B94SDCAB0801HP Wireless G USB Print Server

HP Wireless G USB Print Server User Guide © Copyright 2008 Hewlett-Packard Development Company, L.P. Hewlett-Packard Company notices The information contained in this document is subject to change without notice. All rights reserved. Reproduction, adaptation, or translation of this material is prohibited without prior written permission of Hewlett-Packard, except as allowed under copyright laws. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Regulatory model identification number For regulatory identification purposes, your product is assigned a Regulatory Model Number. The Regulatory Model Number for your product is SDCAB-0801. This regulatory number should not be confused with the marketing name (HP Wireless G USB Print Server) or product number (Q6301A). Disposal of Waste Equipment by Users in Private Households in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product. Contents Contents 3 1Welcome 2Basic setup 3 Using the USB print server Use the Connection Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Connection Manager icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Cancel a print job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Change printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Restart the Connection Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Use Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 4Troubleshooting Cannot detect print server during installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Can print from most software applications, but the HP software (HP Director or HP Solution Center) does not seem to work (cannot scan or read memory cards) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installation completed but still cannot print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 When using Advanced Setup, my print server does not show up in the list . . . . . . . . . . . . . . . . . . . 12 5 Technical information Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Environmental product stewardship program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Protecting the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Plastics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Material safety data sheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Hardware recycling program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Limited warranty statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 FCC statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Wireless regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Exposure to radio frequency radiation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Notice to users in Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Note à l'attention des utilisateurs canadiens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 European Union Regulatory Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Products with 2.4-GHz wireless LAN devices France . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Italy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Notice to Users in China . . . . . . . .…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 1 Total Page: 10 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 2 Rev. 00 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 3 Rev. 00 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 4 Rev. 00 USB Cable Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 5 Rev. 00 LEADER / MU12-2033200-A1 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 6 Rev. 00 LEADER / MU12-2033200-A3 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 7 Rev. 00 LEADER / MU12-2033200-B2 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 8 Rev. 00 LEADER / MU12-2033200-C5 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 9 Rev. 00 PI / P010WA3302 Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 10 Rev. 00 PI / P010WB3302

消銀龍/Printer Server/HP(Snicker) Notes: 1. : #50 Mylar, P (PO37), 2. : + /- 0.2mm 出紙方向 0801 B94SDCAB0801 801 HP Wireless G USB Print Server 2007.11.22 466F-SDCAB801 XXXX-XX-XXXX

Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 1 Total Page: 3 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 2 Rev. 00 Antenna Compliance Certification Services Inc. Report No.: 71004202 Date of Issue: October 24, 2007 Page 3 Rev. 00

Hew Li Industrial Co., Ltd Specification for 61720128IS Electrical Properties ¾ Frequency Range.....................................................................2.4GHz ~ 2.5GHz ¾ Impedance............................................................................. 50 Nominal ¾ VSWR .................................................................................2:1 MAX. ¾ Return Loss............................................................................ –10 dB Maximum ¾ Electrical Wave........................................................................1/4 PIFA ¾ Gain.................................................................................... 0.75 dBi ¾ Admitted Power...................................................................... 1W ¾ Type of Radiation..................................................................... Toroidal 1 Antenna Test Report Customer Measurement Time2006/05/12 Measurement Instrument 1Agilent Technologies E5071A 300K~8.5GHz ENASeries Network Analyzer 2Chamber3.5m(W) * 3.25m(H) * 7.12m(L) Gain Horn AntennaSG-430 1.7~2.6GHz Measurement Frequency2.4 GHz ~ 2.5GHz VSWR Antenna Peak Gain & Average Gain Test Result Antenna Peak Gain (dBi) Average Gain (dBi) Frequency 2.4GHz 2.45GHz 2.5GHz 2.4GHz 2.45GHz 2.5GHz Antenna 0.77 0.79 0.68 -1.81 -1.71 -1.51 Antenna Test Report Antenna Test Report Antenna Pattern 2.4~2.5GHz -40 -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -35 -30 -25 -20 -15 -10 -5 0 5 2.40 GHz H V H + V -40 -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -35 -30 -25 -20 -15 -10 -5 0 5 2.45 GHz H V H + V -40 -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -35 -30 -25 -20 -15 -10 -5 0 5 2.50 GHz H V H + V

Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 1 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For HP Wireless G USB Print Server Model: SDCAB-0801 Tr a d e Na me : H P Issued to Hewlett-Packard Company 16399 West Bernardo Drive San Diego CA 92127-1899 USA Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Pa-De 2nd Rd., Luchu Hsiang, Taoyuan Shien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................3 2. EUT DESCRIPTION ...........................................................................................................................4 3. TEST METHODOLOGY ....................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION........................................................................................................7 4.1 MEASURING INSTRUMENT CALIBRATION......................................................................................7 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................7 5. FACILITIES AND ACCREDITATIONS ..........................................................................................9 5.1 FACILTIES..........................................................................................................................................9 5.2 EQUIPMENT........................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS......................................................................10 6. SETUP OF EQUIPMENT UNDER TEST .......................................................................................11 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................11 6.2 SUPPORT EQUIPMENT ...............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS.............................................................................................12 7.1 6DB BANDWIDTH.............................................................................................................................12 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................21 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................30 7.5 SPURIOUS EMISSIONS ................................................................................................................34 7.6 POWERLINE CONDUCTED EMISSIONS...............................................................................................48 8. APPENDIX I RADIO FREQUENCY EXPOSURE ........................................................................51 9. APPENDIX II PHOTOGRAPHS OF TEST SETUP ......................................................................53 Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Hewlett-Packard Company 16399 West Bernardo Drive San Diego CA 92127-1899 USA Equipment Under Test: HP Wireless G USB Print Server Trade Name: HP Model: SDCAB-0801 Date of Test: October 9 ~ 22, 2007 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: S.C. Wang Miller Lee Executive Vice President Deputy Manager of Linkou Laboratory Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product HP Wireless G USB Print Server Trade Name HP Model Number SDCAB-0801 Model Discrepancy N/A Power Supply VDC from Power Adapter Pow…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 53 Rev. 00 9. APPENDIX II PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 54 Rev. 00 Conducted Emission Set Up Photos Compliance Certification Services Inc. Report No.: 71004202-RP1 FCC ID: B94SDCAB0801 Date of Issue: October 24, 2007 Page 55 Rev. 00 Powerline Conducted Emissions Setup Photos
