C3K1052Microsoft Wireless Notebook Laser Mouse 6000

M www.microsoft.com/hardware M 2 31 Getting Started Microsoft ® Wireless Mouse Products 0505 Part No. X11-27312 X1127312cvr.indd 15/12/2005 9:49:54 AM Welcome Congratulations on your purchase of a Microsoft ® wireless mouse, which includes: 123 45 1 Wireless mouse 2 Receiver (desktop or notebook version, depending on your mouse model) 3 One or more batteries for your wireless mouse, depending on your mouse model 4 CD with Microsoft IntelliPoint mouse software 5 This Getting Started manual Important ● Check the system requirements (located on the packaging) to make sure that your system is compatible with the product that you purchased. ● If you don’t already have a mouse, you can install the IntelliPoint software after you have completed Steps 2 through 5 and your Microsoft wireless mouse is working. HEALTH WARNING Use of a keyboard or mouse may be linked to serious injuries or disorders. When using a computer, as with many activities, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. However, if you experience symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensation, or stiffness, DO NOT IGNORE THESE WARNING SIGNS. PROMPTLY SEE A QUALIFIED HEALTH PROFESSIONAL, even if symptoms occur when you are not working at your computer. Symptoms like these can be associated with painful and sometimes permanently disabling injuries or disorders of the nerves, muscles, tendons, or other parts of the body. These musculoskeletal disorders (MSDs) include carpal tunnel syndrome, tendonitis, tenosynovitis, and other conditions. While researchers are not yet able to answer many questions about MSDs, there is general agreement that many factors may be linked to their occurrence, including: overall health, stress and how one copes with it, medical and physical conditions, and how a person positions and uses his or her body during work and other activities (including use of a keyboard or mouse). The amount of time a person performs an activity may also be a factor. Some guidelines that may help you work more comfortably with your computer and possibly reduce your risk of experiencing an MSD can be found in the “Healthy Computing Guide” installed with this device’s software. If this device did not come with software, see the “Healthy Computing Guide” section of the “Getting Started” manual. You can also access the “Healthy Computing Guide” at www.microsoft.com/hardware or (in the United States only) by calling 1 (800) 360-7561 to request a CD at no charge. If you have questions about how your own lifestyle, activities, or medical or physical condition may be related to MSDs, see a qualified health professional. About Your Rights and Obligations The software included with this product is licensed, not sold. You must either agree to the license contract in the software Setup screen or promptly return the entire product for a refund, excluding the return costs. After you install the software, you may consult the license and the Limited Warranty for the product at any time by looking in the “Legal Information” section of the software Help files. You may also print a copy for your records. X1127312bdy.indd 15/12/2005 9:49:18 AM 1 Welcome Congratulations on your purchase of a Microsoft ® wireless mouse, which includes: 123 45 1 Wireless mouse 2 Receiver (desktop or notebook version, depending on your mouse model) 3 One or more batteries for your wireless mouse, depending on your mouse model 4 CD with Microsoft IntelliPoint mouse software 5 This Getting Started manual Important ● Check the system requirements (located on the packaging) to make sure that your system is compatible with the product that you purchased. ● If you don’t already have a mouse, you can install the IntelliPoint software after you have completed Steps 2 through 5 and your Microsoft wireless mouse is working. 0505 Part No. X11-27312 X1127312bdy.indd 15/12/2005 9:49:19 AM 2 1 Install IntelliPoint Mouse Software IntelliPoint software enables the unique features of your mouse. To install IntelliPoint software (Microsoft Windows ® operating system) 1 Insert the software CD into your computer’s CD drive. If the Setup screen doesn’t appear automatically, do the following: ● Click Start, and then click Run . ● Type [drive]:setup. For example, if your CD drive is drive E, type e:setup 2 On the Setup screen, click Install, and then follow the Setup Wizard instructions on the screen. Restart the computer, if prompted to do so. To install IntelliPoint software (Macintosh) 1 Insert the software CD into your computer’s CD drive. 2 Double-click the Microsoft-Desktop.dmg file. 3 Double-click the Microsoft Desktop.mpkg icon, and then follow the on-screen instructions. Restart the computer, if prompted to do so. 2 Insert the Batteries Whenever you insert batteries, always make sure that each of them is new. Alkaline batteries provide maximum battery life and are included in the package. Desktop MouseNotebook Mouse 1 Remove the battery compartment cover. 2 Insert the batteries, making sure to properly orient the positive (+) and negative (–) ends as specified by the battery compartment labels. 1 Press the Open button on the bottom of the mouse, and then pull the battery compartment out. 2 Insert the battery, making sure to properly orient the positive (+) and negative (–) ends as specified by the battery compartmen t labels. X1127312bdy.indd 25/12/2005 9:49:21 AM 3 2 Insert the Batteries Whenever you insert batteries, always make sure that each of them is new. Alkaline batteries provide maximum battery life and are included in the package. Desktop MouseNotebook Mouse 1 Remove the battery compartment cover. 2 Insert the batteries, making sure to properly orient the positive (+) and negative (–) ends as specified by the battery compartment labels. 1 Press the Open button on the bottom of the mouse, and then pull the battery compartment out. 2 Insert t…

