B4Z-808-UFTUniversal Fire Transmitter

1 Vv‰r…†hy Av…r U…h†€v‡‡r… VAU ITI Part No. 60-917 Installation Instructions Document Number: 466-1940 Rev. A PRELIMINARY January 2002 Preliminary 1/22/02 About this Document This document describes how to install, program and test the Universal Fire Transmitter (UFT). Product Summary The Universal Fire Transmitter is a supervised, battery powered transmitter designed to be connected to externally wired fire detection equipment. The transmitter reports sig- nals from the fire detection equipment to the panel via wire- less signals. The UFT sends supervision transitions to the panel approxi- mately every 64 minutes. An 4.7k Ohm end-of-line resistor must be installed between the UFT and the fire detection equipment for proper supervision of the UFT. The UFT is equipped with a cover tamper and a reed switch designed to provide wall tamper protection. Note The 3.6-volt lithium battery cannot be replaced by installers or users. If you receive a low battery report, you must return the sensor to Interlogix for replacement. Tools Needed ❑#6 flathead screws or 18-gauge brads ❑Screwdriver or brad driver ❑Small wire cutters ❑5/8” drill bit ❑13/16” drill bit (if mounted flush to a wall in a box) ❑Tape measure or ruler ❑pencil, pen or piece of chalk Installation The Universal Fire Transmitter can be installed on a wall or in a non-metallic electrical box. General Sensor Installation Guidelines ❑Keep all sensors within 200-300 feet of the nearest transceiver module. ❑Mount sensors with screws or brads, not double-stick tape. ❑Place sensors at least 5 inches above the floor to avoid damaging them. ❑Use spacers (not included) to keep sensors and magnets away from metal or metallic surfaces such as foil wall- paper. ❑Avoid mounting sensors in areas with a large quantity of metal or electrical wiring, such as a furnace or utility room. ❑Avoid mounting sensors in areas where they will be exposed to moisture. ❑Avoid mounting sensors in locations where the operat- ing temperature (10° to 120° F) will be exceeded. & $87,2 1 Do not remove the jumper from the sensor circuit board! The sensor cannot work without the jumper. Install on a Wall 1.Determine a suitable location for the UFT. 2.Mark where the magnet will be installed. 3.Drill a 3/4” diameter hole 3/4” deep into the wall. 4.Push the magnet into the hole, magnet side first. 5.Remove the UFT cover by squeezing the cover ends firmly to release the tab on the cover from the slot on the UFT base. 6.Remove the circuit board from the UFT base by pulling back the plastic tab and lifting the battery to release the circuit board. 7.Mark where the UFT will be installed over the magnet. See Figure 1 for acceptable magnet locations for a wall mounted UFT. Figure 1. Acceptable magnet locations for a wall mounted UFT. 8.Verify the UFT reed switch is properly aligned with the installed magnet. 9.Mount the UFT base with screws or brads. Use spacers to compensate for metal surfaces or height variations. 2 Preliminary 1/22/02 10. Reattach the circuit board to the UFT base 11.Attach the External Switch (See “Connecting External Switch” in this manual) 12. Reattach the UFT cover to the UFT base. Install in an Electrical Box Use a 4”x4” non-metallic electrical box that is at least 1½” deep. Mounting the box on a wall In this installation method the UFT is mounted in an electri- cal box attached to a wall. The magnet is installed in the wall and passes through the box. 1.Determine a suitable location for the UFT. 2.Mark where the magnet will be installed. 3.Drill a 3/4” diameter hole 3/4” deep into the stud or wall. 4.Mark where the box will be installed over the magnet. 5.Mark the box at the location where the magnet will enter the box. 6.Drill a 13/16” hole in the box at the magnet location. 7.Mark where the UFT will be installed on the box. 8.Verify the UFT reed switch is properly aligned with the magnet hole. 9.Mount the box using screws or brads making sure to align the hole in the box with the hole in the wall or stud. 10. Push the magnet, magnet side first, through the hole in the box and into the hole in the stud or wall. The top of the magnet should be flush with the side of the box. 11. Mount the UFT in the box using velcro strips. 12. Remove the UFT cover by squeezing the cover ends firmly to release the tab on the cover from the slot on the UFT base. 13. Attach the External Switch (See “Connecting External Switch” in this manual) 14. Reattach the UFT cover to the UFT base. Mounting the box in a wall In this installation method the UFT is mounted in an electri- cal box permanently installed in a wall. The magnet is installed in the box. 1.Determine a suitable location for the UFT. 2.Mark the box at the location where the magnet will be installed. 3.Drill a 3/4” hole in the box at the magnet location. 4.Insert the magnet into the hole. 5.Mark where the UFT will be installed on the box 6.Verify the UFT reed switch is properly aligned with the magnet. 7.Mount the box in the wall using screws or brads. 8.Mount the UFT in the box using velcro strips. 9.Remove the UFT cover by squeezing the cover ends firmly to release the tab on the cover from the slot on the UFT base. 10. Attach the External Switch (See “Connecting External Switch” in this manual) 11. Reattach the UFT cover to the UFT base. Connecting External Switch The normally open UFT (60-917) should be connected to a normally open external switch. Connection Guidelines ❑Do not use mechanical switches. ❑Do not use more than 100feet of 18-gauge, stranded or solid core wire in any wire run. ❑Do not use more than 6 feet of untwisted wire in any wire run. ❑Do not run wires parallel to electrical wires. If you can’t avoid a parallel wire run, keep at least 18 inches away from electrical wiring. Note If necessary, you may cross electrical wires at a 90 degree angle. Making the Connection 1.Make the connection to the external fire detection device. (See your device’s instructions.) Important ! A 4.7 k Ohm EOL resistor…

