B4Z-958F-BTWIWiFi and Bluetooth

Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: AdvisorOne Bluetooth and WiFi Module Model: AVO-BTWIFI FCC ID: B4Z-958F-BTWI Dated this 06 th day of June, 2013. Kevin Flanders Global Product Compliance Leader - Intrusion UTC Fire & Security Americas Corporation, Inc. T: 651.773.4663 eFax: 1.860.353.5400 E: [email protected] 1275 Red Fox Rd Arden Hills, MN 55112

1(1) Attention: Application Examiner Re: Request for confidentiality Applicant: UTC Fire and Security FCC ID:B4Z-958F-BTWI To whom it may concern, Request is hereby submitted by UTC Fire and Security to withhold permanently from public review certain portions of this application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Tune up procedure • Parts list • Internal photos o Device is not sold to end user. • User manual o Professional installation required so the manual is not provided to the consumer since the consumer cannot service the device Rationale for request for confidentiality: UTC Fire and Security has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Sincerely, Kevin Flanders Global Product Compliance Leader UTC Fire and Security

RF EXPOSURE COMPLIANCE Report Number: 101039189MIN-001H Project Number: G101039189 RF Exposure Compliance: MPE Requirements For Simultaneous Transmission Operations The following are transmitters that qualify for simultaneous transmission: AVO-GSM3 1900MHz Radio (see report 101039189MIN-001D) - maximum calculated MPE of 0.11mW/cm 2 AVO-BTWI, WiFi Radio (see report 101039189MIN-001B) - maximum calculated MPE of 0.052mW/cm 2 AVO-ZW, Z-Wave Radio – see calculations below: The Maximum Radiated Field Strength for AVO-ZW, Z-Wave Radio at Fundamental Frequency is 93.4dBμV/m = 46.774μV/m = 0.047V/m (see report 101039189MIN-001A) Antenna Gain = 1dBi or 1.26 numeric gain ERP= (E x d) 2 /30G= (0.047 V/m * 3m) / 30 * 1.26 = 0.54mW or -2.7dBm Maximum Permissible Exposure (MPE) calculation: S(mW/cm 2 ) = EIRP(mW) / 4πD 2 , or S = 0.54 / (4πx400) = 0.0001mW/cm 2 Therefore, the sum of the MPE for all three radios operating simultaneously based on calculation is: ΣS(mW/cm 2 ) = 0.11mW/cm 2 + 0.0052mW/cm 2 + 0.0001mW/cm 2 = 0.163mW/cm 2 that is less then 1mW/cm 2 . Prepared by: Date: May 24, 2013 Uri Spector Reviewed by: Date: May 24, 2013 Simon Khazon

TEST REPORT Report Number: 101039189MIN-001B Project Number: G101039189 Testing performed on the AdvisorOne AVO-BTWI, WiFi FCC ID: B4Z-958F-BTWI Industry Canada ID: 1175C-958FBTWI to 47 CFR Part 15. 247:2010 RSS- 210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2010, §15.107 and §15.109, Class / ICES-003, Issue 5:2012 For UTC Fire & Security Americas Corporation, Inc. Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA UTC Fire & Security Americas Corporation, Inc. 1275 Red Fox Road Arden Hills, MN 55112 USA Prepared by: Date: May 3, 2013 Uri Spector Reviewed by: Date: May 3, 2013 Simon Khazon This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report No: 101039189MIN-001B FCC ID: B4Z-958F-BTWI IC ID: 1175C-958FBTWI Page 2 of 125 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY.......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS........................................................................................ 8 3.1 6dB Emission bandwidth (EBW) of the digital modulation ................................................. 8 3.2 Maximum peak output power............................................................................................ 18 3.3 Power spectral density...................................................................................................... 30 3.4 Antenna conducted spurious emissions ........................................................................... 42 3.5 Radiated spurious emissions............................................................................................ 76 3.6 RF Exposure Compliance ............................................................................................... 114 3.7 Transmitter power line conducted emissions ................................................................. 115 3.8 Receiver/digital device radiated emissions..................................................................... 118 3.9 Digital device conducted emissions................................................................................ 122 4.0 TEST EQUIPMENT................................................................................................................... 125 EMC Report No: 101039189MIN-001B FCC ID: B4Z-958F-BTWI IC ID: 1175C-958FBTWI Page 3 of 125 1.0 GENERAL DESCRIPTION Model: AdvisorOne Type of EUT: Security Alarm FCC ID: B4Z-958F-BTWI Industry Canada ID: 1175C-958FBTWI Related Submittal(s) Grants: None Company: UTC Fire & Security Americas Corporation, Inc. Customer: Mr. Kevin Flanders Address: 1275 Red Fox Road Arden Hills, MN 55112 USA Phone: (651) 773-4663 Fax: (651) 779-4884 e-mail: [email protected] Test Standards: 47 CFR, Part 15:2010, §15.247 RSS–210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2010, §15.107 and §15.109, Class B ICES-003, Issue 5:2012 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: February 28, 2013 Test Work Started: February 28, 2013 Test Work Completed: April 30, 2013 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 101039189MIN-001B FCC ID: B4Z-958F-BTWI IC ID: 1175C-958FBTWI Page 4 of 125 1.1 Product Description; Test Facility Product Description: AVO-BTWI, WiFi Board Revision: 55-958 Transmitter Type: FHSS Digital Modulation WiFi Blue Tooth Operating Frequency Range(s): From 2412.0 to 2462.0 MHz Number of Channels: 11 Modulation: 802.11b-DSSS 802.11g-OFDM 802.11n-OFDM Emission Designator: 802.11b-DSSS: 10M1GXW 802.11g-OFDM: 16M3GXW 802.11n-OFDM: 17M8GXW Antenna(s) Info: High Efficiency loop antenna Gain: 2.5dBi Antenna Installation: User Professional Factory Transmitter power configuration: Internal battery External power source 120VAC 230VAC 400VAC VDC Other: Amp. 50Hz 60Hz Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 and FCC 558074 D01 DTS Measurement Guidance EMC Report No: 101039189MIN-001B FCC ID: B4Z-958F-BTWI IC ID: 1175C-958FBTWI Page 5 of 125 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous transmissions (modulated signal) - Continuous transmissions (un-modulated signal) - Continuous receiving - Test program (customer specific) - Operating modes of the EUT: No. Descriptio…
