MOTREX CO., LTD.

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 1 of 15 Appendix I: Photos of the EUT Product Name : Equipo de Audio y Video para Vehiculo Model Number : MTXMO440LBL7m Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 2 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 3 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 4 of 15

贴纸尺寸：8 0*75mm 曾田 AMP INT “Hecho en China” Nombre del producto: Equipo de Audio y Video para Vehiculo Modelo: MTXMO440LBL7m Región: MX Importado por MOTREX. Tel . 55 44 45 44 40/41 ext. 130/148 • VOLTAJE DE ALIMENTACIÓN: 12 Vcc • CONSUMO DE CORRIENTE EN AMPERE • FRECUENCIA DE OPERACIÓ AV 机身贴纸 CES-6382-M 技术说明： 1、大小80,红色外框线为刀模线。 2、材质，80g铜版纸,过哑胶，背不干胶。 3、内容黑色印刷。 4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕； 切边务必整齐,不得歪斜。 x75mm Marca Comercial: HYUNDAI / KIA M 87. 0 7.9 MHz FCC IDBP9-MO440LBL7M label location

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 5 of 15 BT/ WIFI ANT. Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 6 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 7 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 8 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 9 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 10 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 11 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 12 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 13 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 14 of 15 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22092815-8E Page 15 of 15 END

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 1 of 8 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : MOTREX CO., LTD. Address : Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Equipment under Test : Equipo de Audio y Video para Vehiculo Model No. : MTXMO440LBL7m, MTXMO410LNQ5a Trade Mark : HYUNDAI/KIA FCC ID : BP9-MO440LBL7M Manufacturer : Skypine Electronics(Shenzhen) Co.,Ltd Address : 3rd Floor of Building B, Jingang Technology Park, Qiaotou Village, Fuhai Sub-District, Baoan, Shenzhen, China Report No.: DDT-R22092815-2E04 Issued Date: Nov. 25, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 2 of 8 Table of Contents Test report declares.......................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 6 2. RF Exposure Evaluation ................................................................................................ 7 2.1. Requirement ................................................................................................................... 7 2.2. Calculation method ........................................................................................................ 7 2.3. Estimation result ............................................................................................................. 8 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 3 of 8 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R22092815-2E04 Date of Receipt: Oct. 28, 2022 Date of Test: Oct. 28, 2022 ~ Nov. 25, 2022 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : MOTREX CO., LTD. Address : Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Equipment under Test : Equipo de Audio y Video para Vehiculo Model No. : MTXMO440LBL7m, MTXMO410LNQ5a Trade mark : HYUNDAI/KIA Manufacturer : Skypine Electronics(Shenzhen) Co.,Ltd Address : 3rd Floor of Building B, Jingang Technology Park, Qiaotou Village, Fuhai Sub-District, Baoan, Shenzhen, China E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Nov. 25, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 5 of 8 1. General Information 1.1. Description of equipment EUT* Name : Equipo de Audio y Video para Vehiculo Model Number : MTXMO440LBL7m, MTXMO410LNQ5a Difference of models : Their head unit electrical circuit design, layout, components used and internal wiring are identical, the shape and the material are also identical. Only the frontpanel and the packaging material size are different, but the frontpanel circuit design and principle are the same. Therefore the test performed on the model MTXMO440LBL7m and record in this report. EUT Function Description : Please reference user manual of this device Power Supply : DC 12V Radio Specification : Bluetooth V5.0, IEEE 802.11b/g/n, IEEE 802.11a/n/ac Operation Frequency : BT: 2402 MHz - 2480 MHz IEEE 802.11b: 2412MHz—2462MHz IEEE 802.11g: 2412MHz—2462MHz IEEE 802.11n HT20: 2412MHz—2462MHz IEEE 802.11n HT40: 2422MHz—2452MHz IEEE 802.11a: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11ac HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT80: 5210 MHz, 5775 MHz Modulation : BT: GFSK, /4-DQPSK, 8DPSK IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Data Rate : BT: 1 Mbps, 2 Mbps, 3 Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: up to 72.2 Mbps IEEE 802.11n HT40: up to 150 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: 7.2, 21.7, 43.3, 72.2 Mbps IEEE 802.11n HT40: 15, 45, 90, 150 Mbps IEEE 802.11ac HT20: up to 86.6 Mbps IEEE 802.11ac HT40: up to 200 Mbps IEEE 802.11ac HT80: up to 433.3 Mbps Antenna Gain : BT: 3.53 dBi 2.4G WIFI: 3.53 dBi 5G WIFI: 3.62 dBi Sample Type : Series production Sample Number : S22092815-05 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22092815-2E04 Page 6 of 8 1.2. Assess laboratory Dongguan Dongdian Tes…

Text truncated - open the document above for the full version.

