B944965AGIntel Wireless WiFi Link 4965AG

Intel(R) Wireless WiFi Link 4965AGN User Guide With your wireless network card, you can access wireless networks, share files or printers, or even share your Internet connection. All of these features can be explored with a wireless network in your home or office. This wireless local area network (WLAN) solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change. Your Intel(R) Wireless WiFi Link 4965AGN adapter is compatible with 802.11a, 802.11b 802.11g and 802.11n wireless standards. Operating at 5 GHz or 2.4 GHz frequency at speeds of up to 54 Mbps you can now connect your computer to existing high-speed networks that use multiple access points within large or small environments. Your wireless adapter maintains automatic data rate control according to access point location to achieve the fastest possible connection. All of your wireless network connections are easily managed by Intel(R) PROSet/Wireless software. Profiles that are set up through the Intel PROSet/Wireless software provide enhanced security measures with 802.1x network authentication. NOTE: The software is compatible with the Intel(R) Wireless WiFi Link 4965AGN, Intel(R) Wireless WiFi Link 4965AG_, Intel(R) PRO/Wireless 3965ABG Network Connection, Intel(R) PRO/Wireless 3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network Connection, Intel(R) PRO/Wireless 2915ABG Network Connection and the Intel(R) PRO/Wireless 2200BG Network Connection. Table of Contents Use Intel PROSet/Wireless Software Connect to a Network Use Profiles Set up Security Troubleshooting Administrator Tool Glossary Wireless Network Overview Security Overview Specifications Customer Support Safety and Regulatory Information Warranty Adapter Registration Information in this document is subject to change without notice. © 2004–2006 Intel Corporation. All rights reserved. Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 USA The copying or reproducing of any material in this document in any manner whatsoever without the written permission of Intel Corporation is strictly forbidden. Intel(R) is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Intel disclaims any proprietary interest in trademarks and trade names other than its own. Microsoft and Windows are registered trademarks of Microsoft Corporation. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. *Other names and brands may be claimed as the property of others. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. "Important Notice FOR ALL USERS OR DISTRIBUTORS!!!! Intel wireless LAN adapters are engineered, manufactured, tested, and quality checked to ensure that they meet all necessary local and governmental regulatory agency requirements for the regions that they are designated and/or marked to ship into. Since wireless LANs are generally unlicensed devices that share spectrum with radars, satellites, and other licensed and unlicensed devices, it is sometimes necessary to dynamically detect, avoid, and limit usage to avoid interference with these devices. In many instances Intel is required to provide test data to prove regional and local compliance to regional and governmental regulations before certification or approval to use the product is granted. Intel's wireless LAN's EEPROM, firmware, and software driver are designed to carefully control parameters that affect radio operation and to ensure electromagnetic compliance (EMC). These parameters include, without limitation, RF power, spectrum usage, channel scanning, and human exposure. For these reasons Intel cannot permit any manipulation by third parties of the software provided in binary format with the wireless LAN adapters (e.g., the EEPROM and firmware). Furthermore, if you use any patches, utilities, or code with the Intel wireless LAN adapters that have been manipulated by an unauthorized party (i.e., patches, utilities, or code (including open source code modifications) which have not been validated by Intel), (i) you will be solely responsible for ensuring the regulatory compliance of the products, (ii) Intel will bear no liability, under any theory of liability for any issues associated with the modified products, including without limitation, claims under the warranty and/or issues arising from regulatory non-compliance, and (iii) Intel will not provide or be required to assist in providing support to any third parties for such modified products. Note: Many regulatory agencies consider Wireless LAN adapters to be "modules", and accordingly, condition system-level regulatory approval upon receipt and review of test data documenting that the antennas and system configuration do not cause the EMC and radio operation to be non-compliant." October 2006 Back to Contents Use Intel(R) PROSet/Wireless Software Use Intel PROSet/Wireless as your Wireless Manager Start Intel PROSet/Wireless Start Intel PROSet/Wireless from the Taskbar l Taskbar Icons l Tool Tips and Desktop Alerts Intel PROSet/Wireless Main Window l Wireless Networks List l Connection Status Icons l Network Properties l Connection Details l Profiles List Intel PROSet/Wireless Menus l Tools Menu m Application Settings m Intel Wireless Troubleshooter m Administrator Tool l Advanced Menu m Adapter Settings m Advanced Statistics m Use Windows to Manage Wi-Fi l Profiles Menu m Manage Profiles m Manage Exclusions Turn Wireless Radio On or Off Install and Uninstall the Software Use Intel PROSet/Wireless as your Wireless Manager Intel(R) PROSet/Wireless is used to setup, edit and ma…

Text truncated - open the document above for the full version.