Text truncated - open the document above for the full version.

Interactive Technologies Inc 01/24/02 9:23 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\BLOCK.DOC EXHIBIT C Block Diagram of Product UFT Circuitry 106.5MHz Osc RF Amp Micro Controller Universal Fire TransmitterITI Transmitter

Interactive Technologies Inc 01/24/02 9:23 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\extern.DOC EXHIBIT B External Photographs

Interactive Technologies Inc 01/24/02 9:24 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\id_label.DOC EXHIBIT A ID Label / Location

Interactive Technologies Inc 01/24/02 9:24 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\intern.DOC EXHIBIT H Internal Photographs

Interactive Technologies Inc 01/24/02 9:24 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\OP_DESC.DOC Product Description The product is a wireless Universal Fire Transmitter used in conjunction with a wireless security alarm system. The unit is to be hooked up to an external device (ie...fire pull station or other device). When the unit is in alarm it will transmit to the security panel. The panel will then sound its sirens, and call the monitoring station for help. Normally the unit only transmits supervisory signals every hour. This product is manufactured by ITI. ITI has code imbedded in the microcontroller of the Universal Fire Transmitter to control the transmitter. The microcontroller used is a Texas Instruments 430F1121. The RF circuit consists of a 106.5 MHz oscillator followed by an amplifier. The amplifier is turned on and off to modulate the carrier. EXHIBIT I Operational Description

