BCE-OTE21Bluetooth Headset

GET STARTED IN UNDER 81-03979 A NEED MORE HELP? For all support go to jabra.com/support jabra.com/movewireless QUICK START DOWNLOADS CONTACT SUPPORTTROUBLESHOOTING FAQ VIDEOS 1-2-3 jabra.com/movewireless JABRA MOVE WIRELESS GET STARTED IN UNDER MINUTES 5 © 2014 GN Netcom A/S (North America: GN Netcom US, Inc.) All rights reserved. Jabra ® is a registered trademark of GN Netcom A/S. All other trademarks included herein are the property of their respective owners. The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN Netcom A/S is under license. (Design and specifications subject to change without notice). Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. www.jabra.com MADE IN CHINA MODEL: OTE21 ENGLISH .....................................1 FRANÇAIS ..................................5 ESPAÑOL ....................................9 PORTUGUÊS ............................13 1 1 CONNECT Manual Bluetooth® pairing 1. Hold the On/Off/Pairing switch in the Pairing position for 3 seconds. 2. Pairing mode will be announced in the headphones, and the light will flash blue. 3. Follow the voice-guided instructions to connect to your Bluetooth device. WIRELESS CONNECTION Turn on the headset, and follow the voice-guided instructions to connect to your Bluetooth device. 2 ENGLISH WIRED CONNECTION 3.5 mm Jack Connector Connect the headset to your phone’s 3.5 mm Jack Connector using the audio cable. TIP: Bluetooth connections are disabled when connected to the 3.5 mm Jack Connector. CHARGING It takes 1-2 hours to charge the battery using any micro-USB cable. 3 2 DISCOVER On/Off/ Pairing switch Volume up 3.5 mm Jack Connector Micro-USB Port (charging only) Battery and Connection Status Lights Adjustable Headband Multi-function button Volume down 4 3 MUSIC & CHAT Battery and Connection Status Lights Pause/play musicTap the Multi-function button Adjust volume Tap the Volume up or Volume down button Skip music tracks Press and hold either the Volume up or Volume down button Mute Press and hold both the Volume up or Volume down buttons simultaneously Battery status Tap the Volume up or Volume down button when not listening to music or on a call Answer/end call*Tap the Multi-function button Reject call*Press and hold (1 sec) the Multi-function button Redial last number* Double-tap the Multi-function button 5 1 BRANCHER Appariement manuel Bluetooth® 1. Glissez le commutateur Marche/ Arrêt/Appariement à la position Appariement pendant 3 secondes. 2. Le mode d’appariement sera annoncé dans le casque et le voyant clignotera en bleu. 3. Suivez les instructions vocales pour connecter votre périphérique Bluetooth. CONNEXION SANS FIL Allumez le casque, puis suivez les instructions vocales pour connecter votre périphérique Bluetooth. 