BCE-GN9120Cordless Phone

GN 9120 User Guide GN Netcom GN9120 BETA User Guide 11/20/02 5:12 PM Page 1 GN 9120 User GuideComponents1. Base Unit a) On-Line Indicatorb) Mute Indicatorc) Battery Re-Charge Indicatord) Link Indicatore) Telephone Termination Switch 2. Headset a) Multifunction Buttonb) Volume Up c) Volume Down 3. Headband4. Earhook5. Earplate6. Ear cushion7. Base Stand8. Connection Cord 9. Cord Manager10. Power Cord 3 (1a ) (1) (1d) (1b ) (2) (3) (1e) (5) (2b) (4) (8 ) (9) (6) (7.) (10) (2c) (2a) (1c) GN9120 BETA User Guide 11/20/02 5:12 PM Page 2 4) Insert the Base Unit into the Base Stand and twist until secure. Note: Use the Cord Manager to organize all cords attached to the Base Unit. Charging the Battery Fully charge the headset for 1.5 hours prior to initial use. To charge, place the headset in thebase. The Battery-Charging Indicator on the Base Unit will flash while charging and will stop flashing, but remain lit when the battery is fullycharged. A completely charged battery provides up to 8hours of talk time. If the battery needs to berecharged, a beep will sound in the headset every20 seconds. *** REMEMBER *** CHARGE THE BATTERY FOR 1.5 HOURS PRIOR TO INITIAL USE 5 4 Your headset will have one of the following Boom styles: a) Headset with NC (noise canceling microphone) b) Headset with SoundTube TM c) Headset with MidiBoom TM These instructions apply to all 3 Headsets. Installation1) Disconnect the handset cord from the telephone's handset port and connect it to the port marked handset on the Base Unit . 2) Insert the Connection Cord into the telephone's handset port marked handset . Then insert the other end of the Connection Cord into the port on the Base Unit marked telephone . 3) Plug the Power Adapter into the port marked power icon at the bottom of the Base Unit . Connect to a power outlet. (a.) (b.) (c.) GN9120 BETA User Guide 11/20/02 5:12 PM Page 4 Checking Your SystemTo check that your system is set up cor-rectly, first remove the headset from theBase Unit . The green, Link Indicator on the front of the Base Unit will light up and the red, On-Line Indicator on the headset will flash. Adjusting to Your Telephone1) First, make sure the Mute function is off. If the Mute function is activated, you will hear a beep in your headset every 15 seconds. Turn off the Mute function by pressing the Multifunction Button once quickly. 2) Put on the headset.3) Lift the telephone's handset and listen for a dial tone in your headset. 4) If there is little or no dial tone, move the Telephone Termination Switch on the back of the Base Unit , from A through G until the dial tone is clearly heard. 7 6 Adjusting Transmit and Receive Volume 1) Put on the headset . 2) Lift the handset . 3) Call someone and ask them to help you evaluate the headset's transmit volume. 4) Make sure that the boom arm/microphone is positioned closely to your mouth. 5) Press the +/- buttons on the headset simultaneously until you hear a beep. Adjust the Transmit Volume by pressing the + or - Button. + raises transmit and - lowers transmit.When the person you are speaking with finds the volume of your voice appropriate, press the +/- Buttons simultaneously for 2 seconds. This setting is now stored in the headset. 6) Now, adjust the Receive Volume by pressing the + or - Button, until you reach the sound level you desire. This setting is now stored in the headset. Note: When the maximum or minimum volume is reached, you will hear a beep in your headset. GN9120 BETA User Guide 11/20/02 5:12 PM Page 6 Answering telephone calls using the GN 1000 RHL (Remote Handset Lifter):You may purchase a GN 1000 RHL as an accessory, which lets you answer and end telephone calls while away from yourdesk. Please contact your preferred reseller or visitwww .gnnetcom.com for further information. To use the GN 1000 RHL accessory with your GN 9120 telephone: 1) Install a Remote Handset Lifter using the directions provided with that product. 2) To make a call, lift the handset out of the Base Unit. The Remote Handset Lifter will immediately lift up and you will hear a dial tone. To terminate the call, press the Multifunction Button for 2 seconds or put the headset back in its base. 3) To answer a call while wearing the headset, press the Multifunction Button quickly to establish a link. To end the call, press the Multifunction Button on your headset for 6 seconds. The call will be terminated. Conference ModeUsing the Conference Mode, additional headsets may be joinedto a telephone conference via the base station. The headsetused with your Base Unit is the Master headset. 1) Lift your Master headset out of the Base Unit . 2) Initiate or answer a call. Adjusting Receive Tone ControlSelect the tone (Normal, Bass Lift or Treble Lift) according to personal preference:1) Press the Multifunction Button for 6 seconds. A beep will indicate when 6 seconds has passed. 2) Press the volume + or - button to toggle between the 3 sound modes. When the desired sound mode is reached, press the Multifunction Button to exit the sound mode feature. Muting the MicrophoneTo mute the microphone, press the Multifunction Button on the headset once quickly. When the microphone is muted, you will hear a beep every 15 seconds in your headset and the red Mute Indicator on the Base Unit will light. You will still hear the other party. Placing and Answering Telephone Call1) Remove the headset from the Base Unit . The Link Indicator will light. 2) Put on the headset.3) Lift the handset from the phone. Answer or place the call. 4) You can now move freely away from the Base Station . If you move out of trans mission range, you will hear a beep in the headset every 10 seconds. Once back in range, the beeping will stop. To end the call, replace the handset. 9 8 GN9120 BETA User Guide 11/20/02 5:12 PM Page 8 Your headband allows you to wear your headset on yourright or left ear. Rotate the Boom Arm (x) 180 degrees for left ear or right ear wearing. The Stay-Put TM click-stop headband lengthens a…

