BP9-MO430LAI3PEEquipo de Audio y Video para Vehiculo

78 Display Settings Media Change Notifications 1. Press [SETUP] > [Display] > [Media Change notifications]. 2. Select the desired items. ↟[Display Media Change notifications]: Non-media playback screen, media information will be displayed briefly when the playback content changes automatically. Extend Rear Camera Use 1. Press [SETUP] > [Display] > [Extend rear camera use]. 2. Select the desired items. ↟[Extend rear camera use] : The rear camera view is displayed regardless off gear. When the vehicle exceeds a predetermined factory-set speed, the rear camera display turns off. 79 Display Settings Reset Resets the display settings to factory default. 1. Press [SETUP] > [Display] > [Reset]. 2. Press [Yes]. Others 81 Phone Projection Phone Projection What is Android Auto/Apple CarPlay? Securely access your smartphone while driving. Various functions of your smartphone are displayed on and operable from the screen of the media device (e.g. navigation, making a call, listening to music etc.). When connected, an Android Auto/Apple CarPlay icon appears on the screen. Available functions and operations may differ depending on the company model. For more information, visit the Google or Apple website. -Google: http://support.google.com/androidauto/ -Apple: http://www.apple.com/ios/carplay/ Cautions ↟Android Auto is a registered trademark of Google Inc. ↟Apple CarPlay is a registered trademark of Apple Inc. ↟Android Auto and Apple CarPlay are unavailable if the phone OS is not the latest version or if the phone cannot be recognized due to a shutdown caused by a failure or defect in the device itself. ↟Your phone may not be recognised if its battery is low. Charge your phone then try again. ↟If your phone is shut down due to a defect in the device itself, reset your phone and try again. ↟If the USB cable of the Android Auto/Apple CarPlay device is repeatedly disconnected and reconnected in a short period of time, the phone may malfunction. This can also cause a device failure. ↟The device recognition time may differ depending on the device type and firmware/OS version. ↟Using the USB cable that came with the phone is recommended. (Using a non-genuine product may cause noise or malfunction.) ↟Normal operations cannot be guaranteed if the phone is arbitrarily manipulated while Android Auto/Apple CarPlay is active. ↟Apple CarPlay can be run while making a call via Bluetooth. ↟Android Auto or Apple CarPlay may not operate normally due to mobile phone issues. ↟Carrier charges may apply when using Android Auto or Apple CarPlay. ↟Some features may not operate normally according to the version of iOS and Android. ↟The following problems may occur due to phone-related issues: 82 Phone Projection [Android Auto] -Intermittent black screens appear when entering Android Auto. -Differentiation of phones that support Android Auto and those which do not, may not be possible. -Black screens appear in some areas of the screen due to app errors. [Apple CarPlay] -Intermittent black screens appear when entering Apple CarPlay. -Black screens appear in some areas of the screen due to app errors when navigating between screens in Apple CarPlay. -The sound output of a call may be cut upon disconnecting Apple CarPlay during a call via Apple CarPlay. -If services do not work properly due to problems similar to the specified above, check your phone, and if necessary, reconnect your phone after restarting. Using Android Auto or Apple CarPlay 1. Make sure only genuine USB cables are used that were provided by the mobile phone's manufacturer. 2. Enter [Android Auto] or [Apple CarPlay] from the Home screen. 3. Now the features such as navigation, music and phone are ready to be used. NOTICE ↟Before connecting your mobile phone, check whether Android Auto or Apple CarPlay is activated in the [Phone connection] menu. ↟After connecting the mobile phone, the phone has to be unlocked and the disclaimers on the phone have to be accepted in order to launch Android Auto or Apple CarPlay. ↟The screens and features displayed on the infotainment System correspond to the screens and features provided by Google or Apple. They are subject to change according to the policy of the respective company. NOTICE-Android Auto ↟Bluetooth media features will be disabled when Android Auto is activated. After removing the USB cable, these features will be available again. ↟If Android Auto is not activated even after a successful connection, follow these steps: -Check whether an error occurred on the phone. -Check whether Android Auto has been closed on the phone. -Check whether Android Auto is activated in the [Phone connection] menu. ↟If Android Auto does not work normally even after a reconnection has been made, visit the Google website http://support.google.com/androidauto. ↟Please refer to the following website to check the available countries for the [Android Auto]. https://www.android.com/auto/ 83 Phone Projection NOTICE-Apple CarPlay ↟Bluetooth phone/media features will be disabled when Apple CarPlay is activated. After removing the USB cable, these features will be available again. ↟If Apple CarPlay is not activated even after a successful connection, follow these steps: -Check whether Apple CarPlay is disabled in the iPhones application settings. -Check whether Apple CarPlay is activated in the [Phone projection] menu. ↟If Apple CarPlay does not work normally even after a reconnection has been made, visit the Apple website http://www.apple.com/ios/carplay/ ↟Please refer to the following website to check the available countries for the [Apple CarPlay]. http://www.apple.com/ios/feature-availability/ 84 Using Rear Camera (If Equipped) Using Rear Camera (If Equipped) About Rear Camera ↟Rear camera is a feature for the customers who select option. ↟The rear camera provides a view of the rear of the vehicle, when reversing. ↟When the shift lever is placed in R with the vehicle’s ignition turned on, rear camera will oper ate. ↟If you change the shift lev…

