±1 2.77 1.89 0.59 2480MHz 1.84 ±1 2.84 1.92 0.61 Conclusion: the calculated value ≤3.0, SAR is exempted.

Report No.: BLA-EMC-202106-A4402 Page 48 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com 21 APPENDIX 1 21.1 MAXIMUM CONDUCTED OUTPUT POWER Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT 1-DH1 2402 Ant1 1.857 21 Pass NVNT 1-DH1 2441 Ant1 1.217 21 Pass NVNT 1-DH1 2480 Ant1 1.268 21 Pass NVNT 2-DH1 2402 Ant1 2.204 21 Pass NVNT 2-DH1 2441 Ant1 1.528 21 Pass NVNT 2-DH1 2480 Ant1 1.6 21 Pass NVNT 3-DH1 2402 Ant1 2.387 21 Pass NVNT 3-DH1 2441 Ant1 1.77 21 Pass NVNT 3-DH1 2480 Ant1 1.843 21 Pass Power NVNT 1-DH1 2402MHz Ant1 Power NVNT 1-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 49 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Power NVNT 1-DH1 2480MHz Ant1 Power NVNT 2-DH1 2402MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 50 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Power NVNT 2-DH1 2441MHz Ant1 Power NVNT 2-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 51 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Power NVNT 3-DH1 2402MHz Ant1 Power NVNT 3-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 52 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Power NVNT 3-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 53 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com 21.2 -20DB BANDWIDTH Condition Mode Frequency (MHz) Antenna -20 dB Bandwidth (MHz) Limit -20 dB Bandwidth (MHz) Verdict NVNT 1-DH1 2402 Ant1 0.956 0 Pass NVNT 1-DH1 2441 Ant1 0.984 0 Pass NVNT 1-DH1 2480 Ant1 0.99 0 Pass NVNT 2-DH1 2402 Ant1 1.248 0 Pass NVNT 2-DH1 2441 Ant1 1.23 0 Pass NVNT 2-DH1 2480 Ant1 1.248 0 Pass NVNT 3-DH1 2402 Ant1 1.218 0 Pass NVNT 3-DH1 2441 Ant1 1.214 0 Pass NVNT 3-DH1 2480 Ant1 1.219 0 Pass -20dB Bandwidth NVNT 1-DH1 2402MHz Ant1 -20dB Bandwidth NVNT 1-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 54 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com -20dB Bandwidth NVNT 1-DH1 2480MHz Ant1 -20dB Bandwidth NVNT 2-DH1 2402MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 55 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com -20dB Bandwidth NVNT 2-DH1 2441MHz Ant1 -20dB Bandwidth NVNT 2-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 56 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com -20dB Bandwidth NVNT 3-DH1 2402MHz Ant1 -20dB Bandwidth NVNT 3-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 57 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com -20dB Bandwidth NVNT 3-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 58 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com 21.3 OCCUPIED CHANNEL BANDWIDTH Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT 1-DH1 2402 Ant1 0.8530008444 NVNT 1-DH1 2441 Ant1 0.8567090177 NVNT 1-DH1 2480 Ant1 0.8862038518 NVNT 2-DH1 2402 Ant1 1.160974265 NVNT 2-DH1 2441 Ant1 1.171438599 NVNT 2-DH1 2480 Ant1 1.16488914 NVNT 3-DH1 2402 Ant1 1.147221919 NVNT 3-DH1 2441 Ant1 1.14067104 NVNT 3-DH1 2480 Ant1 1.133755755 OBW NVNT 1-DH1 2402MHz Ant1 OBW NVNT 1-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 59 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com OBW NVNT 1-DH1 2480MHz Ant1 OBW NVNT 2-DH1 2402MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 60 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com OBW NVNT 2-DH1 2441MHz Ant1 OBW NVNT 2-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 61 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com OBW NVNT 3-DH1 2402MHz Ant1 OBW NVNT 3-DH1 2441MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 62 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com OBW NVNT 3-DH1 2480MHz Ant1 Report No.: BLA-EMC-202106-A4402 Page 63 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com 21.4 BAND EDGE Condition Mode Frequency (MHz) Antenna Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH1 2402 Ant1 No-Hopping -46.09 -20 Pass NVNT 1-DH1 2480 Ant1 No-Hopping -50.7 -20 Pass NVNT 2-DH1 2402 Ant1 No-Hopping -45.24 -20 Pass NVNT 2-DH1 2480 Ant1 No-Hopping -51.29 -20 Pass NVNT 3-DH1 2402 Ant1 No-Hopping -47.06 -20 Pass NVNT 3-DH1 2480 Ant1 No-Hopping -49.24 -20 Pass Band Edge NVNT 1-DH1 2402MHz Ant1 No-Hopping Ref Band Edge NVNT 1-DH1 2402MHz Ant1 No-Hopping Emission Report No.: BLA-EMC-202106-A4402 Page 64 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Band Edge NVNT 1-DH1 2480MHz Ant1 No-Hopping Ref Band Edge NVNT 1-DH1 2480MHz Ant1 No-Hopping Emission Report No.: BLA-EMC-202106-A4402 Page 65 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com Band Edge NVNT 2-DH1 2402MHz Ant1 No-Hopping Ref Band Edge NVNT 2-DH1 2402MHz Ant1 No-Hopping Emission Report No.: BLA-EMC-202106-A4402 Page 66 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected]…

