AZP-FDL01TUWireless Modem with Serial Interface

Futaba Corporation

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Oct 24, 2005
Application Purpose: Original Equipment
Date of Application: Oct 24, 2005
Equipment Note: Wireless Modem with Serial Interface
Frequency Range: 2403.32800000 - 2480.12800000
Company: Futaba Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

i WIRELESS DATA COMMUNICATION MODEM FDL01TU Wireless Modem with Serial Interface Instruction Manual Futaba Corporation Industrial Radio Control ii I Notice This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Any unauthorized changes or modifications to this device not expressly approved by Futaba Corporation could void the user’s authority to operate the device and possibly result in damage to the equipment and/or cause serious or fatal injuries to the operator or nearby personnel. This device is intended to be installed and used in accordance with the instructions contained in this manual. Failure to comply with these instructions could void the user’s authority to operate the device and possibly result in damage to the equipment and/or cause serious or fatal injuries to the operator or nearby personnel. iii II Important Safety Information The list of dangers, warnings and cautions in this section contain important information that will help ensure safe operation of the system. Please read carefully and understand all of these items. All installers, operators and maintenance personnel should read and understand this information before installation, use, or maintenance of the FDL01TU system. The FDL01TU system by itself is not inherently dangerous. HOWEVER, WHEN THE FDL01TU IS CONNECTED TO OTHER EQUIPMENT FOR THE PURPOSE OF CONTROL, SAFETY AND ALL POSSIBLE ASSOCIATED DANGERS MUST ALWAYS BE GIVEN THE UTMOST CONSIDERATION DURING SYSTEM INTEGRATION, DESIGN, INSTALLATION, AND USE. The FDL01TU system may be used in virtually unlimited applications. Many of these associated systems can, by themselves, pose a mechanical, electrical or other hazard to operators and other persons or equipment. To address all possible applications and associated safety hazards in this manual would be impossible. The warnings below and throughout this manual give information that will allow safe installation and use the modem system applications. If you have questions regarding the safety of your specific application, please contact the appropriate people for help. Your Futaba sales representative, representatives of the equipment being controlled, and the technical support staff at local branch of Futaba Corporation are among those who can provide assistance with your safety concerns. The following warnings are included in the lists that follow but warrant repetition here: In installations where the FDL01TU system is used to control motion or operation of potentially dangerous equipment, it is imperative for safety that all operators and installers be thoroughly trained in the normal function of that equipment before attempting to control it remotely with the FDL01TU system. To help ensure safe operation of the equipment, the FDL01TU system must be connected so that it will operate in a fail-safe way. In other words, the equipment being controlled should stop or return to its safest state in the absence of a control signal or total loss of RF transmission from the FDL01TU system. Our system uses one of the most reliable methods available to transmit data using radio signals. Many factors can affect a radio signal that may block it or interfere enough to disrupt regular transmission. Because of this, equipment motion or dangerous electrical current, for example, that continues during a loss-of-signal condition could be very dangerous. iv Four symbols are used in the margin of the following section and throughout the manual to indicate the level of hazard or information listed. The symbols are defined as follows: Indicates a hazard that will cause severe personal injury, death, or substantial property damage if the warning is ignored. Indicates a hazard that can cause severe personal injury, death, or substantial property damage if the warning is ignored. Indicates a hazard that will or can cause minor personal injury, or property damage if the warning is ignored. Indicates installation, operation, or maintenance information that is important but not hazard-related. Please read the following safety information carefully. Some of these notices are duplicated throughout the manual, in areas of associated content, for your benefit. II.I General Safety Hazards and Notes Improper installation and/or operation of the FDL01TU system can cause serious or fatal injuries to the operator or nearby persons and cause damage to the FDL01TU system, and any equipment it is used to control. Please read and understand this manual completely and the manual of all equipment being controlled before attempting to operate or install this system. Always keep this manual at a location readily accessible to anyone operating the system and related equipment. Ensure that all operators have read and understood this manual, especially all safety and operation procedures contained in it. Please refer to the section in this manual titled How to Obtain Help for the contact that can supply additional manuals or answers to questions not covered in this manual. If this product is passed on to a different user, be sure that this manual accompanies the product. Be certain that the ins…

Text truncated - open the document above for the full version.

