BKMAP003GPS Sports Monitor

Introduction Thank you very much for purchasing this GPS Sports Monitor "WristableGPS". To use the device correctly, make sure you read the supplied Quick Guide along with this User's Guide. Keep the supplied Quick Guide handy to help you resolve any problems. The illustrations and screens shown in the Quick Guide/User's Guide are for the SF-710. By using a built-in GPS sensor and stride sensor, this device can measure running distance, pace elapsed time, altitude, and calories burnt. You can also upload recorded data to a dedicated Web site allowing you to look back over previous workouts. You can then make more effective plans and gain more enjoyment from your running. Descriptions in the User's Guide c Important: Indicates things you must do. Ignoring these instructions or mishandling this device could cause the device to malfunction or operational problems to occur. Note: Indicates additional information and related information. Menu Name Indicates menu items displayed on the screen of the device. A/B/C/D Indicates the device buttons. U Indicates related pages. If the related page is displayed in blue text, click it to display the related page. Trademarks EPSON and EXCEED YOUR VISION are registered trademarks of the Seiko Epson Corporation. Microsoft and Windows are registered trademarks of the Microsoft Corporation in the United States of America and other countries. The Bluetooth word mark and logos are the registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by the Seiko Epson Corporation is under license. Other product names are the trademarks or registered trademarks of their respective companies. Caution: ❏Unapproved copying of part or all of this guide is strictly forbidden. ❏The content of this guide may be changed without prior notice. ❏Although every effort has been made to ensure the accuracy of this guide, contact us if you have any questions or notice any errors in descriptions in the content of this guide. ❏Despite the preceding clause, we cannot accept any responsibility for mishandling due to errors in this guide. ❏We cannot accept any responsibility for malfunctions and so that occur due to ignoring the content of this guide, the device being handled inappropriately, repairs or modifications performed by a third party that is not our company or appointed by our company. SF-710/510/310 User's Guide Introduction 2 Features Chronograph function This function allows you to measure running data such as distance and time. You can measure split and lap times, as well as using the GPS signal to measure distance and pace. U “Measuring Time, Distance, and Speed (Chronograph Function)” on page 39 Split Time: Elapsed time from the start Lap time: Time for each lap You can use the history screen to check recorded measurement data. U “Checking Measurement Data” on page 64 Interval function This function allows you to perform interval training. Interval training: Allows you to repeat sets of light and hard exercise to increase your athletic ability. An exercise menu is created using combinations of hard (sprint) and light (rest) exercise. An alarm sounds when it is time to change between sprinting and resting. U “Setting a Time and Distance for Hard and Light Workouts(Interval Function)” on page 44 Goal function (timed race) Allows you to set a time as your goal and measure the time taken until that goal is reached. You can exercise while checking the elapsed time. You can also calculate the estimated distance. U “Measure until the time or distance set in advance is reached (Goal function)” on page 52 You can use the history screen to check recorded measurement data. U “Checking Measurement Data” on page 64 SF-710/510/310 User's Guide Introduction 3 Goal function (distance race) Allows you to set a distance as your goal and measure the time taken until that goal is reached. You can exercise while checking the distance. You can also calculate the estimated time. U “Measure until the time or distance set in advance is reached (Goal function)” on page 52 You can use the history screen to check recorded measurement data. U “Checking Measurement Data” on page 64 Mes. Settings Allows you to change the measurement settings. ❏When a time or distance is set in advance, laps are recorded automatically (AT Lap function) U “Recording Laps Automatically (AT Lap Function)” on page 57 ❏Automatically stops measuring when you stop running, and resumes when you continue running (AT Pause function) U “Automatically Start/Stop Measuring (AT Pause Function)” on page 59 ❏Set and measure the target time for one kilometer (Target Pace function) U “Setting a Pace and Measuring (Target Pace Function)” on page 61 ❏Monitoring heart rate with the HR Monitor (heart rate function) U “Measuring Heart Rate” on page 72 ❏Change the items and layout of the measurement screen display (screen settings function) U “Screen” on page 97 ❏Tap to load a set function (tap function) U “Tap” on page 21 SF-710/510/310 User's Guide Introduction 4 Settings Allows you to change the settings for the device. ❏Communicate with external devices (communication function) U “Comm. Settings” on page 94 ❏Invert the screen's monochrome display (invert function) U “Sys. Settings” on page 95 ❏Adjust the screen's contrast (adjust contrast function) U “Sys. Settings” on page 95 ❏Turn on the light automatically when the screen changes (Auto Light function) U “Sys. Settings” on page 95 ❏Set an alarm (Alarm function) U “Sys. Settings” on page 95 ❏Turn off operation tones (Operation Tones function) U “Sys. Settings” on page 95 ❏Reset configuration information in the device's memory (Initialize function) U “Sys. Settings” on page 95 Other features ❏Supports the Quasi-Zenith Satellite System (QZSS). U “Supports the Quasi-Zenith Satellite System” on page 32 ❏You can measure pitch and stride using the built-in stride sensor (SF-710/SF-510 only). U “Educating Your Stride Sensor” on page 33 ❏You can skip GPS positioning if it is ta…

