AZP-FRH-SD07TURF Modem using digital modulation

WIRELESS DATA COMMUNICATION MODEM FRH-SD07TU (US Version) FRH-SD07TB (EU Version) Ultra Low Power Consumption Wireless Modem with Serial Interface Instruction Manual Futaba Corporation Industrial Radio Control Page i Futaba Corporation Rev. 020510-01 I Notice This device complies with part 15 of the FCC rules and with ETS 300 440 of the European Telecommunication Standard Institute (ETSI). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Any unauthorized changes or modifications to this device not expressly approved by Futaba Corporation could void the user’s authority to operate the device and possibly result in damage to the equipment and/or cause serious or fatal injuries to the operator or nearby personnel. This device is intended to be installed and used in accordance with the instructions contained in this manual. Failure to comply with these instructions could void the user’s authority to operate the device and possibly result in damage to the equipment and/or cause serious or fatal injuries to the operator or nearby personnel. [Especially for users in Europe] FRH-SD07TB, European version can be used in the following countries: Austria, Belgium, Denmark, Estonia, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Norway, Portugal, Spain, Sweden, Switzerland, The Netherlands and United Kingdom (the Czech Republic and Hungary with limitation, see below). In France and Spain, usable frequency is limited by its country’s regulatory authority. See p.35 F REQUENCY G ROUPING for the frequency usage limitation. Belgium does not authorize FRH-SD07TB itself. FRH-SD07TB must be fitted into the final product, then tested to Radio, EMC and safety requirements. A notification will be only accepted for the final product then. Users in the Czech Republic and Hungary can use FRH-SD07TB modem, but it has some limitation for operation. Please contact local regulatory authority to obtain details before attempt to use FRH-SD07TB modem in that countries. Page ii FRH-SD07TU/TB Manual Rev. 020510-01 II Important Safety Information The list of dangers, warnings and cautions in this section contain important information that will help ensure safe operation of the system. Please read carefully and understand all of these items. All installers, operators and maintenance personnel should read and understand this information before installation, use, or maintenance of the FRH-SD07TU/TB system. The FRH-SD07TU/TB system by itself is not inherently dangerous. HOWEVER, WHEN THE FRH-SD07TU/TB IS CONNECTED TO OTHER EQUIPMENT FOR THE PURPOSE OF CONTROL, SAFETY AND ALL POSSIBLE ASSOCIATED DANGERS MUST ALWAYS BE GIVEN THE UTMOST CONSIDERATION DURING SYSTEM INTEGRATION, DESIGN, INSTALLATION, AND USE. The FRH-SD07TU/TB system may be used in virtually unlimited applications. Many of these associated systems can, by themselves, pose a mechanical, electrical or other hazard to operators and other persons or equipment. To address all possible applications and associated safety hazards in this manual would be impossible. The warnings below and throughout this manual give information that will allow safe installation and use the modem system applications. If you have questions regarding the safety of your specific application, please contact the appropriate people for help. Your Futaba sales representative, representatives of the equipment being controlled, and the technical support staff at local branch of Futaba Corporation are among those who can provide assistance with your safety concerns. The following warnings are included in the lists that follow but warrant repetition here: In installations where the FRH-SD07TU/TB system is used to control motion or operation of potentially dangerous equipment, it is imperative for safety that all operators and installers be thoroughly trained in the normal function of that equipment before attempting to control it remotely with the FRH-SD07TU/TB system. To help ensure safe operation of the equipment, the FRH-SD07TU/TB system must be connected so that it will operate in a fail-safe way. In other words, the equipment being controlled should stop or return to its safest state in the absence of a control signal or total loss of RF transmission from the FRH-SD07TU/TB system. Our system uses one of the most reliable methods available to transmit data using radio signals. Many factors can affect a radio signal that may block it or interfere enough to disrupt regular transmission. Because of this, equipment motion or dangerous electrical current, for example, that continues during a loss-of-signal condition could be very dangerous. Page iii Futaba Corporation Rev. 020510-01 Four symbols are used in the margin of the following section and throughout the manual to indicate the level of hazard or information listed. The symbols are defined as follows: Indicates a hazard that will cause severe personal injury, death, or substantial property damage if the warning is ignored. Indicates a hazard that can cause severe personal injury, death, or substantial property damage if the warning is ignored. Indicates a hazard that will or can cause minor personal inju…

Text truncated - open the document above for the full version.

