B94SDGOB1091802.11 b/g/n WLAN Module

Introduction: 802.11b/g/n WLAN Module, SDGOB-1091 User's Guide Before you begin Things you should know SDGOB-1091 network Before you begin Obtain the following information from your network administrator (if you are a home user, obtain this information from the person that installed your wireless access point): l Network names (SSID) of the specific wireless networks that you want to connect to. l WEP (Wired Equivalent Privacy) key information (if any) for the networks you want to connect to. l For Microsoft® Windows® networking, your customer name and workgroup name. l For your network account, your user name and password. l Your IP address (if not using a DHCP server) Things you should know When you start your computer, your SDGOB-1091 card detects certain wireless networks that are within range. Before you can connect to these and other wireless networks, you must configure a profile for each network using the information you obtained from your network administrator. WEP is a security protocol for wireless local area networks (defined in the IEEE 802.11g standard) that encrypts data sent over radio waves. The use of the WEP key is optional and can be enabled or disabled. If the network you are connecting to has enabled WEP, you must also enable WEP in the network profile and set the WEP key to match the WEP key used by the network. Otherwise, you cannot connect to the network. Broadcom SDGOB-1091 network The SDGOB-1091 card solution allows you to make a wireless connection to a network, as illustrated below. Back to top Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Back to Contents Page Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Overview Utility Components Overview The Broadcom Wireless Utility enables you to do the following network tasks: l Manage your wireless networks and create network connection profiles (Wireless Networks tab) l Connect to available networks (utility icon in notification area) l Get information about the network status and signal and noise of your network connection (Link Status tab) l View current and accumulated statistics (Statistics tab) l Find out which broadcasting networks are in range and search for nonbroadcasting networks (Site Monitor tab) l Run tests on the wireless network adapter (Diagnostics tab) l Get date and version information about the utility, and software, hardware, and location details about your wireless network adapter ( Information tab) l Manually add or delete trusted servers and enable the manual acceptance or rejection of auto- provisioning and A-ID group changes ( Wireless Networks tab) l Manually import EAP-FAST PACs (Wireless Networks tab) In the utility, you can open Wireless Network Wizard to connect to a basic network or create an ad hoc network, or you can open the Wireless Network Connection Settings tool to connect to an advanced network. To do any of the other tasks, click the tab that is associated with the described task. To start using the utility, right-click the utility icon in the notification area, and then click Open Utility. If the icon is not available, open Broadcom Wireless Utility in Control Panel. NOTE: The utility icon may not appear exactly as shown here. See " Table 1. Signal Strength Indicated by the Broadcom Wireless Utility Icon." Utility Components Utility components include the utility icon in the notification area, the six utility tabs, and Wireless Network Connection Settings. file:///P|/User%20Manuals/WLANCard-UM302_LaLa/HTML/utility.htm (1 of 12)4/25/2006 1:57:41 PM Using the Broadcom Wireless Utility: Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide Utility Icon To do any of the following tasks or operations, right-click the utility icon, and then click the appropriate item. l Open the on-line Broadcom AirForce™ 54g™ and Intensi-fi™ Wireless Network Adapter User Guide (Help Files) l Open About WLAN Card Utility to view links to Broadcom and Broadcom Customer Support websites and to view the version and date of the utility (About) l Hide the utility icon (Hide Tray Icon) l Disable or enable the radio (Disable/Enable Radio) l Connect to any of the networks for which you have created a connection profile and are within range (Connect To) l Open the utility to the Wireless Networks tab (Open Utility) l Open the utility to the Link Status tab to view information about the connection (Status) l Display a log of your wireless network events (Display Log) Wireless Networks Tab The Wireless Networks tab has tools that enable you to do the following: l Use the utility to manage your wireless networks l Add a network connection profile l Edit or remove a network connection profile l Change the order in which profiles are listed under Preferred network connections l Connect to any listed network without changing its order in the list l Disable or enable the radio (Disable/Enable Radio) l Show or hide the utility icon in the notification area l Choose which type of network to access l Lock or unlock a preferred network connection profile l Save your wireless network connection profiles as a WPN file l Import a WPN file l Manually add or delete trusted servers and enable the manual acceptance or rejection of auto- provisioning and A-ID group changes l Manually import EAP-FAST PACS On the Add menu, you can use either the wireless network wizard that is available from Broadcom Wireless Utility (see Connecting to a Basic Network or Creating an Ad Hoc Network Using the Wireless Network Wizard") or the utility (see "Connecting to an Advanced Network Using the Broadcom Wireless Utility") to add a network connection profile. To use the utility to manage your wireless networks, select the Let this tool manage your wireless networks check box. To add a network connection profile, click the Add arrow, and then click either Use Wizard (basic network) or Use Ut…

