BP9-MS310ANQ5SMART DISPLAY

Trademarks and Licenses 171 Trademarks and Licenses Bluetooth ® Wireless Technology The Bluetooth Wireless Technology word mark and logos are registered trademarks owned by Bluetooth Wireless Technology SIG, Inc. HD Radio™ Technology Program Info Program Info provides song name, artist, station ID, and other relevant data to the receiver. Digital Sound HD Radio broadcasts deliver crystal clear digital audio quality to consumers. HD2/HD3 Adjacent to traditional main stations are HD2/HD3 Channels, providing new original formats on the FM dial. Artist Experience: Visual images, such as album art and station logos, of over-the-air broadcasts from HD Radio stations. Specification 172 Specification AV product specification Common Operating Temper -20 °C ~ +65 °C Storage Temperature -30 °C ~ +75 °C Bluetooth Supported Profile HFP 1.6, A2DP 1.2, AVRCP 1.5, PBAP 1.1 Supported Bluetooth Specification 3.0 Frequency Range 2402 MHz ~ 2480 MHz Number of Channels 79 Radio AM Tuning Range ME : 522 kHz~1620 kHz SA : 522 kHz~1620 kHz ESA : 531 kHz~1602 kHz MX : 530 kHz~1710 kHz Sensitivity 35 dBuV Signal-to-noise ratio Minimum 45 dB FM Tuning Range ME : 87.5 MHz~108.0 MHz SA : 87.5 MHz~108.0 MHz ESA : 87.5 MHz~108.0 MHz MX : 87.5 MHz~107.9 MHz Sensitivity 12 dBuV Frequency response 30 Hz ~ 10000 Hz Signal-to-noise ratio Minimum 45 dB ↟ Designs and specifications are subject to change without prior notice. WiFi Frequency Range(FCC) : 2412-2462MHz 5180-5240MHz 574 5-5825MHz Frequency Range( CE ) : 2412-2472MHz 5180-5240MHz 5745-5825MHz Specification : IEEE802.11 a/b/g/n/ac Supported Bandwidth : 20MHz, 40MHz, 80MHz Open Source Software Notice 173 Open Source Software Notice This product contains the open source software detailed below. Please refer to the indicated open source licenses (as are included following this notice) for the terms and conditions of their use. Open SourceLicenseCopyright acl 2.2.52 GPL-2.0 LGPL-2.1 Copyright (C) 1999, 2000 Andreas Gruenbacher, <a.gruenbacher@ bestbits.at> alsa-lib 1.1.2LGPL-2.1 alsa-plugins 1.1.0 GPL-2.0 LGPL-2.1 Copyright (C) 2006 Nokia Corporation Copyright (c) 2006 by Takashi Iwai <[email protected]> Copyright (c) 2009 by Peter Stokes <[email protected]> alsa-tools 1.1.3GPL-2.0 Copyright (C) 2003, Thomas Charbonnel Copyright (c) 2003-2004, Peter Zubaj Copyright (c) 2003, Karsten Wiese Copyright (c) 2004-2007, Rui Nuno Capela alsa-utils 1.0.29GPL-2.0 android-external- f2fs-tools 8.0 LGPL-2.1 ATK 2.22.0LGPL-2.1 attr 2.4.47GPL-2.0 AudioManager 6.1MPL-2.0 Copyright (C) 2012, GENIVI Alliance, Inc. Copyright (C) 2012, BMW AG base-files 3.0.14GPL-2.0 base-passwd 3.5.29GPL-2.0 bash 3.2.48GPL-2.0Copyright (c) 2007, 2009, 2011, 2014 Free Software Foundation, Inc. bash-completion 2.4GPL-2.0 Copyright (c) David Paleino (Debian) Copyright (c) Freddy Vulto Copyright (c) Guillame Rousse (Mandriva) Copyright (c) Igor Murzov Copyright (c) Mike Kelly (Exherbo) Copyright (c) Santiago M. Mola (Exherbo) Copyright (c) Ville Skyttä (Fedora/Red Hat) beecrypt 4.2.1LGPL-2.1 Copyright (c) 2004 X-Way Rights BV Copyright (c) 2004 Beeyond Software Holding BV Copyright (c) 2009 Bob Deblier Open Source Software Notice 174 bluez 5.43 GPL-2.0 LGPL-2.1 Copyright (c) 2000-2001, Qualcomm Incorporated Copyright (c) 2002-2003, Maxim Krasnyansky <maxk@qualcomm. com> Copyright (c) 2002-2010, Marcel Holtmann <[email protected]> BusyBox 1.23.2GPL-2.0 ca-certificates 20161130 GPL-2.0 MPL-2.0 Copyright (c) 2003 Fumitoshi UKAI <[email protected]> Copyright (c) 2009 Philipp Kern <[email protected]> Copyright (c) 2011 Michael Shuler <[email protected]> Copyright (c) Various Debian Contributors Copyright (c) 1994-2000, Netscape Communications Corporation cairo 1.15.6MPL-1.1 Copyright (c) 2006 Keith Packard Copyright (c) 2007 Adrian Johnson Check 0.10.0LGPL-2.1Copyright (C) 2001, 2002 Arien Malec Cinematic Experience 1.0 CC-BY- SA-3.0 - cmph 2.0MPL-1.1 Common API C++ dbus runtime 3.1.12 MPL-2.0 Copyright (c) 2013-2015, Bayerische Motoren Werke Aktiengesellschaft (BMW AG) CommonAPI runtime 3.1.12 MPL-2.0 Copyright (c) 2013-2015 Bayerische Motoren Werke Aktiengesellschaft (BMW AG) connman 1.29GPL-2.0Copyright (c) 2007-2012 Intel Corporation. coreutils 6.9GPL-2.0 cracklib 2.9.5LGPL-2.1 Copyright (c) 1993 Alec Muffett <[email protected]> Original CrackLib author for releases up to v2.7 Copyright (c) Nathan Neulinger <[email protected]> version 3.0 modifications and new release dlt-daemon 2.16.0MPL-2.0Copyright (C) 2011-2015, BMW AG dosfstools 2.11GPL-2.0(c) 2004-2015 Canonical Ltd e2fsprogs 1.43.4 GPL-2.0 LGPL-2.1 Copyright 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010 by Theodore Ts'o elfutils 0.170GPL-2.0 Copyright (c) 1996-2015 Red Hat, Inc. Copyright (c) 2012 Tilera Corporation evtest GPL-2.0 faad2 2.7GPL-2.0Copyright (c) 2003-2005 M. Bakker, Nero AG, http://www.nero.com Open Source Software Notice 175 flac 1.3.1 GPL-2.0 LGPL-2.1 Copyright (C) 2002-2009 Josh Coalson Copyright (C) 2011-2013 Xiph.Org Foundation Copyright (C) 2001 Edmund Grimley Evans <[email protected]> Copyright (C) 2003 Philip Jägenstedt Copyright (C) 2001 David Robinson and Glen Sawyer Copyright (C) 1998-2000 Peter Alm, Mikael Alm, Olle Hallnas, Thomas Nilsson and 4Front Technologies flashrom 0.9.6.1GPL-2.0 gdbm 1.8.3GPL-2.0Copyright (C) 1990, 1991, 1993 Free Software Foundation, Inc. gdk-pixbuf 2.30.8 GPL-2.0 LGPL-2.1 Copyright (C) 1995-1997 Peter Mattis, Spencer Kimball and Josh MacDonald Copyright (C) 1999 The Free Software Foundation Copyright (C) 2000 Red Hat, Inc Copyright (C) 2008 Dominic Lachowicz Copyright (C) 2008 Alberto Ruiz Copyright (C) 2004 Matthias Clasen <[email protected]> Copyright (C) 2005 Imendio AB Copyright (C) 2001-2002 convergence integrated media GmbH Copyright (C) 2002 convergence GmbH Copyright (C) 2006 Alexander Larsson <[email protected]> Copyright (C) 1998 Cesar Miquel, Shawn T. Amundson, Mattias Grönlund Copyright (C) 2000 Tony Gale GENIVI Node State Mana…