广州市高科中实通信技术有限公司 Gaoke Ant Co.,Ltd. No. 22, Shengang Guangcong South Road, Taiping Town, Conghua District, Guangzhou 文件编号：GK-FM-J-2022051301/1.0 第 1 页 共 5 页 Product performance test report Name of antenna 2.4&5.8G built-in antenna Model number of prototype CES-6374-M Type of antenna GKZS - 2.4 & 5.8 G - AC358 - RF1.13 I - 140 Number of antennas 1pcs Date of inspection May 13, 2022 Environment al Conditions Ambient temperature: 22 ~ 30°C Relative humidity: 50% ~ 68% Test Items Standing wave ratio, return loss, microwave darkroom detection (direction chart, gain, efficiency) Main instruments and equipment for inspection The serial number The name of themodelSerial number 1 Network analyzer E5071CGKZS-LY-JS032 2 Comprehensive test instrument 8960GKZS-LY-JS007 3 Spectrum analyzer 8595EGKZS-LY-JS004 4 Microwave anechoic chamber / GKZS-LY-JS008 5 Regulated power supply PS-303DMGKZS-LY-JS011 6 The computer HPGKZS-LY-JS018 Survey Overview Test the antenna according to the customer's new prototype, verify the antenna performance; Test performance, test results see page 2-4. Surveyor Liu Guangjin audit Xie Qianju approv al Yang Jingsong The date of 2022.05.13 The date of 2022.05.13 The date of 2022.05.13 广州市高科中实通信技术有限公司 Gaoke Ant Co.,Ltd. 文件编号：GK-FM-J-2022051301/1.0 第 2 页 共 5 页 I. Performance test data 1、Standing wave ratio 2、Loss of return pdf.youdao.com 有道文档翻译 广州市高科中实通信技术有限公司 Gaoke Ant Co.,Ltd. 第 3 页 共 5 页 3、Diagram of direction 广州市高科中实通信技术有限公司 Gaoke Ant Co.,Ltd. 第 4 页 共 5 页 4. Efficiency curve 5. Gain curve Ii. Test results 1. Standing Poppy 2. Gain and efficiency 2400-2500MHz Frequency (MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 On avera ge, peak Gain (dBi) 3.163.52 3.53 3.32 3.07 2.79 2.64 2.71 2.63 2.65 2.59 2.99 3.53 Efficiency (%) 62.39 64.05 65.72 64.31 64.00 61.85 60.25 60.72 59.98 59.37 57.75 61.85 65.72 5150-5850MHz Frequency (MHz) 5150 5200 5250 5300 5350 5400 5450 5500 5550 Gain (dBi) 0.311.06 2.02 2.47 2.70 2.77 2.90 3.00 3.27 Efficiency (%) 24.10 24.11 27.85 29.16 30.52 33.28 34.85 37.27 41.73 Frequency (MHz) 5600 5650 5700 5750 5800 5850 On average , peak Gain (dBi) 2.32 2.77 3.62 2.46 2.17 1.422.46 3.62 Test frequency band 2400-2500 MHZ, 5150-5850 MHZ 2400MHz 2500MHz 5150MHz 5500MHz 5850MHz Standing wave ratio 1.5306 2.1289 2.1069 1.9354 2.0078 Loss of return 13.108 9.2442 9.1536 13.208 8.2476 广州市高科中实通信技术有限公司 Gaoke Ant Co.,Ltd. 第 5 页 共 5 页 Efficiency (%) 35.32 38.68 42.47 33.95 28.80 31.24 32.88 42.47 *** End of report ***

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 110 of 129 TR-4-E-009 Radiated Emission Test Result Test Date: 2022-11-15 Tested By: Johnson Huang EUT: Equipo de Audio y Video para Vehiculo Model Number: MTXMO440LBL7m Test Mode: TX Mode Power Supply: DC12V Condition: Temp:23.4°C;Humi:54.2%;Press:100.3kPa Test Site: DDT 3# Chamber File Path: d:\ts\2022 report data\Q22092815-2E MTXMO440LBL7m\FCC ABOVE 1G 5G WIFI\42 Memo: 11AC20 5180 Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5139.74 48.75 -4.01 44.74 68.20 23.46 PK Vertical 2 5150.00 44.61 -4.01 40.60 68.20 27.60 PK Vertical Note: 1. Level = Reading + Factor. 2. If Peak Result complies with AV limit, AV Result is deemed to comply with AV limit. 