December 11, 2006 American TCB 6731 Whittier Ave., Suite C110 McLean, VA 22101 Gentlemen: The attached documentation is provided in support of a formal submission to your organization for a modular approval of an intentional unlicensed transmitter. On behalf of our client, Aegis Labs has included an application for a Grant of Equipment Authorization pursuant to Subpart C of part 15 of FCC Rules (47 CFR) regarding intentional radiators. The data within the test report demonstrates the equipment was tested in a manner described under Part 2 and 15 of the Code of Federal Regulations. This is a modular approval of the Intel Wireless WiFi Link 4965AGN (MN: 4965AG_, FCC ID: B944965AG), which is a WLAN adapter (802.11a, 802.11b, and 802.11g). It was tested externally to a computer chassis with a set of Ethertronics Antennas continuously transmitting and receiving form Chain A, B, and C antenna ports. If there are any additional questions or if further information is needed, please contact us at your earliest convenience. Sincerely, Johnny Candelas Aegis Labs, Inc. Test Technician Enclosure (1 Emissions Test Report + Exhibits)

Hewlett-Packard Company 20555 SH 249 Mail Stop 060607 Houston, TX 77070-2698 www.hp.com Walter Overcash Product Regulatory Manager Telecom / Safety 281.514.2756 Tel 281.514.8029 Fax [email protected] November 22, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia, Maryland 21046 Dear Sirs: Please be advised that Hewlett-Packard, 20555 SH 249, Houston, TX 77070, authorizes Aegis Labs Inc., 23091 Antonio Parkway Suite 310, Rancho Santa Margarita, CA 92688 to act on our behalf applications submitted limited to the following conditions: 1. This authorization is extended only to the Hewlett-Packard certification of the Intel Model 4965AGN and 4965AG_. 2. This authorization is extended only for FCC certification. 3. All invoices for services rendered should be sent to Aegis Labs Inc. and not to Hewlett-Packard. Licenses and test reports generated on Hewlett-Packard’s behalf must be emailed or copied to my attention when completed. 4. No access should be granted to any existing Hewlett-Packard file or project information. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Top View Bottom View

D7390502 rev01 4965AGN/AG Generic M1 Pre-printed Artwork 1. ALL DIMENSIONS PER D5978901 CURRENT REV 2. ALL TEXT/GRAPHICS TO BE BLACK UNLESS OTHERWISE INDICATED 3. LABEL MATERIAL PER D5978901 CURRENT REV 2111 NE 25th Ave Hillsboro, OR 97124 1 3 2 D73905-002 Pb Regulatory approvals apply only to Intel authorized components, software and antenna solutions. Unauthorized installations or modifications will void regulatory approvals and product warranties. FCC ID: B944965AG IC: 466Q-4965AG TA: XXXXXX-XXX Made in Xxxxxxxx MAC: OOOOOOMMMMMM Intel Wireless WiFi Link 4965AGN Model: 4965AG_ MM1 CT: Label Location

Top View “Insulation removed” Bottom View “Insulation removed” Top View “Shielding removed”

MPE Calculations Systems operating under the provision of 47 CFR 1.1307(b)(1) shall be operated in a manor that ensures that the public is not exposed to radio frequency energy levels in excess of the FCC guidelines. The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user or nearby persons and can therefore be considered a mobile transmitter per 47 CFR 2.1091(b). The MPE calculation for this exposure is shown below. Using the Antennas with highest output power: The peak radiated output power (EIRP) is calculated as follows: Antenna Frequency (GHz) Power input to the antenna (P) (dBm) Power gain of the antenna (G) (dBi) EIRP (P+G) (dBm) EIRP Log -1(dBm/10) (mW) Ethertronics (Chain A) 2.4 23.83 3.00 26.83 481.95 Ethertronics (Chain A) 5 20.91 5.00 25.91 389.94 Ethertronics (Chain B) 2.4 23.63 3.00 26.63 460.26 Ethertronics (Chain B) 5 20.61 5.00 25.61 363.92 EIRP = P + G Where P = Power input to the antenna (mW). G = Power gain of the antenna (dBi) The numeric gain (G) of the antenna with a gain specified in dB is determined by: Antenna Frequency (GHz) Antenna Gain (G) (dBi) Numeric Antenna Gain Log -1(dBm/10) (dB) Ethertronics (Chain A) 2.4 3.00 2.00 Ethertronics (Chain A) 5 5.00 3.16 Ethertronics (Chain B) 2.4 3.00 2.00 Ethertronics (Chain B) 5 5.00 3.16 G = Log -1 (dB antenna gain/10) Power density at the specific separation: Antenna Frequency (GHz) Power input to the antenna (P) (mW) Numeric Power Gain of the Antenna (G) (dB) Maximum Power Spectral Density S=PG/(4R 2 π) (mW/cm 2 ) Maximum Power Spectral Density Limit (mW/cm 2 ) Ethertronics (Chain A) 2.4 241.55 2.00 0.096 1.00 Ethertronics (Chain A) 5 123.31 3.16 0.078 1.00 Ethertronics (Chain B) 2.4 230.67 2.00 0.092 1.00 Ethertronics (Chain B) 5 115.08 3.16 0.072 1.00 S = PG/(4R 2 π) Where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW). G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1mW/cm 2 . The power density at 20cm does not exceed the 1mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules.