6 FRANÇAIS BRANCHEMENT PAR CÂBLE Prise de 3,5 mm Connectez le casque à la prise de votre téléphone 3,5 mm à l'aide du câble audio. CONSEIL : Les connexions Bluetooth sont désactivées lorsque le casque est connecté à la prise 3,5 mm. CHARGE Une pile peut prendre de 1 à 2 heures pour être chargée via un câble micro-USB. 7 2 DÉCOUVRIR Commutateur Marche/Arrêt/ Appariement Augmenter le volume Prise de 3,5 mmPort micro-USB (uniquement pour le chargement) Voyants d'état de la pile et de la connexion Bandeau réglable Bouton Multifonctions Réduire le volume 8 3 MUSIQUE ET CLAVARDAGE Lecture/Pause musique Appuyez brièvement sur le bouton Multifonctions Ajustement du volume Appuyez sur le bouton Augmenter le volume ou Diminuer le volume Sauter les pistes de musique Appuyez et maintenez enfoncé le bouton Augmenter le volume ou Réduire le volume Silence Appuyez et maintenez enfoncé simultanément le bouton Augmenter le volume ou Réduire le volume Niveau de la pile Appuyez brièvement sur le bouton Augmenter le volume ou Réduire le volume quand il n'y a pas d'appel en cours ou que vous n'écoutez pas de musique Répondre/ Raccrocher* Appuyez brièvement sur le bouton Multifonctions Refuser un appel* Appuyez et maintenez enfoncé (1 s) le bouton Multifonctions Recomposez le dernier numéro* Appuyez deux fois sur le bouton Multifonctions 9 1 CONÉCTESE Sincronización manual de Bluetooth® 1. Mantenga presionado el botón Encendido/Apagado/ Sincronización en la posición de Sincronización durante 3 segundos. 2. Se anunciará el inicio del modo de sincronización en el auricular y comenzará a parpadear la luz azul. 3. Siga las instrucciones por voz para conectar su dispositivo Bluetooth. CONEXIÓN INALÁMBRICA Encienda los auriculares y siga las instrucciones por voz para conectar su dispositivo Bluetooth. 10 ESPAÑOL CONEXIÓN ALÁMBRICA Conector de 3,5 mm Conecte el auricular al conector de 3,5 mm de su teléfono usando el cable de audio. CONSEJO: Las conexiones del dispositivo Bluetooth se desactivan cuando se conecta con el conector de 3,5 mm. CARGA Lleva 1-2 horas cargar la batería con cualquier cable microUSB. 11 2 DESCUBRA Botón Encendido/ Apagado/ Sincroni- zación Volumen + Conector de 3,5 mm Puerto microUSB (solo carga) Luces indicadoras del estado de conexión y batería Cinta ajustable para la cabeza Botón Multifun- cional Volumen - 12 3 MÚSICA Y PLÁTICAS Pausar/reproducir música Pulse el botón Multifuncional. Ajustar del volumen Pulse el botón de Volumen + o Volumen -. Saltar pistas de música Mantenga presionado el botón de Volumen + o el de Volumen -. Silencio Mantenga presionados ambos botones Volumen + y Volumen - simultáneamente. Estado de la batería Pulse el botón de Volumen + o Volumen - cuando no esté en una llamada o escuchando música. Responder/finalizar llamadas* Pulse el botón Multifuncional. Rechazar llamadas* Presione y mantenga presionado (1 segundo) el botón Multifuncional. Volver a marcar el último número* Pulse dos veces el botón Multifuncional. 13 1 CONECTAR Pareamento manual do Bluetooth® 1. Segure o interruptor Ligar/ Desligar/Pareamento na posição de Pareamento por 2 segundos. 2. O modo de pareamento será anunciado nos…

