1 Dhyyhv Dpv Preliminary 8/5/04 ZZZJHVHFXULW\FRP B@Trpv 9 Product Summary The module is a UL listed device that adds or expands panel wireless zone capacity. See the spe- cific panel Installation Instructions for complete UL requirements for the system you are install- ing. The transceiver is compatible with all GE Security 319.5 MHz crystal and SAW wireless sensors and touchpads, and can be located up to 2,800 feet away from the panel (see Table 2). It receives information from wireless sensors and touchpads then sends the data to the panel via the Super- Bus 2000 digital data bus. It also transmits information to other transceivers. Power for the mod- ule is provided by the panel. Transceivers are available in 16-zone (-16Z), 32-zone (-32Z), or panel maximum (-MAX) capac- ities. The SuperBus 2000 RF Transceiver Module features: •Compatibility with all GE Security 319.5 MHz wireless sensors, touchpads, and sirens. •Backward compatibility with SuperBus panels. •1,500 feet nominal, open air receiving range. Figure 1 shows the transceiver module components and Table 1 describes those components. Figure 1. Transceiver Board Table 1: Component Descriptions ComponentFunction AntennaProvide communication with wireless devices. Antenna LEDs Terminal Strip 9pr Iir) #%%YYYY Sr 6 6t !# QS@GDHDI6S` Tr7!" ($HCaSA UhprvrHqyr Qh I %YYYY($S 2 SuperBus 2000 319.5 MHZ RF Transceiver Module Installation Instructions Preliminary 8/5/04 InstallationInstallation Guidelines Observe the following guidelines when installing the transceiver module: •Concord ™ systems can accommodate a maximum of 96 wireless sensors/zones. •In Concord systems, up to 16 SuperBus 2000 devices can be connected to the panel (SuperBus 2000 Touchpads, Receivers, Transceivers, HIMs, HOMs, ESMs, etc.). •Each bus device must have a different unit number. •Leave 4 inches above the module for the antenna. •When mounting the module away from the panel, use the wire length guidelines in Tabl e 2. •Avoid areas that are likely to expose the module to moisture. •Avoid areas with excessive metal or electrical wiring, including furnace and utility rooms. If unavoidable, mount on or near metal with the antenna extending above the metallic surfaces, as shown in Figure 2. Figure 2. Mounting on or Near Metal Tools and Supplies •Screwdrivers •Drill with bits •Mounting screws and anchors (included) •4-conductor, 22-gauge or larger, stranded wire •Support standoff (included with Concord cabinet) •¼-inch press-fit reed switch and magnet (not included) •Small hammer Mounting the Transceiver The module can be mounted on any interior wall (protected from the elements). SuperBus 2000 Device ID Number LabelIdentifies unique module SuperBus 2000 device ID number (SuperBus 2000 panels). Transceiver Status LEDOn continuously when the transceiver is powered. Flashes when an RF signal is received. Terminal StripUsed for power and bus connections to panel. Table 1: Component Descriptions ComponentFunction Table 2: Maximum Module Wire Lengths Wire Gauge (Unshielded or Shielded) Max. Wire Length Between Module and Concord Panel 182,800 feet 221,100 feet METAL METAL 3SuperBus 2000 319.5 MHZ RF Transceiver Module Installation Instructions Preliminary 8/5/04 To mount the module on a wall: 1. Remove the panel AC power transformer and disconnect the backup battery. 2. Remove the module cover and set it aside. 3. Hold the base against the mounting surface and mark the three mounting holes. Remember to leave at least 10 inches above the base for the antenna. 4. Drill holes and insert the appropriate anchors. 5. Secure the back-plate to the wall with included panhead screws. Concord Panel Wiring This section describes how to wire the transceiver module to Concord panels. To wire the transceiver module to Concord panels: 1. Disconnect the panel power transformer and backup battery. 2. Wire the module to the panel power and bus terminals as shown in Figure 3. Figure 3. Wiring Module to Concord Panel Power UpUse the following procedures for powering up the system and verifying bus communication. Note In order to enter panel pro- gram mode to verify unit numbers, an alphanumeric touchpad must be con- nected to all Concord pan- els. To power up the panel and transceiver module: 1. Verify that all wiring at the panel, touchpad, and transceiver is correct. 2. Connect the panel backup battery and plug in the panel AC power transformer. 3. Verify that the transceiver module status LED is on. 4. If desired, enter panel program mode to verify unit number exists (see panel Installation Instructions for more information). Note If the transceiver module LED is not on, unplug the panel AC power transformer, disconnect the backup battery, and see Table 3 “Troubleshooting”. SpecificationsCompatibility: ............................ GE Security Concord panels. GE Security 319.5 MHz wireless sensors and touchpads Power Required: ........................ 12 VDC nominal 200 mA maximum draw (from panel) Storage Temperature: ................. -30° to 140°F (-34° to 60°C) Operating Temperature: ............. 32° to 140°F (0° to 60°C) Maximum Humidity: ................. 90% relative humidity, noncondensing Wireless Signal Range: .............. 1,500 feet nominal, 1,500 feet typical open air (may vary with application) Dimensions: .............................. 4.125” x 5.25” x 1.0” (L x W x H), excluding antenna To prevent damaging the panel or module, remove the panel AC power transformer and disconnect the backup battery before installation. Caution ! You must be free of static electricity before handling circuit boards. Wear a ground- ing strap or touch a bare metal surface to discharge static electricity. Static 6345 PANEL TERMINAL STRI P +12 VDC BUS A BUS B GND SUPERBUS 2000 RF TRANSCEIVER MODULE TERMINAL STRI P 4123 +12 VDC BUS A BUS B GND 4 SuperBus 2000 319.5 MHZ RF Transceiver Module Installation Instructions Preliminary …