Text truncated - open the document above for the full version.

Photo SF-310 Photo SF-310 Photo SF-310 Photo SF-310 Photo SF-310

Photo SF-510 Photo SF-510 Photo SF-510

Photo SF-710 Photo SF-710 Photo SF-710

Mark Product：GPS Sports Monitor Model :SF－310 (Unit mm） 18mm 19mm About ａthis square. We print QR-code to facilitate the identification of the product. Label

Mark Product：GPS Sports Monitor Model :SF－510 (Unit mm） 18mm 19mm About ａthis square. We print QR-code to facilitate the identification of the product. Label

Mark Product：GPS Sports Monitor Model :SF－710 (Unit mm） 18mm 19mm About ａthis square. We print QR-code to facilitate the identification of the product. Label

Photo Front Back 2 4G antenna

UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone: +81 463 50 6400 Facsimile: +81 463 50 6401 December 13, 2013 UL Japan, Inc. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN FCC ID: BKMAP003 To whom it may concern, We, UL Japan, Inc., hereby declare that GPS Sports Monitor, model : SF-710 (FCC ID: BKMAP003) of SEIKO EPSON CORPORATION is exempt from RF exposure SAR evaluation as its output power meets the exclusion limits stated in FCC Part 2 §2.1093. KDB 447498D01(v05r01) has the following exclusion for portable devices: The 1g and 10g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances < 50 mm are determined by: [(measured maximum equivalent isotropic radiated power(mW))/(Minimum separation distance(mm))]•[ √ f (GHz)] < 3.0 for 1g SAR and < 7.5 for 10g extremity SAR where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is < 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. This device f = 2.48 GHz, distance = 5mm (minimum separation distance: 5 mm was used in the calculation) and the measured maximum equivalent isotropic radiated power was 0.74 mW So for this device: 0.74 mW [measured maximum equivalent isotropic radiated power] / 5 mm [minimum separation distance] * ( √ 2.48) = 0.23 * caliculation: measured maximum equivalent isotropic radiated power = 10 ^ ( ( maximum peak output power [dBm] + antenna gain [dBi] ) / 10) = 10 ^ ( ( -2.91 [dBm] + 1.6 [dBi] ) / 10) *This is less than 3.0, so no SAR is required. Thank you for your attention to this matter. Akio Hayashi En gineer of Shonan EMC Lab. WiSE Ja pan UL Verification Service UL Japan, Inc.