Text truncated - open the document above for the full version.

EN 81-03046 E WARNING! Permanent hearing loss may result from long-term exposure to sound at high volumes. Use as low a volume as possible. Headsets are capable of delivering sounds at loud volumes and high pitched tones. Under certain circumstances, exposure to such sounds can result in permanent hearing loss damage. The volume level may vary based on conditions such as the phone you are using, its reception and volume settings, and the environment. Avoid prolonged use of the headset at excessive sound pressure levels. Please read the safety guidelines below prior to using this headset. You can reduce the risk of hearing damage by following these safety guidelines: 1. Prior to using this product follow these steps • Before putting on the headset, turn the volume control to its lowest level; • Put the headset on; and then • Slowly adjust the volume control to a comfortable level. 2. During the use of this product • Keep the volume at the lowest level possible and avoid using the headset in noisy environments where you may be inclined to turn up the volume; • If increased volume is necessary, adjust the volume control slowly; • Ringing in the ears may indicate that the sound levels are too high; • If you experience discomfort or ringing in your ears, immediately discontinue using the headset and consult a physician; and • Stop using the headset if it causes great discomfort. With continued use at high volume, your ears may become accustomed to the sound level, which may result in permanent damage to your hearing without any noticeable discomfort. SAFETY INFORMATION! • Use of a headset will impair your ability to hear other sounds. Use caution while using your headset when you are engaging in any activity that requires your full attention. • If you have a pacemaker or other electrical medical devices, you should consult your physician before using this product. • This package contains small parts that may be hazardous to children and should be kept out of reach from children. This product is not a toy – never allow children to play with this product. Always store the product out of reach from children. The bags themselves or the many small parts they contain may cause choking if ingested. • Never try to dismantle the product yourself, or push objects of any kind into the products, as this may cause short circuits which could result in a fire or electric shock. • None of the components can be replaced or repaired by users. Only authorized dealers or service centers may open the product. If any parts of your product require replacement for any reason, including normal wear and tear or breakage, contact your dealer. • Avoid exposing your product to rain, moisture or other liquids to protect against damage to the product or injury to you. • If the product has ear tips, the ear tips should rest against, but not enter the ear canal. • Keep all products, cords, and cables away from operating machinery. • Observe all signs and instructions that require an electrical device or RF radio product to be switched off in designated areas such as hospitals, blasting areas, potentially explosive atmospheres, or aircrafts. • If the product overheats, if the product has been dropped or damaged, if the product has a damaged cord or plug, or if the product has been dropped in a liquid, discontinue use and contact GN Netcom, Inc. • Never mount or store the product over any airbag deployment area, as serious injury may result when an airbag deploys. • Do not use in areas where there are explosive hazards. • Dispose of the product according to local standards and regulations. Remember: Always drive safely, avoid distractions and follow local laws! Using the headset while operating a motor vehicle, motorcycle, watercraft or bicycle may be dangerous, and is illegal in some jurisdictions, just as use of this headset with both ears covered while driving is not permitted in certain jurisdictions. Check your local laws. Use caution while using your headset when you are engaging in any activity that requires your full attention. While engaging in any such activity, removing the headset from your ear or turning off your headset will keep you from being distracted, so as to avoid accident or injury. Do not take notes or read documents while driving. EN BUILT-IN BATTERY CARE: Please observe the following if the product contains a battery • Your product is powered by a rechargeable battery. • The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. • The battery can be charged and discharged hundreds of times, but will eventually wear out. • Unplug the charger from the electrical plug and the product when not in use. Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime. • If left unused, a fully charged battery will lose its charge over time. • Leaving the product in hot or cold places, such as in a closed car in the summer and winter conditions, will reduce the capacity and lifetime of the battery. • Always try to keep the battery between 15°C and 25°C (59°F and 77°F). A product with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing. Battery warning! • ”Caution” – The battery used in this product may present a risk of fire or chemical burn if mistreated. • Do not attempt to open the product or replace the battery. It is built-in and not changeable. Use of other batteries may present a risk of fire or explosion and the warranty will be terminated. • Only recharge your battery with the provided approved chargers designated for this product. • Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste or in a fire as they may explode. • Batteries may explode if damaged. CHARGER CARE: Please observe the following if the product is supplied with a ch…

Text truncated - open the document above for the full version.

GN Netcom A/S Lautrupbjerg 7 P.O.Box 201 DK-2750 Ballerup Denmark Tel. +45 45 75 88 88 www.jabra.com  R&D Product Certifications  Direct  Mobile  E-mail   A GN Great Nordic Company  Att.: Federal Communications Commission / Industry Canada RE.: Letter of agent authorization Hereby we GN Netcom A/S Lautrupbjerg 7, DK-2750 Ballerup, Denmark Telephone: +45 45 75 88 88 authorize Eurofins Product Service, Germany – Mrs. Sandra Henke - to act on our behalf in all matters relating to application for equipment authorization of the product: Jabra OTE21 Bluetooth ® Headset FCC ID: BCE-OTE21 IC: 2386C-OTE21 in USA and Canada. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a). This agreement expires 6 months from the current date Date of issue: 2014-08-08 Place of issue: Ballerup, Denmark Lily Zhuang GN Netcom A/S Global Product Certifications

GN Netcom A/S Lautrupbjerg 7 P.O.Box 201 DK-2750 Ballerup Denmark Tel. +45 45 75 88 88 www.jabra.com  R&D Certification Engineer  Direct +86 592 2634855  Mobile  E-mail [email protected]   A GN Great Nordic Company  Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality RE: Jabra OTE21 FCC ID: BCE-OTE21 FCC Part 15 Certification Gentlemen, In accordance with 0.459 and 0.457 of CFR 47, GN Netcom A/S hereby requests confidentiality of Block Diagrams, Circuit Diagrams (Schematics), Parts List and Operational Description attached for the subject application. These documents contain detailed system and equipment description and related information about the product, which GN Netcom A/S considers to be proprietary, confidential, and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, GN Netcom A/S considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Date of issue: 2014-08-08 Place of issue: Ballerup, Denmark Lily Zhuang GN Netcom A/S Global Product Certifications