Text truncated - open the document above for the full version.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device also complies with Part 15 of the U.S. Federal Communications Commission (FCC) rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Microsoft hardware device(s) that accompanies this software can radiate radio frequency (RF) energy. If not installed and used in strict accordance with the instructions given in the printed documentation and Online User's Guide, the device may cause harmful interference with other radio- communications devices (for example AM/FM radios, televisions, baby monitors, cordless phones, etc.). Any cable that is connected to the device must be a shielded cable that is properly grounded. There is, however, no guarantee that RF interference will not occur in a particular installation. Your Microsoft hardware device has been tested, and it complies with the limits for a Class B digital device in accordance with the specifications in Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful RF interference in a residential installation. To determine if your hardware device is causing interference to other radio-communications devices, disconnect the device from your computer. If the interference stops, it was probably caused by the device. If the interference continues after you disconnect the hardware device, turn the computer off and then on again. If the interference stopped when the computer was off, check to see if one of the input/output (I/O) devices or one of the computer's internal accessory boards is causing the problem. Disconnect the I/O devices one at a time and see if the interference stops. If this hardware device does cause interference, try the following measures to correct it: z Relocate the antenna of the other radio-communications device (for example AM/FM Radios, televisions, baby monitors, cordless phones, etc) until the interference stops. z Move the hardware device farther away from the radio or TV, or move it to one side or the other of the radio or TV. z Plug the computer into a different power outlet so that the hardware device and radio or TV are on different circuits controlled by different circuit breakers or fuses. z If necessary, ask your computer dealer or an experienced radio-TV technician for more suggestions. You may find helpful information about interference issues at the following FCC website: http://www.fcc.gov/cgb/consumerfacts/interference.html or call the FCC at 1-888-CALL FCC to request from the operator "Interference and Telephone Interference" fax sheets Note Any changes or modifications not expressly approved by Microsoft could void the user's authority to operate this device. Quick Start Guide United States and Canada Radio and TV Interference Regulations For use with UL Listed and GS approved personal computers. Not intended for use in machinery or industrial applications. Tested to comply with FCC standards. For home and office use. Model Number: Wheel Mouse (all models), IntelliMouse (all models), IntelliMouse TrackBall (all models), IntelliMouse with IntelliEye (all models), Wheel Mouse Optical (all models), IntelliMouse Web (all models), IntelliMouse Optical (all models), IntelliMouse Explorer (all models), Trackball Optical (all models), Trackball Explorer (all models), Cordless Wheel Mouse and receiver (all models), Wireless IntelliMouse Explorer and receiver (all models), Optical Mouse (all models), Wireless Optical Mouse and receiver (all models) In addition, the following models have been approved under FCC certification rather than under the FCC Declaration of Conformity Process: C3KMS9, C3KMS8, C3KMS7, C3KMS6, C3KZB2, C3KTB3, C3KKS9, C3KKS8, C3KKS2, C3KKMP5, C3KKMP1, C3KAZB1. Important note about wireless pointing devices The Microsoft Wireless IntelliMouse Explorer (all models) and Cordless Wheel Mouse (all models) can emit radio frequency (RF) energy, much like an AM/FM radio, whenever the batteries are installed, even if the mouse is not in operation. For radio interference information regarding any specific medical device or equipment, consult with the manufacturer of such product or with your physician before use. To stop interference, remove the batteries or follow the instructions above. The Microsoft Wireless IntelliMouse Explorer (all models) and Cordless Wheel Mouse (all models) should not be used on any aircraft. Before boarding any aircraft, remove the batteries to ensure that there is no RF transmission. Microsoft Corporation One Microsoft Way Redmond, WA 98052-6399. (800) 426-9400 (United States) (800) 933-4750 (Canada) www.microsoft.com/mouse/

Microsoft Corporation is an equal opportunity employer. July 3, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: C3K1052 TO WHOM IT MAY CONCERN Pursuant to DA 04-1705 of the Commission’s public notice, we request short- term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Test Setup Photos • Block Diagram • Schematics • User’s Manual • Internal Photos • Parts List • Operational Description Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

Microsoft Corporation is an equal opportunity employer. June 3, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Confidentiality request regarding application for certification of FCC ID: C3K1052 TO WHOM IT MAY CONCERN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: • Block Diagram • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

Microsoft Corporation is an equal opportunity employer. June 13, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 AGENCY AUTHORIZATION LETTER To whom it may concern, We, the undersigned, Microsoft® Corporation hereby authorize Advance Data Technology Corp. (ADT) of Taiwan, to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15C for the Microsoft® Corporation product: Model: 1052/FCC ID:C3K1052 Any act carried out by Advance Data Technology Corp. (ADT) of Taiwan within the scope of this authorization shall have the same affect as our own. This Letter of Authorization will expire on June 13, 2006, unless earlier revoked in writing. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

