Application Details
- Equipment Class
- TNB - Licensed Non-Broadcast Station Transmitter
- Date of Grant
- Mar 27, 2013
- Application Purpose
- Original Equipment
- Date of Application
- Jun 10, 2012
- Equipment Note
- Non-directional radio beacon
- Frequency Range
- 0.19000000 - 0.53500000
- Company
- Southern Avionics Company
- Country
- United States
Documents & Files
Select a file to view
Users Manual
Block Diagram
External Photos
ID Label/Location Info
Internal Photos
Operational Description
Parts List/Tune Up Info
Schematics
Test Report
Test Setup Photos
Contact Information
Applicant
Brooks Goodhue(President)
Technical Contact
Southern Avionics CompanyGeorge T Hamilton
[email protected]409-842-1717
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 2 | 87 | 0.19 MHz - 0.535 MHz | 125 W | 2K04A2A | 5 ppm |
