BCE-PHS003WBLUETOOTH SPEAKERPHONE

EN 81-03085 B WARNING! NORTH AMERICA Permanent hearing loss may result from long-term exposure to sound at high volumes. Use as low a volume as possible. Speakers are capable of delivering sounds at loud volumes and high pitched tones. Under certain circumstances, exposure to such sounds can result in permanent hearing loss damage. The volume level may vary based on conditions such as the radio you are using and volume settings. Avoid prolonged use of the speaker at excessive sound pressure levels. Please read the Safety Guidelines below prior to using the speaker. You Can Reduce the Risk of Hearing Damage by Following These Safety Guidelines During the Use of the Product: • Turn the volume control to its lowest level, when connecting the speaker and then • Slowly adjust the volume control to a comfortable level. • Keep the volume at the lowest level possible; • If increased volume is necessary, adjust the volume control slowly; and • If you experience discomfort or ringing in your ears, immediately discontinue using the speaker. With continued use at a high volume, your ears may become accustomed to the sound level, which may result in permanent damage to your hearing without any noticeable discomfort. SAFETY INFORMATION! • Use of a speaker will impair your ability to hear other sounds. Use caution while using your speaker when you are engaging in any activity that requires your full attention. • If you have a pacemaker or other electrical medical devices, you should consult your physician before using the product. • This package contains small parts that may be hazardous to children and should be kept out of reach of children at all times. The product is not a toy – never allow children to play with the product.The bags themselves or the many small parts they contain may cause choking if ingested. • Never try to dismantle the product yourself, or push objects of any kind into the product, as this may cause short circuits which could result in a fire or electric shock. WIRElESS AND CORDED SPEAkERS EN • None of the components can be replaced or repaired by users. Only authorized dealers or service centers may open the product. If any parts of your product require replacement for any reason, including normal wear and tear or breakage, contact your dealer. • Avoid exposing your product to rain, moisture or other liquids to protect against damage to the product or injury to you. • If the product overheats, if the product has been dropped or damaged, if the product has a damaged cord or plug, or if the product has been dropped in a liquid, discontinue use and contact GN Netcom, Inc. • Never mount or store the product over any airbag deployment area, as serious injury may result when an airbag deploys. • Do not use in areas where there are explosive hazards. • Observe all signs and instructions that require an electrical device or RF radio product to be switched off in designated areas such as hospitals or aircrafts. • Dispose of the product according to local standards and regulations. Remember: Always drive safely, avoid distractions and follow local laws! Use of the speaker while operating a motor vehicle may be regulated by local laws. Check with your local authorities. Use caution while using your speaker when you are engaging in any activity that requires your full attention. While engaging in any such activity turning off your speaker will keep you from being distracted, so as to avoid accident or injury. Do not take notes or read documents while driving. BUIlT-IN BATTERY CARE: Please observe the following if the product contains a battery • Your product is powered by a rechargeable battery. The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. • The battery can be charged and discharged hundreds of times, but will eventually wear out. • Unplug the charger from the electrical plug and the product when not in use. Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime. • If left unused, a fully charged battery will lose its charge over time. • Leaving the product in hot or cold places, such as in a closed car in the summer and winter conditions, will reduce the capacity and lifetime of the battery. • Always try to keep the battery between 0°C and 45°C (32°F and 113°F). A product with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing. Battery warning! • ”Caution” – The battery used in the product may present a risk of fire or chemical burn if mistreated. • Unless otherwise specified in the user manual or quick start guide the battery in your product can not be removed or replaced by the user. Any attempt to do so is risky and may result in damage of the product. Use of other batteries may present a risk of fire or explosion and the warranty will be terminated. • Only recharge your battery with the provided approved chargers designated for this product. • Dispose of batteries according to local regulations. Please recycle when possible. • Do not dispose the battery as household waste or in a fire as it may explode. • Batteries may explode if damaged. CHARGER CARE: • Do not attempt to charge your speaker with anything other than the AC adapter provided. The use of any other types may damage or destroy the speaker and could be dangerous. Use of other chargers may invalidate any approval or warranty. • For availability of approved enhancements, please check with your dealer. • Charge the product according to the instructions supplied with the product. Important: Please refer to the user manual for a description of the charging status indicator lights. Some speakers cannot be used while charging. Charger warning! • When you disconnect the power cord or any enhancement, grasp and pull the plug, not the cord. • Never use a charger that is damaged. • Do not attempt to disas…

Text truncated - open the document above for the full version.