Model: 1052 Made in China (N) PN X08-XXXXX Product ID 55083-576- XXXXXXX See software Help for patent Information Model: 1052 Microsoft Corporation One Microsoft Way Redmond, WA 98052 USA FC C ID: C3K10 5 2 Canada 210 LISTED ACCESSORY ITE E145346 Complies with IDA Standards DB101178 R R31264 F CC I D: C3K1052 Canada 210 LISTED ACCESSORY ITE E145346 Complies with IDA Standards DB101178 R31264 Label location

Page 4 Page 5 Page 6 Page 7

FCC ID: C3K1052 Report No.: RF940628L071Report Format Version 2.0.2 FCC TEST REPORT REPORT NO.: RF940628L07 MODEL NO.: 1052 RECEIVED: Jun. 29, 2005 TESTED: Jun. 29, 2005 ISSUED: Jul. 07, 2005 APPLICANT : Microsoft Corporation ADDRESS : One Microsoft Way, Redmond, WA 98052-6399, U.S.A. ISSUED BY : Advance Data Technology Corporation LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION : No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 23 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: C3K1052 Report No.: RF940628L072Report Format Version 2.0.2 Table of Contents 1CERTIFICATION ......................................................................................................... 3 2SUMMARY OF TEST RESULTS................................................................................. 4 2.1MEASUREMENT UNCERTAINTY .............................................................................. 4 3GENERAL INFORMATION ......................................................................................... 5 3.1GENERAL DESCRIPTION OF EUT............................................................................ 5 3.2DESCRIPTION OF TEST MODES.............................................................................. 7 3.2.1CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 7 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.............................. 8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................. 8 3.4DESCRIPTION OF SUPPORT UNITS........................................................................ 8 4TEST PROCEDURE AND RESULT ............................................................................ 9 4.1CONDUCTED EMISSION MEASUREMENT .............................................................. 9 4.2RADIATED EMISSION MEASUREMENT ................................................................... 9 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................................ 9 4.2.2TEST INSTRUMENT................................................................................................. 10 4.2.3TEST PROCEDURE ................................................................................................. 11 4.2.4TEST SETUP ............................................................................................................ 12 4.2.5EUT OPERATING CONDITION ................................................................................ 12 4.2.6TEST RESULTS ........................................................................................................ 13 4PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................... 22 5INFORMATION ON THE TESTING LABORATORIES .............................................. 23 FCC ID: C3K1052 Report No.: RF940628L073Report Format Version 2.0.2 1 CERTIFICATION PRODUCT : Microsoft ® Wireless Laser Mouse 6000 BRAND NAME : Microsoft ® MODEL NO. : 1052 APPLICANT : Microsoft Corporation TESTED : Jun. 29, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 15, Subpart C (Section 15.227) Canada RSS-210, 2001, Issued 5, Amend 1 ANSI C63.4:2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY :, DATE :Jul. 07, 2005 ( Suntee Liu ) TECHNICAL ACCEPTANCE :, DATE :Jul. 07, 2005 Responsible for RF ( Gary Chang ) APPROVED BY :, DATE :Jul. 07, 2005 ( Cody Chang, Deputy Manager ) FCC ID: C3K1052 Report No.: RF940628L074Report Format Version 2.0.2 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestNA Power supply is 1.5Vdc from batteries 15.227 15.209 Radiated Emission TestPASS Minimum passing margin is -8.40dB at 640.38MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: MeasurementFrequencyUncertainty Conducted emissions9kHz~30MHz2.44 dB 30MHz ~ 200MHz3.73 dB 200MHz ~1000MHz3.74 dB 1GHz ~ 18GHz2.20 dB Radiated emissions 18GHz ~ 40GHz1.88 dB FCC ID: C3K1052 Report No.: RF940628L075Report Format Version 2.0.2 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Microsoft ® Wireless Laser Mouse 6000 MODEL NO. 1052 POWER SUPPLY 1.5Vdc from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.045, 27.145 MHz NUMBER OF CHANNEL 2 ANTENNA TYPE Loop antenna DATA CABLE NA I/O PORTS NA NOTE: 1. The EUT is a wireless mouse. 2. Fusion Configuration Information: Configuration #:Comments: DV phase Mouse unit for formal report Manufacturer Component type Part no. Revision no. Description BOM (if known) MicrosoftMouseModel: 1052 STOptical Sensor11300398000A CHIP IC Aviator ASIC TQFP-32L 11300398000 STMicrocontroller11300398000A CHIP IC Aviator ASIC TQFP-32L 11300398000 ULMLaserVCSEL-001NAVCSEL (850nm)10740114200 OSRAMLaserF 0497B - MSNAVCSEL (850nm)10740114200 Microsoftfirmware Fusion_0_35_31_2603_ DV_56p.ram PCB102304542006 SPCB,FUSION TX,AVIATOR,S2L 10230454200 KYEPCB Assy20000691200A PCBA,FUSION HAND SOLDER,TX 20000691200 KYEPCB Assy20000623200APCBA,…

Text truncated - open the document above for the full version.

FCC ID: C3K1052 Report No.: RF940628L0722Report Format Version 2.0.2 4 PHOTOGRAPHS OF THE TEST CONFIGURATION Radiated Emission Test
