Recording Specifi cations CCTV Record When driving, recording is performed in 1 minute increments. After 1 minute, Recorded clip is saved and new clip is created and recording continues. Emergency Record if “REC” button is pressed while driving, Drive recorder will save 10 sec. before and 20 sec after recording when button was pressed and save to emergency record folder. Event Record If module detects impact to the vehicle while driving which have G sensor value 0.7G or above , it will save 10 sec. before and 20 sec. after the time when impact happened. Parking Event Record When vehicle is parked and customer have “Parking Event Record” setting “ON” in Mobile app and impact is detected to the vehicle which is over 0.10 G value, Drive recorder will save 30sec. after impact. Memory Specifi cations Depending on SD card partition ratio selected by customer in mobile app, memory specifi cation are as below: Default setting is 50%:25%:25%. Memory Card Size : 16 GB (Warranty only for the card provided.) Record Ratio Property Continuous Recording (CCTV) Incident Recording (EVENT) Incident Recording in Parking Mode (PARKING) ETC (User Select) Emergency Type A Total Size5.89 GB2.95 GB2.95 GB0.98 GB0.98 GB Recording time29 min13.5 min13.5 min4.5 min4.5 min Recording Ration5025251 GB1 GB Type B Total Size4.66 GB3.5 GB3.5 GB0.98 GB0.98 GB Recording time23 min16 min16 min4.5 min4.5 min Recording Ration4030301 GB1 GB Type C Total Size3.45 GB3.5 GB4.7 GB0.98 GB0.98 GB Recording time17 min16 min21.5 min4.5 min4.5 min Recording Ration3030401 GB1 GB , Note The memory sizes and time values are maximum values when recording at the front and rear. If the memory card is 16 GB, the actual memory space available is approximately 14.8 GB and the memory size is changed with 700 MB of free space to enable recording fi le rotation. It may not work properly when using an SD that is not provided with the product. e.g.) Using an old SD card (SD card replacement cycle: N months) or a physically damaged card Memory Specifi cations AP Mode : It is a mode that the Drive Recorderoperates as a router, and a direct communication between a mobile phone and the device is available. No Internet communication is available. Station Mode : It is a mode that connects the Drive Recorder with a mobile phone, and Internet communication can be used. To use the Server Upload/Download function, set to this mode. M Drive Recorder Installing the app Search for the Drive Recorder app in the Google Play Store or Apple App Store and install it on your smartphone. ➡ ➡ ➡ Membership Registration and Login 1) Touch the ‘Connect to the cloud’ button. 2) Touch the ‘Sign up’ button and enter the information. 3) Enter ID, password, device ID, security key, and email address. 4) Return to the app after completing the authentication within 10 minutes through an authentication email. 5) After signing up and logging in, the cloud main screen appears. , Note - If you are a non-subscribed member, a subscription pop-up will appear when you log in. - Only subscribed members can use the cloud service. - If you have forgotten your password, use the ‘Forgot password’ option to receive the initialized password via email. Connecting with the Dashcam (Android/iOS) ■ Android 1)Turn on Wi-Fi on your phone. 2) Connect to network that matches the Drive Recorder device ID. (Initial password: 0123456789) 3)After confi rming that you are connected to the Dashcam, run the app. 4) Run the app and touch the Connect directly to the dashcambutton. 5) When the connection is completed, ‘Linked to NISSAN00XXXXXXXX.’ notifi cation appears on bottom. ■ iOS 1) Turn on the Wi-Fi on your phone. 2) Connect to the network that matches the Drive Recorder device ID. (Initial password: 0123456789) 3) After confi rming that you are connected to the Dashcam, run the app. 4) Run the app and touch the ‘Connect directly to the dashcam’ button. 5) When the connection is completed, ‘Linked to NISSAN00XXXXXXXX.’ notifi cation appears on bottom. , Note Dashcam status is AP (blue light). Password: 0123456789 (Please change your password later in the app.) 1234 NO LED Name CASELED Color / Time 1MIC / Wi-Fi MIC ON & AP ModeBlue / Always MIC ON & STATION Mode Sky Blue / Always (Blue + Green) MIC OFF & AP ModeOFF / Always MIC OFF & STATION Mode Green / Always 2Power CCTV RecordRed / hold 1 sec Event RecordRed / hold 0.5 sec Emergency RecordRed / hold 0.5 sec Parking Event RecordRed / hold 0.5 sec No.Button NameOperationRemark 3 Emergency Record Starts emergency record at Hard key. 4Reset Reboots DashCam at Hard key. 5Wi-Fi Reset Resets Wi-Fi information and DashCam password at Hard key and restarts. 6Power Turns on/off the power at Hard key slide. Ι: Power ON O: Power OFF BEEPOperationSOUND Power ONDrive recorder ON.Tididing Power OFFInsuffi cient voltage to Drive recorder.Beep Impact / Emergency Record Impact is detected or Emergency “REC” button is pressed. Dingdong SD EmptyNo SD card Tarararara Tarararan ErrorError with SD card or Drive recorder.Ting 1 2 3 6 5 4 Wi-FiWi-Fi AP Mode Wi-Fi Hotspot AP Station Mode Wi-Fi LTE Checking Saved Files 1) Touch icon at the top right of the main screen. 2) Touch ‘Storage location’ under Download on the Settings screen. 3) Select SD Card for ‘Storage location’. 4) Connect to Cloud & Dashcam and touch ‘Video list’. 5) Touch the icon of the video you want to download. 6) Once the download is complete, go to the storage location in the SD card and check the fi le. , Note You can change the video download storage space to SD card only for Android. If you exit the app during download or go to another screen, the download stops. - Downloading: - Download complete: Changing Dashcam Settings 1) Touch the Dashcam settings button on the Dashcam main screen. 2) On the Dashcam settings screen, change the settings. 3) Touch the Save button at the bottom of the Dashcam settings screen to save the changed settings. (If you touch the Back button without pressing the Save button o…
