ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH TEST - REPORT FCC ID: BCE-GN9300 Test report no.: G0M20509-9851-C-1 Certificate 1983-01 ELECTRONIC TECHNOLOGY SYSTEMS STORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBH PHONE +49-33631-888 00 FAX +49-33631-888 66 ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 2 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of approval holder 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test environment 2.3 Test equipment utilized 2.4 Test Procedure 3 Test Results 3.1 Peak Output Power 3.2 De Facto Equivalent Isotropic Radiated Power 3.3 Antenna Requirement 3.4 Transmitter Radiated Emissions in Restricted Bands 3.5 Out of Band Radiated Emission 3.6 Spurious Emissions 3.7 Minimum 6 dB Bandwidth 3.8 Peak Power Spectral Density 3.9 Spurious emissions related to AC power line ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 3 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extractes from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 14.10.2005 D. Hoppe Date ETS-Lab. Name Signature Technical responsibility for area of testing: 14.10.2005 N. Kaspar Date ETS Name Signature ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 4 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1 Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2 Details of accreditation status A CCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: TTI-P-G 126/96 ACCREDITED COMPETENT BODY DAR-REGISTRATION NUMBER: BPT-ZE-026/96 FCC FILED TEST LABORATORY REG. NO. 96970 A2LA Accredited Certification No.1983-01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) Accredited by Bluetooth Qualification Review Board INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 1.3 Details of approval holder Name : GN Netcom A/S Street : Metalbuen 66 Town : DK-2750 Ballerup Country : Denmark Telephone : +45 7211 8653 Fax : +45 7211 8749 Contact : Mr. Jan Hildebrand E-mail : [email protected] ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 5 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4 Application details Date of receipt of application : 26.09.2005 Date of receipt of test item : 26.09.2005 Date of test : 28.09.2005 – 05.10.2005 1.5 Test item Description of test item : GN9300 900 MHz Type identification : GN9300 Base Hardware version : V7rA Software version : 01.00 Serial number : Test sample without serial number Photos : See Appendix A Technical data Frequency band : 902 – 928 MHz Frequency ( ch A) : 903.680 MHz Frequency (ch B) : 915.968 MHz Frequency (ch C) : 926.208 MHz Number of Channels : 12 Operating Modes : duplex Type of modulation : GFSK Fixed point-to-point operation: Yes / No Antenna : Integral antenna Antenna gain : 0 dBi ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 6 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Host device : none Classification : Fixed Device Mobile Device (Human Body distance > 20cm Portable Device (Human Body distance < 20cm Transmitter Unom Umax Umin Power (ch A) : Conducted: 15.27 dBm Conducted: 15.21 dBm Conducted: 15.26 dBm Power (ch B) : Conducted: 15.40 dBm Conducted: 15.45 dBm Conducted: 15.45 dBm Power (ch C) : Conducted: 15.40 dBm Conducted: 15.40 dBm Conducted: 15.40 dBm Transmitter Unom Antenna 1 Unom Antenna 2 Power (ch A) : Radiated: 8.53 dBm Radiated: 9.27 dBm Power (ch B) : Radiated: 6.86 dBm Radiated: 7.63 dBm Power (ch C) : Radiated: 6.18 dBm Radiated: 6.27 dBm Manufacturer: (if applicable) Name : Street : Town : Country : Additional information: The scheme for frequency generation, spectrum spreading, receiver parameters, synchronization procedure, and other parameters will be provided by manufacturers declaration. This report covers three variants of the EUT. There are three different base stations using the same RF part. Base CT realizes PSTN access, Base CU realizes USB connection and Base A covers both connection modes. All RF-relevant tests were performed with the most complicated Base A. For the other both variants additional spurious emission tests and radiated output power tests were done in order to show the compliance for these variants, too. ETS Dr. Genz GmbH, Germany Registration number: G0M20509-9851 -C-1 7 of 32 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6 Test standards Technical standard : FCC RULES PART 15 / SUBPART C § 15.247 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 25 o C Relative hum…