Text truncated - open the document above for the full version.

Block Diagram

GE Security, Inc. 08/05/04 4:44 PM FCC ID: B4Z-875-TCVR C:\DATA\PROJECTS\CURRENT\SUPER BOARD\433_319.5 SUPER BOARD TRANSCEIVER\55875A\55875A General\319.5 A2 Regulation\B4Z-875-TCVR\block.DOC Power Amp RF Amp EXHIBIT C Block Diagram of Product Microchip PIC18LF242 Microcontroller 319.5 MHz Osc. MAX7033 Receiver Chip Antenna Switch

External Photos

GE Security, Inc. 07/28/04 12:59 PM FCC ID: B4Z-875-TCVR C:\DATA\PROJECTS\CURRENT\SUPER BOARD\433_319.5 SUPER BOARD TRANSCEIVER\55875A\55875A General\319.5 A2 Regulation\B4Z-875-TCVR\extern.DOC Figure 1: Picture of the front of the DUT on test table, along with security systems attached. EXHIBIT B External Photographs GE Security, Inc. extern.DOC 07/28/04 12:59 PM FCC ID: B4Z-875-TCVR Page 2 of 2 Figure 1: Picture of the back of the DUT on test table, along with security systems attached.

ID Label/Location Info

GE Security, Inc. 08/06/04 10:39 AM FCC ID: B4Z-875-TCVR C:\DATA\PROJECTS\CURRENT\SUPER BOARD\433_319.5 SUPER BOARD TRANSCEIVER\55875A\55875A General\319.5 A2 Regulation\B4Z-875-TCVR\id_label.DOC EXHIBIT A ID Label / Location

Operational Description

GE Security, Inc. 08/05/04 4:47 PM FCC ID: B4Z-875-TCVR C:\DATA\PROJECTS\CURRENT\SUPER BOARD\433_319.5 SUPER BOARD TRANSCEIVER\55875A\55875A General\319.5 A2 Regulation\B4Z-875-TCVR\op_desc.DOC Product Description This device is a transceiver. It receives signals from existing ITI transmitters or other super board transceivers. It transmits signals to other compatible ITI receivers. Both the receiver and the transmitter operate 319.5 MHz. A hardwire bus provides a data link to an external board or security panel. There are three possible configurations for the hardwire bus: • A Concord security system may be connected to the 4 position terminal block. In this case, 12VDC power is supplied by the Concord security system. • A Networx security system may be connected to the 3 position terminal block. In this case, 12VDC power is supplied by the Networx security system. • A daughter board may be connected to the 8 position header. In this case, 12VDC power is supplied by a Class 2 transformer. The transmitter circuit consists of a 319.5 MHz oscillator followed by an amplifier. The transmitter amplifier is connected to a RF switch which selects either the right or left antenna to be transmitted from. The receiver is of the superheterodyne type. It uses a Maxim MAX7033 chip running on a 4.825 MHz crystal. The receiver input is connected to a RF switch, which selects either the right or left antenna. EXHIBIT I Operational Description

