BJF-STFX150BDEINMARSAT FLEETBROADBAND SYSTEM

FCC ID: BJF-STFX150BDE EXTERNAL PHOTOGRAPHS MAIN UNIT Front View Rear View FCC ID: BJF-STFX150BDE EXTERNAL PHOTOGRAPHS HANDSET Front View RearView FCC ID: BJF-STFX150BDE EXTERNAL PHOTOGRAPHS ANTENNA UNIT Front View

FCC ID: BJF-STFX150BDE Label and Location LABEL & POSITION Sample Label Physical Location of FCC Label on EUT

FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Internal View RFAntenna FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT BaseBandPCB Component Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT BaseBandPCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Microprocessor BoardPCB Component Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Microprocessor BoardPCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Interface BoardPCB Component Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Interface BoardPCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Crystal BoardPCB Component Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Crystal BoardPCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Power SupplyPCB Component Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT Power SupplyPCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT RF ModulePCB Component Side RFModule FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – MAIN UNIT RF ModulePCB Trace Side FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS RF Module Circuit with RFShield Removed FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – ANTENNA UNIT Front View InternalView FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – ANTENNA UNIT Antenna Component View FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – ANTENNA UNIT Antenna Trace View FCC ID: BJF-STFX150BDE INTERNAL PHOTOGRAPHS EUT PHOTOGRAPHS – ANTENNA UNIT RF ATC BoardPCB Component Side

Test Report No. 7191032490-EEC12/04 dated 25 May 2012 Note: Th is re por t is issue d sub ject to the Testin g a nd Certificatio n Reg ul ati ons o f th e T ÜV S ÜD Group and the Gene ral T erms an d Co ndi ti ons of Bu si ness of TÜV SÜD P SB P te Ltd. In a ddi ti on, th is rep ort is go ver ned by th e terms set out within this report. 0%% 0%* 0%& 0%+ 0%+ 0%) 0%' 0%( The results reported herein have been performed in accordance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC- SINGLAS Accreditation Schedule for our laboratory. 0EFSVEXSV] 8À:7À(47&4XI0XH No.1 Science Park Drive Singapore 118221 P ho n e : + 65-6885 1333 Fax : + 65-6776 8670 E-mail: test ing@ tuv-sud-ps b. sg www.tuv-sud-psb.sg Co. Reg : 199002667R 6IKMSREP,IEH3JJMGI 8À:7À(%WME4EGMJMG4XI0XH 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 131 FORMAL REPORT ON TESTING IN ACCORDANCE WITH 47 CFR FCC Parts 2, 15, and 25 : 2011 OF AN INMARSAT FLEETBROADBAND SYSTEM [ Model : FX 150 ] [ FCC ID : BJF-STFX150BDE ] TESTFACILITY TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, No. 1 Science Park Drive, Singapore 118221 TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, 13 International Business Park #01-01, Singapore 609932 FCC REG. NO.99142 (3m and 10m Semi-Anechoic Chamber, Science Park) 160581 (3m and 10m Semi-Anechoic Chamber, International Business Park) IND. CANADA REG. NO.2932I-1 (3m and 10m Semi-Anechoic Chamber, Science Park) 2932N-1 (10m Semi-Anechoic Chamber, International Business Park) PREPARED FORSea Tel Inc. 4030 Nelson Ave,Concord,California,94520, USA Tel : +1 925 798 7979 Fax : :+1 925 288 1420 QUOTATION NUMBER219150213 JOB NUMBER7191032490 TEST PERIOD02 May 2012 – 25 May 2012 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Higher Associate E ngi neer ____________________ Lim Cher Hwee Assistant Vice President Sea Tel Inc.Page 2 of 131 Inmarsat Fleetbroadband System [ Model : FX 150 ] [ FCC ID : BJ F-STFX150BDE ] Test ReportNo. 7191032490-EEC12/04 dated 25 May 2012 TABLE OF CONTENTS TEST SUMMARY ........................................................................................................................................ 3 PRODUCT DESCRIPTION .......................................................................................................................... 5 SUPPORTING EQUIPMENT DESCRIPTION ............................................................................................... 6 EUT OPERATING CONDITIONS ................................................................................................................. 7 RADIATED EMISSION TEST ....................................................................................................................... 8 RF OUTPUT POWER TEST ...................................................................................................................... 12 UNWANTED EMISSIONS AT ANTENNA TERMINAL TEST ...................................................................... 19 RADIATED SPURIOUS EMISSION TEST.................................................................................................. 72 PROTECTION OF AERONAUTICAL RADIO NAVIGATION SATELLITE SERVICE TEST .......................... 78 FREQUENCY STABILITY (TEMPERATURE VARIATION) TEST ............................................................... 97 FREQUENCY STABILITY (VOLTAGE VARIATION) TEST ....................................................................... 102 MAXIMUM PERMISSIBLE EXPOSURE (MPE) TEST .............................................................................. 106 ANNEX A EUT PHOTOGRAPHS / DIAGRAMS ....................................................................................... 108 ANNEX B USER MANUALTECHNICAL DESCRIPTION BLOCK & CIRCUIT DIAGRAMS ........................ 129 ANNEX C FCC LABEL & POSITION ........................................................................................................ 130 Sea Tel Inc.Page 3 of 131 Inmarsat Fleetbroadband System [ Model : FX 150 ] [ FCC ID : BJ F-STFX150BDE ] Test ReportNo. 7191032490-EEC12/04 dated 25 May 2012 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary T est Stand ardDescriptionPass / Fail 47 CFR FCC Parts 2, 15 and 25: 2011 15.107(a), 15.207Conducted EmissionsNot Applicable * See Note 5 15.109Radiated Emissions (Class B)Pass 2.1046(a), 25.204RF Output PowerPass 2.1051, 25.202(f)Unwanted Emissions at Antenna TerminalPass 2.1053, 25.202(f)Radiated Spurious EmissionsPass 25.216(h)(i)(j)Protection of Aeronautical Radio Navigation Satellite Service Pass 2.1055, 25.202(d)Frequency Stability (Temperature Variation)Pass 2.1055, 25.202(d)Frequency Stability (Voltage Variation)Pass 1.1310Maximum Permissible ExposureRefer to page 106 for details Sea Tel Inc.Page 4 of 131 Inmarsat Fleetbroadband System [ Model : FX 150 ] [ FCC ID : BJ F-STFX150BDE ] Test ReportNo. 7191032490-EEC12/04 dated 25 May 2012 TEST SUMMARY Notes 1. Three channels as listed below, which respectively represents the lower, middle and upper channels (transmit and receive) of the Equipment Under Test (EUT). Each channel was configured to operate under the test mode condition. Transmit Channel Frequency (GHz)Receive ChannelFrequency (GHz) Lower Channel1.6266Lower Channel1.5251 Mi ddle Channel1.6435Mi ddle Channel1.5420 Upper Channel1.6604Upper Channel1.5589 2. The following tests were based on conducted measurement method: a. RF Output Power b. Unwanted Emissions at Antenna Terminal c. Frequency Stability (Temperature Variation) d. Frequency Stability (Voltage Variation) 3. All test measurement procedures are…