Page 1 of 13 Report Number: INTEL-061209F Revision Number: NONE Modular Approval Test Report And Application for Grant of Equipment Authorization TEST REPORT PERTAINING TO: Equipment Under Test Model Number(s) Intel Wireless WiFi Link 4965AGN 4965AG_ CONFIGURATION 802.11a / 802.11b / 802.11g with a set of Ethertronics Antennas MEASUREMENTS PERFORMED IN ACCORDANCE WITH THE FOLLOWING STANDARD (S) Regulatory Standard(s) 47 CFR Part 15, Subpart E Section 15.407 (UNII Devices) Test Method: ANSI C63.4: 2003 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz PREPARED FOR: PREPARED BY: Hewlett-Packard Company Aegis Labs, Inc. 20555 SH 249 22431 Antonio Parkway B160-417 Mail Stop 060607 Rancho S. Margarita, CA 92688 Houston, TX 77070-2698 Agent(s): Mr. Rick Candelas Mr. Johnny Candelas Contact(s): Mr. Walter Overcash Test Report #: INTEL-061209F Test Report Revision: NONE APPENDICES REPORT BODY A B TOTAL PAGES PAGES 13 53 1 67 The contents of this report shall not be reproduced except in full, without the written approval of Aegis Labs, Inc. The HP logo is used for identification purposes only and is a registered trademark of the Hewlett-Packard Company Certificate Number: 1111.01 Page 2 of 13 Report Number: INTEL-061209F Revision Number: NONE TABLE OF CONTENTS SECTION TITLE PAGE COVER SHEET......................................................................................................... 01 TABLE OF CONTENTS.................................................................................................................... 02 1.0 REGULATORY COMPLIANCE GUIDELINES................................................................ 03 1.1 Guidelines For Testing To Emissions Standards..................................................................... 03 2.0 SUMMARY OF REGULATORY LIMITS.................................................................................. 04 3.0 ADMINISTRATIVE DATA AND TEST DESCRIPTION..................................................... 07 4.0 DESCRIPTION OF EUT CONFIGURATION....................................................................... 08 4.1 EUT Description ......................................................................................................... 08 4.2 EUT Configuration......................................................................................................................... 09 4.3 List of EUT Sub-Assemblies and Host Equipment........................................................................... 09 4.4 I/O Cabling Diagram and Description ................................................................................. 10 4.5 EMC Test Hardware and Software Measurement Equipment.............................................................. 11 5.0 CONDITIONS DURING EMISSIONS MEASUREMENTS................................................... 12 5.1 General..................................................................................................................... 12 5.2 Conducted Emissions Test Setup.......................................................................................................... 12 5.3 Radiated Emissions Test Setup......................................................................................... 13 APPENDICES A Test Data B Modifications And Recommendations Page 3 of 13 Report Number: INTEL-061209F Revision Number: NONE 1.0 REGULATORY COMPLIANCE GUIDELINES Aegis Labs, Inc. operates as both a Nevada and California Corporation with no organizational or financial relationship with any company, institution, or private individual. Testing and engineering functions provided by Aegis Labs were furnished by RF technicians and engineers with accredited qualifications and training credentials to carry out their duties. The object of this report was to publish verifiable test results of an EUT subjected to the tests outlined in the standard listed on the cover page of this report. 1.1 Guidelines For Testing To Emissions Standards This standard for EMC emission requirements apply to electrical equipment for Information Technology Equipment (ITE). Compliance to these standards and in combination with the other standards listed in this test report can be used to demonstrate presumption of compliance with the protection requirements of the appropriate agency standard. The purpose of this standard is to specify minimum requirements for emissions regarding electromagnetic compatibility (EMC) and protect the radio frequency spectrum 9 kHz. – 400 GHz. from unwanted interference generated from electrical/digital systems that intentionally or unintentionally generated RF energy. The emissions standards, normative documents and/or publications were used to conduct all tests performed on the equipment herein referred to as “Equipment Under Test”. Page 4 of 13 Report Number: INTEL-061209F Revision Number: NONE 2.0 SUMMARY OF TEST RESULTS 802.11a Mode (5150-5350 MHz) Chain A EMISSIONS STANDARD FCC Part 15 Section Description Results Comments Operation in the 5.15-5.25 GHz Band 15.407(d) Any UNII device shall use a transmitting antenna that is an integral part of the device. PASSED The antenna will be integral when installed in a notebook computer 15.407(e) UNII devices will be restricted to indoor operations. PASSED Refer to “User’s Manual” Exhibit 15.407(a)(1) 26dB emissions bandwidth in MHz. N/A 5.18 GHz = 22.00 MHz 15.407(a)(1) Peak transmit power shall not exceed the lesser of 50mW or 4dBm+10logB (where B = 26dB emissions bandwidth). PASSED 5.18 GHz = 16.61dBm (45.81mW) 5.24 GHz = 16.81dBm (47.97mW) 15.407(a)(1) The peak power spectral density shall not exceed 4dBm in any 1MHz band. PASSED 5.18 GHz = -15.06dBm 15.407(a)(1) Peak transmit power and the peak power spectral density shall be reduced by the amount in dB that the transmitting antenna exceeds 6dBi. N/A All antennas tested have less than 6dB…