Text truncated - open the document above for the full version.

OEM Installation Guidance Document For 802.11bgn WLAN Module, SDGOB-1091 FCC ID: B94SDGOB1091; IC: 466D-SDGOB091 Page 1 of 7 Conditions on using the regulatory approvals: A. Customer is responsible for ensuring that antennas used with the product are of the same type, with same or lower gains as approved and providing antenna reports to Broadcom. B. Customer is responsible for regression testing to accommodate changes to the approved designs, new antennas, and portable RF exposure safety testing/approvals. C. Appropriate labels must be affixed to the CUSTOMER Product that comply with applicable regulations in all respects. D. A user’s manual or instruction manual must be included with the customer product that contains the text as required by applicable law. Without limitation of the foregoing, an example (for illustration purposes only) of possible text to include is set forth below: 1. USA—Federal Communications Commission (FCC) FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INFORMATION TO USER: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna -Increase the distance between the equipment and the receiver. -Connect the equipment to outlet on a circuit different from that to which the receiver is connected. OEM Installation Guidance Document For 802.11bgn WLAN Module, SDGOB-1091 FCC ID: B94SDGOB1091; IC: 466D-SDGOB091 Page 2 of 7 -Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. CAUTION: (this only applicable to 5GHz device) This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. System integrators must include the FCC ID on the end product. FCC Radio-Frequency Exposure & Approval Conditions: 1. Antennas must be installed in the display section of Netbook/notebook/laptop computer to provide at least XXcm separation distance from the transmitting antenna to the body of user during normal operating condition. 2. Transmitting antenna(s) can only be installed at the display section of computer. When this device is installed other than notebook computers, at least 20 cm separation distance shall be maintained between the transmitting antenna(s) to the body of user or nearby person. 3. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. 4. Only those antennas with same type and lesser gain filed under this FCC ID number can be used with this device. 5. The regulatory label on the final system must include the statement: “Contains FCC ID: B94SDGOB1091 and/or IC: 466D-SDGOB091” or using electronic labeling method as documented in KDB 784748. 6. The final system integrator must ensure there is no instruction provided in the user manual or customer documentation indicating how to install or remove the transmitter module except such device has implemented two-ways authentication between module and the host system. 7. The final host manual shall include the following regulatory statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in OEM Installation Guidance Document For 802.11bgn WLAN Module, SDGOB-1091 FCC ID: B94SDGOB1091; IC: 466D-SDGOB091 Page 3 of 7 accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna -Increase the distance between the equipment and the receiver. -Connect the equipment to outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference rec…

Text truncated - open the document above for the full version.

Inkjet Consumer Solutions (ICS) Division 16399 West Bernardo Drive San Diego CA 92127-1899, USA _______________________________________________________________ GENERAL DECLARATION We, Hewlett Packard Company, declares that the device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the following product. Model Name: 802.11 b/g/n WLAN Module Model Number: SDGOB-1091 FCC ID: B94SDGOB1091 If you have any questions regarding the declaration, please don’t hesitate to contact us. Thank you! Sincerely yours, 15 October, 2010 Julio Correa Date Product Regulations Engineer 858-655-3017 (tel) 858-655-3961 (fax) [email protected]

Inkjet Consumer Solutions (ICS) Division 16399 West Bernardo Drive San Diego CA 92127-1899, USA Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality In reference to the application under FCC ID: B94SDGOB1091, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block diagram Theory of Operation Antenna specifications The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 4/5/2011: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ___________________________________ 5 October, 2010 Julio Correa Date Product Regulations Engineer 858-655-3017 (tel) 858-655-3961 (fax) [email protected]

