B4Z-846-TCVR900MHz Bus Transceiver

4/23/2004 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Confidentiality for FCC ID# B4Z-846-TCVR Gentlemen: If possible, we would like the following sections of this application to be placed in the nonpublic file. This is necessary to protect proprietary information in these documents. 1) Block Diagram 2) Schematics and parts placement drawings 3) Operational Description Thank you for your help. Sincerely, Paul Saldin Senior Engineer

GE Security, Inc extern.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 3 Figure 1: Picture of DUT on test table, showing daughterboard connected and bus wires for each of the security panels connected. EXHIBIT H External Photographs GE Security, Inc extern.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 2 of 3 Figure 2: Picture of DUT on test table, along with security systems attached. GE Security, Inc extern.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 3 of 3 Figure 3: Picture of test setup for conducted emissions testing.

GE Security, Inc intern.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 2 Figure 1: Picture of DUT board and antenna. Figure 2: Close-up picture of DUT. EXHIBIT I Internal Photographs GE Security, Inc intern.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 2 of 2 Figure 3: Picture of back side of DUT. Figure 4: Picture of circuitry under RF shield.

GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 12 GE Security, Inc. Base Station Transceiver B4Z-846-TCVR Certification GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 2 of 12 Base Station Transceiver B4Z-846-TCVR 3/3/2004 GE Security, Inc. 1275 Red Fox Road Arden Hills, MN 55112 (651) 777-2690 GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 3 of 12 1. INTRODUCTION 4 2. STATEMENT OF COMPLIANCE 4 3. LAB MEASUREMENTS DISCUSSION / TEST NOTES 7 3.1 Frequencies to be Examined [§15.31(m)] 7 3.2 Antenna Requirement [ §15.203 ] 7 3.3 Antenna Characteristics [ §15.204 ] 7 3.3.1 Antenna Type 7 3.3.2 Antenna Manufacturer 7 3.3.3 Antenna Gain 7 3.4 Public Utility Power Line Measurements [ §15.207 ] 7 3.5 Frequency Hopping System Description[ §15.247(a) ] 7 3.5.1 Carrier Frequency Separation 7 3.5.2 Randomization of Hopping Frequencies 8 3.5.3 System Receiver Description 8 3.5.4 Number of Hopping Frequcncies 8 3.5.5 Time of Occupancy 8 3.5.6 20dB Bandwidth 8 3.6 Output Power [§15.247(b)] 8 3.6.1 Peak Output Power 8 3.6.2 De Facto EIRP Limit 8 3.6.3 RF Exposure Compliance Requirements 8 3.7 Spurious Emissions [ §15.247(c) ] 8 3.7.1 Band-Edge Compliance 10 3.7.2 Spurious RF Conducted Emissions 10 3.7.3 Spurious RF Radiated Emissions 11 3.7.3.1 Calculation of allowed limit 11 3.7.3.2 Radiated Emissions Results 11 3.8 True Frequency Hopping Compliance [ §15.247(g) ] 12 3.9 Coordination of Systems [ §15.247(h) ] 12 GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 4 of 12 1. Introduction This device is a radio transceiver. It receives signals from existing ITI transmitters or other transceivers. It transmits signals to other base station transceivers. A hardwired bus provides a data link to an external board or a security panel. Both the receiver and the transmitter operate as frequency hopping spread spectrum (FHSS) links using the 902-928MHz ISM band. We are requesting Certification under FCC Rules, Part 15, Subpart C, Paragraph 15.247. 12VDC power is supplied to the device via either a hardwired bus connection or a Class 2 transformer. Please send comments/suggestions on the report to [email protected]. Grantee Code: B4Z 2. Statement of Compliance §2.907 Certification This is an application for certification §2.911 Application a) This is an application and has been filed electronically with form 731. b) All information required has been supplied. c) The applicant has signed the application (electronically). d) The technical data has been signed. e) Applicant signature block on electronic form 731 completed by officer of the company or authorized company personnel. f) The appropriate fee has been paid electronically with VISA on 03/03/2004. §2.915 Grant This application demonstrates that all applicable technical standards have been met and a grant of this application will serve the public interest. §2.925 Label Each piece of equipment for which authorization will be granted will be uniquely identified with “FCC ID: B4Z-846-TCVR.” The required statement will appear with the FCC ID on the product. See Exhibit A, “id label.pdf”. GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 5 of 12 §2.947 Measurement Procedure a) The scan of the restricted bands was made in a radiated manner, with the unit powered by Class 2 transformer. The radiated measurement procedure follows ANSI C63.4 procedure. b) All other RF measurements were made in a conducted manner. c) Procedural notes are contained in the laboratory report. d) A list of test equipment used is contained in the laboratory report. §2.948 Description of Measurement Facilities Measurements were performed at TUV Testing Services Open Test Site. The FCC keeps a full description of the measurement facilities on file. TUV’s acceptance and approval is dated as December 5, 1993 in a letter received from the FCC. The address of the test facility is: TUV Product Service 19035 Wild Mountain Road Taylors Falls, MN 55084-1758 Phone: 651-638-0297 Contact: Joel Schneider Test Engineer in Charge See Exhibit B, “test_pho.pdf”, for sketch of radiated measurement setup. §2.1033 Application for Certification a) Form 731 has been electronically filed on 03/03/2004. Items that did not apply were left blank. b) This technical report contains the following information where applicable. 1) Full name and mailing address of manufacturer and applicant for certification: GE Security, Inc. 1275 Red Fox Road Arden Hills, MN 55112 2) FCC Identifier: B4Z-846-TCVR 3) Copy of installation instructions: See Exhibit C, “install manual.pdf” GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 6 of 12 4) Brief Description of circuit functions and device operation: See Exhibit D, “op_desc.pdf” for operational description. See Exhibit E, “schematic.pdf” for schematic. See Exhibit F, “ppd.pdf” for parts placement diagram. 5) Block Diagram See Exhibit G, “block.pdf”. 6) Report of the measurements of radiated and conducted emissions: Exhibits M through Z show data and plots, and are discussed later in this report. 7) Photographs External: See Exhibit H, “extern.pdf”. Internal: See Exhibit I, “intern.pdf”. 8) Peripheral or Accessory devices: This device is designed to interface via hardwired bus to an external board or security panel. There are three external ports for the connection of these devices. See Exhibit D, “op_desc.pdf” for more information. The testing for this report was performed with a representative device connected to each of the external ports. 9) Transition Rules This application is not pursuant to the transition rules of §15.37. 10) Application for scanning receivers: Not applicable to this device. 11) Application for operation within the 59 – 64GHz band: Not applicable to this device. c) Composite Systems Not applicable to this device. GE Security, Inc FCC_REPT_TCVR.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 7 of 12 3. Lab Measurements Discussion / Test Notes…

Text truncated - open the document above for the full version.

GE Security, Inc 20dB Bandwidth.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 1 EXHIBIT Q 20dB Bandwidth

GE Security, Inc channel separation.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 1 EXHIBIT P Channel Separation

GE Security, Inc conducted output power.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 1 of 3 Figure 1: Peak conducted output power, low channel. EXHIBIT T Conducted Emissions GE Security, Inc conducted output power.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 2 of 3 Figure 2: Peak conducted output power, mid channel. GE Security, Inc conducted output power.DOC 3/3/2004 FCC ID: B4Z-846-TCVR Page 3 of 3 Figure 3: Peak conducted output power, high channel.