Text truncated - open the document above for the full version.

Car Multimedia System USER'S MANUAL Functions and services in this manual may differ from those in the actual vehicle. Thank you for purchasing this KIA Motors Car Multimedia System. This user’s manual explains how to use the KIA Motors Car Multimedia System. Before using the product, read the contents of this user’s manual carefully and use this product safely. ↟The screens shown in this manual may differ with the actual screens of the product. ↟The design and specification of this product may change without prior notification for product improvement. ↟When transferring the vehicle to another individual, include this user’s manual so that the next driver can continue its use. 3 Table of Contents Table of Contents 3 Start Name of Each Component 5 Basic operation 8 HOME screen 12 Favorites 16 Navigation (If Equipped) Getting started with navigation (Polstar) 20 Searching for destination (Polstar) 27 Using the route menu (Polstar) 35 Settings for navigation (Polstar) 42 Checking on navigation system (Polstar) 51 Getting started with navigation (NNG) 53 Searching for destination (NNG) 59 Using the route menu (NNG) 68 Settings for navigation (NNG) 74 Media Playing USB 80 Bluetooth audio 86 Voice memo 88 Radio Listening to AM 93 Listening to FM 96 Listening to HD Radio™ 100 Phone Bluetooth 103 Making a call 110 Call history 114 Contacts 116 Favourites 119 Messages 122 Setup Settings 125 Phone connection Settings 126 Advanced Settings 130 General settings 133 Sound Settings 137 Display Settings 143 Hybrid (Hybrid Vehicles Only) Hybrid 148 Others Phone Projection 156 Using Rear Came (If Equipped) 159 Reference Precautions for Safety 163 General Information 166 Before thinking there is a product defect 168 Troubleshooting 169 Trademarks and Licenses 171 Specification 172 Open Source Software Notice 173 Table of Contents 시작하기Start Name of Each Component 5 Name of Each Component Head unit Head unit functions may vary for each model. POWER PUSH or PWR / Volume knob ↟Press to turn the power on. ↟When power is on, press and hold to turn power off. ↟When power is on, press to turn Audio off. ↟Turn left/right to control volume. HOME button (AV only) ↟Press to go to the home screen. PHONE button (AV only) ↟Press to go to the phone screen. MAP button (AVN only) ↟Press to display the map screen of the current location. NAV button (AVN only) ↟Press to move to the Navigation menu screen. b (Reset hole) ↟Press with a thin object to reset the unit when it does not operate normally. K (Custom button) ↟Press to move to the [Custom button] menu. After setting a desired function, press to use the desired function. A SEEK/TRACK D (S/W) button When it is pressed for a short time. ↟Radio mode: Plays previous/next available frequency or station. ↟Media mode: Plays previous/next file. When it is pressed and held ↟Radio mode: Plays previous/next available frequency or station. ↟Media mode : Rewinds or fast forwards the file. 5 Name of Each Component 6 RADIO button ↟Press to go to the radio screen. MEDIA button ↟Press to go to the available media. SETUP button ↟Press to go to the settings screen. Tune/Enter knob ↟In Radio mode, turn left/right to change the frequency or station. ↟In Media mode, turn left/right to change file and press to select the desired file. Steering Wheel Remote Control Steering wheel remote control functions may vary for each model. C / MODE button ↟Each time this button is pressed, the Radio or Media mode is changed. ↟If the media is not connected, it is changed in the order FM > AM > FM. ↟When it is pressed and held, move to Advanced settings "Steering wheel MODE button". W/S button When it is pressed for a short time ↟Radio mode: Plays previous/next Favourites. ↟Media mode: Plays previous/next file. When it is pressed and held ↟AM mode: Plays previous/next available frequency or station ↟Media mode: Rewinds or fast forwards the file. i (Voice Recognition button) ↟Press to switch to voice recognition mode. ↟To cancel it, press and hold the button again. W button Press to operate Bluetooth hands-free function. ↟Press to accept a call. ↟Press to make a call from last calls. ↟Press and hold for redialing. Name of Each Component 7 Z button ↟Press to end the phone call during a call. ↟Press to reject the call in the incoming call screen. ↟Press to end Voice memo recording. J / I button ↟Increases or decreases the volume level. d (Mute) ↟Press to mute the sound. (It will be paused in some media modes.) Basic operation 8 Basic operation System ON/OFF The image of this product may be different from the actual product. Starting the system for the first time 1. Press the Engine Start button. Once the system is turned on, the booting process will start and the safety warning page is displayed. 2. Press [Confirm]. If you want to change the system language, press [Language]. , Note ↟You cannot operate the system while it is booting up. It may take some time for all of the features to be ready. ↟The safety warning page is displayed every time the ignition is turned on. The displayed warnings are related to safety, please closely read and comply with the safety warnings. ↟If there is no operation for 10 seconds in the safety warning screen, the system automatically switches to the last played mode. Turning the system off Press and hold Power button on the head unit. To turn the system on again, press power button on the head unit. , Note Pay attention to the volume setting when turning the system on. A sudden output of extreme volume upon turning the system on could lead to hearing impairment. Adjust the volume to a suitable levels before turning off the system or set the startup volume in sound Settings menu. Basic operation 9 AV ON/OFF or Volume Adjustment AV OFF Press Power button on the head unit when the AV is ON. AV ON Press Power button on the head unit when the AV is OFF. Adjusting the volume Turn the Volume knob to control volume. , Note When you turn the system off, the current volume level is automa…

Text truncated - open the document above for the full version.