External Photos

Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Photographs of EUT (External & Internal) Figure 1 Wireless Modem with Serial Interface, General Appearance (Front View) Figure 2 Wireless Modem with Serial Interface, General Appearance (Back View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 3 Wireless Modem with Serial Interface, Internal View (Top Cover Removed) Figure 4 Wireless Modem with Serial Interface, Internal View (Bottom Cover Removed) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 5 Wireless Modem with Serial Interface, Internal View (Main Board, Component Side) Figure 6 Wireless Modem with Serial Interface, Internal View (Main Board, Foil Side) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 7 Printed Antenna, General Appearance (Front View) Figure 8 Printed Antenna, General Appearance (Back View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 9 Pencil Type Antenna, General Appearance (Bottom View) Figure 10 Pencil Type Antenna, General Appearance (Side View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 11 Pedestal Antenna, General Appearance (Top View) Figure 12 Pedestal Antenna, General Appearance (Bottom View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 13 Pedestal Antenna, Internal View Figure 14 Flat Antenna (Single Type), General Appearance (Front View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 15 Flat Antenna (Single Type), General Appearance (Back View) Figure 16 Flat Antenna (Single Type), Internal View (Covers and Antenna/ Back View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 17 Flat Antenna (Single Type), Internal View (Antenna/ Front View) Figure 18 Flat Antenna (Double Type), General Appearance (Front View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 19 Flat Antenna (Double Type), General Appearance (Back View) Figure 20 Flat Antenna (Double Type), Internal View (Covers and Antenna/ Back View) Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU Figure 21 Flat Antenna (Double Type), Internal View (Antenna/ Front View)

ID Label/Location Info

Futaba Corporation Wireless Modem with Serial Interface FCC ID: AZP-FDL01TU ID Label Format and Location z Label Format z Label Placement Location

Internal Photos

Parts List/Tune Up Info

ANTENNA GAIN 1 Printed antenna FAJ01EJ010 (Part Number:*********) 2.14dBi 2 Pencil type antenna (Part Number:1M38A03301) 2.14dBi 3 Pedestal antenna (Part Number: 1M38A05801) 0dBi SMA-P 4 Flat antenna(single type) FAA02EJ010 (Part Number:1M38A09202) 2.14dBi 5 Flat antenna(double type) FAA01EJ010 (Part Number:1M38A09201) 2.14dBi

