Functions and services in this manual may differ from those in the actual vehicle. Car Multimedia System USER'S MANUAL Thank you for purchasing this HYUNDAI Motors Car Multimedia System. This user’s manual explains how to use the HYUNDAI Motors Car Multimedia System. Before using the product, read the contents of this user’s manual carefully and use this product safely. 䠐The screens shown in this manual may differ with the actual screens of the product. 䠐The design and specification of this product may change without prior notification for product improvement. 䠐When transferring the vehicle to another individual, include this user’s manual so that the next driver can continue its use. 3 Table of Contents Table of Contents 3 Start Name of Each Component 5 Basic operation 8 HOME screen 12 Favorites 16 Navigation (If Equipped) Getting started with navigation 20 Searching for destination 26 Using the route menu 33 Setting for navigation 35 Media Playing USB 44 Bluetooth audio 50 Voice memo 52 Radio Listening to AM 57 Listening to FM 60 Phone Bluetooth 65 Making a call 72 Call history 76 Contacts 78 Favourites 81 Messages 84 Setup Settings 87 Phone connection Settings 88 Advanced Settings 92 General settings 95 Sound Settings 99 Display Settings 105 Others Phone Projection 110 Using Rear Camera (If Equipped) 113 Driving Info 116 Reference Precautions for Safety 118 General Information 121 Before thinking there is a product defect 123 Troubleshooting 124 Trademarks and Licenses 126 Specification 127 Open Source Software Notice 128 Table of Contents 시작하기Start 5 Name of Each Component Name of Each Component Head unit Head unit functions may vary for each model. POWER PUSH or PWR / Volume knob 䠐Press to turn the power on. 䠐When power is on, press and hold to turn power off. 䠐When power is on, press to turn Audio off. 䠐Turn left/right to control volume. HOME button (AV only) 䠐Press to go to the home screen. PHONE button (AV only) 䠐Press to go to the phone screen. MAP button (AVN only) 䠐Press to display the map screen of the current location. NAV button (AVN only) 䠐Press to move to the Navigation menu screen. b (Reset hole) 䠐Press with a thin object to reset the unit when it does not operate normally. K (Custom button) 䠐Press to move to the [Custom button] menu. After setting a desired function, press to use the desired function. A SEEK/TRACK D (W/S) button When it is pressed for a short time. 䠐Radio mode: Plays previous/next available frequency or station. 䠐Media mode: Plays previous/next file. When it is pressed and held 䠐Radio mode: Plays previous/next available frequency or station. 䠐Media mode : Rewinds or fast forwards the file. 5 6 Name of Each Component RADIO button 䠐Press to go to the radio screen. MEDIA button 䠐Press to go to the available media. SETUP button 䠐Press to go to the settings screen. Tune/Enter knob 䠐In Radio mode, turn left/right to change the frequency or station. 䠐In Media mode, turn left/right to change file and press to select the desired file. Steering Wheel Remote Control Steering wheel remote control functions may vary for each model. C / MODE button 䠐Each time this button is pressed, the Radio or Media mode is changed. 䠐If the media is not connected, it is changed in the order FM > AM > FM. 䠐When it is pressed and held, move to Advanced settings "Steering wheel MODE button". W/S button When it is pressed for a short time 䠐Radio mode: Plays previous/next Favourites. 䠐Media mode: Plays previous/next file. When it is pressed and held 䠐AM mode: Plays previous/next available frequency or station 䠐Media mode: Rewinds or fast forwards the file. i (Voice Recognition button) 䠐Press to switch to voice recognition mode. 䠐To cancel it, press and hold the button again. W button Press to operate Bluetooth hands-free function. 䠐Press to accept a call. 䠐Press to make a call from last calls. 䠐Press and hold for redialing. 7 Name of Each Component Z button 䠐Press to end the phone call during a call. 䠐Press to reject the call in the incoming call screen. 䠐Press to end Voice memo recording. J / I button 䠐Increases or decreases the volume level. d (Mute) 䠐Press to mute the sound. (It will be paused in some media modes.) 8 Basic operation Basic operation System ON/OFF The image of this product may be different from the actual product. Starting the system for the first time 1. Press the Engine Start button. Once the system is turned on, the booting process will start and the safety warning page is displayed. 2. Press [Confirm]. If you want to change the system language, press [Language]. , Note 䠐You cannot operate the system while it is booting up. It may take some time for all of the features to be ready. 䠐The safety warning page is displayed every time the ignition is turned on. The displayed warnings are related to safety, please closely read and comply with the safety warnings. 䠐If there is no operation for 10 seconds in the safety warning screen, the system automatically switches to the last played mode. Turning the system off Press and hold Power button on the head unit. To turn the system on again, press power button on the head unit. , Note Pay attention to the volume setting when turning the system on. A sudden output of extreme volume upon turning the system on could lead to hearing impairment. Adjust the volume to a suitable levels before turning off the system or set the startup volume in sound Settings menu. 9 Basic operation AV ON/OFF or Volume Adjustment AV OFF Press Power button on the head unit when the AV is ON. AV ON Press Power button on the head unit when the AV is OFF. Adjusting the volume Turn the Volume knob to control volume. , Note When you turn the system off, the current volume level is automatically memorised. Whenever you turn the system on, it operates at the memorised volume level if you do not set the startup volume in sound Sound settings menu. Resetting the system This feature is used to reset the system in the occurrence of an unforeseen error or problem.…

Text truncated - open the document above for the full version.
