AZPPK-PLL7575MHz Synthesized Module

3PK 3-CHANNEL RADIO CONTROL SYSTEM INSTRUCTION MANUAL Futaba© Digital Proportional R/C System Technical updates and additional programming examples available at: http://www.futaba-rc.com/faq/faq-3pk.html FUTZ8533 for FUTJ32**/33** V1.0 Entire Contents © Copyright 2002 3PK with Optional Accessory Offset Adapter Installed 2 Transmitter Controls Antenna Digital trim 2 (DT2) (default throttle trim) Edit buttons Steering wheel LCD screen Push switch 1 (PS1) Power switch CAMPac Digital trim 3 (DT3) Pilot lamp Digital Dial 3 (DL3) (default CH3 knob) Mechanical ATL adjusting screw Throttle trigger Digital trim 1 (DT1) (default steering trim) (See page 9 for operating instructions.) (See page 50 for the adjustment instructions.) (See page 9 for operating instructions.) (See page 9 for operating instructions.) (See page 12 for instructions to change colors.) Grip Handle Push switch 3 (PS3) Display switch Digital Dial 1 (DL1) (default steering dual rate) (See page 9 for the operating instructions.) Push switch 2 (PS2) Digital Dial 2 (DL2) (default ATL) (See page 9 for the operating instructions.) Sound port Use a commercial earphone with a 3.5mm diameter plug. *The switches, knobs and trimmers may all be reassigned. (see pp. 34-35) Precautions when turning the power switch on and off. When the data is changed using the edit keys or trim levers, wait at least two seconds before turning off the power. If the power is turned off within two seconds after the data was changed, the new data will not be written to memory. Charge Port DSC Port DEFAULT ASSIGNMENT TABLE The factory default functions activated by the switches and knobs are shown below. Default assignments may be changed using the FUNC-DIAL and FUNC-SW programming (See pp. 34-35.) Features assigned to DL1, 2, 3, and DT1, 2, 3 are displayed at all times on right side of LCD screen. CONTROLDEFAULT DT1Steering trim DT2Throttle trim DT3NONE DL1Steering dual rate DL2ATL DL3Channel 3 PS1NONE PS2NONE PS3NONE INTRODUCTION • Transmitter Controls and Defaults .................................2 • Owner’s Manual and Additional Technical Help ..........4 • Support and Service .......................................................4 • Contents and Technical Specifications ..........................5 • Optional Accessories......................................................5 • A Quick Introduction to the 3PK System ......................6 • Getting to Know the Transmitter ...................................8 • Display Switch .......................................................8 • Digital Trim Operation...........................................9 • Digital Grip Dial Operation ...................................9 • Installation....................................................................10 PROGRAMMING..........................................................11 • Menu Selection Overview............................................11 • Direct Selection Menu Overview.................................11 • LV1Functions ...............................................................12 • Level Selection LEVEL-SEL...................................12 • System Settings SYSTEM.......................................13 • Backlighting LHT-MODE............................13 • Backlighting time LHT-TIME.......................13 • LCD contrast CONTRAST............................13 • Buzzer tone BUZ-TONE...............................13 • LED pilot lamp LED-MODE........................13 • Home screen display DISPL-SEL................13 • Model Selection MDL-SEL ....................................14 • Model Name MDL-NAME......................................15 • User Name (set within MDL-NAME) ..........15 • Modulation MOD-MODE........................................16 • Failsafe and Battery Failsafe FAIL-SAFE...............17 • Servo Reversing CH-REV.......................................18 • End Point Adjustment CH-EPA.............................18 • Exponential ST-EXP, TH-EXP..................................20 • Sub-Trim SUB-TRIM..............................................22 • LV2Functions ...............................................................23 • Speed ST-SPEED, TH-SPEED...................................23 • ABS ABS...............................................................24 • Throttle Acceleration TH-ACCEL...........................26 • Idle-up IDLE-UP.....................................................27 • Auto-Start/Engine Cut AT-START..........................28 • Timer TIMER.........................................................30 • Lap List LAP-LIST..................................................31 • Model Reset MDL-RES..........................................32 • Model Copy MDL-COPY........................................33 • Function FUNC-SW, FUNC-DIAL..............................34 • Direct Selection Menu Options DIRC-CALL..........36 • LV3Functions ...............................................................37 • Throttle Electronic ATLTH-ATL............................37 • Steering Dual Rates ST-D/R.................................38 • Servo Display SERVO............................................39 • Channel 3 Position CH3-POSI...............................40 • Programmable Mixes PRG-MIX1, PRG-MIX2.........40 • Brake Mix BRAKE-MIX..........................................42 • Boat Mode BOAT-MODE........................................43 • MC Setup MC-SETUP............................................44 • Adjuster ADJUSTER...............................................45 APPENDICES................................................................46 • Appendix I - Precautions and Warnings ......................46 • Application, Export and Reconstruction..............46 • Liability and Warranty .........................................46 • Battery Recycling.................................................46 • Meaning of Special Markings ..............................47 • Safety Precautions (DO NOT operate without reading) ...…