Text truncated - open the document above for the full version.

Functions and services in this manual may differ from those in the actual vehicle. Car Multimedia System USER'S MANUAL Thank you for purchasing this Hyundai Motors Car Multimedia System. This user’s manual explains how to use the Hyundai Motors Car Multimedia System. Before using the product, read the contents of this user’s manual carefully and use this product safely. ↟The screens shown in this manual may differ with the actual screens of the product. ↟The design and specification of this product may change without prior notification for product improvement. ↟When transferring the vehicle to another individual, include this user’s manual so that the next driver can continue its use. 3 Table of Contents Table of Contents 3 Start Name of Each Component 5 Basic operation 8 HOME screen 11 Media Playing USB 17 Bluetooth audio 25 Voice memo 27 Radio Listening to AM 32 Listening to FM 35 Phone Bluetooth 39 Making a call 46 Call history 50 Contacts 52 Favourites 55 Setup Settings 59 Phone connection Settings 60 Button Settings 64 Wi-Fi Settings 65 General settings 66 Sound Settings 69 Display Settings 74 Others Phone Projection 81 Using Rear Camera (If Equipped) 84 Reference Precautions for Safety 88 General Information 91 Before thinking there is a product defect 93 Troubleshooting 94 Trademarks and Licenses 96 Specification 97 Open Source Software Notice 98 Table of Contents Start 5 Name of Each Component Name of Each Component Head unit Head unit functions may vary for each model. POWER PUSH or PWR / Volume knob ↟Press to turn on the screen. ↟When power is on, press and hold to turn off the screen. ↟When power is on, press to turn radio/media off. ↟Turn left/right to control volume. b (Reset hole) ↟Press with a thin object to reset the unit when it does not operate normally. A SEEK/TRACK D (W/S) button When it is pressed for a short time ↟Radio mode: Plays previous/next available frequency or station. ↟Media mode: Plays previous/next file. When it is pressed and held ↟Radio mode: Plays previous/next available frequency or station. ↟Media mode: Rewinds or fast forwards the file. RADIO button ↟Press to go to the radio screen. MEDIA button ↟Press to go to the available media. SETUP button ↟Press to go to the settings screen. Tune/Enter knob ↟In Radio mode, turn left/right to change the frequency or station. ↟In Media mode, turn left/right to change file and press to select the desired file. ☆ (Custom button) ↟Press to move to the [Custom button] menu. After setting a desired function, press to use the desired function. 6 Name of Each Component Steering Wheel Remote Control Steering wheel remote control functions may vary for each model. C / MODE button ↟Each time this button is pressed, the Radio or Media mode is changed. ↟If the media is not connected, it is changed in the order FM > AM > FM. ↟When it is pressed and held, move to Advanced settings "Steering wheel MODE button". W/S button When it is pressed for a short time ↟Radio mode: Plays previous/next Favourites. ↟Media mode: Plays previous/next file. When it is pressed and held ↟Radio mode: Plays previous/next available frequency or station. ↟Media mode: Rewinds or fast forwards the file. i (Voice Recognition button) ↟Press to switch to voice recognition mode. ↟To cancel it, press and hold the button again. W button Press to operate Bluetooth hands-free function. ↟Normal mode, press and hold to enter phone mode, long press to redial. ↟When a call comes in, press and hold to answer, long press to reject. ↟During a call, press and hold to hang up. ↟During the 1st call, when the 2nd call is reserved, press and hold to keep the 1st call, and the 2nd call is in progress;long press to end the 1st call and answer the 2nd call. ↟During a 1st call, when a 2nd call comes in, press and hold to keep the 1st call and answer the 2nd call, long press to hang up the 2nd call, and the 1st call remains unchanged. 7 Name of Each Component Z button ↟Increases or decreases the volume level. d (Mute) ↟Press to mute the sound. (It will be paused in some media modes.) ★ (Custom button) ↟Press to move to the [Custom button] menu. ↟After setting a desired function, press to use the desired function. ↟If the custom key is not defined, press the custom key to enter the custom button settings interface. ↟You can choose one of four functions: none, reject or end call, privacy mode, and voice memo. ↟If the custom key has been defined, pressing is the corresponding function. 8 Basic operation Basic operation System ON/OFF The image of this product may be different from the actual product. Starting the system for the first time 1. Press the Engine Start button. Once the system is turned on, the booting process will start and the safety warning page is displayed. 2. Press [Confirm]. If you want to change the system language, press [Language]. , Note ↟You cannot operate the system while it is booting up. It may take some time for all of the features to be ready. ↟The safety warning page is displayed every time the ignition is turned on. The displayed warnings are related to safety, please closely read and comply with the safety warnings. ↟If there is no operation for 10 seconds in the safety warning screen, the system automatically switches to the last played mode. Turning the screen off Press and hold Power button on the head unit. To turn the screen on again, press power button on the head unit. , Note Pay attention to the volume setting when turning the system on. A sudden output of extreme volume upon turning the system on could lead to hearing impairment. Adjust the volume to a suitable levels before turning off the system or set the startup volume in sound Settings menu. 9 Basic operation AV ON/OFF or Volume Adjustment AV OFF Press Power button on the head unit when the AV is ON. AV ON Press Power button on the head unit when the AV is OFF. Adjusting the volume Turn the Volume knob to control volume. Resetting the system This feature is used to reset the system in t…