3. Test setup: RBW: 1 MHz, VBW: 3 MHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 111 of 129 TR-4-E-009 Radiated Emission Test Result Test Date: 2022-11-15 Tested By: Johnson Huang EUT: Equipo de Audio y Video para Vehiculo Model Number: MTXMO440LBL7m Test Mode: TX Mode Power Supply: DC12V Condition: Temp:23.4°C;Humi:54.2%;Press:100.3kPa Test Site: DDT 3# Chamber File Path: d:\ts\2022 report data\Q22092815-2E MTXMO440LBL7m\FCC ABOVE 1G 5G WIFI\51 Memo: 11AC40 5190 Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5148.55 52.58 5.99 58.57 68.20 9.63 PK Horizontal 2 5150.00 44.60 5.99 50.59 68.20 17.61 PK Horizontal Final Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5148.56 38.89 5.99 44.88 54.00 9.12 AV Horizontal 2 5150.00 40.02 5.99 46.01 54.00 7.99 AV Horizontal Note: 1. Level = Reading + Factor. 2. If Peak Result complies with AV limit, AV Result is deemed to comply with AV limit. 3. Test setup: RBW: 1 MHz, VBW: 3 MHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 112 of 129 TR-4-E-009 Radiated Emission Test Result Test Date: 2022-11-15 Tested By: Johnson Huang EUT: Equipo de Audio y Video para Vehiculo Model Number: MTXMO440LBL7m Test Mode: TX Mode Power Supply: DC12V Condition: Temp:23.4°C;Humi:54.2%;Press:100.3kPa Test Site: DDT 3# Chamber File Path: d:\ts\2022 report data\Q22092815-2E MTXMO440LBL7m\FCC ABOVE 1G 5G WIFI\52 Memo: 11AC40 5190 Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5144.04 47.96 5.99 53.95 68.20 14.25 PK Vertical 2 5150.00 45.26 5.99 51.25 68.20 16.95 PK Vertical Final Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5144.04 38.26 5.99 44.25 54.00 9.75 AV Vertical 2 5150.00 37.19 5.99 43.18 54.00 10.82 AV Vertical Note: 1. Level = Reading + Factor. 2. If Peak Result complies with AV limit, AV Result is deemed to comply with AV limit. 3. Test setup: RBW: 1 MHz, VBW: 3 MHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 113 of 129 TR-4-E-009 Radiated Emission Test Result Test Date: 2022-11-15 Tested By: Johnson Huang EUT: Equipo de Audio y Video para Vehiculo Model Number: MTXMO440LBL7m Test Mode: TX Mode Power Supply: DC12V Condition: Temp:23.4°C;Humi:54.2%;Press:100.3kPa Test Site: DDT 3# Chamber File Path: d:\ts\2022 report data\Q22092815-2E MTXMO440LBL7m\FCC ABOVE 1G 5G WIFI\59 Memo: 11AC80 5210 Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5121.49 52.58 5.98 58.56 68.20 9.64 PK Horizontal 2 5150.00 48.19 5.99 54.18 68.20 14.02 PK Horizontal 3 5350.00 44.16 6.15 50.31 68.20 17.89 PK Horizontal 4 5411.51 47.44 6.20 53.64 68.20 14.56 PK Horizontal Final Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5121.49 38.59 5.98 44.57 54.00 9.43 AV Horizontal 2 5149.96 39.13 5.99 45.12 54.00 8.88 AV Horizontal 3 5350.00 38.26 6.15 44.41 54.00 9.59 AV Horizontal 4 5411.51 39.46 6.20 45.66 54.00 8.34 AV Horizontal Note: 1. Level = Reading + Factor. 2. If Peak Result complies with AV limit, AV Result is deemed to comply with AV limit. 