MOTREX CO., LTD. Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Date: Jun 07, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: BP9-MS310ANQ5 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, MOTREX CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give MOTREX CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Sungyoung Park Reaearcher

MOTREX CO., LTD. Seoyoung Bldg. 25, Hwangsaeul-ro 258beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Date: Jun 07, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: BP9-MS310ANQ5 including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from MOTREX CO., LTD. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Sungyoung Park Reaearcher

FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 1 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 2 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 3 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 4 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 5

FCC ID: BP9-MS310ANQ5 SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 1 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 2 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 3 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 4 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 5 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 6

FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 7 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 8 FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 9 <Antenna> FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 10 <Antenna> FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 11 <Antenna> <Antenna> FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 12 <Antenna> <Antenna> FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. View 13 <Module>

FCC ID: Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) Bluetooth(1Mbps) 2 402.0 ~ 2 480.0 1.00 3.25 4.25 2.661 0.000 6 1.000 Bluetooth(2,3Mbps) 2 402.0 ~ 2 480.0 -3.00 3.25 0.25 1.060 0.000 3 1.000 ~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 2.661 S= Maximum power density(mW/cm 2 ) 0.0006 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the anten n BP9-MS310ANQ5 MPE Calculation : Bluetooth Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. FCC ID: Mode(Antenna) Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11g(Ant 2) 2 412.0 ~ 2 462.0 6.00 3.22 9.22 8.357 0.001 7 1.000 802.11a(Ant 1) 5 180.0 ~ 5 240.0 8.00 2.95 10.95 12.446 0.002 5 1.000 802.11a(Ant 1) 5 745.0 ~ 5 825.0 8.00 1.93 9.93 9.841 0.002 0 1.000 802.11a(Ant 2) 5 180.0 ~ 5 240.0 8.00 0.25 8.25 6.684 0.001 4 1.000 802.11a(Ant 2) 5 745.0 ~ 5 825.0 8.00 2.99 10.99 12.561 0.002 5 1.000 802.11a(MIMO) 5 180.0 ~ 5 240.0 11.00 4.71 15.71 37.240 0.008 0 1.000 802.11a(MIMO) 5 745.0 ~ 5 825.0 11.00 5.49 16.49 44.566 0.009 0 1.000 ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : BP9-MS310ANQ5 MPE Calculation : WLAN Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 12.446 S= Maximum power density(mW/cm 2 ) 0.0025 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the anten n ▪▪ BT(Antenna 1) + WLAN 5GHz(Antenna 2) 1.000 0 WLAN 0.000 6 0.002 5 - 0.000 6 0.002 5 MPE ratio (Power Density/Requirement) Mode(Antenna) 0.002 5 --- -- -- RF function or mode(Worst case) 0.003 1 BT Σ of MPE ratios 1Mbps(Ant 1) 0.000 6 - 802.11a(Ant 2) -- - Power Density (mW/cm2) - -- - - - - -- Requirement (mW/cm2) 1.000 0 Worst case(MPE ratio) - -- - - The exposure condition of this device is compliant with FCC rul es. Conclusion : Σ of MPE ratios ≤ 1 ▪ Requirment = - - -- - BP9-MS310ANQ5 FCC ID: RF Exposure Compliance for simultaneous operations Worst case for simultaneous operations - Band 2.4GHz 5GHz(NII-3) - - -

