BCE-OTE15Bluetooth Headset

EN 81-03046 E WARNING! Permanent hearing loss may result from long-term exposure to sound at high volumes. Use as low a volume as possible. Headsets are capable of delivering sounds at loud volumes and high pitched tones. Under certain circumstances, exposure to such sounds can result in permanent hearing loss damage. The volume level may vary based on conditions such as the phone you are using, its reception and volume settings, and the environment. Avoid prolonged use of the headset at excessive sound pressure levels. Please read the safety guidelines below prior to using this headset. You can reduce the risk of hearing damage by following these safety guidelines: 1. Prior to using this product follow these steps • Before putting on the headset, turn the volume control to its lowest level; • Put the headset on; and then • Slowly adjust the volume control to a comfortable level. 2. During the use of this product • Keep the volume at the lowest level possible and avoid using the headset in noisy environments where you may be inclined to turn up the volume; • If increased volume is necessary, adjust the volume control slowly; • Ringing in the ears may indicate that the sound levels are too high; • If you experience discomfort or ringing in your ears, immediately discontinue using the headset and consult a physician; and • Stop using the headset if it causes great discomfort. With continued use at high volume, your ears may become accustomed to the sound level, which may result in permanent damage to your hearing without any noticeable discomfort. SAFETY INFORMATION! • Use of a headset will impair your ability to hear other sounds. Use caution while using your headset when you are engaging in any activity that requires your full attention. • If you have a pacemaker or other electrical medical devices, you should consult your physician before using this product. • This package contains small parts that may be hazardous to children and should be kept out of reach from children. This product is not a toy – never allow children to play with this product. Always store the product out of reach from children. The bags themselves or the many small parts they contain may cause choking if ingested. • Never try to dismantle the product yourself, or push objects of any kind into the products, as this may cause short circuits which could result in a fire or electric shock. • None of the components can be replaced or repaired by users. Only authorized dealers or service centers may open the product. If any parts of your product require replacement for any reason, including normal wear and tear or breakage, contact your dealer. • Avoid exposing your product to rain, moisture or other liquids to protect against damage to the product or injury to you. • If the product has ear tips, the ear tips should rest against, but not enter the ear canal. • Keep all products, cords, and cables away from operating machinery. • Observe all signs and instructions that require an electrical device or RF radio product to be switched off in designated areas such as hospitals, blasting areas, potentially explosive atmospheres, or aircrafts. • If the product overheats, if the product has been dropped or damaged, if the product has a damaged cord or plug, or if the product has been dropped in a liquid, discontinue use and contact GN Netcom, Inc. • Never mount or store the product over any airbag deployment area, as serious injury may result when an airbag deploys. • Do not use in areas where there are explosive hazards. • Dispose of the product according to local standards and regulations. Remember: Always drive safely, avoid distractions and follow local laws! Using the headset while operating a motor vehicle, motorcycle, watercraft or bicycle may be dangerous, and is illegal in some jurisdictions, just as use of this headset with both ears covered while driving is not permitted in certain jurisdictions. Check your local laws. Use caution while using your headset when you are engaging in any activity that requires your full attention. While engaging in any such activity, removing the headset from your ear or turning off your headset will keep you from being distracted, so as to avoid accident or injury. Do not take notes or read documents while driving. EN BUILT-IN BATTERY CARE: Please observe the following if the product contains a battery • Your product is powered by a rechargeable battery. • The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. • The battery can be charged and discharged hundreds of times, but will eventually wear out. • Unplug the charger from the electrical plug and the product when not in use. Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime. • If left unused, a fully charged battery will lose its charge over time. • Leaving the product in hot or cold places, such as in a closed car in the summer and winter conditions, will reduce the capacity and lifetime of the battery. • Always try to keep the battery between 15°C and 25°C (59°F and 77°F). A product with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing. Battery warning! • ”Caution” – The battery used in this product may present a risk of fire or chemical burn if mistreated. • Do not attempt to open the product or replace the battery. It is built-in and not changeable. Use of other batteries may present a risk of fire or explosion and the warranty will be terminated. • Only recharge your battery with the provided approved chargers designated for this product. • Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste or in a fire as they may explode. • Batteries may explode if damaged. CHARGER CARE: Please observe the following if the product is supplied with a ch…