RF Exposure Info

CONDUCTED EMISSIONS Test Report #: WC403493 Run 5 Test Area: LTS EUT Model #: 56-875-95R with Concord Panel Date: 7/30/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 23.0 °C Test Method: FCC B Air Pressure: 98.0 kPa Customer: GE Sercurity Rel. Humidity: 46.0 % EUT Description: 319.5 MHz Super board transceiver. Notes: Data File Name: 3493.dat Page: 1 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature List of measurements for run #: 5 FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) EUT Lead DELTA1 FCC-B CE DELTA2 161.23 kHz 25.38 Qp 0.0 / 0.05 / 0.0 / 0.0 25.43 L1 n/a n/a 161.23 kHz 4.32 Av 0.0 / 0.05 / 0.0 / 0.0 4.37 L1 n/a n/a 278.61 kHz 30.43 Qp 0.0 / 0.04 / 0.0 / 0.0 30.47 L1 n/a n/a 278.61 kHz 21.19 Av 0.0 / 0.04 / 0.0 / 0.0 21.23 L1 n/a n/a 890.0 kHz -0.98 Qp 0.0 / 0.04 / 0.0 / 0.0 -0.94 L1 -48.94 n/a 29.492 MHz 21.73 Qp 0.5 / 0.68 / 0.0 / 0.0 22.91 L1 -25.09 n/a 29.492 MHz 19.42 Av 0.5 / 0.68 / 0.0 / 0.0 20.6 L1 n/a n/a 8.1 MHz 3.69 Qp 0.2 / 0.11 / 0.0 / 0.0 4.0 L1 -44.0 n/a 29.755 MHz 14.92 Qp 0.5 / 0.69 / 0.0 / 0.0 16.11 L1 -31.89 n/a 30.0 MHz 13.72 Qp 0.5 / 0.7 / 0.0 / 0.0 14.92 L1 -33.08 n/a 29.0 MHz 13.33 Qp 0.5 / 0.66 / 0.0 / 0.0 14.49 L1 -33.51 n/a 890.0 kHz 1.91 Qp 0.0 / 0.04 / 0.0 / 0.0 1.95 N -46.05 n/a 8.1 MHz 1.97 Qp 0.2 / 0.11 / 0.0 / 0.0 2.28 N -45.72 n/a 29.0 MHz 13.52 Qp 0.5 / 0.66 / 0.0 / 0.0 14.68 N -33.32 n/a 29.492 MHz 23.72 Qp 0.5 / 0.68 / 0.0 / 0.0 24.9 N -23.1 n/a 29.755 MHz 15.79 Qp 0.5 / 0.69 / 0.0 / 0.0 16.98 N -31.02 n/a 30.0 MHz 14.79 Qp 0.5 / 0.7 / 0.0 / 0.0 15.99 N -32.01 n/a CONDUCTED EMISSIONS Test Report #: WC403493 Run 5 Test Area: LTS EUT Model #: 56-875-95R with Concord Panel Date: 7/30/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 23.0 °C Test Method: FCC B Air Pressure: 98.0 kPa Customer: GE Sercurity Rel. Humidity: 46.0 % EUT Description: 319.5 MHz Super board transceiver. Notes: Data File Name: 3493.dat Page: 2 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature Measurement summary for limit1: FCC-B CE (Qp) FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) EUT Lead DELTA1 FCC-B CE 29.492 MHz 23.72 Qp 0.5 / 0.68 / 0.0 / 0.0 24.9 N -23.1 29.755 MHz 15.79 Qp 0.5 / 0.69 / 0.0 / 0.0 16.98 N -31.02 30.0 MHz 14.79 Qp 0.5 / 0.7 / 0.0 / 0.0 15.99 N -32.01 29.0 MHz 13.52 Qp 0.5 / 0.66 / 0.0 / 0.0 14.68 N -33.32 8.1 MHz 3.69 Qp 0.2 / 0.11 / 0.0 / 0.0 4.0 L1 -44.0 890.0 kHz 1.91 Qp 0.0 / 0.04 / 0.0 / 0.0 1.95 N -46.05 CONDUCTED EMISSIONS Test Report #: WC403493 Run 5 Test Area: LTS EUT Model #: 56-875-95R with Concord Panel Date: 7/30/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 23.0 °C Test Method: FCC B Air Pressure: 98.0 kPa Customer: GE Sercurity Rel. Humidity: 46.0 % EUT Description: 319.5 MHz Super board transceiver. Notes: Data File Name: 3493.dat Page: 3 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature Graph: 100kHz1MHz10MHz100MHz 0 5 10 15 20 25 30 35 40 45 50 FCC-B CE Qp-measurements Av-measurements

