PTC-921 DOS User’s Guide PTC-921 DOS User’s Guide Part Number: 23451-000-02 Release Date: 5/27/98 Telxon is a registered trademark of Telxon Corporation. MS-DOS is a registered trademark of Microsoft Corporation. The information contained in this manual is subject to change without notice. Telxon Corporation shall not be liable for technical or editorial omissions or mistakes in this manual nor shall it be liable for incidental or consequential damages resulting from your use of the information contained in this manual. This manual is copyrighted. All rights are reserved. No part of this manual may be photocopied or reproduced in any form without the prior written consent of Telxon. © Copyright 1998 Telxon Corporation All Rights Reserved. Contents Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General regulations . . . . . . . . . . . . . . . . . . . . . 1 FCC statement . . . . . . . . . . . . . . . . . . . . . 1 DOC statement . . . . . . . . . . . . . . . . . . . . . 1 CE statement . . . . . . . . . . . . . . . . . . . . . . 2 If your PTC contains an Air-I/O 500 radio module . . . . . 2 FCC statement . . . . . . . . . . . . . . . . . . . . . 2 FCC regulations . . . . . . . . . . . . . . . . . . . . . 2 DOC statement . . . . . . . . . . . . . . . . . . . . . 2 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Using and disposing of lithium-ion batteries . . . . . . . . 3 If your PTC contains a radio . . . . . . . . . . . . . . . . 3 Using the internal laser scanner . . . . . . . . . . . . . . 4 Scope of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Document conventions . . . . . . . . . . . . . . . . . . . 5 Warnings . . . . . . . . . . . . . . . . . . . . . . . . 5 Cautions . . . . . . . . . . . . . . . . . . . . . . . . . 5 Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Overview of the PTC-921 DOS . . . . . . . . . . . . . . . . . . . . . . 6 Entering data . . . . . . . . . . . . . . . . . . . . . . . . 6 Through the keyboard . . . . . . . . . . . . . . . . . 6 With the internal laser scanner . . . . . . . . . . . . 7 Via the radio . . . . . . . . . . . . . . . . . . . . . . . 7 Storing data . . . . . . . . . . . . . . . . . . . . . . . . . 7 Communicating data . . . . . . . . . . . . . . . . . . . . 7 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Unpacking the PTC-921 DOS . . . . . . . . . . . . . . . . 8 Installing the battery pack . . . . . . . . . . . . . . . . . 8 i Charging the battery pack . . . . . . . . . . . . . . . . . . 9 Turning on the PTC . . . . . . . . . . . . . . . . . . . . . 9 Checking the PTC . . . . . . . . . . . . . . . . . . . . . . 9 Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Radio (optional) . . . . . . . . . . . . . . . . . . . . . . . 10 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Autodiscrimination between bar codes . . . . . . . . . . . 13 Automatic off . . . . . . . . . . . . . . . . . . . . . . . . . 13 Automatic return at on . . . . . . . . . . . . . . . . . . . 13 Backup system . . . . . . . . . . . . . . . . . . . . . . . . 13 Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Communication . . . . . . . . . . . . . . . . . . . . . . . 14 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Scanning bar-code labels . . . . . . . . . . . . . . . . . . . . . . . . 16 Communicating data . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using a communication cradle . . . . . . . . . . . . . . . 17 Using the radio . . . . . . . . . . . . . . . . . . . . . . . . 17 Replacing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . 18 Removing the battery pack . . . . . . . . . . . . . . . . . 18 Installing a new battery pack . . . . . . . . . . . . . . . . 18 Maintaining the PTC-921 DOS . . . . . . . . . . . . . . . . . . . . . . 19 Operating conditions . . . . . . . . . . . . . . . . . . . . . 19 Handling the PTC . . . . . . . . . . . . . . . . . . . . . . 19 Storing the PTC . . . . . . . . . . . . . . . . . . . . . . . 20 Cleaning the PTC . . . . . . . . . . . . . . . . . . . . . . 20 Servicing the PTC . . . . . . . . . . . . . . . . . . . . . . 21 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 The PTC does not turn on . . . . . . . . . . . . . . . . . . 22 The laser scanner fails to read a label . . . . . . . . . . . 22 Your radio fails to establish contact . . . . . . . . . . . . 23 Other problems . . . . . . . . . . . . . . . . . . . . . . . 23 ii Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Specifications . . . . . . . . . . . . . . . . . . . . . . . . 25 Communication . . . . . . . . . . . . . . . . . . . . . 25 Display . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Electrical . . . . . . . . . . . . . . . . . . . . . . . . 25 Environmental . . . . . . . . . . . . . . . . . . . . . 26 Laser scanner . . . . . . . . . . . . . . . . . . . . . . 26 Memory . . . . . . . . . . . . . . . . . . . . . . . . . 26 Physical . . . . . . . . . . . . . . . . . . . . . . . . . 26 Processor . . . . . . . . . . . . . . . . . . . . . . . . 27 Software . . . . . . . . . . . . . . . . . . . . . . . . . 27 Appendix B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Accessory part numbers . . . . . . . . . . . . . . . . . . . 29 Appendix C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Bar-code types and scanning distances . . . . . . . . . . . 31 Bar-code types supported . . . . . . . . . . . . . . . . 31 Scanning distances . . . . . . . . . . . . . . . . . . . 31 Appendix D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Index . . . . . . . . . . …

