B94HNC75CHWCPHP ELITEPAD 900

Federal Communications Commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by HP may void the user's authority to operate the equipment. Cables To maintain compliance with FCC Rules and Regulations, connections to this device must be made with shielded cables having metallic RFI/EMI connector hoods. 2Chapter 1 Regulatory notices Declaration of Conformity for products marked with the FCC logo (United States only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: 1.This device may not cause harmful interference. 2.This device must accept any interference received, including interference that may cause undesired operation. If you have questions about the product that are not related to this declaration, write to Hewlett-Packard Company P. O. Box 692000, Mail Stop 530113 Houston, TX 77269-2000 For questions regarding this FCC declaration, write to Hewlett-Packard Company P. O. Box 692000, Mail Stop 510101 Houston, TX 77269-2000 or call HP at 281-514-3333 To identify your product, refer to the part, series, or model number located on the product. Products with wireless LAN devices or HP Mobile Broadband Modules This device must not be co-located or operating in conjunction with any other antenna or transmitter. WARNING!Exposure to Radio Frequency Radiation The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact is minimized during normal operation of tablet PCs and notebook computers. During normal operation of tablet PCs and notebook computers with displays equal to or less than 12 inches: This device is tested per FCC RF exposure guideline and meets FCC requirement of SAR . To identify the location of the wireless antennas, refer to the computer user guides. To access the user guides, select Start > Help and Support > User Guides. During normal operation of notebook computers with displays greater than 12 inches: To avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antennas should not be less than 20 cm (8 inches), including when the computer display is closed. To identify the location of the wireless antennas, refer to the computer user guides. To access the user guides, select Start > Help and Support > User Guides. CAUTION:When using IEEE 802.11a wireless LAN, this product is restricted to indoor use, due to its operation in the 5.15- to 5.25-GHz frequency range. The FCC requires this product to be used indoors for the frequency range of 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel mobile satellite systems. High-power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65- to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device. Federal Communications Commission notice3 compliance, when tested directly contacted to the body

User Guide © Copyright 2012 Hewlett-Packard Development Company, L.P. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Centrino are trademarks of Intel Corporation in the U.S. and other countries. AMD is a trademark of Advanced Micro Devices, Inc. SD Logo is a trademark of its proprietor. Java is a U.S. trademark of Sun Microsystems, Inc. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. First Edition: October 2012 Document Part Number: 698485-001 Product notice This user guide describes features that are common to most models. Some features may not be available on your computer. To obtain the latest information in this guide, contact support. For U.S. support, go to http://www.hp.com/go/contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/ wwcontact_us.html. Software terms By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a refund subject to the refund policy of your place of purchase. For any further information or to request a full refund of the computer, please contact your local point of sale (the seller). Safety warning notice WARNING!To reduce the possibility of heat-related injuries or of overheating the tablet, do not place the tablet directly on your lap or obstruct the tablet air vents. Use the tablet only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The tablet and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950). iii iv Safety warning notice Table of contents 1 Welcome .......................................................................................................................................................... 1 Finding information ............................................................................................................................... 2 2 Getting to know your tablet ........................................................................................................................... 5 Display .................................................................................................................................................. 5 Rear ...................................................................................................................................................... 7 Top ....................................................................................................................................................... 8 Bottom .................................................................................................................................................. 9 Changing your tablet's settings .......................................................................................................... 10 Changing your tablet's view ............................................................................................... 10 Adjusting your tablet's autorotate lock ............................................................... 10 Adjusting your tablet's screen brightness .......................................................... 10 Finding your hardware and software information ............................................................................... 11 Locating hardware ............................................................................................................. 11 Locating software ............................................................................................................... 11 Updating the software installed on the tablet ..................................................................... 11 3 Connecting to a network .............................................................................................................................. 13 Connecting to a wireless network ....................................................................................................... 13 Using the wireless controls ................................................................................................ 13 Using operating system controls ....................................................................... 13 Using a WLAN ................................................................................................................... 14 Using an Internet service provider .................................................................... 14 Setting up a WLAN ............................................................................................ 15 Configuring a wireless router ............................................................................ 15 Protecting your WLAN ....................................................................................... 15 Connecting to a WLAN ...................................................................................... 16 Using GPS (select models only) ........................................................................................ 16 Using Bluetooth wireless devi…

Text truncated - open the document above for the full version.

