FCC ID Label FCC ID: AZPT6DA-72 Location of Label on the EUT FCC Label Locati on

Garwood Laboratories, Inc. Garwood Laboratories, Inc.Garwood Laboratories, Inc. Garwood Laboratories, Inc. - World Compliance Division Electromagnetic Compatibility Document No. FR1575EUT: R/C Transmitter Model T6DADate: November 7, 2000Page 1 of 28 EMC Measurement / Technical Report FCC Test Specification : FCC Part 95, Subpart C Radio Control (R/C) Radio Service Equipment Authorization : Certification Manufacturer : Futaba Corporation of America Equipment Under Test : 72 MHz Radio Control Transmitter Model T6DA Test Report No. : FR1575 Purchase Order No. : JPH-70061 Document History RevisionIssue DateAffected Pages Description of ModificationsRevised By Approved By N/CNovember 7, 2000 Initial release Garwood Laboratories, Inc. Garwood Laboratories, Inc.Garwood Laboratories, Inc. Garwood Laboratories, Inc. - World Compliance Division Electromagnetic Compatibility Document No. FR1575EUT: R/C Transmitter Model T6DADate: November 7, 2000Page 2 of 28 EMC Measurement / Technical Report Document No. FR1575 From Garwood Laboratories, Inc. World Compliance Division Test for Futaba Corporation of America 72 MHz Radio Control Transmitter Model T6DA Test PersonnelTest Dates Arnulfo Tapia- EMC Sr. Technician2 November 2000 Test Facility Address City, State, Zip Code Phone Fax Garwood Laboratories, Inc.-OC 565 Porter Way Placentia, CA 92870 (714) 572-2027 (714) 572-2025 This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report pertain only to the specified equipment tested. This report may not be used to claim product endorsement by NVLAP or any agency of the U.S. government. Garwood Laboratories, Inc. Garwood Laboratories, Inc.Garwood Laboratories, Inc. Garwood Laboratories, Inc. - World Compliance Division Electromagnetic Compatibility Document No. FR1575EUT: R/C Transmitter Model T6DADate: November 7, 2000Page 3 of 28 TABLE OF CONTENTS MEASUREMENT/TECHNICAL REPORT SUMMARY ................................................................ 4 1. GENERAL INFORMATION ............................................................................................................ 5 1.1 Product Description ....................................................................................................................... 5 1.2 Configuration of Tested System .................................................................................................... 5 1.3 Test Facility.................................................................................................................................... 6 2. TECHNICAL INFORMATION ....................................................................................................... 7 2.1 Circuit Diagram ............................................................................................................................. 7 2.2 Function of Each Active Device.................................................................................................... 7 2.3 Tune - Up Alignment Procedure .................................................................................................... 7 2.4 Frequency Stabilizing Circuitry...................................................................................................... 7 2.5 Additional Circuit Information....................................................................................................... 8 3. PRODUCT LABELING ................................................................................................................... 9 3.1 FCC ID Label................................................................................................................................. 9 3.2 Location of Label on the EUT ....................................................................................................... 9 3.3 Information to the User .................................................................................................................. 9 4. BLOCK DIAGRAMS OF EUT ....................................................................................................... 10 5. TEST RESULTS .............................................................................................................................. 11 5.1 Transmitter Power ....................................................................................................................... 11 5.2 Emission Bandwidth .................................................................................................................... 12 5.3 Field Strength of Spurious Radiation ........................................................................................... 13 5.4 Frequency Stability ..................................................................................................................... 14 5.5 Modulation Characteristics ......................................................................................................... 16 5.6 Crystal Access Restrictions.......................................................................................................... 17 6. PHOTOGRAPHS OF TEST ARRANGEMENTS & EUT CONSTRUCTION ............................ 18 APPENDIX A - TEST EQUIPMENT USED .................................................................................... 24 APPENDIX B - SUPPLEMENTAL TEST DATA ........................................................................... 25 ATTACHMENTS ........................................................................................…