3. Test setup: RBW: 1 MHz, VBW: 3 MHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 114 of 129 TR-4-E-009 Radiated Emission Test Result Test Date: 2022-11-15 Tested By: Johnson Huang EUT: Equipo de Audio y Video para Vehiculo Model Number: MTXMO440LBL7m Test Mode: TX Mode Power Supply: DC12V Condition: Temp:23.4°C;Humi:54.2%;Press:100.3kPa Test Site: DDT 3# Chamber File Path: d:\ts\2022 report data\Q22092815-2E MTXMO440LBL7m\FCC ABOVE 1G 5G WIFI\60 Memo: 11AC80 5210 Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5147.16 50.86 5.99 56.85 68.20 11.35 PK Vertical 2 5150.00 45.74 5.99 51.73 68.20 16.47 PK Vertical 3 5350.00 45.02 6.15 51.17 68.20 17.03 PK Vertical 4 5381.34 47.32 6.18 53.50 68.20 14.70 PK Vertical Final Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 5147.16 38.24 5.99 44.23 54.00 9.77 AV Vertical 2 5150.00 39.26 5.99 45.25 54.00 8.75 AV Vertical 3 5350.00 37.98 6.15 44.13 54.00 9.87 AV Vertical 4 5381.34 38.42 6.18 44.60 54.00 9.40 AV Vertical Note: 1. Level = Reading + Factor. 2. If Peak Result complies with AV limit, AV Result is deemed to comply with AV limit. 3. Test setup: RBW: 1 MHz, VBW: 3 MHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 115 of 129 11A_Ant1_Low_5745 11A_Ant1_High_5825 11N20SISO_Ant1_Low_5745 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 116 of 129 11N20SISO_Ant1_High_5825 11N40SISO_Ant1_Lo…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 62 of 129 11AC20SISO_Ant1_5825 11AC40SISO_Ant1_5190 11AC40SISO_Ant1_5230 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 63 of 129 11AC40SISO_Ant1_5755 11AC40SISO_Ant1_5795 11AC80SISO_Ant1_5210 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 64 of 129 11AC80SISO_Ant1_5775 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 65 of 129 8. Frequency Stability Measurement 8.1. Limit of Frequency Stability Manufacturers of U-NII devices are responsible for ensuring frequency stability such that an emission is maintained within the band of operation under all conditions of normal operation as specified in the user’s manual. 8.2. Measuring Instruments The measuring equipment is listed in the section 4 of this test report. 8.3. Test Procedures (1) To ensure emission at the band edge is maintained within the authorized band, those values shall be measured by radiation emissions at upper and lower frequency points, and finally compensated by frequency deviation as procedures below. (2) The EUT was operated at the maximum output power, and connected to the spectrum analyzer, which is set to maximum hold function and peak detector. The peak value of the power envelope was measured and noted. The upper and lower frequency points were respectively measured relatively 10 dB lower than the measured peak value. (3) The frequency deviation was calculated by adding the upper frequency point and the lower frequency point divided by two. Those detailed values of frequency deviation are provided in table below. 8.4. Test Setup 8.5. Test Result Voltage Test Mode Antenn a Channe l Voltage [Vdc] Temper ature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdic t 11A Ant1 5180 NV NT 0.00 0.000000 20 PASS LV NT 20000.00 3.861004 20 PASS HV NT 0.00 0.000000 20 PASS 5200 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5240 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5745 NV NT 0.00 0.000000 20 PASS LV NT 20000.00 3.481288 20 PASS HV NT 0.00 0.000000 20 PASS 5785 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 66 of 129 HV NT 0.00 0.000000 20 PASS 5825 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 11N20SI SO Ant1 5180 NV NT 0.00 0.000000 20 PASS LV NT 20000.00 3.861004 20 PASS HV NT 0.00 0.000000 20 PASS 5200 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT -20000.00 -3.846154 20 PASS 5240 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 