C3K1069Microsoft Presenter 3000

 M Contents Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Guia de Introdução . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Mise en route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Introducción . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 International Technical Support Numbers (partial list only) . . . . . . . . . .61 Microsoft Product Guide Read this guide for important safety and health information and the terms of the Warranty that cover the Microsoft ® device that you have purchased. Warning Failure to properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. Read this guide and keep all printed guides for future reference. For replacement guides, go to www.microsoft.com/hardware or refer to the Microsoft Help and Support section for contact information. This document includes important information about many Microsoft products. Refer to sections that apply to the features of your device: Important Safety Information AC-Powered Devices Battery-Powered Devices Wireless Devices Keyboard and Mouse Devices Devices with Laser Pointers All Devices Healthy Computing Guide Laser and LED Specifications Regulatory Information Radio Frequency Technical Specifications Radio and TV Interference Regulations Disposal of Waste Electrical and Electronic Equipment Patent Information Microsoft Help and Support Limited Warranty 0306 Part No. X2- 69 2-02 X121691202mnl.indb 13/27/2006 9:59:14 AM 2 This symbol identifies safety and health messages in this Product Guide and other product manuals . Important Safety Information AC-Powered Devices These precautions apply to all products that plug into a standard wall power outlet. Failure to take the following precautions can result in serious injury or death from electric shock or fire or in damage to the device. To select an appropriate power source for your device: ● Use only the power supply unit and AC power cord that came with your device or that you received from an authorized repair center. ● Confirm that your electrical outlet provides the type of power indicated on the power supply unit (in terms of voltage [V] and frequency [Hz]). If you are not sure of the type of power supplied to your home, consult a qualified electrician. ● Do not use non-standard power sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet. ● Do not overload your wall outlet, extension cord, power strip, or other electrical receptacle. Confirm that they are rated to handle the total current (in amps [A]) drawn by the device (indicated on the power supply unit) and any other devices that are on the same circuit. To avoid damaging the power cords and power supply: ● Protect the power cords from being walked on. ● Protect cords from being pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit, and the device. ● Do not jerk, knot, sharply bend, or otherwise abuse the power cords. ● Do not expose the power cords to sources of heat. ● Keep children and pets away from the power cords. Do not allow them to bite or chew on them. ● When disconnecting the power cords, pull on the plug—do not pull on the cord. If a power cord or power supply becomes damaged in any way, stop using it immediately. Unplug your device during lightning storms or when unused for long periods of time. For devices with an AC power cord that connects to the power supply, always connect the power cord according to the following instructions: 1 Plug the AC power cord into the power supply until it stops. 2 Plug the other end of the AC power cord into the wall outlet. Battery-Powered Devices These precautions apply to all products that use rechargeable or disposable batteries. Improper use of batteries may result in battery fluid leakage, overheating, or explosion. Released battery fluid is corrosive and may be toxic. It can cause skin and eye burns, and is harmful if swallowed. X121691202mnl.indb 23/27/2006 9:59:15 AM 3 To reduce the risk of injury: ● Keep batteries out of reach of children. ● Do not heat, open, puncture, mutilate, or dispose of batteries in fire. ● Do not mix new and old batteries or batteries of different types (for example, carbon-zinc and alkaline batteries). ● Do not allow metal objects to touch the battery terminals on the device; they can become hot and cause burns. ● Remove the batteries if they are worn out or before storing your device for an extended period of time. ● Always remove old, weak, or worn-out batteries promptly and recycle or dispose of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries, taking care to keep the leaked fluid from touching your skin or clothes. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. Before inserting new batteries, thoroughly clean the battery compartment with a damp paper towel, or follow the battery manufacturer’s recommendations for cleanup. Disposable (non-rechargeable) batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with correct size and type (alkaline, zinc-carbon, or zinc-chloride) of batteries. Rechargeable batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the same type and rating as the batteries provided. ● Charge only with the recharger provided with the product. Wireless Devices Before boarding any aircraft or packing a wireless device in luggage that will be checked, remove the batteries from the wireless device or turn the wireless device off (if it has an on/off switch). Wir…

Text truncated - open the document above for the full version.