EMV-Pr ̧fzentrum EMI/EMC-Testcenter Coordinates: ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] ! http://www.senton.de Senton GmbH ! ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing Phoenix Test-Lab TCB July 23, 2002 In reference to FCC ID AZP-FRH-SD07TU Antenna Information, Your inquiry dated 23 July 2002 1) Description of antenna The antenna is a simple tuned half-wave dipole, see photo below. EMV-Pr ̧fzentrum EMI/EMC-Testcenter Coordinates: ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] ! http://www.senton.de 2) Description of the antenna connector The antenna connector is a micro MCX connector which meets the ìunique antenna couplerî requirement. Johann Roidt Senton GmbH

EMV-PrüfzentrumEMI/EMC-Testcenter Coordinates: Äussere Frühlingstrasse 45 ü D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] ü http://www.senton.de Senton GmbH ü Äussere Frühlingstrasse 45 ü D-94315 Straubing Phoenix Test-Lab TCB June 03, 2002 In reference to FCC ID AZP-FRH-SD07TU Justification for Part 15 Unlicensed Modular Transmitter Approval according to DA 00-1407 1. Own RF Shielding Complied, see EUT internal Photographs. No shieldings required 2. Buffered Modulation inputs Complied, see schematic diagrams 3. Own power supply regulation Complied, voltage regulated power supply on board, see schematic diagram 4. Antenna requirements Complied, unique antenna couple employed) 5. Test in stand-alone configuration Complied, see test report for details. Cable lengths typical to actual use. 6. Own FCC ID Complied, the exterior label will be „Contains FCC ID AZP-FRH-SD07TU“ 7. Not applicable, the unit operates under Section 15.247 of the FCC Rules 8. RF Exposure requirements Not applicable since the unit operates under section 15.247 of the FCC Rules, the reference guide contains general installation and operation instructions. Johann Roidt Senton GmbH

Request for Confidentiality June 03, 2002 PHOENIX TEST-LAB GmbH Königswinkel 10 D32825 Blomberg Germany RE: Certification Application FCC ID:AZP-FRH-SD07TU Please be advised that the following information is to be held confidential on behalf of Futaba Corporation of America: • Schematics • Block Diagram • Technical Description The application contains technical information which Futaba Corporation of America deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory Johann Roidt

EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZP-FRH-SD07TU Test Report No. 55503-20031 Page 40 of 103 Pages EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZP-FRH-SD07TU Test Report No. 55503-20031 Page 41 of 103 Pages

FCC ID: AZP-FRH-SD07TU This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZP-FRH-SD07TU Test Report No. 55503-20031 Page 42 of 103 Pages EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZP-FRH-SD07TU Test Report No. 55503-20031 Page 43 of 103 Pages EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZP-FRH-SD07TU Test Report No. 55503-20031 Page 44 of 103 Pages

Page viii FRH-SD07TU/TB Manual Rev. 020510-01 Operational Safety Hazards and Notes Before each use of the FRH-SD07TU/TB modem, ensure that the area where the equipment will be operated is clear of people or obstacles that may affect its safe operation. Before each use of the FRH-SD07TB/TU modem, verify that both the equipment being controlled and the modem are in proper operating condition. When rewriting the FRH-SD07TB/TU modem’s memory registers, do not turn the modem’s power off until the modem returns a “P0” response. If the power is interrupted before a P0 response is returned, the memory contents may be lost or corrupted and the modem operation will be unpredictable. If the memory contents are lost or corrupted, they may be restored to original default settings by reinitializing them. (See p.44 Memory R EGISTER I NITIALIZATION for more details.) Do not attempt to operate remotely controlled equipment outside the communication range of the FRH-SD07TU/TB system. Doing so could cause loss of control of the equipment. Without implementing proper serial communication flow control settings, the baud rate between the modem and its terminal equipment (wire linked) can exceed the wireless link data rate and cause the modem buffer to overflow. This can result in malfunction of the systems being controlled and/or data corruption. Ensure that the appropriate flow control settings are being used for your upper layer application protocol.