Text truncated - open the document above for the full version.

__________________________________________________________________________________ ETSHandelsregister:Bankverbindung: Electronic Technology Systems Dr. Genz GmbHAmtsgericht Frankfurt/Oder HRB 5151Sparkasse Oder-Spree Storkower Strasse 38cGeschäftsführung: Dr. Dietmar GenzBLZ 170 550 50 D-15526 Reichenwalde b. Berlin Norbert KasparKto. Nr. 3105165974 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH - ETS - STORKOWER STRASSE 38c, D-15526 REICHENWALDE B. BERLIN Tel: 033631 888 000 FAX: 033631 888660 TIMCO Engineering Inc. 849 NW State Road 45 Newberry, Florida 32669 USA IHR ZEICHEN / YOUR REF.IHR SCHREIBEN / YOUR INFORM.UNSER ZEICHEN / OUR REF. DATUM / DATE 18.12.2002 Subject:Application for Certification GN Netcom Inc. FCC ID: BCE-GN9120 Dear Sirs, Submitted herewith, on behalf of GN Netcom Inc. is an application for certification of the following 2.4 GHz wireless headset and base station: FCC ID:BCE-GN9120 The system consists of a base unit (mobile device that is used at a distance of at least 20 cm from the body) and a headset (portable device, body worn). A SAR test has been carried out for the remote unit. Attached are the 731 form, authorization letter, confidentiality request letter, technical description, test report (TestRp1=test data and TestRpt2_Base (antenna 1) and TestRpt3_Base (antenna 2), TestRpt2_Headset (antenna 1) and TestRpt3_Headset (antenna 2) = test plots), SAR test report (TestRpt4), FCC ID label and label location information, test setup photographs, internal and external photographs, operational description, part’s list, block diagram, schematics and the user manual. In accordance with 0.459 of CFR 47 GN Netcom Inc. hereby requests confidentiality of all Technical Specifications, Block Diagrams, Circuit diagrams, Circuit Description, Part lists, and Operational description attached for the subject application (see Confidentiality request letter). Concerning the labeling requirements GN Netcom Inc. wants to apply in reference to section 15.19 (a)(5) of the FCC Rules because the device is to small for placing the 2-part-statement on it. Please find the complete statement in the user manual. Please review the report and documents and submit them to the FCC for Certification as a single application as already discussed with Mr. Sid Sanders. Should you have any questions or comments concerning the above, please contact the undersigned. Best Regards Jenifer Täubert

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 1 of 3 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 2 of 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 3 of 3

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 1 of 3 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 2 of 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 3 of 3

0 1 1 GN 9120 Label location US version. -- Location of barcode label (serial no.) and base label (FCC ID. Only for US versions) on base unit. 25/11/2002 Serial no. label Base label

FCC ID LABEL LOCATION HEADSET DRAFT JBR This label on US version ONLY This label on all versions Location of the FCC ID label

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 1 of 4 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 2 of 4 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 3 of 4 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-47 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 4 of 4

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 1 of 6 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 2 of 6 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 3 of 6 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 4 of 6 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 5 of 6 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH REGISTRATION NUMBER: G0M20211-7347-T-48 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN Appendix Page 6 of 6