Text truncated - open the document above for the full version.

Page 1 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Add: Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District, Shenzhen, Guangdong Province, China Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com TEST REPORT Product Name : S300 SPEAKER Brand Mark : CROSLEY Model No. : S300A-BK, S300XX-XXXX. FCC ID : AUSS300A Report Number : BLA-EMC-202106-A4402 Date of Sample Receipt : 2021/6/16 Date of Test : 2021/6/16 to 2021/6/30 Date of Issue : 2021/6/30 Test Standard : 47 CFR Part 15, Subpart C 15.247 Test Result : Pass Prepared for: Modern Marketing Concepts, Inc. 1220 E Oak, St. Louisville, KY 40204 United States Prepared by: BlueAsia of Technical Services(Shenzhen) Co.,Ltd. Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District, Shenzhen, Guangdong Province, China TEL: +86-755-23059481 Compiled by: Review by: Approved by: Date: 2021/6/29 Report No.: BLA-EMC-202106-A4402 Page 2 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com REPORT REVISE RECORD Version No. Date Description 00 2021/6/29 Original Report No.: BLA-EMC-202106-A4402 Page 3 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com TABLE OF CONTENTS 1 TEST SUMMARY ........................................................................................................................................6 2 GENERAL INFORMATION .........................................................................................................................7 3 GENERAL DESCRIPTION OF E.U.T. .........................................................................................................7 4 TEST ENVIRONMENT ................................................................................................................................8 5 TEST MODE ................................................................................................................................................8 6 MEASUREMENT UNCERTAINTY ..............................................................................................................8 7 DESCRIPTION OF SUPPORT UNIT...........................................................................................................9 8 LABORATORY LOCATION .........................................................................................................................9 9 TEST INSTRUMENTS LIST ..................................................................................................................... 10 10 ANTENNA REQUIREMENT ..................................................................................................................... 14 10.1 CONCLUSION ....................................................................................................................................................... 14 11 CONDUCTED SPURIOUS EMISSIONS .................................................................................................. 15 11.1 LIMITS .............................................................................................................................................................. 15 11.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 15 11.3 TEST DATA .......................................................................................................................................................... 16 12 RADIATED EMISSIONS WHICH FALL IN THE RESTRICTED BANDS................................................. 17 12.1 LIMITS .............................................................................................................................................................. 17 12.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 18 12.3 PROCEDURE ..................................................................................................................................................... 18 12.4 TEST DATA .......................................................................................................................................................... 20 13 CONDUCTED BAND EDGES MEASUREMENT ..................................................................................... 24 13.1 LIMITS .............................................................................................................................................................. 24 13.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 24 13.3 TEST DATA .......................................................................................................................................................... 25 14 DWELL TIME ............................................................................................................................................ 26 14.1 LIMITS .............................................................................................................................................................. 26 14.2 BLOCK DIAGRAM OF TEST SETUP ..................................................................................................................... 26 14.3 TEST DATA .......................................................................................................................................................... 27 15 HOPPING CHANNEL NUMBER .............................................................................................................. 28 Report No.: BLA-EMC-202106-A4402 Page 4 of97 BlueAsia of Technical Services(Shenzhen) Co., Ltd. Tel: +86-755-23059481 Email: [email protected] www.cblueasia.com 15.1 LIMITS ..........................…

Text truncated - open the document above for the full version.

Model No.: S300A-BK