Text truncated - open the document above for the full version.

June 23, 1998 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Certification Application under FCC Part 15, Subpart C, Para. 15.247, Frequency Hopping Spread Spectrum Transmitters Operating in the Frequency Band 2402 - 2478 MHz. Applicant:TELXON CORPORATION Product:PTC-921 DOS FCC ID:BC5-24-LP Dear Sir/Madam, The product sample, as provided by you, has been tested and found to comply with FCC Part 15, Subpart C, Para. 15.247, Direct Sequence Spread Spectrum Transmitters operating in the Frequency Band 2402 - 2478 MHz. Please feel to contact us if you have any further questions. Best Regards, Tri M. Luu, P.Eng. V.P. Engineering

FCC ID: BC5-24-LP CANADA:

CONFIDENTIAL 1 of 29/2/98 AeroComm/Telxon Transmitter Operation The AeroComm/Telxon transmitter transmits on 77 frequencies from 2402 MHz to 2479 MHz. The frequency channel carrier frequencies are separated by 1 MHz . The 20dB bandwidth of the transmitter is 900 kHz. The carrier frequencies are selected from a pseudorandom - ordered table of frequencies located in the system ROM area of memory. Each frequency has an occupancy time of 256 mS. controlled by the system microprocessor. I. Pseudorandom Hopping Sequence The pseudorandom - ordered sequence is chosen from one of 77 hopping patterns by setting the variable ‘x’ and using the index ‘i‘ which increments every hop time (256 mS.) to look up the channel frequency to select. The following equation depicts the actual look- up and calculation of the selected frequency. F x (i) = [b(i) + x] mod (77) Where: b(i) is defined in Table 1 i = 1 to 77 x = hopping pattern x = 00,03,06,09,12,15,18,21,24,27,30,33,36,39,42,45,48,51,54,57,60,63,66,69,72,75 x = 01,04,07,10,13,16,19,22,25,28,31,34,37,40,43,46,49,52,55,58,61,64,67,70,73,76 x = 02,05,08,11,14,17,20,23,26,29,32,35,38,41,44,47,50,53,56,59,62,65,68,72,74,77 TABLE 1 -- The list of frequencies b(i) relative to 2402 MHz. i b(i)i b(i)i b(i)i b(i)i b(i)i b(i)i b(i) 10012 3223 5534 6245 1556 4967 17 216136424393537460457366859 30914 0525 7236 1147 6558 2869 74 43415 6626 3037 3148 4759 4470 27 57016 7327 6838 6349 3860 2171 57 65217 0228 0739 4850 2661 5972 20 76718 5829 5640 5451 5362 0673 50 81919 2530 7641 4052 3363 4174 61 90120 1031 4342 4653 5264 1475 24 10 3521 2332 1843 1354 2265 6976 75 11 0822 1233 7244 0355 4266 4577 29 CONFIDENTIAL 2 of 29/2/98 II.Channel Usage Channel usage is controlled by the Master unit. The master hops to a new channel every 256 ms. The master follows the pseudorandom sequence until all 77 frequency channels have been used. The sequence then repeats. III. Receiver Bandwidth and Synchronization. The receiver bandwidth matches the transmitter bandwidth. Frequency hopping is controlled by the Master unit. Receivers synchronize with a master transmitter by decoding Beacon data. Beacon data consists of preamble, address, frequency and timing information. The synchronization sequence is as follows: 1. The master unit transmits a Beacon (approx. 4ms. in duration) at approximately a 32 ms. rate. 2. Slave units scan all available hopping frequencies searching for the Beacon data. 3. Once the slave units decode the Beacon data, they load the frequency and timing information into internal timers and hop in unison with the master‘s hopping algorithm.