Merry/Troy Hung2014-07-21 10 mm 10 mm 1/1 ConfidentialBHC631_Metal Part BHC 631-001: Metal Part ArtworkMerry/Troy Hung Merry Design Center Rev-01 006-000249 006-000249 006-000249 21 mm 10.356mm 1 mm 1 mm 0.4 mm 0.4 mm Scale: 1:1 10.1 mm 5mm Scale: 1:1

GN Netcom A/S Lautrupbjerg 7 P.O.Box 201 DK-2750 Ballerup Denmark Tel. +45 45 75 88 88 www.jabra.com  R&D Product Certifications   Direct  Mobile  E-mail   A GN Great Nordic Company  Applicant's declaration concerning User Manual Statements Federal Communications Commission & Industry Canada Re: application for Jabra OTE21 Bluetooth ® Headset FCC ID: BCE-OTE21 IC: 2386C-OTE21 Gentlemen, The North American version of the User Manual for the Jarba OTE21 Bluetooth ® Headset will include the following statements: FCC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Jabra (GN Netcom) will void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that  R&D Product Certifications  Direct  Mobile  E-mail   A GN Great Nordic Company  interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC:” before the certification/registration number only signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada approved the equipment. This equipment complies with IC RF radiation exposure limits set forth for an uncontrolled environment as per RSS-102 issue 2. Date of issue: 2014-08-08 Place of issue: Ballerup, Denmark Lily Zhuang GN Netcom A/S Global Product Certifications

SPORTON INTERNATIONAL INC. Page Number : 1 of 5 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 RF Exposure Evaluation Report Report No. : FA470942 RF Exposure Evaluation Report APPLICANT : GN Netcom A/S EQUIPMENT : Bluetooth headset BRAND NAME : Jabra MODEL NAME : OTE21 MARKETING NAME : Jabra Move FCC ID : BCE-OTE21 STANDARD : 47 CFR Part 2.1093 FCC KDB 447498 D01 v05r02 We, SPORTON INTERNATIONAL INC., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1093, and pass the limit. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. Page Number : 2 of 5 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 RF Exposure Evaluation Report Report No. : FA470942 Table of Contents 1. Administration Data ........................................................................................................................... 3 2. General Information ........................................................................................................................... 4 2.1 Description of Device Under Test (DUT) ........................................................................................... 4 3. Maximum RF output power among production units ......................................................................... 4 4. RF Exposure Evaluation .................................................................................................................... 5 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA470942 Rev. 01 Initial issue of report Aug. 08, 2014 SPORTON INTERNATIONAL INC. Page Number : 3 of 5 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 RF Exposure Evaluation Report Report No. : FA470942 1. Administration Data Testing Laboratory Test Site SPORTON INTERNATIONAL INC. Test Site Location No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. TEL: +886-3-327-3456 FAX: +886-3-328-4978 Applicant Company Name GN Netcom A/S Address Lautrupbjerg 7, 2750 Ballerup, Denmark Manufacturer Company Name GN Netcom A/S Address Lautrupbjerg 7, 2750 Ballerup, Denmark SPORTON INTERNATIONAL INC. Page Number : 4 of 5 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 RF Exposure Evaluation Report Report No. : FA470942 2. General Information 2.1 Description of Device Under Test (DUT) Product Feature & Specification DUT Type Bluetooth headset Brand Name Jabra Model Name OTE21 Marketing Name Jabra Move FCC ID BCE-OTE21 Wireless Technology and Frequency Range Bluetooth: 2402 MHz ~ 2480 MHz Mode •Bluetooth v3.0+EDR Antenna Type PIFA Antenna HW Version R4 SW Version V2.0.6 DUT Stage Production Unit Remark: The above DUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. 3. Maximum RF output power among production units Mode / Band Bluetooth 1Mbps 2Mbps 3Mbps 2.4GHz Bluetooth 9.50 6.50 6.50 SPORTON INTERNATIONAL INC. Page Number : 5 of 5 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 RF Exposure Evaluation Report Report No. : FA470942 4. RF Exposure Evaluation Bluetooth Max Power (dBm) mW Separation Distance (mm) Frequency (GHz) Exclusion Thresholds 9.5 8.00 < 5 2.48 2.52 Note: 1. Per KDB 447498 D01v05r02, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Conclusion: Per KDB 447498 D01v05r02, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The test exclusion threshold is 2.52 which is <= 3, SAR testing is not required.