Test report No. : 10035783S-B Page : 2 of 29 Issued date : December 12, 2013 Revised date : March 3, 2014 FCC ID : BKMAP003 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 REVISION HISTORY Original Test Report No.: 10035783S-B Revision Test report No. Date Page revised Contents - (Original) 10035783S-B December 12, 2013 - - 1 10035783S-B March 3, 2014 5 Addition of description (3.1 Test specification) Test report No. : 10035783S-B Page : 3 of 29 Issued date : December 12, 2013 FCC ID : BKMAP003 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Contents Page SECTION 1: Customer information ..................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ....................................................................... 4 SECTION 3: Test specification, procedures & results ......................................................... 5 SECTION 4: Operation of E.U.T. during testing ................................................................. 7 SECTION 5: 6dB bandwidth & Occupied bandwidth (99%) ............................................. 8 SECTION 6: Maximum peak output power ........................................................................ 8 SECTION 7: Out of band emissions (Antenna port conducted) ......................................... 8 SECTION 8: Peak power density.......................................................................................... 8 SECTION 9: Radiated emission ........................................................................................... 9 Contents of APPENDIXES ................................................................................................... 11 APPENDIX 1: Data of Radio tests ...................................................................................... 12 APPENDIX 2: Test instruments ......................................................................................... 27 APPENDIX 3: Photographs of test setup ........................................................................... 28 Test report No. : 10035783S-B Page : 4 of 29 Issued date : December 12, 2013 FCC ID : BKMAP003 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 1: Customer information Company Name : SEIKO EPSON CORPORATION Address : 281 Fujimi, Fujimi-machi, Suwa-gun, Nagano-ken 399-0293 Japan Telephone Number : +81-266-61-0617 Facsimile Number : +81-266-61-2045 Contact Person : Manabu Komiyama SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : GPS Sports Monitor Model Number : SF-710 Serial Number : Refer to 4.2 in this report. Rating : DC3.7V Country of Mass-production : Japan Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Receipt Date of Sample : September 20, 2013 Modification of EUT : No modification by the test lab. 2.2 Product description Model: SF-710 (referred to as the EUT in this report) is a GPS Sports Monitor. Clock frequency(ies) in the system : 26MHz, 32MHz, 32.768kHz, 48MHz <Radio part> Equipment type : Transceiver Frequency of operation : 2402-2480MHz Bandwidth / Channel spacing : 1MHz / 2MHz Type of modulation : GFSK Antenna type / Antenna connector type : 1/4λ chip antenna / None Antenna gain : 1.6dBi ITU code : F1D Operation temperature range : -5 to +50 deg.C FCC 15.31 (e) The RF transmitter is constantly provided voltage (DC3.1V) through the regulator regardless of input voltage. Therefore, the equipment complies with the requirement. FCC 15.203 It is impossible for end users to replace the antenna, because the antenna is mounted inside of the EUT. Therefore, the equipment complies with the antenna requirement. Similar models: SF-510 and SF-310 All the modules are common. Form and the color of the case are different. These models have same RF module. SF-710 SF-510 SF-310 Full-option No vibration alert function No acceleration meter No vibration alert function Test report No. : 10035783S-B Page : 5 of 29 Issued date : December 12, 2013 Revised date : March 3, 2014 FCC ID : BKMAP003 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 3: Test specification, procedures & results 3.1 Test specification Test specification : FCC Part 15 Subpart C: 2013, final revised on September 30, 2013 and effective October 30, 2013 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.207 Conducted limits Section 15.209 Radiated emission limits, general requirements Section 15.247 Operation within the bands 902-928MHz, 2400-2483.5MHz, and 5725-5850MHz * The revision on September 30, 2013 does not affect the test specification applied to the EUT. The EUT has been tested for compliance with FCC Part 15 Subpart B by the customer. 3.2 Procedures & Results Item Test Procedure *1) Specification RemarksDeviationWorst Margin Results Conducted emission ANSI C63.10:2009 FCC 15.207 - N/A *2) Complied 6dB bandwidth ANSI C63.10:2009 FCC 15.247 (a)(2) ConductedN/A * See data Complied Maximum peak output power ANSI C63.10:2009 FCC 15.247 (b)(3) ConductedN/A Complied Out of band emission & Restricted band edges ANSI C63.10:2009 FCC 15.109, 15.247 (d) & 15.209 Conducted / Radiated N/A 10.9 dB Complied Freq.: 7206.000MHz Polarization: Horizontal Detection: Average Mode: Tx 2402MHz Freq.: 7440.000MHz Polarization: Horizontal Detection: Average Mode: Tx 2480MHz Power density ANSI C63.10:2009 FCC 15.247 (e) ConductedN/A * See data Complied Note: UL Japan’s EMI Work Procedures No.13-EM-W0420 and 13-EM-W0422. *1) These tests were also referred to K…