20000.00 3.816794 20 PASS 5745 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5785 NV NT -20000.00 -3.457217 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5825 NV NT 0.00 0.000000 20 PASS LV NT 20000.00 3.433476 20 PASS HV NT 0.00 0.000000 20 PASS 11N40SI SO Ant1 5190 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5230 NV NT -40000.00 -7.648184 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5755 NV NT -40000.00 -6.950478 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5795 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 11AC80 SISO Ant1 5210 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS 5775 NV NT 0.00 0.000000 20 PASS LV NT 0.00 0.000000 20 PASS HV NT 0.00 0.000000 20 PASS Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 67 of 129 Temperature Test Mode Antenn a Channe l Voltage [Vdc] Temper ature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdic t 11A Ant1 5180 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 20000.00 3.861004 20 PASS NV 50 20000.00 3.861004 20 PASS 5200 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5240 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5745 NV -30 0.00 0.000000 20 PASS NV -20 20000.00 3.481288 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5785 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5825 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 68 of 129 NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 11N20SI SO Ant1 5180 NV -30 0.00 0.000000 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 0.00 0.000000 20 PASS NV 0 0.00 0.000000 20 PASS NV 10 0.00 0.000000 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 0.00 0.000000 20 PASS NV 40 0.00 0.000000 20 PASS NV 50 0.00 0.000000 20 PASS 5200 NV -30 -20000.00 -3.846154 20 PASS NV -20 0.00 0.000000 20 PASS NV -10 -20000.00 -3.846154 20 PASS NV 0 -20000.00 -3.846154 20 PASS NV 10 -20000.00 -3.846154 20 PASS NV 20 0.00 0.000000 20 PASS NV 30 20000.00…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 33 of 129 11AC80SISO_Ant1_5775 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 34 of 129 6db EBW: 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 35 of 129 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 36 of 129 11N40SISO_Ant1_5755 11N40SISO_Ant1_5795 11AC20SISO_Ant1_5745 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 37 of 129 11AC20SISO_Ant1_5785 11AC20SISO_Ant1_5825 11AC40SISO_Ant1_5755 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 38 of 129 11AC40SISO_Ant1_5795 11AC80SISO_Ant1_5775 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22092815-2E03 Page 39 of 129 5. Duty Cycle 5.1. Block diagram of test setup 5.2. Limit Just for Report. 5.3. Test procedure (1) Connected the EUT’s antenna port to the Spectrum Analyzer by suitable attenuator, The cable loss and attenuator loss have been put into spectrum analyzer as amplitude offset. set the Spectrum Analyzer as below: Centre Frequency: The centre frequency of the middle hopping channel. Resolution BW: 10 MHz. Video BW: 10 MHz. Span: Zero span. Detector: Peak. Trace Mode: Max Hold. Sweep: Video Trigger (2) When the trace is complete, measure the sending time of 1 burst and the duty cycle of 1 burst cycle. (3) Calculate dwell time follow below formula: Duty cycle= Pulse’s on ti…