Text truncated - open the document above for the full version.

Futaba PK-FSM 75 Synthesized RF Module Instructions l To install the PK-FSM 75 into your T3PK, make sure the power switch is in the “off” position. Next, Plug the PK-FSM 75 in place of the crystal type module. Push it all the way in until you hear it “Click” to ensure all contacts are in place. l On the top of the PK-FSM 75,you will find two rotary dials marked X10 and X1. With the supplied plastic screwdriver, carefully turn the slots in each dial corresponding to the channel number you wish to transmit on. l Next, change or select the channel of the receiver to match the channel you have selected. l Turn on the transmitter first and then turn on the receiver. ( approx. 1 second later) To make sure everything is working properly it is advised that you perform a range test with the transmitter antenna shortest position. l If you confirmed everything working properly, you could play your r/c model with the transmitter antenna extended. l Note: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. l Always use only genuine Futaba receivers. Futaba will not be responsible for problems caused by the use of other than Futaba genuine parts. Use the parts specified in the instruction manual and catalog. l This RF module has been exclusively designed for use in transmitter model T3PK. Operation in any other transmitter is not authorized and could void the user's authority to operate the equipment. Only OEM integrators are authorized to install this RF module.

Request for Confidentiality 23 July 2004 EMCCert DR. RAŠEK - Certification Institute- Boelwiese 5 D-91320 Ebermannstadt RE: Certification Application FCC ID: AZPPK-PLL75 Please be advised that the following information is to be held confidential on behalf of Futaba Corporation: • Schematics • Parts List • Block Diagram • Technical Description The application contains technical information which Futaba Corporation deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75 FCC ID AZPPK - PLL75 FUTABA MADE IN TAIWAN