Microsoft Corporation is an equal opportunity employer. July 6, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Confidentiality request regarding application for certification of FCC ID: C3K1069 TO WHOM IT MAY CONCERN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: • Block Diagram • Schematics • Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

Microsoft Corporation is an equal opportunity employer. July 6, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: C3K1069 TO WHOM IT MAY CONCERN Pursuant to DA 04-1705 of the Commission’s public notice, we request short- term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Test Setup Photos • User’s Manual • Internal Photos • Operational Description Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

From: Stephen Stegner [mailto:[email protected]] Sent: Monday, July 24, 2006 2:27 PM To: steve.cheng Cc: [email protected]; [email protected]; [email protected]; William Hilleary; Scott Brown (HARDWARE); Sheri Brassell; Felicia Chu Subject: RE: C3K1069-FCC COMMENT (FCC has responded !) Importance: High Hi Steve, I contacted the FCC about this particular situation. Please find the attached response (Response to Inquiry FCC (Tracking Number 912309)). From attached e-mail: Response: The proposal to place the label inside the battery compartment is acceptable in this case. Please assure that all labeling requirements are addressed including Part 15. Is there anything else you need to proceed with the submittal? Regards, Stephen Stegner EMC/Safety Engineer Microsoft Corporation (425) 706-2697 From: steve.cheng [mailto:[email protected]] Sent: Wednesday, July 19, 2006 6:12 AM To: Stephen Stegner Cc: [email protected]; [email protected]; [email protected]; William Hilleary; Scott Brown (HARDWARE); Sheri Brassell; 'Felicia Chu' Subject: RE: C3K1069-FCC COMMENT Hi Stephen, Sorry for the late response to your question (was occupied by couple of dated urgent applications). As you have observed that there are many devices that do not have label on the product surface. Generally speaking, all products have to follow 2.925 (d) (1) & (2) i.e. have their label visible on the product surface, except product fall into one of the following categories: 1. Cell phone product 2. product size smaller than normal palm size 3. has special approval from FCC (Cell phone is one of the sample) Unfortunately, your product seems not fit in the first 2 categories and hence the only way to be exempted from this requirement is get an approval from FCC. Hope this help and please feel free to contact me if I can be of further help. Thank you for contact me. Best regards, Steve Cheng Curtis-Straus LLC From: Stephen Stegner [mailto:[email protected]] Sent: Tuesday, July 18, 2006 2:15 PM To: [email protected] Cc: [email protected]; [email protected]; [email protected]; William Hilleary; Scott Brown (HARDWARE); Sheri Brassell; Felicia Chu Subject: RE: C3K1069-FCC COMMENT Hi Steve, I understand that you are the TCB reviewer for the C3K1069 product and had some concerns about the labeling with respect to the FCC ID#. CFR 47 section 2.925 (d)(1) indicates that the FCC ID shall be readily visible and permanently affixed to the equipment. From (d)(2) of the same section readily visible means that the nameplate or nameplate data must be visible from the outside of the equipment enclosure. However there a millions of cell phones sold that have their FCC ID numbers inside the battery door (inside the equipment enclosure) so I’m assuming there must be a justification for this route. The space on this product for labeling on the exterior (the exterior labeling contains the Class 2 laser statement as prescribed by the FDA) is so limited that we adopted the cell phone’s labeling approach by putting the FCC ID# (along with other regulatory information) inside the battery door which the user will see when putting the batteries into the device. Because the battery door is detachable we attached this label to the product with one of the screws that holds the device together. Is there additional information or steps we need to take to make this approach acceptable? Best regards, Stephen Stegner EMC/Safety Engineer Microsoft Corporation (425) 706-2697 TCB Review Comments for (C06-0714a- C3K1069- Microsoft Presenter) -EMC- Question #1: Per FCC policy, the label must be applied on the surface of EUT. However, the label location indicated that the label will go into the battery chamber and it is not allowed by the FCC policy. Please correct. Best regards, Steve Cheng Curtis-Straus LLC

Microsoft Corporation is an equal opportunity employer. July 6, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 AGENCY AUTHORIZATION LETTER To whom it may concern, We, the undersigned, Microsoft® Corporation hereby authorize Advance Data Technology Corp. (ADT) of Taiwan, to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15C for the Microsoft® Corporation product: Model: 1069/FCC ID:C3K1069 Any act carried out by Advance Data Technology Corp. (ADT) of Taiwan within the scope of this authorization shall have the same affect as our own. This Letter of Authorization will expire on July 6, 2007, unless earlier revoked in writing. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, Stephen M. Stegner EMC/Safety Engineer Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

