B94HHB407DTablet

User Manual Model: HSTNH-B407D Product Overview  Micro USB 2.0 HS  Earphone 3.5mm Slot  Front-Camera  Power Key  Volume Key +  Volume Key-  Micro SD Slot  SIM Card Slot  Speaker  Rear-Camera Getting Started Turning the tablet On/Off To turn On the tablet 1. Press and hold the PWR key for a few seconds. 2. Unlock the screen with your finger. To turn Off the tablet 1. Press and hold the PWR key, select Power Off; 2. Tap OK. The tablet will be off in a few seconds. Unlocking screen The screen is locked by default when you turn on the tablet. To unlock the screen, 1. Press the PWR key. 2. Drag the inner ring to the edge of the circle to unlock the screen. Draw a pattern if the screen is protected by pattern lock. Enter a PIN or a password if the screen is locked by a PIN or a password. ➠ Locking screen To lock the screen, press the PWR key. It is recommended to lock the screen to protect information in the tablet and reduce battery usage. You can also configure your tablet to automatically lock after a certain period of time.Tap →Settings→Display→Sleep to set the sleep time from 15 seconds, 30 seconds, 1 minute, 2 minutes, 5 minutes, 10 minutes, or 30 minutes. Using touch screen All of the functions of the tablet, except for power and volume, are performed on the touch screen. Therefore, it is essential to know how to use the touch screen. The following finger actions might help you easily understand how to use the touch screen.  Tap: Touch an item (e.g. application or widget) once that appears on the screen with your finger to run it or access a menu or an option  Double tap: Tap an item twice with your finger  Drag: Tap and hold your finger on an item and move it without losing contact with the screen  Flick: Place a finger on an empty space of the screen and move the screen up or down, or left or right  Pinch: Place two fingers on the screen and move them apart to zoom in a picture, a document or a web page, or move them together to zoom out  Select and tap: Tap an item in the list of options available  Press and hold: Press a key or any item for a few seconds until a list of options appears Cautions:  Do not use sharp tools that can scratch the touch screen.  Do not allow the touch screen to come in contact with chemicals. The screen may malfunction in chemicals.  Do not sit on the tablet: the touch screen can be damaged. Status bar The status bar at the top of the screen notifications from various apps, time, and the states of various devices such as battery status, WIFI status, Signal status and so on. 1. Notification panel displays notification icons to inform you of new Email, messages, and so on. Slide the panel down to view the notifications and then tap a notification icon to view details of the notification. 2. Status panel displays status icons to show the current state of your tablet, such as battery charging progress, alarms, Bluetooth, and so on. Slide the panel down to access more settings and configuration options Screen orientation For optimal viewing experience, the screen orientation changes automatically depending on how you hold the tablet. NOTE: To enable or disable auto-rotate, slide down the status panel and tap the Auto-rotate icon. Keys and functions 1. Back key  Tap to return to the previous screen and exit the running application.  Tap to close the on-screen keyboard in text input mode. 2. Home key  Tap to return to the main screen.  Tap and hold to open the Google search. 3. Menu key  Tap to open the applications list used recently. Apps and widgets Apps: Software that allows you to perform a specific task. Your tablet is preloaded with a variety of applications, and additional applications can be downloaded from the Play Store. Widgets: A small application which resides on the home screen and provides quick and easy access to information. Connecting to the Internet using WiFi NOTE: The range and quality of the WIFI signal is affected by the distance between the tablet and the wireless router,the number of connected devices, infrastructure, and objects through which the signal is transmitted. 1. Ta p→ Settings→ WIRELESS & NETWORKS→ WIFI. 2. Enable WIFI by moving the slider to On position. The tablet scans for WIFI networks in range. 3. Tap the network you want to connect to. 4. Type a password (if connecting to a secure network) and tap Connect to connect to the selected WIFI network. NOTE: To connect to a secured WIFI network, you must provide the security key. If you do not have the security key, contact the person who manages your WIFI network or the router manufacturer. NOTE: To start a new search for available WIFI networks, on the WIFI screen, tap → Scan Connecting to the Internet using mobile broadband 1. Ta p→ Settings→ WIRELESS & NETWORKS→ WIFI, then touch WIFI to disable it. 2. The tablet automatically searches for the carrier signal and connects to the network. When the tablet is connected to a mobile broadband network, the network type appears in the status bar. NOTE: Make sure you have a valid SIM/USIM IN the tablet On the mobile broadband model, if both WIFI and mobile broadband networks are available, the tablet gives priority to WIFI connection. Safety Information The following list shows how to maintain your tablet, together with precautions to take.  Keep your tablet and its accessories out of the reach of pets.  Do not allow children to use your tablet. If children use the device, make sure that they use the tablet properly.  Maintain your tablet in dry conditions and keep it within normal operating temperatures. Temperatures higher than 55°C (131°F) or lower than -20°C (-4°F) may damage your tablet.  Do not try to dry your tablet in a microwave oven. If you do, sparks can occur and cause an explosion or fire.  Do not use or store your tablet in dusty or dirty areas.  Do not attempt to disassemble your tablet.  Do not drop or cause severe impact to your tablet.  Do not use chemical products, cleaning solvents …