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] September 27, 2012 Dear Sirs: Our radio with FCC ID: B94HNC75CHWCP has disabled the ad hoc peer-to-peer and hotspot function. The software and associated drivers will not initiate any transmission in the following frequency bands: 5150MHz - 5250MHz 5250MHz – 5350MHz 5470MHz – 5725MHz In DFS frequency bands, the device acts as a client device which does not support radar detection capability. In addition, 5600MHz -5650MHz capability is notched in this device when marketed in US and Canada. For the 802.11b/g/n function of this device, hotspot capabilities and ad hoc functionality is not supported in non-US frequencies. For all 802.11a 5GHz bands, country code selection is also disabled. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] September 27, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Subject: FCC Application for FCC ID: B94HNC75CHWCP Dear Sirs: We will apply the Declaration of Conformity procedure to the class B computer portion of this composite filing. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Authorizationon Behalf of Hewlett-Packard Company For the US Federal Communications Commission Office of Engineering and TechnologyandOther FCC Programs and Offices 1. I, David P. Adams, am Canada/USA Technical Regulations Manager for Hewlett- Packard Company (“Hewlett-Packard”) and Applicant/Grantee Contact of Recordfor Hewlett- Packard together with its subsidiaries and affiliates worldwide (collectively, “HP”) for HP’s dealings withthe United States Federal Communications Commission (“”FCC”). I am duly authorized by HP to make this Authorization on HP’s behalf. 2. This Authorization will designate the person named below to act on my behalf and HP’s behalf as authorized agent and representative, until further notice, with the additional power to designate one or more third partyagents for HP withregard to particular matters and applications. All acts carried out and requests made by this named representativerelating to any matter before the FCC, including requests for confidentiality,shallhave the same effect as mine. Name:Walter Overcash Title:RegulatoryEngineer Address:Hewlett-Packard Company Mailstop 050807 11445 Compaq Center Drive W Houston, TX 77070 Telephone:281-514-2756 E-mail:[email protected] 3. Questionsabout the scope and effect ofthis Authorization should be addressed as follows: David P. Adams Canada/USA Region Technical Regulations Manager 1501 Page Mill Road, MS1229 Palo Alto, CA 94304-1126 650.857.4423 Telephone 650.857.4882 Fax [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed atPalo Alto, California, on the date indicated below my signature. ____________________________ Signature David P. Adams Canada/USA Technical Regulations Manager Hewlett-Packard Company _March 5, 2008______________ Date

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] September 27, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Permanent Confidentiality Request for FCC ID: B94HNC75CHWCP Dear Sirs: Pursuant to Sections 0.457 and 0.459 of the Commission’s rules, we request Permanent Confidential treatment of information accompanying this application as outlined below: • Schematics • Block Diagram • Parts List • Operation Description • Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to us and provide unjustified benefits to our competitors. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] September 27, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Power of Attorney for FCC ID: B94HNC75CHWCP Dear Sirs: We have designated Jones Tsai in Sporton International Inc. as the person being responsible for this project and to sign the Form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. in the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. Neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product with FCC ID: B94HNC75CHWCP. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] September 27, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Certification Application for FCC ID: B94HNC75CHWCP Dear Sirs: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we request the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: • External Photos • Internal Photos • Test Setup Photos • User Manual The application contains technical information, which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage in the market place. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Hewlett-Packard Company 11445 Compaq Center Drive Mail Stop 510101 Houston, TX 77070 www.hp.com Walter Overcash Product Regulatory Engineer Telecom / Safety 281.514.2756 Tel [email protected] October 5, 2012 Product With FCC ID: B94HNC75CHWCP Dear Sirs: This product with FCC ID: B94HNC75CHWCP integrates a WWAN module and a WLAN module: Brand Name FCC ID Grant Date WWAN module Huawei QISMU733 03/07/2012 WLAN module HP B94HNQR03 09/21/2012 The antenna gain is as follows: Cellular Band AWS band PCS band WWAN antenna -0.5dBi 0dBi -0.2dBi 2.4GHz band 5150-5350 MHz 5470-5850MHz WLAN antenna 1.4dBi 3dBi 4dBi No hardware design changes are made on the modules, and the software has not been changed to increase the RF output power of the modules. The original modular reports of QISMU733 are submitted to represent the compliance of Parts 22/24/27. The original modular reports of B94HNQR03 are submitted to represent the compliance of Part s 15.247 and 15.407. For SAR compliance, the 5GHz band3 802.11n MIMO output power is reduced 1dB compared to original WLAN modular filing; detailed 802.11n MIMO maximum rated output power information is submitted in operational description exhibit. The unconditional reduction is controlled by software of the host. The power reduction cannot be disabled / modified by end users, and the fixed reduction level won’t change under any operating condition. If you have any comments or questions, please feel free to contact me. Sincerely, Walter Overcash

Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 1 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP 720510 1. External Photograph of EUT Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 2 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 3 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP List of Accessory: Specification of Accessory AC Adapter Brand Name HP Model Name HSTNN-DA34 Battery Brand Name HP Model Name HSTNN-DB3U WWAN Module Brand Name HUAWEI Model Name MU733 WLAN & Bluetooth Module Brand Name hp Model Name HSTNN-QR03 GPS Module Brand Name HP Model Name GPS-M21 Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 4 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP 720510 Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 5 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP AC Adapter Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 6 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Battery

Back of EUT (Tablet) Label Location

FCC ID: B94HNC75CHWCP Model: HSTNN-C75C Brand Name: hp

Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 7 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP 720510 3. Internal Photograph of EUT Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 8 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 9 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 10 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 11 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 12 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WWAN Module Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 13 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 14 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 15 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP GPS Module Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 16 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 17 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 18 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WLAN & Bluetooth Module Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 19 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 20 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 21 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP NFC Chip Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 22 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WWAM Main Antenna <Tx / Rx> Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 23 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 24 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WWAN Aux. & GPS Antenna < Rx> Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 25 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 26 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WLAN & Bluetooth Main Antenna <Tx / Rx> Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 27 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 28 of 30 TEL : 886-3-327-3456 Report Issued Date : Oct. 03, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP WLAN & Bluetooth Aux. Antenna <Tx / Rx> Photographs of EUT Report No.: EP290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 29 of 30 TEL : 886-3-327-3456 Report Issu…

Text truncated - open the document above for the full version.

Photographs of EUT Report No.: 290555 Brand Name: hp / Model Name: HSTNN-C75C SPORTON INTERNATIONAL INC. Page Number : 1 of 1 TEL : 886-3-327-3456 Issued Date : Oct. 02, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : B94HNC75CHWCP Antenna location Length Width WWAN Main Antenna <Tx / Rx> 7.5 cm 1.2 cm WWAN Aux. & GPS Antenna <Rx> 5.0 cm 1.2 cm WLAN Antenna 0 <Tx / Rx> 1.3 cm 1.2 cm WLAN/BT Antenna 1 <Tx / Rx> 1.3 cm 1.2 cm NFC Antenna <Tx / Rx> 5.3 cm 1.8 cm WWAN Aux. & GPS Antenna WWAN Main Antenna WLAN Antenna 0 16.2 cm WLAN/BT Antenna 1 19.3 cm 14.6 cm 3.9 cm 3.2 cm NFC Antenna 1.8 cm 14.1 cm 2.3 cm 18.4 cm

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/9/8 System Check_Body_835MHz_120908 DUT: D835V2-SN:499 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_120908 Medium parameters used: f = 835 MHz; σ = 0.996 mho/m; ε r = 55.4; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6R - SN1788; ConvF(5.75, 5.75, 5.75); Calibrated: 2012/1/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1338; Calibrated: 2012/6/12 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.71 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.8 V/m; Power Drift = -0.116 dB Peak SAR (extrapolated) = 3.88 W/kg SAR(1 g) = 2.5 mW/g; SAR(10 g) = 1.57 mW/g Maximum value of SAR (measured) = 2.73 mW/g 0 dB = 2.73mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/9/25 System Check_Body_835MHz_120925 DUT: D835V2-SN:499 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_850_120925 Medium parameters used: f = 835 MHz; σ = 0.953 mho/m; ε r = 52.741; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3578; ConvF(8.45, 8.45, 8.45); Calibrated: 2012/6/21; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2012/5/3 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15 mm, dy=15 mm Maximum value of SAR (interpolated) = 2.53 W/kg Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.611 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 3.410 mW/g SAR(1 g) = 2.33 mW/g; SAR(10 g) = 1.56 mW/g Maximum value of SAR (measured) = 2.51 W/kg 0 dB = 2.51 W/kg = 7.99 dB W/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/9/25 System Check_Body_1750MHz_120925 DUT: D1750V2-SN:1023 Communication System: CW; Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: MSL_1750_120925 Medium parameters used: f = 1750 MHz; σ = 1.546 mho/m; ε r = 51.742; ρ = 1000 kg/m 3 Ambient Temperature：22.7 °C; Liquid Temperature：21.7 °C DASY5 Configuration: - Probe: EX3DV4 - SN3578; ConvF(7.1, 7.1, 7.1); Calibrated: 2012/6/21; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2012/5/3 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15 mm, dy=15 mm Maximum value of SAR…