Text truncated - open the document above for the full version.

238 Open Source Software Notice with other software or devices. 2.2. Contributor Grant. Subject to third party intellectual property claims, each Contributor hereby grants You a world-wide, royalty-free, non-exclusive license a. under intellectual property rights (other than patent or trademark) Licensable by Contributor, to use, reproduce, modify, display, perform, sublicense and distribute the Modifications created by such Contributor (or portions thereof) either on an unmodified basis, with other Modifications, as Covered Code and/or as part of a Larger Work; and b. under Patent Claims infringed by the making, using, or selling of Modifications made by that Contributor either alone and/or in combination with its Contributor Version (or portions of such combination), to make, use, sell, offer for sale, have made, and/or otherwise dispose of: 1) Modifications made by that Contributor (or portions thereof); and 2) the combination of Modifications made by that Contributor with its Contributor Version (or portions of such combination). c. the licenses granted in Sections 2.2 (a) and 2.2 (b) are effective on the date Contributor first makes Commercial Use of the Covered Code. d. Notwithstanding Section 2.2 (b) above, no patent license is granted: 1) for any code that Contributor has deleted from the Contributor Version; 2) separate from the Contributor Version; 3) for infringements caused by: i) third party modifications of Contributor Version or ii) the combination of Modifications made by that Contributor with other software (except as part of the Contributor Version) or other devices; or 4) under Patent Claims infringed by Covered Code in the absence of Modifications made by that Contributor. 3. Distribution Obligations. 3.1. Application of License. The Modifications which You create or to which You contribute are governed by the terms of this License, including without limitation Section 2.2. The Source Code version of Covered Code may be distributed only under the terms of this License or a future version of this License released under Section 6.1, and You must include a copy of this License with every copy of the Source Code You distribute. You may not offer or impose any terms on any Source Code version that alters or restricts the applicable version of this License or the recipients' rights hereunder. However, You may include an additional document offering the additional rights described in Section 3.5. 3.2. Availability of Source Code. Any Modification which You create or to which You contribute must be made available in Source Code form under the terms of this License either on the same media as an Executable version or via an accepted Electronic Distribution Mechanism to anyone to whom you made an Executable version available; and if made available via Electronic Distribution Mechanism, must remain available for at least twelve (12) months after the date it initially became available, or at least six (6) months after a subsequent version of that particular Modification has been made available to such recipients. You are responsible for ensuring that the Source Code version remains available even if the Electronic Distribution Mechanism is maintained by a third party. 239 Open Source Software Notice 3.3. Description of Modifications. You must cause all Covered Code to which You contribute to contain a file documenting the changes You made to create that Covered Code and the date of any change. You must include a prominent statement that the Modification is derived, directly or indirectly, from Original Code provided by the Initial Developer and including the name of the Initial Developer in (a) the Source Code, and (b) in any notice in an Executable version or related documentation in which You describe the origin or ownership of the Covered Code. 3.4. Intellectual Property Matters (a) Third Party Claims If Contributor has knowledge that a license under a third party's intellectual property rights is required to exercise the rights granted by such Contributor under Sections 2.1 or 2.2, Contributor must include a text file with the Source Code distribution titled "LEGAL" which describes the claim and the party making the claim in sufficient detail that a recipient will know whom to contact. If Contributor obtains such knowledge after the Modification is made available as described in Section 3.2, Contributor shall promptly modify the LEGAL file in all copies Contributor makes available thereafter and shall take other steps (such as notifying appropriate mailing lists or newsgroups) reasonably calculated to inform those who received the Covered Code that new knowledge has been obtained. (b) Contributor APIs If Contributor's Modifications include an application programming interface and Contributor has knowledge of patent licenses which are reasonably necessary to implement that API, Contributor must also include this information in the LEGAL file. (c) Representations. Contributor represents that, except as disclosed pursuant to Section 3.4 (a) above, Contributor believes that Contributor's Modifications are Contributor's original creation(s) and/or Contributor has sufficient rights to grant the rights conveyed by this License. 3.5. Required Notices. You must duplicate the notice in Exhibit A in each file of the Source Code. If it is not possible to put such notice in a particular Source Code file due to its structure, then You must include such notice in a location (such as a relevant directory) where a user would be likely to look for such a notice. If You created one or more Modification(s) You may add your name as a Contributor to the notice described in Exhibit A. You must also duplicate this License in any documentation for the Source Code where You describe recipients' rights or ownership rights relating to Covered Code. You may choose to offer, and to charge a fee for, warranty, support, indemnity or liability obligations to one or more recipients of Covered Code. However, Y…