GN Netcom A/S Lautrupbjerg 7 P.O.Box 201 DK-2750 Ballerup Denmark Tel. +45 45 75 88 88 www.jabra.com  R&D Product Certifications  Direct  Mobile  E-mail   A GN Great Nordic Company  Applicant's declaration concerning RF Exposure Federal Communications Commission Re: application for FCC ID: BCE-OTE21 We hereby indicate that the product Jabra OTE21 Bluetooth ® Headset is considered to be a portable transmitter for General Population/Uncontrolled exposure. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. A safety statement will be integrated in the user’s manual to provide end-users with transmitter operating instructions for satisfying RF exposure compliance. As Jabra OTE21 is transmitting max. 10 mW, it is excluded from routine environmental evaluation for RF exposure as it does not fall under the product categories listed in Section 2.1093 of the FCC's Rules. Date of issue: 2014-08-08 Place of issue: Ballerup, Denmark Lily Zhuang GN Netcom A/S Global Product Certifications

SPORTON INTERNATIONAL INC. Page Number : 1 of 71 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 Report Template No.: BU5-FR15CBT Version 1.0 FCC RF Test Report Report No. : FR470942 FCC RF Test Report APPLICANT : GN Netcom A/S EQUIPMENT : Bluetooth headset BRAND NAME : Jabra MODEL NAME : OTE21 MARKETING NAME : Jabra Move FCC ID : BCE-OTE21 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter The product was received on Jul. 09, 2014 and testing was completed on Jul. 19, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 71 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 Report Template No.: BU5-FR15CBT Version 1.0 FCC RF Test Report Report No. : FR470942 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ........................................................................................ 5 1.4 Product Specification subjective to this standard .............................................................................. 5 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Testing Location ................................................................................................................................ 6 1.7 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Descriptions of Test Mode ................................................................................................................. 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system ........................................................................ 10 2.5 EUT Operation Test Setup .............................................................................................................. 10 2.6 Measurement Results Explanation Example ................................................................................... 10 3 TEST RESULT .......................................................................................................................................... 11 3.1 Number of Channel Measurement .................................................................................................. 11 3.2 Hopping Channel Separation Measurement ................................................................................... 13 3.3 Dwell Time Measurement ................................................................................................................ 20 3.4 20dB and 99% Bandwidth Measurement ........................................................................................ 22 3.5 Peak Output Power Measurement .................................................................................................. 35 3.6 Conducted Band Edges Measurement............................................................................................ 37 3.7 Conducted Spurious Emission Measurement ................................................................................. 44 3.8 Radiated Band Edges and Spurious Emission Measurement ........................................................ 54 3.9 AC Conducted Emission Measurement........................................................................................... 65 3.10 Antenna Requirements .................................................................................................................... 69 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 70 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 71 APPENDIX A. SETUP PHOTOGRAPHS SPORTON INTERNATIONAL INC. Page Number : 3 of 71 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 Report Template No.: BU5-FR15CBT Version 1.0 FCC RF Test Report Report No. : FR470942 REVISION HISTORY REPORT NO. VERSION DESCR…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : 1 of 19 TEL : 886-3-327-3456 Report Issued Date : Aug. 08, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : BCE-OTE21 Report Template No.: BU5-FD15B Version 1.0 FCC Test Report Report No. : FV470942 FCC Test Report APPLICANT : GN Netcom A/S EQUIPMENT : Bluetooth headset BRAND NAME : Jabra MODEL NAME : OTE21 MARKETING NAME : Jabra Move FCC ID : BCE-OTE21 STANDARD : FCC 47 CFR FCC Part 15 Subpart B CLASSIFICATION : Verification The product was received on Jul. 09, 2014 and testing was completed on Jul. 13, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures given in ANSI C63.4-2009 and has been in complian…

Text truncated - open the document above for the full version.
