Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 8 | 15E | 5.67 GHz - 5.67 GHz | 40.00 mW |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesOutput Power listed is the maximum summed conducted peak output power as indicated in the filing. Limited Host Specific Modular Approval. Approval is limited to OEM installation only, and the host in which this module is integrated should provide stable 12 VDC and 3 VDC to 12 VDC power to this module through regulator circuit. his OEM RF module is only approved for integration into host device(s) as defined in
this filing under the control of the Grantee. End users may not be provided with the module installation instructions. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Operating of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz. 5510 to 5670 MHz and 5670 MHz.