Text truncated - open the document above for the full version.

MOTREX CO., LTD.

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 1 of 14 Appendix I: Photos of the EUT Product Name : Equipo de Audio y Video para Vehiculo Model Number : MTXMO430LAI3PE Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 2 of 14 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 3 of 14 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 4 of 14

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 4 of 15 registration mast Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 5 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 6 of 15 BT/WIFI ANT. Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 7 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 8 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 9 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 10 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 11 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 12 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 13 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 14 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-7E Page 15 of 15 END

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-4E04 Page 1 of 8 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : MOTREX CO., LTD. Address : Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Equipment under Test : Equipo de Audio y Video para Vehiculo Model No. : MTXMO430LAI3PE, MTXMO400LBDmFL, MTXMO400LSCPE, MTXMO400LSP2i, MTXMO400LSU2i, MTXMO400LSK3, MTXMO400LMQ4a, MTXMO420LBR2PE Trade Mark : HYUNDAI/KIA FCC ID : BP9-MO430LAI3PE Manufacturer : Skypine Electronics(Shenzhen) Co.,Ltd Address : 3rd Floor of Building B, Jingang Technology Park, Qiaotou Village, Fuhai Sub-District, Baoan, Shenzhen, China Report No.: DDT-R22092815-4E04 Issued Date: Nov. 29, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-4E04 Page 2 of 8 Table of Contents Test report declares.......................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 6 2. RF Exposure Evaluation ................................................................................................ 7 2.1. Requirement ................................................................................................................... 7 2.2. Calculation method ........................................................................................................ 7 2.3. Estimation result ............................................................................................................. 8 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-4E04 Page 3 of 8 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R22092815-4E04 Date of Receipt: Oct. 18, 2022 Date of Test: Oct. 18, 2022 ~ Nov. 29, 2022 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : MOTREX CO., LTD. Address : Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Equipment under Test : Equipo de Audio y Video para Vehiculo Model No. : MTXMO430LAI3PE, MTXMO400LBDmFL, MTXMO400LSCPE, MTXMO400LSP2i, MTXMO400LSU2i, MTXMO400LSK3, MTXMO400LMQ4a, MTXMO420LBR2PE Trade mark : HYUNDAI/KIA Manufacturer : Skypine Electronics(Shenzhen) Co.,Ltd Address : 3rd Floor of Building B, Jingang Technology Park, Qiaotou Village, Fuhai Sub-District, Baoan, Shenzhen, China E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-4E04 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Nov. 29, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-4E04 Page 5 of 8 1. General Information 1.1. Description of equipment EUT* Name : Equipo de Audio y Video para Vehiculo Model Number : MTXMO430LAI3PE, MTXMO400LBDmFL, MTXMO400LSCPE, MTXMO400LSP2i, MTXMO400LSU2i, MTXMO400LSK3, MTXMO400LMQ4a, MTXMO420LBR2PE Difference of models : Their head unit electrical circuit design, layout, components used and internal wiring are identical, the shape and the material are also identical. Only the frontpanel and the packaging material size are different, but the frontpanel circuit design and principle are the same. Therefore the test performed on the model MTXMO430LAI3PE and record in this report. EUT Function Description : Please reference user manual of this device Power Supply : DC 12V Radio Specification : Bluetooth V5.0, IEEE 802.11b/g/n, IEEE 802.11a/n/ac Operation Frequency : BT: 2402 MHz - 2480 MHz IEEE 802.11b: 2412MHz—2462MHz IEEE 802.11g: 2412MHz—2462MHz IEEE 802.11n HT20: 2412MHz—2462MHz IEEE 802.11n HT40: 2422MHz—2452MHz IEEE 802.11a: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11ac HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT80: 5210 MHz, 5775 MHz Modulation : BT: GFSK, /4-DQPSK, 8DPSK IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Data Rate : BT: 1 Mbps, 2 Mbps, 3 Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: up to 72.2 Mbps IEEE 802.11n HT40: up to 150 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: 7.2, 21.7, 43.3, 72.2 Mbps IEEE 802.11n HT40: 15, 45, 90, 150 Mbps IEEE 802.11ac HT20: up to 86.6 Mbps IEEE 802.11ac HT40: up to 200 Mbps IEEE 802.11ac HT…

Text truncated - open the document above for the full version.