FCC ID: C3K1069 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL

Page 1 CONSTRUCTION PHOTOS OF EUT

ARTWORK NUMBERDESCRIPTION PROPRIETARY NOTE TOLERENCES DWN./DATE SOFTWAREVERSION DRAWING NUMBERREVISION THE INFO RMATION CONTAINED HEREON IS CONFIDENTIAL, IS SUBMITTEDIN CONFIDENCE,AND IS PROPRIETARY INFORMATIONOFMICROSOFTCORPORA- TION,AND SHALL ONLY BE USED IN THEFURTHERANCEOF,THE CONTRACTOF WHICHTHIS DRAWING FORMS A PART,AND SHALL NOT, WITHOUTMICROSOFT CORPORATION'S PRIOR WRITTENAPPROVAL, BE REPRODUCEDORINANYWAY USED IN WHOLEOR IN PARTIN CONNECTION WITH SERVICES OR EQUIPMENT OFFEREDFOR SALE OF FURNISHED TO OTHERS,THE INFORMATIONCONTAINED HER EONMAY NOT BE DISCLOSEDTOATHIRDPARTY WITHOUT CONSENTOF MICROSOFT CORPORATION,AND THEN, ONLY PURSUANTTOAMICROSOFT APPROVED NONDISCLOSURE AGREEMENT. UNLESS OTHERWISE SPECIFIED DIMENSIONSARE IN MILLIMETERS FILE NAME 1 inch x 1 inch reference John Silverman05/31/2006 N/AA Adobe Illustrator 11.0 AW807891-003_OUTLINE.pdf AW807891-003 2:1 1:1 ARTWORK, LABEL, PID/AGENCY,MYLAR,POINTER, PRESENTER 3000 WIN USB PORT OUTLINE DOES NOT PRINT SIDE ASIDE B

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: C3K1069 Report No.: RF950530A07 Operational Description The transmitter of the EUT (Microsoft ® Presenter 3000) is powered by 3.0Vdc batteries. The type of antenna is Integrated antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF950530A071Report Format Version 2.0.5 FCC TEST REPORT REPORT NO. : RF950530A07 MODEL NO. : 1069 RECEIVED : May 30, 2006 TESTED : July 7, 2006 ISSUED : July 11, 2006 APPLICANT : MICROSOFT CORPORATION ADDRESS : ONE MICROSOFT WAY REDMOND, WA 98052- 6399, U.S.A ISSUED BY : Advance Data Technology Corporation LAB LOCATION : No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 22 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950530A072Report Format Version 2.0.5 Table of Contents 1.CERTIFICATION...........................................................................................3 2.SUMMARY OF TEST RESULTS...................................................................4 2.1MEASUREMENT UNCERTAINTY................................................................4 3.GENERAL INFORMATION............................................................................5 3.1GENERAL DESCRIPTION OF EUT..............................................................5 3.2DESCRIPTION OF TEST MODES................................................................6 3.2.1CONFIGURATION OF SYSTEM UNDER TEST...........................................6 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...............................8 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4.TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT................................................9 4.2RADIATED EMISSION MEASUREMENT.....................................................9 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT...................................9 4.2.2TEST INSTRUMENTS................................................................................10 4.2.3TEST PROCEDURES.................................................................................11 4.2.4DEVIATION FROM TEST STANDARD.......................................................11 4.2.5TEST SETUP..............................................................................................12 4.2.6EUT OPERATING CONDITIONS................................................................12 4.2.7TEST RESULTS..........................................................................................13 4.3BAND EDGES MEASUREMENT................................................................17 4.3.1LIMITS OF BAND EDGES MEASUREMENT..............................................17 4.3.2TEST INSTRUMENTS................................................................................17 4.3.3TEST PROCEDURE...................................................................................17 4.3.4DEVIATION FROM TEST STANDARD.......................................................17 4.3.5EUT OPERATING CONDITION..................................................................17 4.3.6TEST RESULTS..........................................................................................17 5.PHOTOGRAPHS OF THE TEST CONFIGURATION..................................20 6.INFORMATION ON THE TESTING LABORATORIES................................21 APPENDIX-A.......................................................................................................A-1 Report No.: RF950530A073Report Format Version 2.0.5 1. CERTIFICATION PRODUCT : Microsoft ® Presenter 3000 BRAND NAME : Microsoft ® MODEL NO. : 1069 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : MICROSOFT CORPORATION TESTED : July 7, 2006 STANDARDS : FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:July 11, 2006 ( Annie Chang ) TECHNICAL ACCEPTANCE:, DATE:July 11, 2006 Responsible for RF ( Ken Liu ) APPROVED BY:, DATE:July 11, 2006 ( Gary Chang / Supervisor ) Report No.: RF950530A074Report Format Version 2.0.5 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission Test N/A Power supply is 3Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is -4.12dB at 4836.00MHz 2.1MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. MeasurementUncertainty Radiated emissions3.55 dB Report No.: RF950530A075Report Format Version 2.0.5 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUTMicrosoft ® Presenter 3000 MODEL NO.1069 FCC IDC3K1069 POWER SUPPLY3.0Vdc from batteries MODULATION TYPE GFSK FREQUENCY RANGE 2402, 2414, 2418, 2462, 2466MHz NUMBER OF CHANNEL 5 ANTENNA TYPEIntegrated Antenna with –2.76dBi gain DATA CABLEN/A I/O PORTN/A NOTE: 1. The EUT is a wireless presenter, which is a transceiver. 2. The above EUT information was declared by manufacturer and for more detailed features description, please re…

Text truncated - open the document above for the full version.

Report No.: RF950530A0720Report Format Version 2.0.5 5. PHOTOGRAPHS OF THE TEST CONFIGURATION Radiated Emission Test