Report No.: DRTFCC2106-0060(1) FCC ID: BP9-MS310ANQ5 This test report is prohibited to copy or reissue in whole or in part without the approval of DT&C Co., Ltd. TRF-RF-234(06)210316 Pages: 2 / 93 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2106-0060 Jun. 04, 2021 Initial issue ChangWon Lee JaeJin Lee DRTFCC2106-0060(1) Jul. 20, 2021 Add the test method(KDB662911 D01v02v01) Inhee Bae JaeJin Lee Report No.: DRTFCC2106-0060(1) FCC ID: BP9-MS310ANQ5 This test report is prohibited to copy or reissue in whole or in part without the approval of DT&C Co., Ltd. TRF-RF-234(06)210316 Pages: 3 / 93 CONTENTS 1. EUT DESCRIPTION ...................................................................................... 4 1.1 EUT Description ..................................................................................... 4 1.2 Transmitting configuration of EUT .......................................................... 4 2. Information about test items ...................................................................... 5 2.1 Test Mode ............................................................................................... 5 2.2 Tested Channel Information .................................................................... 5 2.3 Testing Environment............................................................................... 5 2.4 EMI Suppression Device(s)/Modifications .............................................. 5 2.5 Measurement Uncertainty ...................................................................... 6 3. SUMMARY OF TESTS .................................................................................. 7 4. TEST METHODOLOGY ................................................................................ 8 4.1 EUT configuration ................................................................................... 8 4.2 EUT exercise .......................................................................................... 8 4.3 General test procedures ......................................................................... 8 4.4 Description of test modes ....................................................................... 8 5. INSTRUMENT CALIBRATION...................................................................... 9 6. FACILITIES AND ACCREDITATIONS .......................................................... 9 6.1 Facilities ................................................................................................. 9 6.2 Equipment .............................................................................................. 9 7. ANTENNA REQUIREMENTS ....................................................................... 9 8. TEST RESULT ............................................................................................ 10 8.1 Emission Bandwidth (26 dB Bandwidth) .......................................................... 10 8.2 Minimum Emission Bandwidth (6 dB Bandwidth) ............................................ 23 8.3 Maximum Conducted Output Power ................................................................ 36 8.4 Maximum Power Spectral Density ................................................................... 41 8.5 Radiated Spurious Emission Measurements ................................................... 66 8.6 AC Conducted Emissions ................................................................................ 72 9. LIST OF TEST EQUIPMENT ...................................................................... 73 APPENDIX I .................................................................................................... 74 APPENDIX II ................................................................................................... 75 APPENDIX III .................................................................................................. 78 Report No.: DRTFCC2106-0060(1) FCC ID: BP9-MS310ANQ5 This test report is prohibited to copy or reissue in whole or in part without the approval of DT&C Co., Ltd. TRF-RF-234(06)210316 Pages: 4 / 93 1. EUT DESCRIPTION 1.1 EUT Description FCC Equipment Class Unlicensed National Information Infrastructure TX(NII) Product SMART DISPLAY Model Name MS310ANQ5 Add Model Name NA Power Supply DC 12 V Modulation type OFDM Antenna Specification Antenna type: PCB Pattern Antenna Antenna gain: Refer to the clause 7 in test report. 5GHz Band Mode Tx frequency (MHz) Max power(dBm) U-NII 1 802.11a 5 180 ~ 5 240 10.44 802.11n(HT20) 5 180 ~ 5 240 10.36 802.11ac(VHT20) 5 180 ~ 5 240 10.33 802.11n(HT40) 5 190 ~ 5 230 10.34 802.11ac(VHT40) 5 190 ~ 5 230 10.31 802.11ac(VHT80) 5 210 9.25 U-NII 3 802.11a 5 745 ~ 5 825 9.81 802.11n(HT20) 5 745 ~ 5 825 9.70 802.11ac(VHT20) 5 745 ~ 5 825 9.67 802.11n(HT40) 5 755 ~ 5 795 9.87 802.11ac(VHT40) 5 755 ~ 5 795 9.82 802.11ac(VHT80) 5 775 8.73 1.2 Transmitting configuration of EUT Mode SISO MIMO (CDD) MIMO (SDM) Ant 1 Ant 2 Ant 1 & 2 Ant 1 & 2 Data rate 802.11a 6 ~ 54 Mbps 6 ~ 54 Mbps 6 ~ 54 Mbps - 802.11n(HT20) MCS 0 ~ 7 MCS 0 ~ 7 MCS 0 ~ 7 MCS 8 ~ 15 802.11ac(VHT20) MCS 0 ~ 8 (1SS) MCS 0 ~ 8 (1SS) MCS 0 ~ 8 (1SS) MCS 0 ~ 8 (2SS) 802.11n(HT40) MCS 0 ~ 7 MCS 0 ~ 7 MCS 0 ~ 7 MCS 8 ~ 15 802.11ac(VHT40) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (2SS) 802.11ac(VHT80) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (1SS) MCS 0 ~ 9 (2SS) Note1: SDM = Spatial Diversity Multiplexing, CDD = Cycle Delay Diversity, SS = Spatial Streams Report No.: DRTFCC2106-0060(1) FCC ID: BP9-MS310ANQ5 This test report is prohibited to copy or reissue in whole or in part without the approval of DT&C Co., Ltd. TRF-RF-234(06)210316 Pages: 5 / 93 2. Information about test items 2.1 Test Mode Test Mode ANT configuration Worst data rate TM 1 802.11a CDD Multiple transmitting 6 Mbps TM 2 802.11n(HT20) SDM Multiple transmitting MCS 8 TM 3 802.11n(HT40) SDM Multiple transmitting MCS 8 TM 4 802.11ac(VHT80) SDM Multiple transmitting MCS 0 Note 1: The worst case data rate is de…

Text truncated - open the document above for the full version.

FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement EUT Position: X-axis FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz)) FCC ID : BP9-MS310ANQ5 Copyright Ⓒ 2021, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz)