Text truncated - open the document above for the full version.

jabra.com/classic Jabra classic For more information, please visit www.jabra.com NEED MOrE HElP? Why wait? Go to our support page and find all the answers you’re looking for 24-hours a day. www.jabra.com/classic 81-03804 a Get started in under Minutes 5 TOll FrEE customer contact Details: Na support Email: [email protected] Twitter: twitter.com/jabra_Us http://www.jabra.com/mobilesupport (For the latest support info and online user manuals) 1 (800) 327-2230 (U.s.) 1 (800) 489-4199 (canada) Design registration Pending international www.jabra.com © 2013 GN Netcom a/s (North america: GN Netcom Us, i nc.). all rights reserved. Jabra ® is a registered trademark of GN Netcom a/s. all other trademarks included herein are the property of their respective owners. The bluetooth ® word mark and logos are owned by the bluetooth siG, inc. and any use of such marks by GN Netcom a/s is under license. (Design and specifications subject to change without notice). English .....................................1 FRAnÇAis ..................................5 EspAñol ....................................9 poRTUgUÊs ...........................13 MaDE iN cHiNa MODEl: OTE15 Fcc iD: bcE-OTE15 ic: 2386c-OTE15 21 1 how to connect CONNECTING WITH A BLUETOOTH® DEVICE 1. Turn the headset on (set the On/Off switch to the on position). 2. press and hold (3 secs) the Answer/end button until the Bluetooth indicator flashes blue and pairing mode is announced in the headset. 3. Follow the voice-guided pairing instructions to pair to your Bluetooth device. 2 how to weAR The headset can be worn with or without the earhook. ATTACHING THE EARHOOK The earhook can be attached to the headset for the perfect fit. English 43 3 how to USe FUNCTIONACTION Answer/end callTap the Answer/end button Reject call press and hold (1 sec) the Answer/end button Redial last numberDouble-tap the Answer/end button Adjust speaker volume Tap the Volume up or Volume down button Mute/un-mute microphone Tap both the Volume up and Answer/end button at the same time it takes approx. 2 hours to fully charge the battery Micro-UsB port Answer/End button Volume up/down buttons Battery indicator Bluetooth indicator on/off switch IMPORTANT Download the Jabra Assist App for your Android TM or ios device to enhance your Jabra experience. Design registration Pending international This headset has been designed and manufactured to not exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. The highest SAR value for this headset when tested for use at the ear is 0.889 W/ kg. For Canada market only: This EUT is compliant with SAR for general population/ uncontrolled exposure limits in IC RSS-102 and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528. 65 1 comment le connecteR SE CONNECTER À UN PÉRIPHÉRIQUE BLUETOOTH MD 1. Allumez le casque (réglez le commutateur Marche/Arrêt à la position Marche). 2. Appuyez et maintenez appuyé (3 secondes) le bouton Réponse/ Fin jusqu'à ce que l'indicateur Bluetooth clignote en bleu et que le mode d'appariement soit annoncé dans le casque. 3. suivez les instructions vocales d'appariement pour apparier votre périphérique Bluetooth. 2 comment le PoRteR le casque peut être porté avec ou sans le crochet auriculaire. ATTACHER LE CROCHET AURICULAIRE le crochet peut être fixé sur le casque pour un ajustement parfait. FRAnÇAis 87 3 comment l 'UtIlISeR FONCTIONACTION Répondre/mettre fin à un appel Tapez sur la touche Réponse/fin Refuser un appel Appuyez et maintenez appuyé (1 seconde) la touche Réponse/fin Recomposer le dernier numéro Tapez deux fois sur la touche Réponse/ fin Régler le volume du haut-parleur Tapez sur le bouton Augmenter le volume ou Réduire le volume Activer ou désactiver le mode de discrétion du microphone Appuyez sur les deux boutons Augmenter le volume et Réponse/fin en même temps Une charge complète s'effectue en environ 2 heures port micro-UsB Touche Réponse/fin Boutons augmenter le volume/réduire le volume indicateur de pile indicateur Bluetooth Commutateur Marche/arrêt IMPORTANT Télécharger l'application Jabra Assist pour votre Android MC ou un appareil ios pour améliorer votre expérience Jabra. Enregistrement de dessin en attente au niveau international Ce casque a été conçu et fabriqué pour ne pas dépasser les limites d’exposition aux fréquences radio (RF) fixées par la Commission fédérale des communications (Federal Communications Commission - FCC) du gouvernement américain et par les autorités réglementaires canadiennes. La valeur du DAS la plus élevée pour ce casque lorsque testé pour une utilisation à l’oreille est de 0,889 W/kg. Pour le marché canadien seulement : ce MAE est conforme aux limites d’exposition DAS incontrôlée pour la population générale de la norme CNR-102 d’Industrie Canada et a été testé en conformité avec les méthodes de mesure et procédures spécifiées dans IEEE 1528. 109 1 cómo conectARlo CONEXIÓN A UN DISPOSITIVO BLUETOOTH® 1. Encienda el auricular (ajuste el botón Encender/Apagar en la posición de encendido). 2. presione y mantenga presionado (3 segundos) el botón Responder/Finalizar del auricular hasta que parpadee la luz azul de Bluetooth y se anuncie el modo de sincronización en el auricular. 3. siga las instrucciones de voz para sincronizar su dispositivo Bluetooth. 2 cómo USARlo puede usar el auricular con o sin el gancho para la oreja. CÓMO COLOCAR EL GANCHO PARA LA OREJA puede instalar el gancho para la oreja en el auricular para un ajuste perfecto. EspAñol 1211 3 cómo UtIlIZARlo FUNCIÓNACCIÓN Responder/ Finalizar llamadas pulse el botón Responder/Finalizar Rechazar llamadas presione el botón Responder/Finalizar y manténgalo presionado (1 segundo) Volver a marcar el último número pulse dos veces el botón Responder/Finalizar Ajuste del volumen del altavoz pulse el botón de volumen + o - silenciar/activar micrófono pulse …