Applicant/Grantee Broadcom Corporation FCC ID: B94SDGOB1091 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Refer to external photos. Shield is over the radio circuit module. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Refer to Schematics. Y 3 The modular transmitter must have its own power supply regulation. Internal 3.3V power regulator. Refer to schematics. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Module contains a hirose connector. The module will go inside final product where the antenna(s) will be integral to the end product, which can be considered permanently attached. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Module was tested outside. Refer to test setup photos in test report. Y equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. Refer to label provided. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to manual Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Refer to MPE calculation in the Test report Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

D esi gn a ti on of T h i r d P a r ty R epr esen ta ti v e B y A u th or i z ed A gen t of H ewl ett-Pack ar d C ompany 1. I am an authorized agent and representative of Hewlett-Packard Company together with its subsidiaries and affiliates (collectively, “HP”), designated as such by David P. Adams as HP’s Applicant/Grantee Contact of Record for the FCC, pursuant to his Authorization as attached hereto. My name, address and contact information appear below. Any questions about the scope of this Designation of Third Party Representative should be directed to me. 2. Pursuant to this authority, I designate the third party identified below as HP’s agent for the matters and applications specified below, for the term specified below, unless earlier terminated by HP. a. Name, address and contact information of third party: Compliance Certification Services ( Certification Division) 47173 Benicia Street Fremont, CA 94538, USA b. Matters and applications covered (product and/or model identification, FCC ID where available): Product name: 802.11 b/g/n WLAN Module Model name: SDGOB-1091 FCC ID: B94SDGOB1091 c: Term of designation, unless earlier terminated by HP: 1 year(s). 3. All invoices for FCC’s services should be sent as specified in paragraph 2a, above. Licenses and test reports generated for HP should be sent as specified in paragraph 2a but copied to the undersigned. No access should be granted to any HP file or project information except as necessary in connection with the matters and applications specified in paragraph 2b. All acts carried out and requests made by the third party representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as HP’s own. Signature Name: Julio Correa Title: Product Regulations Engineer Address: Hewlett-Packard Company Attention: Julio Correa, Mailstop 65-220 16399 West Bernardo Dr. San Diego, CA 92127-1899 Telephone: 858-655-3017 E-mail: [email protected] October 13, 2010 Date

Authorizationon Behalf of Hewlett-Packard Company For the US Federal Communications Commission Office of Engineering and TechnologyandOther FCC Programs and Offices 1. I, David P. Adams, am Canada/USA Technical Regulations Manager for Hewlett-Packard Company (“Hewlett-Packard”) and Applicant/Grantee Contact of Recordfor Hewlett-Packard together with its subsidiaries and affiliates worldwide (collectively,“HP”) for HP’s dealings withthe United States Federal Communications Commission (“FCC”). I amduly authorized by HP to make this Authorization on HP’s behalf. 2. This Authorization will designate the person named below to act on my behalf and HP’s behalf as authorized agent and representative, until further notice, with the additional power todesignate one or more third partyagents for HP with regard to particular matters and applications. Allacts carried out and requests made by this named representativerelating to any matter before the FCC, including requests for confidentiality,shall have the same effect as mine. Name:Julio Correa Title:Product RegulationsEngineer Address:Hewlett-Packard Company Attention: Julio Correa Mailstop 8-90 16550 West Bernardo Dr. San Diego, CA 92127-1899 Telephone:858-655-3017 E-mail:[email protected] 3. Questions about the scope and effect ofthis Authorization should be addressed as follows: David P. Adams Canada/USA Region Technical Regulations Manager 1501 Page Mill Road, MS1222 Palo Alto, CA 94304-1126 650.857.4423 Telephone 650.857.4882 Fax [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed atPalo Alto, California, on the date indicated below my signature. ____________________________ Signature David P. Adams Canada/USA Technical Regulations Manager Hewlett-Packard Company 14 January 2009_______________ Date