Text truncated - open the document above for the full version.

SHEN ZHEN VLG WIRELESS TECHNOLOGY CO.,LTD. Antenna Test Report Customer No. : INT70AH Bluebank Date : 2014. 07.28 1 ME :HailingTang RF : Andy Liu CONTENTCONTENT 1. Tablet PC introduce .......................................................................32. Antenna S11 parameter .................................................................4-63 At i lti 7 9 3 . A n t enna i so l a ti on......................... .............................................................. 7 - 9 4. Efficiency and Gain ....................................................................10-125. Antenna Matching circuit...........................................................................136 3 D chamber data 14 1 6 6 . 3 D chamber data ............................... ..................................................... 14 - 1 6 7. Summary ...................................................................................17 2 1.Tablet PC introduce  Customer name: Bluebank  Product type ： Tablet  Custome r P/N: INT70AH  Antenna bands: GPRS 850/900/1800/1900 ， WCDMA 850/900/1700/1900/2100 WIFI&GPS850/900/1700/1900/2100 , WIFI&GPS 3 RL/ VSWR/Smith chart __ Main antenna 2. Antenna S11 parameter 4 RL/ VSWR/Smith chart __ diversity antenna 2. Antenna S11 parameter 5 RL/ VSWR/Smith chart __ WIFI&GPS antenna 2. Antenna S11 parameter 6 Main antenna VS Diversity antenna 3. Antenna Isolation 7 Main antenna VS WIFI&GPS antenna 3. Antenna Isolation 8 Diversity antenna VS WIFI&GPS antenna 3. Antenna Isolation 9 4. Efficiency and Gain Main antenna Frequency(MHz) Efficiency AVG Gain(dB) Peak Gain(dBi) 824 25.63% -5.91 -1.44 850 26.38% -5.79 -1.26 880 26.66% -5.74 -1.21 960 26.85% -5.71 -1.18 1710 38.91% - 4.10 - 0.47 1710 38.91% 4.10 0.47 1750 40.24% -3.95 -0.30 1770 41.24% -3.85 -0.18 1800 41.40% -3.83 -0.14 1820 41 98% 377 007 1820 41 . 98% - 3 . 77 - 0 . 07 1860 42.66% -3.70 -0.02 1880 42.27% -3.74 -0.07 1900 41.95% -3.77 -0.07 1950 41.79% -3.79 -0.02 1990 40.93% -3.88 -0.03 2100 40.12% -3.97 -0.03 2150 39 57% - 403 - 003 2150 39 . 57% 4 . 03 0 . 03 2170 38.97% -4.09 -0.04 10 4. Efficiency and Gain diversity antenna Frequency(MHz) Efficiency AVG Gain(dB) Peak Gain(dBi) 824 21.77% -6.62 -1.09 850 21.44% -6.69 -1.20 880 20.91% -6.80 -1.34 960 20.40% -6.90 -1.49 1710 33.55% - 4.74 - 0.05 1710 33.55% 4.74 0.05 1750 32.76% -4.85 -0.06 1770 31.89% -4.96 -0.09 1800 30.67% -5.13 -0.17 1820 29 54% 530 026 1820 29 . 54% - 5 . 30 - 0 . 26 1860 28.61% -5.43 -0.94 1880 29.10% -5.36 -0.77 1900 29.50% -5.30 -0.63 1950 29.56% -5.29 -0.59 1990 29.47% -5.31 -0.51 2100 29.24% -5.34 -0.43 2150 28 73% - 542 - 039 2150 28 . 73% 5 . 42 0 . 39 2170 28.20% -5.50 -0.36 11 4. Efficiency and Gain GPS&WIFI antenna Frequency(MHz) Efficiency AVG Gain(dB) Peak Gain(dBi) 2400 43.68% -3.60 1.19 2450 43.34% -3.63 1.63 2500 42.94% -3.67 1.63 1570 41.05% -3.87 1.51 1575 42 42 00% - 377 156 1575 . 42 42 . 00% 3 . 77 1 . 56 1580 40.23% -3.95 1.48 12 4. Antenna Matching circuit CD28=33pF CD27=33pF R2 未改变 L6=22pF RD003 空 RD002=22pF RD004 空 CD25=22pF R3 未改变 CD24=68pF 13 RD002=22pF RD004 空 CD25=22pF R3 未改变 CD24=68pF 5. 