GN Netcom A/S Lautrupbjerg 7 DK-2750 Ballerup P.O. Box 99 Phone +45 4575 0000 Co. Reg. No. 15069511 www.jabra.com September 26, 2012 Equipment Authorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA To Whom It May Concern: GN Netcom Inc, the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the GN Netcom Inc solely in matters relating to the application for an FCC equipment authorization for FCC ID BCE-PHS003W including the signing of documents in connection with this Application. Necessary acts carried out by GN Netcom Inc on our behalf of the GN Netcom Inc in connection with the Application shall have the same effect as acts of the GN Netcom Inc. The GN Netcom Inc also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Ballerup, Denmark 2012-09-26 Steen Kaiser ................................. .......................... ............................... (Place) (Date) (Name - print) ....................................................................................................

GN Netcom A/S Lautrupbjerg 7 DK-2750 Ballerup P.O. Box 99 Phone +45 4575 0000 Co. Reg. No. 15069511 www.jabra.com September 26, 2012 Equipment Authorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Request for Confidentiality Jabra Speak 450 FCC ID: BCE-PHS003W In accordance with 0.459 and 0.457 of CFR 47, GN Netcom A/S hereby requests confidentiality of Block Diagrams, Circuit Diagrams (Schematics), Parts List and Operational Description attached for the subject application. Additionally, in accordance with DA-04-1705A1, GN Netcom A/S hereby requests short- term confidentiality of External Photos, Test Setup Photos, Internal Photos and User’s Manual attached for the subject application. These documents contain detailed system and equipment description and related information about the product, which GN Netcom A/S considers to be proprietary, confidential, and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, GN Netcom A/S considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Ballerup, Denmark 2012-09-26 Steen Kaiser ................................. .......................... ............................... (Place) (Date) (Name - print) ....................................................................................................

External Photos

FCC ID: BCE-PHS003W Label Label Location FCC Label

Internal Photos

Report No.: SZ12080188E02 Page 2 of 16 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 1.3.1 Facilities .................................................................................................................................... 5 1.3.2 Test Environment Conditions .................................................................................................... 5 1.3.3 Measurement Uncertainty ......................................................................................................... 5 2. TEST CONDITIONS SETTING............................................................................................... 6 2.1 Test Mode .................................................................................................................................... 6 2.2 Test Setup and Equipments List ................................................................................................ 7 2.2.1 Conducted Emission.................................................................................................................. 7 2.2.2 Radiated Emission ..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 3.1 Conducted Emission ................................................................................................................. 11 3.1.1 Requirement ............................................................................................................................ 11 3.1.2 Test Description ...................................................................................................................... 11 3.1.3 Test Result ............................................................................................................................... 11 3.2 Radiated Emission .................................................................................................................... 13 3.2.1 Requirement ............................................................................................................................ 13 3.2.2 Test Description ...................................................................................................................... 13 3.2.3 Test Result ............................................................................................................................... 13 Change History Issue Date Reason for change 1.0 October 12, 2012 First edition Report No.: SZ12080188E02 Page 3 of 16 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ........................Bluetooth Speakerphone Serial No. ........................(n.a., marked #1 by test site) Hardware Version .......... .E Software Version ............. Applicant ......................... Manufacturer ................... 0-11-0 GN Netcom Inc 77 Northeastern Blvd. Nashua N.H.3062 USA GN Netcom A/S Lautrupbjerg 7, DK-2750 Ballerup, Denmark Modulation Type .............FHSS Power Supply ................. .Model No.: AHB343948PAT Serial No.: (n.a. marked #1 by test site) Capacitance: 600mAh Rated Voltage: 3.7V Ancillary Equipment 1 ....USB Power Cable NOTE: 1. The EUT is a Bluetooth Speakerphone, it’s a small portable music player and speaker. It supports ISM 2.4GHz Bluetooth band. 2. The EUT is equipped with a micro-USB port for audio input and charging. 3. For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ12080188E02 Page 4 of 16 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2009. Report No.: SZ12080188E02 Page 5 of 16 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 - 60 Atmospheric Pressure (kPa): 86 -106 1.3.3 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. Uncertainty of Conducted Emission: ±1.8dB Uncertainty of Radiated Emission: ±3.1dB Report No.: SZ12080188E02 Page 6 of 16 2. TEST CONDITIONS SETTING 2.1 Te s t M o d e (1) The first test mode The EUT configuration of the emission tests is EUT + PC. During the measurement, the EUT was connected with the PC via the USB cable …

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2．RE
