Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 55503-050686 (Edition 2) Page 1 of 34 Pages Straubing, 13 December 2005 T E S T - R E P O R T No. 55503-050686 (Edition 2) for T2PI Transmitter for Model Control Applicant: Futaba Corporation Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 95, Subpart C&E FCC Code of Federal Regulations, CFR 47, Part 2, Subpart J Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 2 of 34 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 4 3 Identification of the Test Laboratory ........................................................................... 5 4 Summary .................................................................................................................... 6 5 Operation Mode and Configuration of EUT................................................................. 7 6 Measurement Procedures........................................................................................... 9 6.1 Maximum Transmitter Power................................................................................ 9 6.2 Frequency tolerance........................................................................................... 12 6.3 Emission Bandwidth ........................................................................................... 14 6.4 Unwanted Emission 30 MHz - 1 GHz ................................................................. 15 7 Photographs Taken During Testing .......................................................................... 17 8 Test Results .............................................................................................................. 21 8.1 Maximum transmitter power ............................................................................... 22 8.2 Carrier Frequency Stability ................................................................................. 24 8.3 Emission Bandwidth ........................................................................................... 27 8.4 Unwanted Radiation 30 MHz - 1 GHz................................................................. 29 9 Referenced Regulations ........................................................................................... 33 10 Additional Information ............................................................................................... 34 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 3 of 34 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : T2PI Parts 2 : 1 Serial number(s): A50415053 Manufacturer: Futaba Corporation Type of equipment: Transmitter for Model Control Version: As delivered FCC ID: AZPT2PIFM-75 Additional parts/accessories: Technical data of EUT Application frequency range: 75.41 - 75.99 MHz Frequency range: 75.41 ñ 75.99 MHz Operating frequency: 75.710 MHz Type of modulation: FSK Pulse train: --- Pulse width: --- Number of RF-channels: 1 Channel spacing: 20 kHz Designation of emissions 3 : 5K0F1D Type of antenna: Telecope Antenna Size/length of antenna: 83 cm Connection of antenna: detachable not detachable Type of power supply: Battery supply Specifications for power supply: nominal voltage: 12.0 V minimum voltage: 10.2 V maximum voltage: 13.8 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 4 of 34 Pages 2 Administrative Data Application details Applicant (full address): Futaba Corporation Electronic Systems 1080, Yabutsuka Chosei-mura, Chosei-gun, Chiba-ken 299-4395 Japan Contact person: Mr. Susumu Sakuma Contract identification: --- Receipt of EUT: 25 October 2005 Date(s) of test: October / November 2005 Note(s): --- Report details Report number: 55503-050686 Edition: 2 Issue date: 9 November 2005 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 5 of 34 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: Senton GmbH EMI/EMC Test Center Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-P-171/94-02 FCC test site registration number 90926 Industry Canada test site registration: IC 3050 Contact person: Mr. Johann Roidt Phone: (+49) (0)9421 5522-0 Fax: (+49) (0)9421 5522-99 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 6 of 34 Pages 4 Summary Summary of test results The tested sample complies with the requirements set forth in the Code of Federal Regulations CFR 47, Part 95, Subpart C & E and the Code of Federal Regulations CFR 47 Part 2, Subpart J of the Federal Communication Commission (FCC). Personnel involved in this report Laboratory Manager: Mr. Johann Roidt Responsible for testing: Mr. Martin Steindl Responsible for test report: Mr. Martin Steindl Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 2) Page 7 of 34 Pages 5 Operation Mode and Configuration of EUT Operation Mode(s) - Transmitting continuously. 4 - With battery supply, nominal 12.0 V. 5 - Antenna extended to maximum. 6 - Operating frequency: 75.710 MHz - For conducted measurements a dummy load was used as delivered by the applicant: 560 470 120 120 12…

Text truncated - open the document above for the full version.

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 1) Page 18 of 34 Pages Test setup for radiated emission measurement (fully anechoic room) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 1) Page 19 of 34 Pages Test setup for radiated emission measurement (fully anechoic room) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55503-050686 (Edition 1) Page 20 of 34 Pages Test setup for carrier frequency stability measurement