SDGOB-1091 Proposed Regulatory Label Label Location: on the back of the EUT PROPOSED FCC ID LABEL FOR HOST DEVICE THIS DEVICE CONTAINS HP SDGOB-1091 FCC ID: B94SDGOB1091 IC: 466D-SDGOB091 內含射頻模組 CCXXxxLPyyyZz

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 7 CERTIFICATION TEST REPORT FOR 802.11 b/g/n WLAN MODULE MODEL NUMBER: SDGOB-1091 FCC ID: B94SDGOB1091 IC: 466D-SDGOB091 REPORT NUMBER: 10U13408-1 ISSUE DATE: OCTOBER 12, 2010 Prepared for HEWLETT PACKARD COMPANY 3000 HANOVER STREET PALO ALTO, CA 94304, U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES (UL CCS) 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 10U13408-1 DATE: OCTOBER 12, 2010 FCC ID: B94SDGOB1091 IC: 466D-SDGOB091 Page 2 of 59 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. Revision History Rev. Issue Date Revisions Revised By -- 10/12/10 Initial Issue M. Heckrotte REPORT NO: 10U13408-1 DATE: OCTOBER 12, 2010 FCC ID: B94SDGOB1091 IC: 466D-SDGOB091 Page 3 of 59 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS.................................................................................... 5 2. TEST METHODOLOGY ........................................................................................................ 6 3. FACILITIES AND ACCREDITATION.................................................................................... 6 4. CALIBRATION AND UNCERTAINTY .................................................................................. 6 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................... 6 4.2. SAMPLE CALCULATION.............................................................................................. 6 4.3. MEASUREMENT UNCERTAINTY................................................................................ 6 5. EQUIPMENT UNDER TEST ................................................................................................. 7 5.1. DESCRIPTION OF EUT................................................................................................ 7 5.2. MAXIMUM OUTPUT POWER....................................................................................... 7 5.3. DESCRIPTION OF AVAILABLE ANTENNAS............................................................... 7 5.4. SOFTWARE AND FIRMWARE..................................................................................... 7 5.5. NUMBER OF TRANSMIT CHAINS............................................................................... 7 5.6. WORST-CASE CONFIGURATION AND MODE .......................................................... 7 5.7. DESCRIPTION OF TEST SETUP................................................................................. 9 6. TEST AND MEASUREMENT EQUIPMENT ....................................................................... 11 7. ANTENNA PORT TEST RESULTS .................................................................................... 12 7.1. 802.11b MODE IN THE 2.4 GHz BAND...................................................................... 12 7.1.1. 6 dB BANDWIDTH .............................................................................................. 12 7.1.2. 99% BANDWIDTH .............................................................................................. 15 7.1.3. OUTPUT POWER ............................................................................................... 18 7.1.4. POWER SPECTRAL DENSITY .......................................................................... 19 7.1.5. CONDUCTED SPURIOUS EMISSIONS............................................................. 22 7.2. 802.11g MODE IN THE 2.4 GHz BAND...................................................................... 26 7.2.1. 6 dB BANDWIDTH .............................................................................................. 26 7.2.2. 99% BANDWIDTH .............................................................................................. 29 7.2.3. OUTPUT POWER ............................................................................................... 32 7.2.4. POWER SPECTRAL DENSITY .......................................................................... 33 7.2.5. CONDUCTED SPURIOUS EMISSIONS............................................................. 36 8. RADIATED TEST RESULTS .............................................................................................. 40 8.1. LIMITS AND PROCEDURE ........................................................................................ 40 8.1.1. TRANSMITTER ABOVE 1 GHz FOR 802.11b MODE IN THE 2.4 GHz BAND .. 41 8.1.2. TRANSMITTER ABOVE 1 GHz FOR 802.11g MODE IN THE 2.4 GHz BAND .. 44 8.2. RECEIVER ABOVE 1 GHz IN THE 2.4 GHz BAND ................................................... 47 8.3. WORST-CASE BELOW 1 GHz................................................................................... 48 REPORT NO: 10U13408-1 DATE: OCTOBER 12, 2010 FCC ID: B94SDGOB1091 IC: 466D-SDGOB091 Page 4 of 59 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. 9. AC POWER LINE CONDUCTED EMISSIONS .................................................…