Work Instruction AA_ETS_5.4_01_56 Measurement Dwell Time according to FCC Part 15.247 AA_ETS_5.4_01_56 Version: 01Page:1 of 6 VersionRemarkDateIssuedApproved 01Original29.08.2002Hoppe Content 1Object ............................................................................................................ 2 2Validity Range............................................................................................... 2 3Abbreviations and Acronyms........................................................................ 2 4Changing Service .......................................................................................... 2 5Related Documents ....................................................................................... 2 6Responsibilities............................................................................................. 3 7Industrial Safety ............................................................................................ 3 8Quality Assurance ......................................................................................... 3 9 Review of documentation and labelling........................................................3 10 Methods of Measurement.............................................................................. 4 Time of Occupancy, Measurement configuration.........................................5 11 Documentation .............................................................................................. 6 12 Enclosures ..................................................................................................... 6 Work Instruction AA_ETS_5.4_01_56 Measurement Dwell Time according to FCC Part 15.247 AA_ETS_5.4_01_56 Version: 01Page:2 of 6 Object This Work Instruction describes the measurement of Time of Occupancy for Frequency Hopping Systems in accordance to the section 15.247. Validity Range This Work Instruction is valid in the test laboratories of ETS. Safety tests are not subject of this work instruction. Abbreviations and Acronyms ETSElectronic Technology Systems AAArbeitsanweisung (Work Instruction) VAVerfahrensanweisung (Standard Operation Procedure) EUTEquipment Under Test Changing Service This Work Instruction is object of the intern documents changing service according to VA_ETS_4.3_01 “Lenkung der Dokumente und Daten” Related Documents ISO/IEC 17025“General requirements for the competence of testing and calibration laboratories” “Quality Management Manual of Electronic Technology Systems” VA_ETS_4.3_01„Lenkung der Dokumente und Daten“ (controlling documents and data) VA_ETS_4.5_01„Vergabe von Unteraufträgen“ (placing sub-orders) VA_ETS_5.4_01„Prüfverfahren“ (test-procedures) VA_ETS_5.4_05“Schätzung von Meßunsicherheiten” (estimation of measurement uncertainties) VA_ETS_5.5_01„Prüfmittelüberwachung, -wartung und Kalibrierung“ (controlling and calibrating test equipment) Work Instruction AA_ETS_5.4_01_56 Measurement Dwell Time according to FCC Part 15.247 AA_ETS_5.4_01_56 Version: 01Page:3 of 6 Responsibilities The laboratory manager is responsible for the Implementation of the technical tests in his laboratory domain. He assures that the laboratory has the necessary technical provisions for the particular test runs. The test operator performs the tests. The technical tests are performed according to the present Work Instruction. Industrial Safety The rules of industrial safety have to be observed strictly. Especially in case of powered de- vices the requirements of the electrical safety have to be respected. In case of transmitters with significant transmitting power (e.g. relay station) the exposition has to be limited by distance or other suitable steps. Quality Assurance The quality of test results in general have to be assured according to chapter 5.9 of the Quality Management Manual of ETS. Traceability of measurement results is assured according to chapter 5.6 of the Quality Man- agement Manual. All used test equipment has to be calibrated according to VA_ETS_5.5_01 “Prüfmittelüber- wachung, -wartung und Kalibrierung” (controlling and calibrating test equipment). VA_ETS_5.4_01 „Prüfverfahren“ (test-procedures) assures the usage of the last version of standards and public notices. Estimation of measurement uncertainty has to be done according to VA_ETS_5.4_05 “Schätzung von Meßunsicherheiten” (estimation of measurement uncertainties). Review of documentation and labelling In preparation of the tests and for review purposes are to check the requirements for docu- mentation and labelling. For that is to use the attached document „Formal requirements ac- cording FCC procedure Declaration of Conformity (DOC). This work can be done by test op- erator or by certification operator, following laboratory manager`s decision. Work Instruction AA_ETS_5.4_01_56 Measurement Dwell Time according to FCC Part 15.247 AA_ETS_5.4_01_56 Version: 01Page:4 of 6 Methods of Measurement The measuring test takes place with the measuring construction as per draft. The gate time of the generator HP 33120A must comply with the demanded measuring period depending on EUT. example: 0,4 s x number of the hopping channels for hopping systems in the 2400-2483.5 MHz band the necessary gate time amounts to 0.4 s x 79 channels = 31.6 s Settings for Timer HP33120A f=1/2t (Gate time for Counter) (f = 0,015823 Hz) The described measuring construction delivers the number of events where a fix frequency is activated. The measured number of events is multiplied with the measured burst time. The result is the Dwell time (time of occupancy). Repeat this instructions for Time of Occupancy in Master Inquiry Mode For Inquiry measurement use HCI Command 0x0001 0x30 0x05 E.g. -for CSR chip use controll software BtCLI type in inquiry giac 0x30 0x05 for longer inquiry time (61,4s). -for other chipset use special software from customer to realize Master Inquiry for longer then 13s. Work Instruction AA_ETS_5.4_01_56 Measurement Dwell Time according to FCC Part 15…