1 / 11 Date: November 19, 2022 WiFi antenna test report Gaoke Ant Co.,Ltd. No. 22, Shengang Guangcong South Road, Taiping Town, Conghua District, Guangzhou 2 / 11 Sales Person: Wei Qiaoling 18927480411 [email protected] Technical Director: Yang Jingsong 15915759775 [email protected] 一、 Projec t Int roduction Client Name: Tianpai Electronics (Shenzhen) Co., LTD Machine type: vehicle navigation instrument Project name: XXX Antenna name: WIFI antenna Antenna material: PCB Antenna frequency: 2.4-2.4835GHz&5.170-5.850GHz Antenna area: Inside the machine Antenna status: Sample Antenna size: 35mm*8mm Lead length: 29CM. Antenna tpye: PCB antenna Antenna model: GKZS-2.4&5.8G-AC358-RF1.13I-290 3 / 11 Seco nd, t he t est e nvi ro nme nt Test equipment: network analyzer, microwave anechoic room Tester: Yuming Huang 4 / 11 二、 Physical image of antenna pdf.youdao.com 有道文档翻译 5 / 11 Ant enna size diagram 6 / 11 Four, placing position The picture of the antenna position of the prototype 7 / 11 V. Test data 5.1 Customer antenna test data 5.1.1 Return loss and standing wave ratio of customer's original band antenna 5.1.3 Customer original darkroom with antenna passive test data 8 / 11 Frequency ID Frequency (MHz) Efficiency (dBi) Gain (dBi) Efficiency (%) 12380.0-14.39-9.213.64 22390.0-15.30-9.412.95 32400.0-13.93-7.574.05 42410.0-15.77-9.152.65 52420.0-16.65-9.512.16 62430.0-15.50-8.192.82 72440.0-15.15-7.703.06 82450.0-17.17-9.781.92 92460.0-16.57-9.292.20 102470.0-16.33-9.222.33 112480.0-18.12-11.071.54 122490.0-17.61-10.431.73 132500.0-16.77-9.532.10 142510.0-18.75-11.441.33 152520.0-19.58-12.341.10 165150.0-6.92-0.5720.34 175170.0-6.66-0.0821.60 185190.0-6.460.1422.58 195210.0-6.40-0.0422.91 205230.0-6.480.2122.48 215250.0-6.020.4424.98 225270.0-6.150.6524.28 235290.0-5.820.9526.16 245310.0-5.441.1928.59 255330.0-6.280.2123.57 265350.0-6.78-0.5221.00 275370.0-6.47-0.2822.55 285390.0-7.21-1.5619.00 295410.0-7.21-1.2518.99 305430.0-7.21-0.3919.03 315450.0-8.34-0.8414.67 325470.0-8.63-0.6013.71 335490.0-8.65-0.4413.63 345510.0-9.63-1.1110.88 355530.0-9.65-1.3210.83 365550.0-9.66-1.5710.82 375570.0-9.70-1.9810.70 385590.0-9.45-2.1011.36 395610.0-9.61-2.4710.93 405630.0-9.47-2.2811.31 415650.0-9.29-2.1411.79 425670.0-8.86-2.0012.99 435690.0-8.85-2.2813.02 