3D chamber data Ct Bl b k C us t omer： Bl ue b an k Model： Main antenna Test Condition： 3D chamber Band Channel TRP(Spec ) TRP(Measured) TIS(S pec) TIS(Measured) GPRS85 0 128 () 26.43 -102.15 GPRS85 0 for（Asia,EU,Japan) 26 ( 2 Tx ) -100.5 190 26.33 -102.08 251 26.86 -101.37 GPRS900 1 26.35 -102.06 GPRS900 for（Asia,EU,Japan) 27 -102 62 26.64 -101.76 124 26.43 -101.54 512 27.11 -105.18 GPRS1800 for（Asia,EU,Japan) 24 -102 698 26.75 -105.85 885 26.20 -106 GPRS1900 for（Asia,EU,Japan) 512 24.5(2 Tx) 27.64 -101.5 -104.85 661 27.37 -104.59 810 27.22 -103.89 14 Customer： Bluebank 6. 3D chamber data Model： Main antenna Test Condition： 3D chamber Band Channel TRP(Spec TRP(Measured) TIS(Spec) TIS(Measured) Band Channel ) TRP(Measured) TIS(Spec) TIS(Measured) WCDMA2100 10562/9612 18 20.20 -103 -105.67 10700/9750 20.27 -105.96 10838/9888 18.15 -106.51 WCDMA1900 9662 18 20.39 -103 -105.19 9800 20.37 -105.08 9938 20.02 -104.98 WCDMA 1700 1537 19 20.68 - 105 -105.90 1638 20 88 - 105 47 WCDMA 1700 19 105 1638 20 . 88 105 . 47 1738 19.85 -105.78 WCDMA 850 4357 17 17.59 100 -103.21 4408 18 48 103 34 WCDMA 850 17 - 100 4408 18 . 48 - 103 . 34 4458 18.17 -102.47 2937 17.77 -102.21 15 WCDMA 900 18 -100 3012 17.89 -101.24 3088 17.46 -101.47 Customer： Bluebank 7. 3D chamber data Model： Diversity antenna Test Condition： 3D chamber Band Channel TRP(Spec TRP(Measured) TIS(Spec) TIS(Measured) Band Channel ) TRP(Measured) TIS(Spec) TIS(Measured) WCDMA2100 10562/9612 -100 -100.95 10700/9750 -100.41 10838/9888 -100.74 WCDMA1900 9662 -100 -101.14 9800 -100.98 9938 -100.79 WCDMA 1700 1537 - 102 -102.48 1638 - 102 74 WCDMA 1700 102 1638 102 . 74 1738 -102.56 WCDMA 850 4357 97 -99.15 4408 99 79 WCDMA 850 - 97 4408 - 99 . 79 4458 -99.24 2937 -99.25 16 WCDMA 900 -97 3012 -99.72 3088 -99.68 8. Summary The test date above was m ade out with the new machine. 17 Thanks for your valuable comment!Thanks for your valuable comment! 18

Authorization on Behalf of Hewlett-Packard Company For the US Federal Communications Commission Office of Engineering and Technology and Other FCC Programs and Offices 1. I, David P. Adams, am Canada/USA Technical Regulations Manager for Hewlett-Packard Company (“Hewlett-Packard”) and Applicant/Grantee Contact of Record for Hewlett-Packard together with its subsidiaries and affiliates worldwide (collectively, “HP”) for HP’s dealings with the United States Federal Communications Commission (“FCC”). I am duly authorized by HP to make this Authorization on HP’s behalf. 2. This Authorization will designate the person named below to act on my behalf and HP’s behalf as authorized agent and representative, until further notice, with the additional power to designate one or more third party agents for HP with regard to particular matters and applications. All acts carried out and requests made by this named representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as mine. Name: Leszek Langiewicz Title: Regulatory Program Manager Address: Hewlett-Packard Company 16399 West Bernardo Drive San Diego, CA 92127 Telephone: +1 858 655 5783 E-mail: [email protected] 3. Questions about the scope and effect of this Authorization should be addressed as follows: David P. Adams Canada/USA Region Technical Regulations Manager Hewlett-Packard Company 1501 Page Mill Road, MS 1419 Palo Alto, CA 94304-1126 +1 650 258 7586 Telephone +1 650.362.6534 Fax [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed at Palo Alto, California, on the date indicated below my signature. ____________________________ Signature David P. Adams Canada/USA Technical Regulations Manager Hewlett-Packard Company ____June 24, 2013 ________________________ Date