RF Exposure Info

CONDUCTED EMISSIONS Test Report #: 3424 Run 6 Test Area: LTS EUT Model #: 57-875-95R Date: 7/23/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 22.0 °C Test Method: Air Pressure: 100.0 kPa Customer: GE Security Rel. Humidity: 60.0 % EUT Description: 319.5 MHz Super Board transceiver Notes: Power via Networx panel Data File Name: rescue.dat Page: 1 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature List of measurements for run #: 6 FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) EUT Lead DELTA1 FCC-B CE DELTA2 450.0 kHz -5.95 Qp 0.0 / 0.04 / 0.0 / 0.0 -5.91 N -53.91 n/a 1.0 MHz -5.84 Qp 0.0 / 0.04 / 0.0 / 0.0 -5.8 N -53.8 n/a 5.0 MHz 0.0 Qp 0.1 / 0.09 / 0.0 / 0.0 0.19 N -47.81 n/a 10.0 MHz 15.73 Qp 0.2 / 0.22 / 0.0 / 0.0 16.15 N -31.85 n/a 20.0 MHz 7.27 Qp 0.3 / 0.4 / 0.0 / 0.0 7.97 N -40.03 n/a 30.0 MHz 30.05 Qp 0.5 / 0.7 / 0.0 / 0.0 31.25 N -16.75 n/a 450.0 kHz -6.08 Qp 0.0 / 0.04 / 0.0 / 0.0 -6.04 N -54.04 n/a 1.0 MHz -6.09 Qp 0.0 / 0.04 / 0.0 / 0.0 -6.05 N -54.05 n/a 5.0 MHz -3.12 Qp 0.1 / 0.09 / 0.0 / 0.0 -2.93 N -50.93 n/a 10.0 MHz 11.94 Qp 0.2 / 0.22 / 0.0 / 0.0 12.36 N -35.64 n/a 20.0 MHz 8.67 Qp 0.3 / 0.4 / 0.0 / 0.0 9.37 N -38.63 n/a 30.0 MHz 33.26 Qp 0.5 / 0.7 / 0.0 / 0.0 34.46 N -13.54 n/a CONDUCTED EMISSIONS Test Report #: 3424 Run 6 Test Area: LTS EUT Model #: 57-875-95R Date: 7/23/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 22.0 °C Test Method: Air Pressure: 100.0 kPa Customer: GE Security Rel. Humidity: 60.0 % EUT Description: 319.5 MHz Super Board transceiver Notes: Power via Networx panel Data File Name: rescue.dat Page: 2 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature Measurement summary for limit1: FCC-B CE (Qp) FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) EUT Lead DELTA1 FCC-B CE 30.0 MHz 33.26 Qp 0.5 / 0.7 / 0.0 / 0.0 34.46 N -13.54 10.0 MHz 15.73 Qp 0.2 / 0.22 / 0.0 / 0.0 16.15 N -31.85 20.0 MHz 8.67 Qp 0.3 / 0.4 / 0.0 / 0.0 9.37 N -38.63 5.0 MHz 0.0 Qp 0.1 / 0.09 / 0.0 / 0.0 0.19 N -47.81 1.0 MHz -5.84 Qp 0.0 / 0.04 / 0.0 / 0.0 -5.8 N -53.8 450.0 kHz -5.95 Qp 0.0 / 0.04 / 0.0 / 0.0 -5.91 N -53.91 CONDUCTED EMISSIONS Test Report #: 3424 Run 6 Test Area: LTS EUT Model #: 57-875-95R Date: 7/23/04 EUT Serial #: EUT Power: 60 Hz / 110 VAC Temperature: 22.0 °C Test Method: Air Pressure: 100.0 kPa Customer: GE Security Rel. Humidity: 60.0 % EUT Description: 319.5 MHz Super Board transceiver Notes: Power via Networx panel Data File Name: rescue.dat Page: 3 of 3 Tested by: J. C. Sausen Printed Signature Reviewed by: Printed Signature Graph: 100kHz1MHz10MHz100MHz -10 0 10 20 30 40 50 FCC-B CE Qp-measurements

Test Setup Photos

GE Security, Inc. 07/28/04 1:01 PM FCC ID: B4Z-875-TCVR C:\DATA\PROJECTS\CURRENT\SUPER BOARD\433_319.5 SUPER BOARD TRANSCEIVER\55875A\55875A General\319.5 A2 Regulation\B4Z-875-TCVR\test_pho.DOC 0.8 Meters EUT Receiving Antenna 3 Meters EXHIBIT F Test Setup Sketch for Radiated Emissions 1 Meter