Interactive Technologies Inc 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 1 of 23 C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\FCC_REPT.DOC Interactive Technologies, Inc. Universal Fire Transmitter B4Z-808-UFT Certification Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 2 of 23 Universal Fire Transmitter B4Z-808-UFT 1/24/2002 Interactive Technologies, Inc. 2266 North Second Street North Saint Paul, MN 55109 (651) 777-2690 Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 3 of 23 1. INTRODUCTION4 2. STATEMENT OF COMPLIANCE4 3. LAB MEASUREMENTS DISCUSSION / TEST NOTES7 3.1 Test Notes7 3.1.1 Transmissions shall cease within 5 seconds of activation [ §15.231(a)(2) ]7 3.1.2 Supervisory Calculation [ §15.231(a)(3) ]9 3.1.3 Duty Cycle Correction Factor [§15.231(b)(2) and §15.35(c)]9 3.1.4 Bandwidth Measurement [ §15.231(c) ]12 3.1.5 Emissions Measurements16 3.1.5.1 Radiated Emissions Summary16 3.1.5.2 FCC Emissions Calculation16 3.1.5.2.1 Terms16 3.1.5.2.2 Example Calculation17 3.1.5.3 Radiated Emissions17 3.1.5.4 Forbidden Bands17 Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 4 of 23 1. Introduction This device is a Universal Fire Transmitter for use in a wireless security system. The unit is powered by one 3.6 Volt Lithium battery. The transmitter’s frequency is crystal controlled and is not adjustable by the user. The device measures approximately 3.25” in width, 1” in depth and 1.5′′ in height. The unit weighs approximately 1.8 ounces with battery. We are requesting Certification under FCC Rules, Part 15, Subpart C, Paragraph 15.231. Please send comments/suggestions on the report format to: [email protected]. 2. Statement of Compliance §2.907Certification This is an application for certification §2.911Application a)This is an application and has been filed electronically with form 731. b)All information required has been supplied. c)The applicant has signed the application (electronically). d)The technical data has been signed. (See Radiated Emissions) e)Applicant signature block on electronic form 731 completed by officer of the company or authorized company personnel. f) The appropriate fee has been paid electronically with VISA on 1/24/02. §2.915Grant This application demonstrates that all applicable technical standards have been met and a grant of this application will serve the public interest. §2.925Label Each piece of equipment for which authorization will be granted will be uniquely identified with “FCC ID: B4Z-808-UFT.” The required statement will appear with the FCC ID on the product and, although not required, in the installation instructions. See Exhibit A, PDF file id_label.pdf Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 5 of 23 §2.947Measurement Procedure a)The measurement procedure follows ANSI C63.4 procedure. Procedural notes are contained in the laboratory report. d)A list of test equipment used is contained in the laboratory report. §2.948Description of Measurement Facilities Measurements were performed at TUV Testing Services Open Test Site. The FCC keeps a full description of the measurement facilities on file. TUV’s acceptance and approval is dated as December 5, 1993 in a letter received from the FCC. The address of the test facility is: TUV Product Service 19035 Wild Mountain Road Taylors Falls, MN 55084-1758 Phone: 651-638-0297 Contact:Joel Schneider Test Engineer in Charge See Exhibit F, PDF file test_pho.pdf for sketch of measurement setup §2.1033Application for Certification a)Form 731 has been electronically filed on 1/24/02. Items that did not apply were left blank. b)This technical report contains the following information where applicable. 1)Full name and mailing address of manufacturer and applicant for certification: Interactive Technologies Inc 2266 North Second Street North Saint Paul, MN 55109 2)FCC Identifier: B4Z-808-UFT 3)Copy of installation instructions: See Exhibit G, PDF file: user_man.pdf 4)Brief Description of circuit functions and device operation: See Exhibit I, PDF file op_desc.pdf See Exhibit D, PDF file schemat.pdf for schematics (page 1) and parts placement (page 2) diagrams. Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 6 of 23 5) Block Diagram See Exhibit C, PDF file block.pdf. 6)Report of the measurements of radiation and conducted emissions: This document. 7)Photographs External: See Exhibit B, PDF file extern.pdf Internal: See Exhibit H, PDF file intern.pdf 8)Peripheral or Accessory devices: This is not applicable since this device is stand-a- lone product. 9) Transition Rules This application is not pursuant to the transition rules of §15.37 10)Emergency Broadcast decoding: This is not applicable to device in this application. 11)Application for direct sequence spread spectrum devices... This is not applicable to device in this application. 12)Application for scanning receivers... This is not applicable to device in this application. c)Composite Systems This is not applicable to device in this application. Interactive Technologies Inc FCC_REPT.DOC 01/24/02 11:07 AM FCC ID: B4Z-808-UFT Page 7 of 23 3. Lab Measurements Discussion / Test Notes 3.1 Test Notes 3.1.1 Transmissions shall cease within 5 seconds of activation [ §15.231(a)(2) ] When the unit communicates with the security alarm panel, 8 packets are sent in a transmission. The packet duration is, at most, 30 mS, see Duty Cycle Correction Factor [§15.231(b)(2) and §15.35(c)] . The time between packets random between 100 mS and 450 mS so the length of the longest transmission is: 8*30mS + 7*450mS = 3.39 seconds. So long as the alarm condition is present, the device will re-transmit every minute as allowed in §15.231(a)(4). The following plot shows a 8 packet transmission that concludes in less than 5 seconds. Interactive Technologies Inc FCC_REPT.DO…

Text truncated - open the document above for the full version.

Interactive Technologies Inc 01/24/02 9:24 AM FCC ID: B4Z-808-UFT C:\WINNT\Profiles\Kenl.Nelson\Desktop\FCC Documintation\Submittles\UFT\peices\TEST_PHO.DOC 0.8 Meters EUT Receiving Antenna 3 Meters EXHIBIT F Test Setup Sketch for Radiated Emissions 1 Meter
