BT 300 User Manual 1 of 6 BT300 BLUETOOTH WIRELESS HEADSET USERS MANUAL (July 2002, Preliminary) GN Netcom BT 300 User Manual 2 of 6 BT300 Bluetooth Wireless Headset Introduction The BT300 Headset is a lightweight “over the ear” wireless headset utilizing Bluetooth technology in the 2.4 GHz band for a short range (up to 10 meters) RF link. The headset contains a microphone and a receiver, and is intended for hands free communications with mobile telephones containing Bluetooth compatibility or any other device that has a Bluetooth Audio Gateway. Headset power is provided by a rechargeable battery. The battery can be charged with a vehicular charge adapter or an AC charge adapter. Battery Life is approximately 4 hours {“Talk Time”) and 100 hours standby (“Sniff”) time The headset has the following user operated controls (see Figure 1): 1. On/Off Switch---Press and hold to toggle state. 2. Function Button---This button is pushed for various lengths of time to initiate a call, hang up a call, pairing, transferring a call to a headset, and microphone mute. 3. Volume Rocker Switch---The upper portion of this switch is pushed momentarily to INCREASE the receive volume in steps and the lower portion of this switch is pushed momentarily to DECREASE the receive volume in steps. The headset has the following visual indicator: Green LED in center of the Function Button---LED flashes at various rates and durations to indicate Power ON/OFF, Charging, Search & Pairing, BT Link Established, Standby Mode, and Audio Link (on a call). Red LED in center of the Function Button---LED flashes as above, but the red color indicates low battery state. The headset has the following audio indicator: Tone in receiver---Tone varies in duration, duty cycle and frequency to indicate Volume Steps, Volume Min, Volume Max, Low Battery, Microphone Mute, Incoming Call, and Pairing. BT 300 User Manual 3 of 6 I BT300 Bluetooth Headset Operation---Preliminary 1. The battery must be charged before using. 2. To charge battery plug charger connector into rectangular Charge Jack located on edge of housing opposite microphone. (Note that the headset is not functional while charging). The LED will stay red during charging and go green when charging is complete (and the charger is still plugged in). 3. The headset is supplied for use on the right ear. For left ear use open the ear loop 90 degrees from the closed position, carefully snap ear loop off of hinge, rotate 180 degrees and snap back onto hinge. II Pairing with Mobile Phone (Mobile phone must be Bluetooth compatible.) (Note: Pairing must be done every time the headset establishes a link with a different mobile phone or other Bluetooth compatible device) 1. Verify power of mobile phone to be paired with is ON and phone is within 10 feet of headset. 2. Headset must be powered off. Press and hold On/Off button for more than 5 seconds to switch headset to pairing mode. Green LED is constantly ON. 3. The green LED will flash fast ON & OFF when Bluetooth pairing has been completed. 4. If pairing fails, the green LED will go OFF. III Receiving an Incoming Call 1. Place the headset on your ear after switching it ON, placing the earhook over your ear, and close the earhook so the receiver is close to your ear. The microphone should be pointed toward your mouth. 2. If there is an incoming call while the headset is ON and the devices are paired, the call will automatically be answered by the headset. The Incoming Call Alert is 1 second of 700 Hz Warble Tone. 3. When on a call, the green LED will flash at a rate of 1 second. 4. To adjust the Receive Volume Up, momentarily press the upper end of the rocker switch one or more times until the desired level is achieved. A ½ second 2 kHz beep will be heard when the max volume is reached. 5. To adjust the Receive Volume Down, momentarily press the lower end of the rocker switch one or more times until the desired level is achieved. A ½ second 2 kHz beep will be heard when the min volume is reached. IV Making an Outgoing Connection 1. If the headset is powered up, dialing can be done from the cell phone or by Voice Dialing if available. 2. Press the Function Button for more than 2 seconds and release. Dialing can be done from the cell phone or by Voice Dialing if available. BT 300 User Manual 4 of 6 V Other Functions 1. Low Battery Warning is indicated by five 50 millisecond 2 kHz beeps in the receiver every 20 seconds. This will start 10 minutes before the headset battery is out of power. The red LED warning will appear already when half an hour of battery life is left. 2. Out of Range is indicated by deterioration of audio quality (noisy signal) in the receiver. VI Storage 1. Always store with power OFF and in a cloth or plastic bag to keep dust and lint out of microphone and speaker openings. 2. Avoid storage at high temperatures (above 60 C or 134 F), such as in a hot vehicle in direct sunlight. Storage at high temperatures can degrade performance and reduce battery life. 3. Do not expose headset to rain or other liquids. VII Parts Replacement 1. Battery: This product is equipped with a Lithium Rechargeable Battery. Replacement must be done at a qualified service center or returned to the manufacturer. Use only P/N xxxxxx battery 2. AC Charger: Use only P/N xxxxxx 3. Vehicular Charger: Use only P/N xxxxxx VIII Certification and Safety Approvals for BT300 Bluetooth Wireless Headset EU:This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC). Hereby, GN Netcom, declares that this this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For further information please consult http://www.gnnetcom.com. Please note that this product uses radio frequency bands not harmonised within EU. Within the EU this product is intended to be used in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland. Italy, Luxembourg, The Netherlands, Portugal, Spain,…