Hewlett-Packard Company 1501 Page Mill Road, MS 1419. Palo Alto, CA 94304, USA hp.com Designation of Third Party Representative By Authorized Agent of Hewlett-Packard Company 1. I am an authorized agent and representative of Hewlett-Packard Company together with its subsidiaries and affiliates (collectively, “HP”), designated as such by David P. Adams as HP’s Applicant/Grantee Contact of Record for the FCC, pursuant to his Authorization as attached hereto. My name, address and contact information appear below. Any questions about the scope of this Designation of Third Party Representative should be directed to me. 2. Pursuant to this authority, I designate the third party identified below as HP’s agent for the matters and applications specified below, for the term specified below, unless earlier terminated by HP. a. Name, address and contact information: SGS Taiwan Ltd. Name: Willis Chen Title: Technical Asst. Manager 134, Wu Kung Road, Wuku Industrial Zone, TW- New Taipei City 24803 Tel: +886 2 2299 3279 Email: [email protected] b. Matters and applications covered (product and/or model identification, FCC ID): Hewlett-Packard Regulatory Model Number: HSTNH-B407D FCC ID: B94HHB407D c. Term of designation, unless earlier terminated by HP: 10 year(s). 3. All invoices for FCC’s services should be sent as specified in paragraph 2a, above. Licenses and test reports generated for HP should be sent as specified in paragraph 2a but copied to the undersigned. No access should be granted to any HP file or project information except as necessary in connection with the matters and applications specified in paragraph 2b. All acts carried out and requests made by the third party representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as HP’s own. _______________________________ 8.18.2014 Signature Date Name: Leszek Langiewicz Title: Regulatory Program Manager Address: Hewlett-Packard Company 16399 West Bernardo Drive, San Diego, CA 92127 Telephone: +1 858 655 5783 E-mail: [email protected]

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) Equipment: Tablet Trademark(s) and Model(s): HP / HSTNH-B407D Manufacturer: Bluebank Communication Technology Co.Ltd FCC ID in case other parts of this equipment are subject to certification: B94HHB407D This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number:Issue date: EM/2014/70117 2014/08/28 The following manufacturer/importer/entity (located in the USA) is responsible for this declaration: Company name: Hewlett-Packard Company Name/Title (legal representative): Leszek M. Langiewicz Address: 1501 Page Mill Road Palo Alto United States 94304 Phone: (858) 655-5783 Fax: (858) 655-3054 E-mail: [email protected] Agent’s business name: Contact Name/Title: Address: Phone: Fax: E-mail: Date: SGS Taiwan Ltd. Willis Chen 134, Wu Kung Road, WuKu Industrial Zone, New Taipei City, 248 Taiwan +886 2 2299 3279 ext: 1194 +886 2 2298 269 [email protected] 2014-08-29 Authorized Signature: FCC

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Hewlett-Packard Company Address: 1501 Page Mill Road Palo Alto United States 94304 City: Palo Alto Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: B94HHB407D Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Planned Release Date STC: 180 dys (notes 2, 3, 4, 5) Date: 2014.08.14 Name and signature of applicant: Leszek M. Langiewicz Regulatory Program Manager Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

All View of EUT Front View of EUT Back View of EUT Side View of EUT – 1 Side View of EUT – 2 Side View of EUT – 3 Side View of EUT – 4 Adapter Data Cable (USB) Battery

Label & Location as below : Model No. ： HSTNH-B407D FCC ID ： B94HHB407D

Open View of EUT – 1 Open View of EUT – 2 Open View of EUT – 3 Open View of EUT – 4 Open View of EUT – 5 Open View of EUT – 6 Internal View of EUT – 1 Internal View of EUT – 2 Internal View of EUT – 3 Internal View of EUT – 4 Internal View of EUT – 5 Internal View of EUT – 6 Internal View of EUT – 7 Internal View of EUT – 8 Internal View of EUT – 9 Internal View of EUT – 10 Antenna-BT/ WLAN Antenna-GPS Antenna-WWAN

Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除 非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天 。本報告未經本公司 書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible atand, for electronic format documents, subject to Terms and Conditions for Electronic Documents atAttention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd.No.134,Wu Kung Road, New Taipei Industrial Park, Wuku District, New Taipei City, Taiwan 24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司t (8862) 22993279f (8862) 22980488www.tw.sgs.com Member of SGS Group Report No. : ES/2014/70006 Page : 1 of 142 SAR TEST REPORT The following samples were submitted and identified on behalf of the client as: Equipment Under Test Ta b l e t Marketing Name HP 7 Plus G2 Brand Name HP Model No. HSTNH-B407D Company Name Hewlett-Packard Company Company Address 1501 Page Mill Road,Palo Alto, CA 94304,United States Standards IEEE /ANSI C95.1 , C95.3, IEEE 1528, KDB248227 D01, KDB616217 D04, KDB865664 D01, KDB865664D02, KDB941225 D01, KDB941225 D02, KDB941225 D03, FCC ID B94HHB407D Date of Receipt Jul. 24, 2014 Date of Test(s) Aug. 13, 2014 ~ Aug. 19, 2014 Date of Issue Aug. 27, 2014 In the configuration tested, the EUT complied with the standards specified above. Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any confi guration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Taiwan Electronic & Communication Laboratory or testin g done by SGS Taiwan Electronic & Communication Laboratory in connection with distribution or use of the product described in this report must be approved by SGS Taiwan Electronic & Communication Laboratory in writing. Signed on behalf of SGS Engineer Sr. Engineer Sam Kuo John Yeh Date: Aug. 27, 2014 Date: Aug. 27, 2014 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除 非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天 。本報告未經本公司 書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible atand, for electronic format documents, subject to Terms and Conditions for Electronic Documents atAttention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd.No.134,Wu Kung Road, New Taipei Industrial Park, Wuku District, New Taipei City, Taiwan 24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司t (8862) 22993279f (8862) 22980488www.tw.sgs.com Member of SGS Group Report No. : ES/2014/70006 Page : 2 of 142 Version Report Number Revision Date Memo ES/2014/70006 00 2014/8/27 Initial creation of test report. This test report contains a reference to the previous version test report that it replaces. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除 非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天 。本報告未經本公司 書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible atand, for electronic format documents, subject to Terms and Conditions for Electronic Documents atAttention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd.No.134,Wu Kung Road, New T…

Text truncated - open the document above for the full version.

FCC ID: B94HHB407D Report No.: ER/2014/70097 Issue Date: Sep. 18, 201 4 Page: 1 of 167 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-327 9f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 22 SUBPART H, PART 24 SUBPART E and PART 27 SUBPART C REQUIREMENT OF Product Name: Tablet Brand Name: HP Marketing Name: HP 7 Plus G2 Model No.: HSTNH-B407D Model Difference: N/A FCC ID: B94HHB407D Report No.: ER/2014/70097 Issue Date: Sep. 18, 2014 FCC Rule Part: 2 , 22H & 24E & 27C Prepared for: Hewlett-Packard Company 1501 Page Mill Road,Palo Alto, CA 94304,United States Prepared by: SGS Taiwan Ltd. Electronics & Communication Laboratory No.134, Wu Kung Road, New Taipei Industrial Park, Wuku District, New Taipei City, Taiwan 24803 Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. FCC ID: B94HHB407D Report No.: ER/2014/70097 Issue Date: Sep. 18, 2014 Page: 2 of 167 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group VERIFICATION OF COMPLIANCE Applicant: Hewlett-Packard Company 1501 Page Mill Road,Palo Alto, CA 94304,United States Product Name: Tablet Brand Name: HP Marketing Name: HP 7 Plus G2 Model No.: HSTNH-B407D Model Difference: N/A FCC ID: B94HHB407D File Number: ER/2014/70097 Date of test: Jul. 29, 2014 ~ Aug. 22, 2014 Date of EUT Received: Jul. 29, 2014 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. Electronics & Communication Laboratory The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA-603-C-2004 and the energy emitted by the sample EUT tested as …

Text truncated - open the document above for the full version.