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 SUBPART E DFS TEST REPORT FOR 802.11 A/B/G/N MINI-PCI EXPRESS NETWORK ADAPTER MODEL NUMBER: 4965AGN FCC ID: PD94965AGN REPORT NUMBER: 06U10551-1 ISSUE DATE: OCTOBER 17, 2006 Prepared for INTEL 2111 N. E. 25TH AVE HILLSBORO, OR 97124 Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 06U10551-1 DATE: OCTOBER 17, 2006 EUT: 802.11 a/b/g/n Mini-PCI Express Network Adapter FCC ID: PD94965AGN Page 2 of 25 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 10/17/06 Initial Issue AI REPORT NO: 06U10551-1 DATE: OCTOBER 17, 2006 EUT: 802.11 a/b/g/n Mini-PCI Express Network Adapter FCC ID: PD94965AGN Page 3 of 25 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. SOFTWARE AND FIRMWARE .................................................................................................... 6 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 7 7. LIMITS AND RESULTS ................................................................................................................... 8 7.1. DYNAMIC FREQUENCY SELECTION ....................................................................................... 8 7.1.1. LIMITS ................................................................................................................................. 8 7.1.2. DESCRIPTION OF EUT.................................................................................................... 11 7.1.3. TEST AND MEASUREMENT SYSTEM ......................................................................... 12 7.1.4. SETUP OF EUT AND SUPPORT EQUIPMENT ............................................................. 16 7.1.5. PLOTS OF NOISE, RADAR WAVEFORMS, AND WLAN SIGNALS.......................... 18 7.1.6. TEST CHANNEL AND METHOD ................................................................................... 21 7.1.7. CHANNEL MOVE TIME AND CHANNEL CLOSING TRANSMISSION TIME ......... 21 8. SETUP PHOTOS .............................................................................................................................. 24 REPORT NO: 06U10551-1 DATE: OCTOBER 17, 2006 EUT: 802.11 a/b/g/n Mini-PCI Express Network Adapter FCC ID: PD94965AGN Page 4 of 25 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Intel 2111 N. E. 25th Ave Hillsboro, OR 97124 EUT DESCRIPTION: 802.11 a/b/g/n Mini-PCI Express Network Adapter MODEL TESTED: 4965agn SERIAL NUMBER: KDR200060806D-2-R4 DATE TESTED: October 16, 2006 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART E NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: ALVIN ILARINA WILLIAM ZHUANG ENGINEERING MANAGER EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 06U10551-1 DATE: OCTOBER 17, 2006 EUT: 802.11 a/b/g/n Mini-PCI Express Network Adapter FCC ID: PD94965AGN Page 5 of 25 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4-2003, FCC CFR 47 Part 2, FCC CFR 47 Part 15 and FCC 06-96 APPENDIX “COMPLIANCE MEASUREMENT PROCEDURES FOR UNLICENSED-NATIONAL INFORMATION INFRASTRUCTURE DEVCIES OPERATING IN THE 5250-5350 MHz AND 5470-5725 MHz BANDS INCORPORATING DYNAMIC FREQUENCY SELECTION”. 3. FACILITIES …

Text truncated - open the document above for the full version.

Maximum Peak Output Power Measurement Setup Conducted Emissions at Antenna Terminal Setup AC Conducted Emissions Measurement (Front View) Setup AC Conducted Emissions Measurement (Rear View) Setup Radiated Emissions Measurement (Front View) Setup Radiated Emissions Measurement (Rear View) Setup