Text truncated - open the document above for the full version.

7 layers AG Borsigstr.11 40880 Ratingen Germany Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 CONFIDENTIALITY REQUEST FOR “Jabra OTE15” FCC ID: BCE-OTE15 Sirs, In accordance with FCC Rule Section 0.457 and 0.459 of CFR 47, 7 layers AG (authorized by GN Netcom A/S) hereby requests the following documentation as Long-term confidential: - Schematic diagrams - Block diagrams - Operational Description Short-term confidential (until 180 Days from listing): - Internal Photos - External Photos - Test Setup Photos - User Manual These documents contain detailed system and equipment description and related information about the product, which GN Netcom A/S considers to be proprietary. This information should never get into the possession of competitors, which would be harmful for our business. Do not hesitate to contact me if you have any additional questions. Patrick Lomax Ratingen, 22/05/2013

GN Netcom A/S Lautrupbjerg 7 P.O.Box 201 DK-2750 Ballerup Denmark Tel. +45 45 75 88 88 www.jabra.com  R&D TA Engineer  Direct +86 592 2634855  Mobile  E-mail [email protected]   A GN Great Nordic Company  Att.: Federal Communications Commission / Industry Canada RE.: Letter of agent authorization Hereby we GN Netcom A/S Lautrupbjerg 7, DK-2750 Ballerup, Denmark Telephone: +45 45 75 88 88 Authorizes 7 Layers AG, Ratingen, Germany, to act on our behalf in all matters relating to application for equipment authorization of the product: Jabra OTE15 Bluetooth ® Headset FCC ID: BCE-OTE15 IC ID: 2386C-OTE15 in USA and Canada. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a). This agreement expires 6 months from the current date China 2013-05-06 Lily Zhuang ............................................................... .............................................. .......................................................................................................... (Place) (Date) (Name - print) [Company stamp] .................................................................................................... (Legally valid signature)

GN US (GN Netcom US) 77 Northeastern Blvd. Nashua, NH, 3062 USA www.jabra.com „ R&D Global Product Certifications „ Direct „ Mobile „ E-mail A GN Great Nordic Company Att.: Federal Communications Commission / Industry Canada RE.: Letter of authorization Hereby GN US Inc. (GN Netcom US Inc.) authorize Jørn B. Rasmussen GN Netcom A/S, Lautrupbjerg 7, DK-2750, ballerup, Denmark Lily Zhuang GN Netcom A/S Lautrupbjerg 7, DK-2750 Ballerup, Denmark Telephone: +45 45 75 88 88 and Tom Ringtved GN Netcom A/S Alfred Nobelsvej 21, DK-9220 Aalborg, Denmark Telephone: +45 45 75 88 88 to act on our behalf in all matters relating to application for equipment authorization of all our p products with brand names: J Jabra or GN usi using the BCE grantee code in USA and the 2386c grantee code in Canada. St Steen Kaiser 2008-04-29 s [email protected]