Test Report

FCC ID. AZP-FDL01TU Page 1 of 141 Audix Corporation Report No. EM-F940215 APPLICATION FOR CERTIFICATION On Behalf of Futaba Corporation Wireless Modem with Serial Interface Model No.：FDL01TU FCC ID：AZP-FDL01TU Prepared for : Futaba Corporation 1080 Yabutsuka Chosei-son Chosei-gun Chiba, 299-4395 Japan. Prepared by : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou, Taipei County, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax: (02) 2609-9303 File Number ： EM941048 Report Number ： EM-F940215 Date of Test ： Sep. 14 ~ Oct. 04, 2005 Date of Report ： Oct. 07, 2005 FCC ID. AZP-FDL01TU Page 2 of 141 Audix Corporation Report No. EM-F940215 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION .......................................................................................................4 1. GENERAL INFORMATION .........................................................................................................5 1.1. Description of Device (EUT).................................................................................................................. 5 1.2. Tested Supporting System Details .......................................................................................................... 6 1.3. Description of Test Facility .................................................................................................................... 8 1.4. Measurement Uncertainty....................................................................................................................... 8 2. CONDUCTED EMISSION MEASUREMET...............................................................................9 2.1. Test Equipment ....................................................................................................................................... 9 2.2. Block Diagram of Test Setup.................................................................................................................. 9 2.3. Conducted Emission Limits (§15.207) ................................................................................................... 9 2.4. Operating Condition of EUT ................................................................................................................ 10 2.5. Test Procedure ...................................................................................................................................... 10 2.6. Test Results........................................................................................................................................... 10 3. RADIATED EMISSION MEASUREMENT ..............................................................................21 3.1. Test Equipment ..................................................................................................................................... 21 3.2. Test Setup ............................................................................................................................................. 21 3.3. Radiated Emission Limits (§15.209) .................................................................................................... 22 3.4. Operating Condition of EUT ................................................................................................................ 22 3.5. Test Procedure ...................................................................................................................................... 23 3.6. Test Results........................................................................................................................................... 23 4. 6dB BANDWIDTH MEASUREMENT .....................................................................................105 4.1. Test Equipment ................................................................................................................................... 105 4.2. Block Diagram of Test Setup.............................................................................................................. 105 4.3. Specification Limits (§15.247(a)(2)) .................................................................................................. 105 4.4. Operating Condition of EUT .............................................................................................................. 105 4.5. Test Procedure .................................................................................................................................... 105 4.6. Test Results......................................................................................................................................... 106 5. MAXIMUM PEAK OUTPUT POWER MEASUREMENT ...................................................109 5.1. Test Equipment ................................................................................................................................... 109 5.2. Block Diagram of Test Setup.............................................................................................................. 109 5.3. Specification Limits (§15.247(b)-(3))................................................................................................. 109 5.4. Operating Condition of EUT .............................................................................................................. 109 5.5. Test Procedure .................................................................................................................................... 109 5.6. Test Results......................................................................................................................................... 110 6. EMISSION LIMITATIONS MEASUREMENT ......................................................................111 6.1. Test Equipment ................................................................................................................................... 111 6.2. Block Diagram of Test Setup......................…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID. AZP-FDL01TU Page 124 of 141 Audix Corporation Report No. EM-F940215 11. PHOTOGRAPHS 11.1. Photos of Conducted Emission Measurement Test Antenna: Printed Antenna FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID. AZP-FDL01TU Page 125 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pencil Type Antenna FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID. AZP-FDL01TU Page 126 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pedestal Antenna FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID. AZP-FDL01TU Page 127 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Single Type) FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID. AZP-FDL01TU Page 128 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Double Type) FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID. AZP-FDL01TU Page 129 of 141 Audix Corporation Report No. EM-F940215 11.2. Photos of Radiated Measurement at Semi-Anechoic Chamber 11.2.1. Frequency Range: 30MHz to 1GHz Test Antenna: Printed Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 130 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pencil Type Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 131 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pedestal Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 132 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Single Type) FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 133 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Double Type) FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 134 of 141 Audix Corporation Report No. EM-F940215 11.2.2. Frequency Range: Above 1GHz Test Antenna: Printed Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 135 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pencil Type Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 136 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Pedestal Antenna FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 137 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Single Type) FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 138 of 141 Audix Corporation Report No. EM-F940215 Test Antenna: Flat Antenna (Double Type) FRONT VIEW OF RADIATED MEASUREMENT BACK VIEW OF RADIATED MEASUREMENT FCC ID. AZP-FDL01TU Page 139 of 141 Audix Corporation Report No. EM-F940215 11.3. Photo of 6dB Bandwidth Measurement 11.4. Photo of Maximum Peak Output Measurement FCC ID. AZP-FDL01TU Page 140 of 141 Audix Corporation Report No. EM-F940215 11.5. Photo of Emission Limitations Measurement 11.6. Photo of Band Edges Measurement FCC ID. AZP-FDL01TU Page 141 of 141 Audix Corporation Report No. EM-F940215 11.7. Photo of Power Spectral Density Measurement 11.8. Photo of Occupied Bandwidth 99% Power Measurement

Contact Information

Applicant

Toshikazu Hama(Manager)

[email protected]+81-475-30-1061Fax: +81-475-32-6203

Test Firm

Audix Technology CorporationJeff Chen

[email protected]886-2-26092133Fax: 886-2-26099303

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	6.64 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