June 23, 1998 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Certification Application under FCC Part 15, Subpart C, Para. 15.247, Frequency Hopping Spread Spectrum Transmitters Operating in the Frequency Band 2402 - 2478 MHz. Applicant:TELXON CORPORATION Product:PTC-921 DOS FCC ID:BC5-24-LP Dear Sir/Madam, The product sample, as provided by you, has been tested and found to comply with FCC Part 15, Subpart C, Para. 15.247, Direct Sequence Spread Spectrum Transmitters operating in the Frequency Band 2402 - 2478 MHz. Please feel to contact us if you have any further questions. Best Regards, Tri M. Luu, P.Eng. V.P. Engineering June 23, 1998 TELXON CORPORATION 3330 West Market Street Akron, OH USA, 44313 Attn.:Mr. Dan Miller Subject:Certification Application under FCC Part 15, Subpart C, Para. 15.247, Frequency Hopping Spread Spectrum Transmitters Operating in the Frequency Band 2402 - 2478 MHz. Applicant:TELXON CORPORATION Product:PTC-921 DOS FCC ID:BC5-24-LP Dear Mr. Miller, The product sample, as provided by you, has been tested and found to comply with FCC Part 15, Subpart C, Para. 15.247, Frequency Hopping Spread Spectrum Transmitters operating in the Frequency Band 2402 - 2478 MHz. We, UltraTech Engineering Labs Inc., as appointed agent for TELXON CORPORATION, will prepare the application to Federal Communications commission (FCC) for authorization of this equipment under Certification requirements of FCC Rules. The engineering report and required application documents have been submitted to FCC for inspection. Enclosed you will find copies of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl. ENGINEERING TEST REPORT PTC-921 DOS FCC ID: BC5-24-LP FCC PART 15, SUBPART C, PARA. 15.247 FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTERS OPERATING IN THE FREQUENCY BAND FROM 2402 - 2478 MHz UltraTech FILE NO.: BC5-015FTX Tested for: TELXON CORPORATION 3330 West Market Street Akron, OH USA, 44313 Tested by: ULTRATECH GROUP OF LABS 4181 Sladeview Crescent, Unit 33 Mississauga, Ontario Canada L5L 5R2 REPORT PREPARED BY: Tri M. Luu, P.Eng. DATE: June 23, 1998 FCC PART 15, SUBPART C, SEC. 15.247 – FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTERSPage # 2 PTC-921 DOS, FCC ID: BC5-24-LP ULTRATECH GROUP OF LABSFile #: BC5-015FTX 4181 Sladeview Cres., Unit 33, Mississauga, Ontario, Canada L5L 5R2June 23, 1998 Tel. #: 905-569-2550, Fax. #: 905-569-2480, Wesite: http://www.ultratech-labs.com • Accredited by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australian • Recognized/Listed by FCC (USA), Industry Canada (Canada) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS 1.EXHIBIT 1 - SUMMARY OF TEST RESULTS & GENERAL STATEMENT OF CERTIFICATION........3 1.EXHIBIT 2 - GENERAL INFORMATION.......................................................................................................5 1.1.APPLICANT.....................................................................................................................................................5 1.2.MANUFACTURER............................................................................................................................................5 1.3.DESCRIPTION OF EQUIPMENT UNDER TEST.......................................................................................................5 1.4.RELATED SUBMITTAL(S)/GRANT.....................................................................................................................6 1.5.TEST METHODOLOGY.....................................................................................................................................6 1.6.TEST FACILITY...............................................................................................................................................6 1.7.UNITS OF MEASUREMENTS..............................................................................................................................7 2.EXHIBIT 3 - SYSTEM TEST CONFIGURATION..........................................................................................8 2.1.TEST SYSTEM DETAILS...................................................................................................................................8 BLOCK DIAGRAMS FOR CONDUCTED & RADIATED EMISSION MEASUREMENTS..............................................................8 2.3.PHOTOGRAPH FOR RF EMISSION MEASUREMENTS............................................................................................9 2.4.JUSTIFICATION...............................................................................................................................................12 2.5.EUT OPERATING CONDITION.........................................................................................................................12 2.6.SPECIAL ACCESSORIES...................................................................................................................................12 2.7.EQUIPMENT MODIFICATIONS..........................................................................................................................12 3.EXHIBIT 4 - TEST DATA................................................................................................................................13 3.1.HOPPING CHANNEL CARRIER FREQUENCY CHARACTERISTICS @ FCC CFR 47, PARA 15.247(A)(1) & (A)(1)(II)13 3.2.MAXIMUM PEAK OUTPUT POWER @ FCC 15.247(B) AND RF EXPOSURE LIMIT FCC 1.1310............................23 3.3.TRANSMITTER RADIATED EMISSIONS @ 3 METERS, FCC CFR 47, PARA. 15.247(C), 15.209 & 15.205............26 4.EXHIBIT 5 - GENERAL TEST PROCEDURES.............................................................................................40 4.1.ELECTRICAL FIELD RADIATED EMISSIONS MEASUREMENTS - GENER…