445710.0-9.49-2.6911.26 455730.0-8.79-1.7113.20 465750.0-8.41-0.9114.41 475770.0-9.52-1.9511.17 485790.0-8.86-1.0513.00 495810.0-8.75-1.4113.35 505830.0-9.29-1.8411.79 515850.0-8.55-1.4113.97 9 / 11 5.2 High-Tech antenna test data 5.2.1 Return loss and standing wave ratio of high-tech antenna 5.2.2 HKO antenna darkroom passive test data 10 / 11 Frequency I D Frequency (MHz) Efficiency (dBi) Gain (dBi) Efficiency (% ) 12380.0-3.843.4941.34 22390.0-3.883.5440.89 32400.0-3.863.7641.15 42410.0-3.853.8441.25 52420.0-3.684.0442.88 62430.0-3.614.3043.51 72440.0-3.644.5243.29 82450.0-3.854.4141.18 92460.0-3.934.2740.50 102470.0-4.074.0639.21 112480.0-4.113.7438.80 122490.0-4.093.6538.96 132500.0-4.263.4637.53 142510.0-4.383.2736.51 152520.0-4.483.1235.64 165150.0-3.193.3148.02 175170.0-3.232.9947.53 185190.0-3.392.7445.86 195210.0-3.373.0545.99 205230.0-3.102.9348.94 215250.0-2.933.6350.90 225270.0-2.994.1150.20 235290.0-2.894.1751.41 245310.0-2.844.0952.02 255330.0-2.963.6050.52 265350.0-3.223.2447.68 275370.0-3.652.9743.16 285390.0-3.533.2144.33 295410.0-3.573.3943.95 305430.0-3.673.6342.93 315450.0-3.933.2740.44 325470.0-3.963.7440.17 335490.0-3.844.2141.32 345510.0-3.754.4642.16 355530.0-3.754.3542.19 365550.0-3.554.3944.12 375570.0-3.234.5647.51 385590.0-3.124.8348.78 395610.0-3.234.5047.50 405630.0-3.154.3648.47 415650.0-2.924.3951.03 425670.0-2.904.6851.27 435690.0-2.984.5450.37 445710.0-3.004.2050.09 455730.0-2.864.3051.72 465750.0-2.883.9551.48 475770.0-2.943.8850.77 485790.0-2.923.6751.03 495810.0-2.903.6351.28 505830.0-2.873.7951.65 515850.0-3.163.5048.30 11 / 11 Vi. Test Conclusion: Compared with the customer's original WIFI antenna, the gain and efficiency of the WIFI antenna designed by Gaoke have been significantly improved, which can fully meet the customer's normal use. 2380.0MHz H+V, Eff: 41.3%Back View3.49 1.65 -0.19 -2.03 -3.88 -5.72 -7.56 -9.4 -11.24 -13.09 -14.93 -16.77 -18.61 -20.46 -22.3 -24.14 -25.98 -27.82 2440.0MHz H+V, Eff: 43.3%Back View4.52 2.68 0.84 -1.01 -2.85 -4.69 -6.53 -8.37 -10.22 -12.06 -13.9 -15.74 -17.59 -19.43 -21.27 -23.11 -24.95 -26.8 2520.0MHz H+V, Eff: 35.6%Back View 3.12 1.28 -0.56 -2.4 -4.24 -6.09 -7.93 -9.77 -11.61 -13.45 -15.3 -17.14…

Text truncated - open the document above for the full version.