FCC ID AZPPK-PLL75 FCC ID AZPPK - PLL75 FUTABA MADE IN TAIWAN

FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75 FCC ID AZPPK-PLL75

EMV-Pr ̧fzentrum EMI/EMC-Testcenter Page 1 of 48 Pages Straubing, 20 July 2004 T E S T - R E P O R T No. 55503-40449 for PK-FSM 75 MHz (with T3PK) R/C Transmitter Module Applicant: Futaba Corporation Purpose of testing: To show compliance with - FCC Code of Federal Regulations, CFR 47, Part 95 - FCC Code of Federal Regulations, CFR 47, Part 2, Subpart J Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 2 of 48 Pages Table of Contents 1. Administrative Data ..............................................................................................3 2. Identification of Test Laboratory ...........................................................................4 3. Summary of Test Results.....................................................................................5 4. Operation Mode of EUT .......................................................................................6 5. Configuration of EUT and Peripheral Devices ......................................................7 6. Measuring Methods..............................................................................................8 6.1. Maximum Transmitter Power (ß95.639) ........................................................8 6.2. Frequency tolerance (ß95.623) ...................................................................10 6.3. Emission Bandwidth (ß95.633) ....................................................................12 6.4. Unwanted Emission 30 MHz - 1 GHz (ß95.635, ß95.639) ...........................13 7. Photographs of Test Setups...............................................................................15 8. Equipment List ...................................................................................................18 9. Referenced Regulations.....................................................................................20 10. List of Measurements.........................................................................................21 11. Test Results .......................................................................................................22 12. Additional Information supplementary to the Test Report ...................................36 12.1. Calculation of the necessary bandwidth (Section 2.202b) ...........................36 12.2. Additional Information..................................................................................37 13. Additional Results ..............................................................................................42 EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 3 of 48 Pages 1. Administrative Data Equipment Under Test (EUT): PK-FSM 75 MHz (with T3PK) Serial number(s): 001 Type of equipment: R/C Transmitter Module Type of emission: 6K0F1D Parts/accessories: --- FCC-ID: AZPPK-PLL75 Applicant: Futaba Corporation (full address) R/C Engineering Unit 1 1080, Yabutsuka Chosei-son, Chosei-gun, Chiba-ken, 299-4395 Japan Contract identification: --- Contact person: Mr. Fujita Manufacturer: Futaba Corporation Receipt of EUT: June 28, 2004 Dates of test: July, 2004 Note: --- Responsible for testing: Martin Steindl Responsible for test report: Martin Steindl EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 4 of 48 Pages 2. Identification of Test Laboratory Test Laboratory: Senton GmbH EMI/EMC Test Center (full address): Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Contact person: Mr. Johann Roidt Communication: Telephone (+49) 0 94 21 / 55 22-0 Fax (+49) 0 94 21 / 55 22-99 eMail: [email protected] FCC registration number: 90926 Industry Canada file number: IC 3050 EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 5 of 48 Pages 3. Summary of Test Results The tested sample complies with the requirements for R/C Transmitters set forth in the The Code of Federal Regulations 47, Part 95, Subpart C & E and The Code of Federal Regulations 47 Part 2, Subpart J. of the Federal Communication Commission (FCC). Johann Roidt Martin Steindl Laboratory Manager Test Engineer EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 6 of 48 Pages 4. Operation Mode of EUT • transmitting continuously 1 • with battery supply nominal 9.6 V DC) 2 • antenna extended to maximum 3 • operating with f = 75.690 MHz For conducted measurements a dummy load was used as delivered by applicant. A short description of the circuit and the method to stop modulation can be found in the following figure. 1 Modulation as indicated on appropriate test record 2 For conducted measurements replaced by external DC supply 3 For radiated emissions only EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 7 of 48 Pages 5. Configuration of EUT and Peripheral Devices EUT is a transmitter module. it was tested with the T3PK transmitter. Configuration of cables of EUT Not applicable Configuration of peripheral devices connected to EUT Not applicable EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 8 of 48 Pages 6. Measuring Methods 6.1. Maximum Transmitter Power (ß95.639) The maximum transmitter power was measured conducted and radiated. 6.1.1. Conducted Maximum Transmitter Power A spectrum analyzer / EMI test receiver was connected to the output of the transmitter power amplifier (conducted measurement) via dummy load while EUT was operating in transmit mode using the assigned frequency. The trace mode of the spectrum analyzer was set to max hold with: RBW = 100 kHz, VBW = 100 kHz, span = 1 MHz, sweep = 20 ms (auto mode) See figure 1 for the measurement setup. Test equipment used (see equipment list for details): 02,…

Text truncated - open the document above for the full version.

EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 16 of 48 Pages Test setup unwanted radiation 30 MHz - 1 GHz EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: AZPPK-PLL75 Test Report No. 55503-40449 Page 17 of 48 Pages Test setup unwanted radiation 30 MHz - 1 GHz (continued)