Date of Change:Description of Change: Responsible: 2011/04/28 Matr. Spec: (See B.O.M.) 3D revision: Created by:Created on: Tool marking: Drawing Scale:Size: Matr. type: A zchen 15-March-2013 . 1:1 A4 GN PDM file: Approved by:Approved on:Units: Projection: MARKmm Description:Document No:Doc. Revision: Design Status: Page No: REAR HOUSING PADPRINT PLACEMENT 50-06404 A DESIGN 1 of 1 CONFIDENTIALITY NOTICE: Process control dimensions are marked: This document is the property of GN Netcom A/S and must be treated as confidential. The document must not be used, or disclosed to any third party, without written permission by GN Netcom A/S. Copyright © 2008 GN Netcom A/S. All rights reserved. IQC/OQC Characteristics for Evaluation: # Cosmetic Standard: GSC.ST.00002 Part Marking.: GSC.PR.00102 Notes: 1.Artwork refer to the artwork drawing 83-03219. 2.The tolerance is +/- 0.15mm. 3.Pantone print color No.:Pantone 431C. FOR VIEW ONLY(the right drawing includes the speaker tower) SCALE 2:1 Artwork Scale:1:1 . Pre-release the new drawing zchen 21-March-2013 Jabra CLASSICJabra CLASSIC Jabra CLASSIC Jabra CLASSIC

PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg Germany Patrick Lomax 21.12.2011 Phone +49 (0) 2102 749 331 Fax +49 (0) 2102 749 350 FCC ID: BCE-OTE15 SAR Exemption for “Jabra OTE15 Bluetooth® Headset “ The Bluetooth device “Jabra OTE15 Bluetooth® Headset” by GN Netcom A/S is exempted from SAR evaluation because the source-based time–averaged output power is below 10mW, as per “KDB 447498”. Please find the calculation on next page. Best Regards, Patrick Lomax ANNEX for SAR Ex emption Model: OTE15 FCC ID: BCE-OTE15 IC: 2386C-OTE15 Please find below the calculation for the EIRP value. Maximum peak output power (conducted): 7.39 dBm Antenna Gain: 0.0 dBi EIRP (calculated): 7.39 dBm = 5.482 mW

Final Report on Model:OTE15 MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B Re port Reference: Ma y 13, 2013Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany No te : The following test results re late only to the devices spe cifie d in this document. This report shall not be reproduce d in parts without the wr itten approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht re gistere d in: Borsigstrasse 11 Cha irman of the Supervisory Board: D üs se ldorf , HRB 44 09 6 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Ph on e: +4 9 (0) 21 02 7 49 0Vorstand  Board : D E 20 315 96 52 Fax : +49 (0 ) 21 02 74 9 35 0 Dr. H .-J . Me cke lburg T AX No. 1 47 /58 69 /03 85 www.7Layers.com F CC I D: BCE- OTE15 I C: 2 386C-OTE15 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B 1Administrative Data 1.1Project Data Patrick LomaxPro ject Responsible: 2013/05/13Date Of Test Re port: 2013/05/10Date of first test: 2013/05/10Date of last test: 1.2Applicant Data Company Name:GN Netcom A/S Lautrupbjerg 7Street: DK-2750 Ballerup City: DenmarkCountry: Contact Person:Mr. Tom Ringtved +45 45 75 91 86Phone: [email protected]: 1.3Test Laboratory Data The following list shows all places and laboratories involved for test result generation: 7 layers DE Company Name :7 layers AG Street :Borsigstrasse 11 City :40880 Ratingen Country :Germany Contact Person :Mr. Michael Albert Phone :+49 2102 749 201 Fax :+49 2102 749 444 E Mail :[email protected] Laboratory Details Accreditation InfoLab IDIdentificationResponsible DAkkS-Registration no. D-PL-12140-01-01Conducted EmissionsLab 1Mr. Robert Machulec Mr. Andreas Petz DAkkS-Registration no. D-PL-12140-01-01Radiated EmissionsLab 2Mr. Robert Machulec Mr. Andreas Petz 1.4Signature of the Testing Responsible Patrick Lomax responsible for tests performed in: Lab 1, Lab 2 Page 2 of 23 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B 2.3OUT Features Features for OUT: Jabra OTE15 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 ACThe OUT is powered by or connected to AC Mains BTEUT supports Bluetooth data rate of 1 Mbps with GFSK modulation in the band 2400 MHz - 2483.5 MHz BTLESupport of Bluetooth Low Energy EDR2EUT supports Bluetooth using data rate of 2 Mbps with PI/4 DQPSK modulation in the band 2400 MHz - 2483.5 MHz EDR3EUT supports Bluetooth using data rate of 3 Mbps with 8DPSK modulation in the band 2400 MHz - 2483.5 MHz IantIntegral Antenna: permanent fixed antenna, which may be built-in, designed as an indispensable part of the equipment TantCtemporary antenna connector, which may be only built-in for testing, designed as an example part of the equipment 2.4Auxiliary Equipment AE No.Serial No.SW StatusHW StatusDescriptionType Designation AE 020335C2065A30638114250Fujitsu Siemens Power Supply AE 01AMILO Pro V3205YK2H014267110V / 60Hz ACFujitsu Siemens Laptop AE 05Flatron L1740BQ509WANF1W607 110V / 60 Hz AC LG TFT Display AE 03M-BB48LZC90505478Logitech Mouse AE 04RS 6000 USB ONG 0000273 2P28CHERRY Keyboard 2.5Operating Mode(s) Ref.-No.Description 01Data transfer via USB cable to Laptop computer. Bluesuite3 test softare is used to ensure that continuous data is transfered over USB between the Laptop and the DUT. Page 4 of 23 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B 2.6Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No.List of OUT samplesList of auxiliary equipment PC1_A01 (Computer Equipment Setup) AE 02Fujitsu Siemens Power SupplyA01BT Radiated sampleSample: AE 01Fujitsu Siemens Laptop AE 05LG TFT Display AE 03Logitech Mouse AE 04CHERRY Keyboard 3Results 3.1General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied standard. In cases where 'Declaration' is printed, the required documents are available in the manufacturers product documentation. In cases where 'not applicable' is printed, the test case requirements are not relevant to the specific equipment implementation. Documentation of tested devices: Interpretation of the test results: The laboratory environmental conditions are recorded and available in the Interlab system for each performed test. Note: 3.2List of the Applicable Body (Body for Scope: FCC_v2) DesignationDescription Part 15, Subpart B - Unintentional RadiatorsFCC47CFRChIPART15bRADIO FREQUENCY DEVICES 3.3List of Test Specification Test Specification:FCC part 2 and 15 Version10-1-11 Edition Title:PART 2 - GENERAL RULES AND REGULATIONS PART 15 - RADIO FREQUENCY DEVICES Page 5 of 23 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B 3.4Summary Test Case Identifier / Name SetupDate of TestResultTest (condition)Ref. Lab 15b.1 Conducted Emissions (AC Power Line) §15.107 15b.1; Mode = Charge via USB 2013/05/10PC1_A01Lab 1Passed operating mode: 01 15b.2 Spurious Radiated Emissions §15.109 15b.2; Mode = Charge via USB 2013/05/10PC1_A01Lab 2Passed operating mode: 01 Page 6 of 23 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B 3.5Detailed Results 3.5.115b.1 Conducted Emissions (AC Power Line) §15.107 Test: 15b.1; Mode = Charge via USB Result:Passed Setup No.:PC1_A01 Date of Test:2013/05/10 15:47 Body:FCC47CFRChIPART15bRADIO FREQUENCY DEVICES Test Specification:FCC part 2 and 15 Page 7 of 23 Reference: MDE_GNNET_1305_FCCa According to: FCC 47 CFR Ch.1 Part 15 Subpart B Detailed Results: AC MAINS CONDUCTED EUT: Jabra OTE15 (CJ230a01) Manufacturer: GNNET Operating Condition: …
